COMPACT CADET® 3 FloWise®
ELONGATED ONE-PIECE TOILET
VITREOUS CHINA
COMPACT CADET® 3 FloWise® ELONGATED
RIGHT HEIGHT™ ONE-PIECE TOILET WITH SEAT
❑ 2403.128
• Vitreous china
• Meets denition for HET (High Efciency Toilet)
• High Efciency (4.8 Lpf/1.28 gpf)
• Space saving compact design - Elongated
Right Height bowl ts in the same space as
a round front toilet
• EverClean® surface inhibits the growth of
stain- and odor-causing bacteria, mold,
and mildew on the surface
• Featuring the Cadet
®
3 Flushing System
• One-piece design
• Elongated siphon action jetted bowl with
2-1/8" trapway
• Internal trapway area fully glazed
• Rim height at 419mm (16-1/2") for accessible
application
• Includes color-matched and design-matched
solid plastic toilet seat and cover with slow-
close hinges and EverClean
®
surface.
Seat features unique sanitary seat lift tab
• Oversized 3" Flush Valve with Chemical
Resistant Flapper
• 10" x 8" water surface area
• 2 bolt caps
• Chrome Trip Lever
• 100% factory ush tested
• 5 year warranty
❑ 2403.513 Same as above, except with
Aquagurad liner in tank
Nominal Dimensions:
724 x 394 x 724mm
(28-1/2" x 15-1/2" x 28-1/2")
Fixture only, supply by others
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A112.19.2M for Vitreous China Fixtures -
includes Flush Performance, Ball Pass Diameter,
Trap Seal Depth and all Dimensions
• Los Angeles Department of Water and Power
Supplementary Purchase Specication for
Non-Adjustability
• Certied in EPA WaterSense HET program
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARATELY.
* DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the
range of tolerance established by ANSI Standard A112.19.2
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided pages.
724mm
(28-1/2)
159mm
(6-1/4)
16 ± 6mm
(5/8 ± 1/4)
419mm
(16-1/2)
292mm
(11-1/2)
267mm
(10-1/2)
724mm
(28-1/2)
381mm
(15)
394mm
(15-1/2)
79mm
(3-1/8)
FINISHED WALL
422mm
(16-5/8)
305mm
(12)
C/L OF OUTLET
241mm
(9-1/2)
140mm
(5-1/2)
SUPPLY
AS
REQ'D
*
FINISHED
FLOOR
C/L OF SEAT POST
HOLES 140mm
(5-1/2) CENTERS
MEETS THE AMERICANS WITH DISABILITIES ACT GUIDELINES AND
ANSI A117.1 REQUIREMENTS FOR ACCESSIBLE AND USABLE
BUILDING FACILITIES-CHECK LOCAL CODES.
Revised 2/08
Certified by
IAPMO R&T
