Colebrook 6 Drawer Dresser
5969308COM
Keep this Assembly Manual for future reference
Unit can p over causing severe injury or death.
- Anchor unit to stud in wall
- Do Not allow children to climb on unit
- Put heavy items on lower shelves or drawers
- Two people required for assembly

Warning
Helpful Hints
Do NOT return this product!
Contact our friendly customer service team rst for help
Call us!
1-800-489-3351
Monday-Friday
9am - 5pm CST
Visit ameriwoodhome.com
Assembly Tips
2
ameriwoodhome.com
- Open your item in the area you plan to keep it for less heavy liing
- Idenfy, sort and count the parts before aempng assembly
- Compression dowels are tapped in with a hammer
- Slides are labeled with a R (right) and L (le) for proper placement
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge
- Use all the nails provided for the back panel and spread them out equally
- Back Panel must be used to make sure your unit is sturdy
- Do NOT use harsh chemicals or abrasive cleaners on this item
- Never push, pull, or drag your furniture

Board Idencaon
Not actual size
5969308COM
Colebrook 6 Drawer Dresser
3
ameriwoodhome.com
x1
T5969308010
TOP PANEL
x1
T5969308020
SIDE PANEL LEFT
x1
T5969308030
SIDE PANEL RIGHT
x1
T5969308040
PARTITION PANEL
x6
T5969308050
DRAWER FRONT
x6
T5969308060
DRAWER BACK
x6
T5969308070
DRAWER SIDE LEFT
x6
T5969308080
DRAWER SIDE RIGHT
x1
T5969308090
SIDE RAIL LEFT
x1
T5969308100
SIDE RAIL RIGHT
x2
T5969308110
BRACE LEFT
x2
T5969308120
BRACE RIGHT
1
5
9
12
10 11
6
7 8
2 3
4

Board Idencaon
Not actual size
5969308COM
Colebrook 6 Drawer Dresser
4
ameriwoodhome.com
x1
T5969308150
BACK PANEL
x6
T5969308160
DRAWER BOTTOM
x1
T5969308130
KICK PANEL
x1
T5969308140
BOTTOM PANEL
13 14
16
15

Part List
Actual Size
5969308COM
Colebrook 6 Drawer Dresser
5
ameriwoodhome.com
x10
TTA0001
Cam Bolt
x14
TTA0003
Cam Lock
15-11.5
x84
TTA0005
CBS 3.5 x 12
x38
TTA0010
CSK 4 x 32
x24
TTA0013
PHCB 4 X 12
x12
TTA0014
PH M4 X 20
x56
TTA0016
DOWEL 6 X 30
x28
TTA0018
NAIL

Part List
Not Actual Size
5969308COM
Colebrook 6 Drawer Dresser
6
ameriwoodhome.com
x6
TTA0032
PULL HANDLE
96MM
x6 Set
TTA0033
DRAWER SLIDE
300 MML
x1 set
TTA0026
ANTI TIPPING KIT
x2
TTA0036
DOUBLE END
BOLT 64MM
x12
TTA0030
DRAWER BRACKET

Before You Start
Cam Lock Fastening System
5969308COM
Colebrook 6 Drawer Dresser
7
ameriwoodhome.com
P
P
P
P
P
This Cam Lock Fastening System will be used throughout the assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, Phillips Head
Screwdriver and Hammer
Cauon: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is ght.
Failure to do so may result in stripping the screw.
Quick
Tip
Assembly
1
3
2
4

5969308COM
Colebrook 6 Drawer Dresser
8
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 1
2
FRONT BACK
SCREW HOLE POSITION
x2
TTA0003 x4 TTA0016 x12
TTA0005
x2
TTA0001 x3
TTA0033
x3

5969308COM
Colebrook 6 Drawer Dresser
9
ameriwoodhome.com
Step 2
x2
TTA0003 x4 TTA0016
4
x24
TTA0005
LEFT SURFACE
x3
x3
RIGHT SURFACE
FRONT BACK
FRONTBACK
SCREW HOLE POSITION
SCREW HOLE POSITION
x3
TTA0033

5969308COM
Colebrook 6 Drawer Dresser
10
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 3
3
FRONTBACK
SCREW HOLE POSITION
x2
TTA0003 x4 TTA0016 x12
TTA0005
x2
TTA0001 x3
TTA0033
x3

5969308COM
Colebrook 6 Drawer Dresser
11
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 4
11
x4
TTA0003 x4 TTA0016
x2 Set

5969308COM
Colebrook 6 Drawer Dresser
12
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 5
12
x4
TTA0003 x4 TTA0016
x2 Set

5969308COM
Colebrook 6 Drawer Dresser
13
ameriwoodhome.com
Step 6
11
2
11

5969308COM
Colebrook 6 Drawer Dresser
14
ameriwoodhome.com
Step 7
4
211
11
x2
TTA0036

5969308COM
Colebrook 6 Drawer Dresser
15
ameriwoodhome.com
Step 8
4
12
12
11
11
2

5969308COM
Colebrook 6 Drawer Dresser
16
ameriwoodhome.com
Step 9
211
11
412
12
3

5969308COM
Colebrook 6 Drawer Dresser
17
ameriwoodhome.com
Step 10
9
x2
TTA0016

5969308COM
Colebrook 6 Drawer Dresser
18
ameriwoodhome.com
Step 11
10
x2
TTA0016

5969308COM
Colebrook 6 Drawer Dresser
19
ameriwoodhome.com
Step 12
13
x8
TTA0016

5969308COM
Colebrook 6 Drawer Dresser
20
ameriwoodhome.com
Step 13
13
9
