SINGLE CONTROL KITCHEN
FAUCET WITH CAST SPOUT
Installation
Instructions
M968188E
Thank you for selecting American-Standard...the benchmark
of fine quality for over 100 years.
To ensure that your installation proceeds smoothly--please
read these instructions carefully before you begin.
Certified to comply with ANSI A112.18.1M
3821.631 SERIES
3821.641 SERIES
3821.634 SERIES
3821.644 SERIES
1
2
3
4
5
6
7
8
AB
9
CAUTION
1INSTALL FAUCET WITH OR WITHOUT DECK ESCUTCHEON
Turn off hot and cold water supplies before beginning.
PUTTY
SPOUT BASE SPOUT BASE
SINK OR
MOUNTING
SURFACE
Assemble RUBBER WASHER (5), BRASS WASHER (6), and threaded LOCKNUT (7) onto SHANK (4) from underside
of sink or mounting surface. Hand tighten LOCKNUT (7) and check that rotation of HANDLE (8) from HOT to COLD
is centered.
Push O-RINGS (2) onto SPOUT SHANK. Make certain the O-RING (2) is properly seated in recess of DECORATIVE
FLANGE (10).
Insert SUPPLY TUBES (3) and SHANK (4) through mounting hole and seat DECORATIVE FLANGE (10) onto sink or
mounting surface.
Use a screwdriver to tighten SCREWS (9) on LOCKNUT (7). Work your way around LOCKNUT (7), tightening
the screws slightly each time until all are snug to ensure even pressure.
(A) Installation with ESCUTCHEON (1). Apply a bead of putty to bottom edge of ESCUTCHEON (1). Insert supply
TUBES (3) and SHANK (4) through hole of ESCUTCHEON (1) and mounting surface. Make certain the O-RING (2)
is properly seated in recess of SPOUT BASE. Follow mounting instructions below to secure faucet to mounting surface.
(B) Installation less ESCUTCHEON (1). Remove ESCUTCHEON (1) , feed FAUCET TUBES (3) and SHANK (4) through
DECORATIVE FLANGE (10). Push FLANGE so the raised step fits into recess of SPOUT BASE.
Plumbers' Putty or Caulking
Adjustable Wrench
Phillips Screwdriver
Channel Locks
TOOLS REQUIRED
Tubing Cutter
2
3
4
5
6
7
9
10
Regular Screwdriver
8

M968188E
On model with separate spray, place the SPRAY HOLDER (1)
into the appropriate mounting hole. Assemble the SPRAY
HOLDER WING NUT (2) onto the shank of SPRAY HOLDER (1)
from below and tighten. Do not use putty.
On model with spray through the ESCUTCHEON (3), place
SPRAY HOLDER (4) into the hole of ESCUTCHEON (3). Assemble
SPRAY HOLDER NUT (5) onto the shank of SPRAY HOLDER (4)
from below and tighten. Do not use putty.
For installation less spray cap off SPRAY HOSE CONNECTION
with PIPE CAP (6).
3INSTALL SPRAY HOLDER
1
3
56
42
4CONNECT HOSE SPRAY
3
4
1
2
Feed SPRAY HOSE (1) through SPRAY HOLDER (2) and attach
COUPLING NUT (3) of HOSE (1) to HOSE ADAPTOR (4) on valve
body. Tighten COUPLING NUT (3) firmly.
Carefully bend COPPER SUPPLIES to meet water supply
lines using the palms of the hands to avoid kinking.
Connect HOT water supply line to left tube, and COLD
water supply line to right tube using appropriate
connectors.
2
3 4
FERRULE
SPRAY HOSE
CONNECTION
HOT
COLD
MAKE WATER SUPPLY CONNECTIONS
Use 1/2" IPS FLEXIBLE SUPPLIES (3) or 3/8" O.D.
BULL-NOSE RISERS (4). Use adjustable wrench to tighten
connections. Do not over tighten. Be careful not to kink
copper supply when bending. Use tubing cutter to cut to
proper length.
NOTE: FLEXIBLE SUPPLIES HAVE TO BE PURCHASED SEPARATELY
COPPER SUPPLIES
TUBES

M968188E
5TEST INSTALLED FAUCET
Move HANDLE down into "off" position and remove AERATOR.
Turn on water supplies and check connections for leaks.
Operate HANDLE up and down, left and right to flush water
lines thoroughly.
For faucet with spray, direct SPRAY HEAD into sink and
activate SPRAY. Check hose connections for leaks.
Move HANDLE down to "off" position and replace AERATOR.
AERATOR
CHECK CONNECTIONS
FOR LEAKS
Spout leakage. If fitting leaks above or below SPOUT HUB remove SPOUT as follows
and check SPOUT O-RINGS and SPACER O-RINGS.
Loosen SET SCREW (1). Pull HANDLE (2) off valve stem.
Remove CAP (3) and and RETAINER (4). Loosen CARTRIDGE SCREWS (5) and
remove CARTRIDGE (6).
Pull off SPACER (7) and O-RINGS (8).
Remove SPOUT (11) by pulling up gently while moving SPOUT (11) side to side.
Check both SPOUT O-RINGS (10). Replace if necessary.
On models with SPRAYS, DIVERTER (9) can be cleaned by pulling
DIVERTER (9) out of the MANIFOLD (12). Clean DIVERTER (9) and
MANIFOLD (12). Push DIVERTER (9) back into MANIFOLD (12).
Reverse procedure to reinstall SPOUT, CARTRIDGE and HANDLE.
Loosen HANDLE SCREW (1) and remove HANDLE (2).
Remove ESCUTCHEON CAP (3). unscrew the three CARTRIDGE SCREWS (5).
Clean inlets of CARTRIDGE (6) and MANIFOLD (12).
Reassemble CARTRIDGE (6), alternately tightening SCREWS (5). Replace CAP (3) and HANDLE (2). Check flow.
SERVICE
6
Clogged CARTRIDGE outlets or inlets may cause reduced flow.
To clean, first turn off water supply then:
Reduced flow. If the flow gradually reduces over a number of months, the AERATOR
may have collected debris. To clean, remove AERATOR and rinse with water and
remove any debris. Turn on faucet to wash any debris out of the faucet. Thread
AERATOR back into spout. Operate faucet. 2
1
6
10
12
11
3
4
5
7
9
8
Remove as much surface dirt and film using clear
water and soft cotton cloth (as described).
Use any of the following to remove tough surface
film and build-up:
Mild liquid detergents
Clear ammonia free liquid glass cleaners
Non-acidic, non-abrasive gentle liquid or fully
dissolved powder cleansers mixed according to
manufacturers directions.
Non-abrasive liquid polishers
Once clean, rinse faucet again with clear water to
thoroughly remove cleaner or polish and and blot dry
with a cotton cloth.
To keep your new faucet looking new, please follow
these simple care instructions:
DO: Simply rinse the faucet clean with clear water.
Dry the faucet with a soft cotton cloth.
DO NOT:
Do not use any abrasive cleaners, cloths, or
paper towels.
Do not use any cleaning agents containing acids,
polish abrasives, or harsh cleaners or soaps.
Regular and routine cleaning will reduce the need for
heavy cleaning and polishing. If heavy cleaning is
required, the following procedures are recommended:
7
Failure to follow these care instructions may
damage the faucet's finish.
CARE INSTRUCTIONS
HANDLE
SPRAY
AERATOR
SPOUT
HUB

M968188E
MODEL NUMBERS
SINGLE CONTROL KITCHEN
FAUCET WITH CAST SPOUT
042850-0070A
DIVERTER
060366-0070A
SPOUT SEAL KIT
912647-0070A
O-RING SEAL
921877-0070A
CAP RETAINER
060485-YYY0A
ESCUTCHEON
060484-YYY0A
ESCUTCHEON WITH
SPRAY HOLE
M953040-YYY0A
SPRAY HOLDER
024220-0070A
SUPPLY NUT
M962146-0070A
MOUNTING KIT
066070-YYY0A
AERATOR
060341-0070A
PIPE CAP
CHROME
WHITE
BONE
BLACK NICKEL
POLISHED BRASS
WHIT HEAT
SATIN
SATIN/BRASS
CHROME/BRASS
002
020
021
072
099
208
295
297
299
Replace the "YYY" with
appropriate finish code
