Ameriwood HOME 5990196COM User manual

B345990196COM
Do Not Return This Product!
Contact our customer service team for help rst
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
–Unit can p over causing severe injury or death.
–Anchor unit to stud in wall (if instructed to)
–Do not allow children climb on unit
–Put heavy items on lower shelves or drawers
Carver 4 Drawer Dresser
5990196COM
Date of Purchase: ____/____/_____
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
Easy Tough
Assembly Diculty Meter
Follow Ameriwood Home

Helpful Hints
Do NOT return this product!
Contact our friendly customer service team rst for help
Call us!
1-800-489-3351
Monday-Friday
9am - 5pm CST
PEOPLE NEEDED FOR ASSEMBLY: 1-2
ESTIMATED ASSEMBLY TIME: 1 HOUR
Visit ameriwoodhome.com
Assembly Tips
2
ameriwoodhome.com
- Open your item in the area you plan to keep it for less heavy liing
- Idenfy, sort and count the parts before aempng assembly
- Compression dowels are tapped in with a hammer
- Slides are labeled with a R (right) and L (le) for proper placement
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge
- Use all the nails provided for the back panel and spread them out equally
- Back Panel must be used to make sure your unit is sturdy
- Do NOT use harsh chemicals or abrasive cleaners on this item
- Never push, pull, or drag your furniture

Before You Start
Cam Lock Fastening System
3
ameriwoodhome.com
P
P
P
P
P
This Cam Lock Fastening System will be usedthroughoutthe assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Cauon: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is ght.
Failure to do so may result in stripping the screw.
Quick
Tip
Asse
m
b
ly
1
3
2
4

Board Idencaon
Notactual size
4
ameriwoodhome.com
x1
T5990196010
TOP PANEL
x1
T5990196020
LEFT SIDE PANEL
x1
T5990196030
RIGHT SIDE PANEL
x1
T5990196040
BOTTOM PANEL
x1
T5990196050
TOP MOLDING
x4
T5990196090
BACK DRAWER
1
5
9
2 3
4
x4
T5990196060
LEFT DRAWER SIDE
6
x4
T5990196070
RIGHT DRAWER SIDE
7
x4
T5990196080
FRONT DRAWER
8

Board Idencaon
Notactual size
5
ameriwoodhome.com
x2
T5990196110
SIDE RAIL
11
x4
T5990196120
LEG
12
x4
T5990196100
DRAWER BOTTOM
10
x2
T5990196130
FRONT & BACK RAIL
13
x4
T5990196140
DRAWER SUPPORT
14
x1
T5990196150
BACK PANEL
15
x1
T5990196160
FRONT SUPPORT
x2
T5990196170
BACK SUPPORT
16 17

Part List
Actual Size
6
ameriwoodhome.com
x8
TUD0010
PH M4 X 18
x18
TUD0006
NAIL
x42
TUD0001
Cam Bolt
x27
TUD0009
CBS 4 x 38
x42
TUD0002
Cam Lock
15-12
x30
TUD0004
DOWEL 8 X 25
x76
TUD0008
CBS 3.5 x 16
x2
TUD0020
L-BRACKET
Hardware Bag Reference Number:
25990196COM0

Part List
NotActual Size
7
ameriwoodhome.com
x1 set
TUD0021
ANTI TIPPING KIT
x4 SET
TUD0016
DRAWER SLIDE 12”
x4
TUD0012
HANDLE
x8
TUD0014
STOPPER 35MM
Hardware Bag Reference Number:
25990196COM0

8
ameriwoodhome.com
* raw edges are shaded
Step 1
x4
TUD0001
1
Insert Cam Bolt and fully ghten it.

9
ameriwoodhome.com
* raw edges are shaded
Step 2
x3
TUD0009
x1
TUD0021
1
5
Fix top molding to the top panel. Fix an - pping kit,
do not fully  ghten in this step

10
ameriwoodhome.com
* raw edges are shaded
Step 3
12
x4
x8
TUD0001
Insert Cam Bolt and fully ghten it.

11
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
Step 4
x10
TUD0002
x10
TUD0004
13
17
16
x2
x2
Please ensure direcon of
Cam lock

12
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
Step 5
11
x4
TUD0002
x4
TUD0004
x2
Please ensure direcon of
Cam lock

13
ameriwoodhome.com
* raw edges are shaded
Step 6
11
12
12
x2 SET
Fix legs to side rail by ghten the Cam Lock

14
ameriwoodhome.com
* raw edges are shaded
Step 7
13
13
11
12
Fix front rail & back rail by ghten the Cam
Lock

15
ameriwoodhome.com
* raw edges are shaded
Step 8
11
Fix side rail by ghten the Cam Lock

16
ameriwoodhome.com
* raw edges are shaded
Step 9
x4
TUD0009
13
4
Fix boom panel by using screw.

17
ameriwoodhome.com
* raw edges are shaded
Step 10
x4
TUD0008
x2
TUD0020
4
Secure boom panel installaon by using screw & L-Bracket.

18
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
Step 11
2
x4
TUD0004
x8
TUD0008
x4
TUD0014
x2
TUD0002
Preparaon of le side panel

19
ameriwoodhome.com
* raw edges are shaded
Step 12
x16
TUD0008
x4 (CL)
TUD0016
2
x3
TUD0001
Screw Posion
Install drawer slide CL to le side panel

20
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
* raw edges are shaded
Step 13
3
x4
TUD0004
x8
TUD0008
x4
TUD0014
x2
TUD0002
Preparaon of right side panel
