AmeriGlide PR458 Series User manual

AmeriGlide
OWNER’S MANUAL
PR458 Series
PR458
MSWARB-AG 11/17
AmeriGlide
3901 Commerce Park Drive
Raleigh, NC 26710

2
Safety Guidelines
The symbols below are used in the owner’s manual and/or on the product
to identify warnings and notify you of important safety information. Make sure
you read and understand them completely.
WARNING! Indicate(s) a hazardous situation which, if not
avoided, could result in death or serious injury. This icon is
represented as a black symbol on a yellow triangle with a
black border.
MANDATORY! Failure to perform mandatory actions could
cause personal injury and/or equipment damage. This icon
is represented as a white symbol on a blue dot with a white
border.
PROHIBITED! Indicate(s) an action(s) that should not be
performed under any circumstance. Failure to adhere could
cause personal injury and/or equipment damage. This icon is
represented as a black symbol with a red circle and red slash.
Safety Symbols
The symbols below identify warnings, mandatory actions, and prohibited
actions. They can be found in the owner’s manual and/or on the product. Make
sure you understand all safety labels before operating the product. Do not remove
safety labels from your product.
Read and follow
owner’s manual!
Pinch/Crush Point
Hazard!
Transformer
Crush Hazard!
Fire Hazard!
Child and/or Pet
Crush Hazard!
Adult, Child and/
or Pet Tip Over
Hazard!
continued on next page

3
continued from previous page
Safety Guidelines
Class II Device!
Indoor use only!
Do Not Smoke!
Electrical hazard!
Do not dispose in trash!
Batteries required!

4
MANDATORY
READ THIS MANUAL FIRST BEFORE INSTALLING OR
OPERATING YOUR POWER LIFT AND RECLINE CHAIR.
Your power lift and recline chair has been engineered from the
leg levelers up to provide the ultimate in strength and reliability.
Great care has been taken to provide you with total comfort and safety. Each unit
is thoroughly inspected and tested prior to shipment.
WARNING
Your power lift chair is a medical device. Therefore, you are required
to exercise caution when operating it to ensure your personal safety
and that of others around you. The following are rules for the safe
operation of your power lift chair.
Care should be taken in the unpacking of this unit, so as not to cause
injury to persons or damage to the unit. Dispose of all plastic bags and
covers, as they can be a smothering hazard to small children.
Do not allow children or pets near the chair while
the chair is operating.
Do not allow children to play with or operate the
chair at any time.
Hand control should be unplugged and placed out of
the reach of children when the chair is not in use.
Do not flop down into the chair when getting into it, or while it is in
its lift position. Flopping down into the chair will damage it and could
cause personal injury.
Do not allow anyone to sit on your lap, or on the arm of the chair, or
on the footrest while in or operating the chair, as it may cause tipping
and could result in personal injury.
Do not place fingers or hands between the seat cushion and the inside
arm of the chair while sitting in the chair or when the chair is in
operation or plugged into a power source.

5
Do not retrieve fallen objects from inside or under the chair while the
chair is plugged into a power source.
Do not operate the chair if there are any persons,
pets or other obstructions under or in front of the
footrest, under the chair or behind the chair.
Do not position yourself, child and/or pet too high on
the chair while the chair back is reclined. This can
cause a tip over hazard. Make sure you are properly
fitted for the lift chair prior to operating the chair.
Do not smoke while operating, sitting or resting in the chair.
To reduce risk of electrical shock, do not immerse any of the
electrical components into a liquid, or spill any liquids onto electrical
components. Do not open any of the electrical components. There are
no serviceable parts.
Warranty will be void if any of the electrical components are opened
by other than a qualified service person.
Make sure the chair is placed at the specified distance from a wall/
corner (page 6). Failure to do so can damage the chair and will void
the warranty.
Do not use any type of electrical extension cord to plug your
chair into an electrical outlet. Make sure that all electrical
products and their wires are positioned away from your chair
as the metal lift frame mechanism could crush them and
create a fire hazard and/or may cause personal injury.
Do not operate your lift chair while intoxicated or taking medications
that impair your mental or physical abilities to operate the chair safely.
Consult with your doctor about any medications you are taking that
may affect the safe operation of the chair.
Do not operate this product if you have any medical conditions that
result in limited, debilitating mental or physical capacity. You should
consult your doctor before using this product.
Consult with your physician regarding using the Trendelenburg
position.

6
L.E.D. light
L.E.D. light
From motor
To outlet
115-120V A.C.
DC Power
Bottom view of
Transformer
Transformer
Plug
Install two 9 volt batteries
in transformer for battery
backup (See page 8)
(batteries not included)
3. Place the chair in the desired position in the room, keeping it 18" away from
the wall. If placing the chair into a corner, keep it 18" from the wall as shown.
Wall
Side
View
Corner
To p
View
18" 18" 18"
Distance Required From
Wall When Reclined
Model Number Wall Corner
4. Adjust the leg levelers on the bottom of the chair if necessary to level the chair.
Some high pile carpets can obstruct the footrest operation by rubbing against
it. Adjust the levelers to a height above the pile.
5. Slide the hand control from between the back and arm out toward the back of
the chair. Secure the cord into the quick release cable clamp located above the
magazine pocket on the arm of the chair.
1. Remove the transformer from the transformer box (located behind the lower
outside back). Place two 9 volt alkaline batteries into slots provided as shown.
Place transformer on floor behind the chair.
2. Plug the transformer into a 115-120V 60Hz A.C. outlet and connect the power
cable from the chair into the transformer as shown. Power cable is located under
the chair attached to the motor with white zip tie. Remove zip tie, extend the
cable under and out behind the chair.
PR458-SMA 17 in. 17 in.
PR458-S23 17 in. 17 in.
PR458-MED 17 in. 17 in.
PR458-M23 17 in. 17 in.
PR458-LAR 18 in. 18 in.
INSTALLATION FOR YOUR POWER LIFT CHAIR
P
A
T
E
N
T
E
D

7
Power Lift Chair Operation
1. To recline your chair, press the down button (S2) and hold until you reach
your desired position. Then release the button.
2. To return to a seated position from recline, press the up button (S1)
and hold until the chair returns to a closed seated position. Then release the
button.
3. To lift your chair, press the up button (S1) and
hold until you reach your desired height. Then
release the button.
4. To return to a seated position from lift, press
the down button (S2) and hold until the chair
returns to the floor seated position. Then release
the button.
5. To lift your chair from a reclined position,
press the up button (S1) and hold, the chair will
keep going past the seated position and start to
lift, release the button when the chair reaches the desired
height.
6. To recline your chair from the lift position, press the
down button (S2) and hold. The chair will keep going past
the seated position and start to recline. Release the button
when the chair reaches the desired reclined position.
7. Getting into your lift chair. While standing next to your
chair, press the chair up button (S1) and raise the chair
to a height you can sit against. This height will vary from
person to person depending on the individual’s needs. Raise the chair high
enough so you do not have to flop down into the chair. Flopping down into
the chair can cause personal injury and damage to the chair. Press the
chair down button (S2). As the chair continues downward, adjust yourself into
a position that is comfortable to you. Continue pressing the button until chair
is in the seated position (chair firmly on the floor), then release the button.
8. Getting out of your chair, press the chair up button (S1) and raise the chair
to a height that enables you to easily stand. Release the button. Return the
chair to the seated position (chair firmly on the floor) after getting out of the
chair so children, pets or obstructions do not get under the chair.
Note: Your Golden power lift chair can be stopped at any time during
lift or recline by releasing the selected button, offering you a wide range
of comfortable positions. Select the position that best suits your needs.
The motor is set to shut off when it reaches its fully extended or fully
retracted position if the selected button is not released. If you should go
past your desired position, select the button to bring you back to your
desired position. You can repeat the process as often as you like.
S1
S2
L.E.D
.
light

8
Battery Back Up System
Your power lift chair comes with a battery back up system so the chair can return
to the seated position in the event of a household power failure. The batteries
have enough energy to bring the chair to a seated position from the recline
position. The batteries do not have enough energy nor are they intended to operate the
chair for a prolonged period of time in the absence of standard household voltage (120
volt, 60 Hz). Batteries should be replaced after one use. Batteries should be
changed yearly. (See installation page 6.)
Smart Tek™ (Power Indication)
Your power lift chair is equipped with an indicator light on the hand control. This
light illuminates green when any button on the hand control is pressed, indicating
power to the hand control.
Your power lift chair also comes with a power indicator light on the transformer
and on the power cord connecting the motor to the transformer. The lights
illuminate green constantly, indicating power from the outlet to the transformer
and the motor. The lights have been provided to help you identify electrical
disconnects, should they occur, and to help your provider to diagnose electrical
problems, should they occur.
Should the chair not operate and the lights are out, check all electrical connections
to the chair. Make sure everything is plugged in properly and there is power to
the outlet into which the chair is plugged (see installation on page 6 for electrical
connections). Should you ever encounter a problem with the operation of
your power lift chair and the lights are on, such as mechanical problems
or one light is out, discontinue all use of the product upon discovery of the
problem. Contact the provider from whom you purchased your chair. They will
be able to resolve problems and take care of proper factory service if needed. You
will need to be prepared to answer some basic questions about your power lift
chair, such as model and serial number. The model and serial number are located
on the back of the hand control and the rear of the lift frame. Your provider will
ask you questions about your power indicator lights, such as which one is out.
Prior to calling your provider, check all the electrical connections to the chair.
Make sure everything is plugged in properly and there is power to the outlet into
which the chair is plugged (see installation on page 6 for electrical connections).
P
A
T
E
N
T
E
D

9
CONSUMER LIMITED LIFETIME WARRANTY
AmeriGlide, through its authorized distributor/service organization, warrants this chair to original consumer
only, against defects in material or workmanship as follows:
LIFETIME WARRANTY
AmeriGlide, warrants for the lifetime of the chair by the original consumer to repair or replace at their
option the Lift Mechanism, Chair Frame and Recline Mechanism. Labor to replace these parts is subsidized
for three years. AmeriGlide, shall not be responsible or obligated to pay for any cost or expense for
examination of any warranted parts nor is AmeriGlide to pay for costs for transportation, handling and
packaging of the parts or components.
THREE YEAR PARTS WARRANTY
AmeriGlide, warrants the electrical parts against defects to original consumer only, for a period of three
years from the date of original purchase by a consumer. Labor to replace these parts is subsidized for one
year. AmeriGlide, shall not be responsible or obligated to pay for any costs or expenses for examination of
any warranted parts nor is AmeriGlide to pay cost for transportation, handling and packaging of the parts
or components.
TERMS APPLICABLE TO WARRANTY
AmeriGlide will, at its option, repair and/or replace the defective parts and/or components provided
that the warranty parts have not been subject to misuse, abuse or improper service by the consumer,
have not been damaged in transit or handling and/or have not been altered or repaired by unauthorized
representatives. This warranty does not include costs for unnecessary service calls, i.e., in-home service
calls solely for the purpose of educating the consumer about the product, or finding an unsatisfactory
power connection, etc. Exceeding the weight capacity of the chair will void the warranty. Fabric shading
cannot be guaranteed for replacement parts or replacement chairs.
PR458-SMA .............................300 lbs.
PR458-MED .............................375 lbs.
PR458-LAR...............................375 lbs.
PR458-S23...............................375 lbs.
PR458-M23 .............................375 lbs.
In the event that the product does not conform to this warranty at any time while this warranty
is in effect, AmeriGlide will correct the defect in conformity with the Consumer Limited Lifetime
Warranty. THE LIMITED LIFETIME WARRANTY SET FORTH ABOVE IS THE SOLE AND ENTIRE WARRANTY
PERTAINING TO THE PRODUCT AND IS IN LIEU OF AND EXCLUDES ALL OTHER WARRANTIES OF
ANY NATURE WHATSOEVER, WHETHER EXPRESSED, IMPLIED, OR ARISING BY OPERATION OF
LAW INCLUDING, BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. THIS WARRANTY DOES NOT COVER OR PROVIDE FOR THE
REIMBURSEMENT OR PAYMENT OF INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow this exclusion or limitation of incidental damages so the above limitation
or exclusion may not apply to you.
AmeriGlide shall not be liable for any incidental or consequential damage or loss not contained in this
Warranty.
This warranty gives you specific legal rights, and you may also have other rights, which may vary from
state to state.
All warranty claims must be approved by AmeriGlide before any service is performed.
Warranty is valid in all 50 states, Canadian Provinces and Puerto Rico.

#
CAUTION
Do not allow children to play on this mechanized
furniture or operate the mechanism.
Leg rest folds down on closing so that a child could
possibly be injured.
Always leave chair in a sitting position. Keep hands
and feet clear of mechanism. Only the occupant
should operate it.
CARE AND MAINTENANCE
Your lift chair will require routine maintenance checks. You can perform some
of these checks, while others may require assistance from a provider. By
following these maintenance checks, you can make sure your lift chair gives
you years of trouble-free operation. If you have any questions or concerns
regarding your lift chair’s care and maintenance, contact your provider.
9Before cleaning your lift chair, consult your provider for the proper types
of cleaner and cleaning methods.
9Keep all electrical components free from moisture and liquid spills.
Intended for indoor use only.
9Periodically inspect all wiring harnesses to make sure they are not cut,
damaged, frayed, or disconnected. If damage of any type is present,
unplug the lift chair and contact your provider.
9Periodically check all fasteners for tightness, wear, and corrosion. If any
of these are present, unplug the lift chair and contact your provider.
Warning: Be careful of pinch points and sharp metal parts (wear
gloves).
9Replace the batteries after one use. Replace the batteries yearly, even if
they were not used. Batteries are intended for one use only!

Please take a moment to fill out your warranty registration card. Your
submission of this completed card assures your purchase is protected
by the industry’s leading warranty. Be sure to make a copy of your
registration. In the event a problem should occur, you will have all the
necessary information needed to acquire service.
Name __________________________________________________________
Address ________________________________________________________
City ___________________________________State_____ Zip ____________
Serial Number ___________________________________________________
Model No. & Size ________________________________________________
Please list the AmeriGlide Location your Lift Chair was purchased from:
________________________________________________________________
Purchase Date __________________
Please remember to read your owner’s manual in its entirety. Should you have
any questions or need additional information please contact the franchisee the
chair was purchased from.
AmeriGlide
Warranty registration Card
#

AmeriGlide 3901 Commerce Park Drive Raleigh, NC 26710
#
PLACE
STAMP
HERE
