Model 270SF
Gas Sample Probe with
NH
3
Convertor
Instruction Manual

270NH3.MAN.REVD.062019 Page 2 of 17
TABLE OF CONTENTS
1.0Receiving and Storage .......................................................................................... 3
2.0Definition of Symbols ............................................................................................. 4
3.0Product Identification & Configuration ................................................................... 5
4.0Specifications ........................................................................................................ 6
5.0Description and Principle of Operation .................................................................. 7
6.0Installation ............................................................................................................. 9
7.0Start-Up ............................................................................................................... 10
8.0Shutdown ............................................................................................................ 11
9.0Maintenance ........................................................................................................ 12
10.0Troubleshooting ................................................................................................... 13
11.0Drawings and Spare Parts ................................................................................... 14
12.0Standard Terms & Conditions of Sale and Warranty ........................................... 15

270NH3.MAN.REVD.062019 Page 3 of 17
1.0 Receiving and Storage
The Universal Analyzers Model 270SF gas sample probe with ammonia converter comes completely pre-
assembled. No assembly is necessary when received on-site.
Carefully inspect the product and included accessories immediately on arrival by removing them from the
packing and checking for missing articles against the packing list.
Check the items for any damage which may have occurred during transit and immediately inform the shipping
insurance company of any damage found.
Storage location should be protected from the elements. Although all components provided are designed to
resist corrosion, additional protection from heat (>140°F/ 60°C) and humidity is recommended.

270NH3.MAN.REVD.062019 Page 4 of 17
2.0 Definition of Symbols
CAUTION, RISK OF DANGER SYMBOL INDICATES INJURY MAY OCCUR IF MANUFACTURER’S
INSTRUCTIONS ARE NOT ADHERED TO.
PLEASE READ MANUAL CAREFULLY WHEN SYMBOL IS DISPLAYED
CAUTION, HOT SURFACE SYMBOL INDICATES EXPOSED SURFACE TEMPERATURE CAN
CAUSE BURNS OR PERSONAL INJURY. CARE SHOULD BE TAKEN WHEN CONTACT IS
REQUIRED.
CAUTION, RISK OF ELECTRICAL SHOCK SYMBOL INDICATES ELECTRICAL SHOCK MAY
OCCUR. CAUTION SHOULD BE TAKEN BEFORE DISCONNECTING OR CONTACTING ANY
ELECTRICAL CONNECTIONS.
PROTECTIVE CONDUCTOR TERMINAL SYMBOL INDICATES THE TERMINAL LOCATION FOR
THE PROTECTIVE CONDUCTOR. FAILURE TO CONNECT TO THE PROTECTIVE CONDUCTOR
TERMINAL MAY RESULT IN A SHOCK HAZARD.

270NH3.MAN.REVD.062019 Page 5 of 17
3.0 Product Identification & Configuration
For the current version of all Model 270SF with Ammonia Convertor product configuration, visit the Universal
Analyzers website.
https://www.universalanalyzers.com/
Navigate to: Products -> Gas Sample Probes -> Model 270SF w/NH3
A link to the current configuration is provided at the bottom of the page.

270NH3.MAN.REVD.062019 Page 6 of 17
4.0 Specifications
OPERATING SPECIFICATIONS
Sample Flow Rate 0 to 10 l/m
Calibration Gas Requirement Sample flow rate plus 10%
Operating Pressure Drop At 10 l/m 12” water column
Maximum Gas Temperature At Inlet 700°F (370°C)
Filter Oven Temperature 350°F (176°C)
Dimensions 18” H x 30” W x 10” D
Weight 50lbs (Plus Probe)
Input Power Requirement 1600 watts
Input Voltage Requirement 115/230VAC, 50/60 Hz
Blowback Tank Volume 0.7scf when at 100psig
Blowback Duration 2 seconds suggested
Blowback Timer Period Controlled externally
Blowback Solenoid Valve Voltage As specified
Maximum NH3 Concentration
20 ppm by volume
MATERIAL SPECIFICATIONS
Enclosure
Sample Probe Fiberglass or 304SS (NEMA 4X)
Ammonia Converter Painted steel (NEMA 4X)
Sample Line Connection 3” Heat shrink boot
Filter Heater Type Rod heaters in aluminum tube, controlled with integral
thermal switch
Oven Insulation Material Jacketed fiberglass
Filter Chamber Material 316SS
Filter Element Types 2 µm ceramic or 316SS filter elements; ceramic element
with 0.1 µm coating inside
Ammonia Converter Heater Type Ceramic fiber heater (controlled remotely, sensed with Type
K Thermocouple)
Converter Canister 316 Stainless Steel

270NH3.MAN.REVD.062019 Page 7 of 17
5.0 Description and Principle of Operation
APPLICATION
The Ammonia (NH3) Converter is typically bolted to the side of, and plumbed to, a 270 series probe. The
assembly is designed to sample gas in stacks where ammonia is added and must be analyzed. There is an
unconverted sample output located immediately after the filter on the probe. A second sample connection is
made after the converter. NO is analyzed from samples at both locations, and the difference in concentration
is a measure of the amount of ammonia that has been converted.
All other standard model 270 probe options may be ordered along with the ammonia converter, including high
pressure blowback functions, calibration gas injection, and all standard flange sizes. Refer to the specific
model 270 manuals for more information regarding the probe specifications.
GENERAL DESCRIPTION, HEATED FILTER SECTION
The Heated Stack Filter Section of the NH3 Conversion Assembly consists of the 270 heated filter mounted
on the left side of the converter and contains a blowback solenoid valve to be activated by external means. An
acid blocking component is provided to protect the valve from acid in the sample. The solenoid valve can be
provided with any of the available solenoid coils to allow the external control system to provide the opening
coil power which is most convenient.
The NEMA 4X enclosure is fastened directly to the mounting flange which is sized to match the mating
sample flange on the stack. There is a heat shrink boot on the bottom of the enclosure to accept a heated
sample line. When the heated sample line is properly supported, the flange mounting of the enclosure is
sufficient to support the entire assembly.
A 125 watt Heater Assembly is mounted on the outside of the filter cavity. The heater holds the temperature
of the filter at 340°F. A bi-metallic thermal switch fused to the heater keeps the temperature from exceeding
340°F (171°C) by opening the circuit at that temperature. An optional independent thermocouple/RTD can be
provided as a means to measure and transmit or record the temperature of the filter. A second thermal switch,
set at 225°F (105°C.) is provided to be used as an alarm contact if the temperature drops below the switch
temperature.
Several types of filter elements can be supplied with the Model 270. The 2 μm ceramic filter is supplied as an
economical general purpose filter. A similar ceramic filter with an internal 0.1 μm coating is available for finer
filtration or to provide a surface to enhance the blowback capability where the fines have a tendency to fill the
pores of the 2 μm element. A 2μm, 316SS filter can be inserted for those applications where the ceramic filter
is determined to be unsuitable. Additional filtration materials and pore sizes are available on request.
The blowback accumulator is a 7” diameter stainless steel sphere. It is designed to be pressurized to a
maximum pressure of 125 psig compressed air. At that pressure there is a 1/2 cubic foot of air stored to flush
the particulate matter out of the filter and through the probe and into the stack.
Compressed air is used to clean the filter element. Compressed air supplied to the blowback assembly needs
to be clean and dry. Instrument quality air is preferred. The pressure should be as high as possible, up to 125
psig. High pressure air fills the accumulator and provides a substantial blast when the solenoid valve opens.
This loosens the particles on the filter surface and forces them back through the sample probe into the stack.
The period of time between blowback cycles should be commanded to occur before the pressure drop across
the filter begins to increase. This should be as often as every 15 minutes but no less frequently than once per
day. The time period between blowback cycles can be based on a calculation to estimate the amount of
sample required to deposit from 3 to 5 grams of solid in the filter element.
Instrument air usage is minimal and smoothed by the fact that the air accumulator is charged over a period of
time through a 1/4” instrument air line. The recharge time could be extended with a restriction in the air line, if
it were desired to reduce the pressure pulses on the instrument air supply and to consume instrument air
more slowly.

270NH3.MAN.REVD.062019 Page 8 of 17
GENERAL DESCRIPTION, AMMONIA CONVERSION SECTION
The NH3 converter mounts to the right side of a standard 270 series probe enclosure. The probe enclosure is
fastened directly to a mounting flange on the stack. A heat shrink boot on the bottom of the probe enclosure
provides a sealed input location for all sample lines and electrical wiring for both units.
Tubing connects one of the heated probe filter outputs to the input on the NH3 converter. This tubing is
wrapped with a heater to ensure that no condensate forms. This heater, along with the heater inside the
converter chamber, is terminated in the probe enclosure, where user power is provided.
Blowback is typically provided with the probe assembly to flush particulate matter out of the filter. When the
accumulator sphere is discharged, small amounts of air will also travel through the converter. Blowback air
does not harm the converter but will momentarily disturb both sample outputs. Clean and dry instrument
quality air is essential to avoid particulate buildup in the converter chamber. Typical blowback time intervals
are user controlled, as frequent as every 15 minutes, but not more` than 24 hours.
Calibration (cal) gas is injected into the probe chamber, ahead of the filter. This fulfills most EPA
requirements for cal gas insertion with respect to proximity of the sample source. A back-pressure check
valve, set to approximately 3 psi, is provided in the cal gas injection path to ensure that the gas does not leak
into the sample path during normal operation. After the filter, cal gas is drawn through both the converted and
unconverted sample outputs.
The converter canister provides a torturous gas path through 316 stainless steel disks and balls, with elevated
surface temperatures above 1200°F. The temperature of the chamber is user controlled via monitoring of the
pre-installed type K thermocouple which is welded to the chamber core. The oven temperature may be safety
controlled up to 1500°F; however, the stainless steel surfaces, along with the ammonia gases, oxidize at the
high end of the range, reducing the service life of the reactor.
As the sample passes through the reactor, all NOX and NH3 are thermally oxidized into Nitric Oxide (NO).
Reaction of NH3 proceeds according to this exothermic reaction:
4 NH3 + 5 O2 → 4 NO + 6 H2O
The controlled temperature, gas concentration, and flow rate through the converter should be optimized by
each user through empirical means. It is recommended to first test the conversion efficiency at 1250°F. Most
applications result in as high as 95% effectiveness at this temperature. Testing above 1500°F has shown to
reduce effectiveness in many instances.
For maximum conversion efficiency and long reaction life (several years), observe the following:
 Ratio of O2 to NH3 should be greater than 1.25.
 Flow through the reactor should be limited to 1 – 1.5 l/m.
 Do not expose the reactor to ammonia concentrations > 20 ppm.
 Minimize (NH3 ppm * hours * flow rate) for longest reactor life.

270NH3.MAN.REVD.062019 Page 9 of 17
6.0 Installation
The Ammonia Converter is typically bolted to the side of a probe enclosure, which provides all the structural
support necessary. Interfacing to the stack, connecting to sample bundles, and termination of electrical wiring
is done through the probe assembly. The probe mounts to a flange face, which should be vertical or canted
slightly to allow any entrained liquid in the sample to drain back into the stack. The probe tube should extend
into the center third of the stack.
Heated sample line bundles should be supported externally to the probe housing, such that no weight is
transferred to the enclosure wall. Connect the two sample tubes to the appropriate fittings before and after
the converter. Unheated portions of these tubes should be kept to a minimum to avoid condensation. The cal
gas input line connects directly to the check valve on the side of the chamber. The blowback instrument air
tubing connects to the fitting close to the accumulator sphere. If an external air line is to be utilized, use a
bulkhead fitting in the side of the probe enclosure for support.
Electrical terminals in the probe enclosure provide connections to the converter heater and thermocouple.
Drawings in the back of this manual should be used for reference only, since wiring of different probe models
will vary slightly. Always be sure that the power supplied to the probe and the NH3 converter matches the
voltage requirement shown on the serial number tag. Type K thermocouple extension wire should be used in
the bundle to connect to the temperature controller. A solid state relay may be necessary in the heater
control process. Approximately 1250 watts of power is required. An independent ground wire should be run
to the grounding terminal in the probe enclosure.
Secure the enclosure and ensure that the sample tubing is kept at a temperature above the dew point of the
gas all the way to the cooler/dehydrator.

270NH3.MAN.REVD.062019 Page 10 of 17
7.0 Start-Up
Apply power to the unit. Allow the probe filter chamber and NH3 converter to come up to operation
temperature. This warm-up period is extremely important to avoid condensation, which can cement
particulates to the filter surface and in the converter path.
Only after the unit has come up to full temperature, start the gas sample pump(s) and determine that the
proper amount of sample is being supplied to secondary instrumentation.
Run a calibration cycle to ensure that tubing is properly installed and sealed. A flow meter should be installed
in the cal gas supply line to ensure that at least 10% more gas is being supplied than what is withdrawn as
sample. This calculation should include the sum of the unconverted and converted sample paths. Excess cal
gas is discharged through the probe into the stack.
Charge the accumulator and manually perform a blowback cycle to ensure proper wiring. A slight pulse of
instrument air in the sample tubing will cause a momentary dilution of sample at the analyzers. This is normal
and signifies that a blowback cycle has occurred.
AMMONIA OXIDATION TEMPERATURES
It is suggested that the temperature of the reactor oven be first controlled to 1250°F (677°C). to determine if
satisfactory ammonia conversion efficiencies can be obtained at that temperature.

270NH3.MAN.REVD.062019 Page 11 of 17
8.0 Shutdown
1. It is recommended to introduce inert gas or instrument air through the cal gas port for 15 to 30
minutes to purge the filter chamber, NH3 converter, and sample lines of potentially hazardous
substances.
2. Shut down the sample pump before the end of the purge cycle to avoid drawing in new gasses.
3. Filter replacement may now be safely performed. Caution: The filter chamber is typically controlled to
temperatures above 300°F and can cause serious burns.
4. For further disassembly, shut down all heaters in the probe and converter.
5. It is recommended to flow instrument air through the converter for several hours to cool down to
acceptable temperatures. Caution: The NH3 canister operates at temperatures above 1250°F and
can cause serious burns. Depending on the installation and application parameters, the well-
insulated chamber may take up to 24 hours for a sufficient cool down period.
6. Turn off instrument air for blowback and manually perform a blowback cycle to empty the accumulator
chamber and reduce any stored energy in the system.

270NH3.MAN.REVD.062019 Page 12 of 17
9.0 Maintenance
CHANGING THE FILTER
CAUTION: THIS PROCEDURE CAN CAUSE SEVERE BURNS. USE PROPER
PROTECTION.
Changing the filter in the Model 270 Heated Filter Assembly is extremely easy. Using gloves to protect the
hand, grasp the cap on the end of the filter body opposite the probe and turn it counterclockwise. The cover
may be hot to the touch and may cause burns to the hand if not protected. Removing the cover exposes the
filter. The cover is secured to the assembly with a retainer chain. Reach into the heated oven with pliers to
pull out the old filter.
Inspect the O-Rings which are at each end of the filter to ensure they are still elastic and will seal the filter.
Replace O-Rings if they are charred or deformed.
Replace the filter with a new one, again handling it with pliers. Ensure that the filter is pushed in the center of
the oven so that it is in contact with the O-Ring on the far end of the filter. Screw the cap back on the filter
body. The filter replacement procedure is complete.
NH
3
CONVERTER
The NH
3
Converter requires relatively little maintenance, but over a long period of time (years), the
effectiveness can drop off due to oil and oxidation coatings on the internal components. This is measurable
by comparing the cal gas analysis through both sample ports. When the converter effectiveness is no longer
acceptable, a replacement chamber may be installed.
Complete a full shutdown sequence and include enough time for adequate cool down. The canister starts at
over 1250°F and is well insulated, so cool down may take up to 24 hours. Pumping instrument air through the
canister will reduce cool down time.
1. Unbuckle the ceramic heater/insulator strap and open the front half of the unit. There should be
adequate room to leave the heater wired up and still perform the swap.
2. Slide the thermocouple down and out of the canister.
3. Loosen the fittings from the canister tubes at the bulkhead wall and remove the canister.
It is not recommended to perform maintenance on any other part of the converter assembly.

270NH3.MAN.REVD.062019 Page 13 of 17
10.0 Troubleshooting
The following table should give an overview of possible errors and an instruction to check and to repair them.
Error Possible reason Check/Repair
No sample gas flow Filter element plugged
Filter chamber exit port plugged
Check/ replace filter element
Remove filter element and
inspect exit port. Exit port will be
located at 0° or 180° from the top,
dependin
g
on confi
g
uration
Low temperature alarm Insufficient warm-up time
Power disconnected
Control switch defective
Ensure power has been applied
to the unit for a minimum of 15
minutes
Ensure power is supplied to the
unit. Check by measuring for AC
voltage on TB1-1 & 2
Verify by measuring for a closed
circuit between TB1-1 & 4
High oxygen readings/ low
pollutant readings
Leak Leaking past the filter cap O-ring:
Remove filter element using the
filter change instructions. Inspect
the O-ring under the filter cap by
removing the 3 screws in the top
of the cap and removing the
aluminum section from the filter
cap plug. The O-ring under the
aluminum cap should be pliable,
undamaged, and seated in its
groove. Replace the O-ring if
necessary.
Leaking blowback solenoid valve:
Block or disconnect the blowback
supply and look for a change in
the analyzer readings.
Loose connection:
Verify all fittings are tight and leak
free
Low readings during calibration Insufficient calibration gas flow Ensure calibration flow is at least
110% of the sample
g
as flow

270NH3.MAN.REVD.062019 Page 14 of 17
11.0 Drawings and Spare Parts
For the current revision of all Model 270SF with Ammonia Convertor drawings and spare parts, visit the
Universal Analyzers website.
https://www.universalanalyzers.com/
Navigate to: Products -> Gas Sample Probes -> Model 270SF w/NH3
Links to all current drawings and spare parts for standard probe configurations are provided at the bottom of
the page.

270NH3.MAN.REVD.062019 Page 15 of 17
12.0 Standard Terms & Conditions of Sale and Warranty
THE FOLLOWING TERMS/CONDITIONS, TOGETHER WITH ANY OTHER TERMS/CONDITIONS SPECIFICALLY
AGREED TO IN WRITING BY SELLER, SHALL APPLY TO ALL ORDERS (“Order(s)”) FROM, AND SALES OF
PRODUCTS (“Products”) OR SERVICES (“Services”) TO BUYER. ANY ACCEPTANCE OF ANY ORDER OF BUYER IS
CONDITIONED UPON THESE TERMS/CONDITIONS. ANY ADDITIONAL OR DIFFERENT TERMS/CONDITIONS
PROPOSED BY BUYER IN ANY DOCUMENT ARE OBJECTED TO AND SHALL NOT BE BINDING UPON SELLER.
No salesperson is authorized to bind Seller to any promise or understanding not expressed herein.
I. PRICES
All prices are subject to change without notice in the event of
any changes in cost of materials or labor, specifications,
quantities, delivery schedules, customs duties, other factors
beyond Seller’s control, or in the event of delays caused by
instructions of the Buyer, or failure of the Buyer to give Seller
adequate information. Further, prices payable by the Buyer
shall be subject to immediate increase, should the Seller as a
result of governmental action or regulation including, without
limitation, those contemplated by an investigation under
Section 232 of the Trade Expansion Act of 1962 (19
U.S.C.§1862), incur additional duties, tariffs or restrictions on
products sold hereunder, or on the raw materials that are used
in making such products. In no event shall prices include any
amounts imposed on the Buyer in connection with Buyer’s
purchases from Seller, such as taxes, including but not limited
to Value Added Tax (VAT) or excise taxes, duties, tariffs, or
any other costs assessed against the Buyer by a governmental
authority.
II. DELIVERY
Delivery dates are approximate and are dependent on prompt
receipt by Seller of all necessary information. Seller may deliver
all or any part of Products/ Services as early as 30 days in
advance of agreed schedule. The point of delivery shall be
"Exworks" Seller’s premises, unless otherwise specified by
Seller. Upon delivery, title to Products and all risk of loss or
damage thereto shall pass to Buyer. Where Buyer notifies
Seller that it cannot take timely delivery of the Products, Seller
may place such Products in storage, at the risk of Buyer, and
Buyer shall reimburse Seller for all expenses incurred in
connection with such storage. Buyer shall dispose of the
packing materials for Products at its own expense, and shall
defend, indemnify and hold harmless Seller from any legal
obligations in connection with such packing waste.
III. PAYMENT
A. The term of payment shall be net 30 days from date of
Seller's invoice, unless otherwise specified. Payments shall be
made by Buyer without any deduction or set-off. Unless
otherwise agreed, payment shall be made in U.S. dollars.
Seller may charge late payment fees at the rate of 1.5% per
month, or the highest rate permitted by law, whichever is less,
accruing daily.
B. If the financial condition of Buyer is unsatisfactory to Seller,
Seller may require full or partial payment in advance, or
satisfactory security, in the form of a letter of
credit or otherwise. In the event of bankruptcy or insolvency of
Buyer, Seller may immediately cancel any Order then
outstanding.
C. Buyer grants Seller a purchase money security interest in
Products located in the United States, or Services, as well as
any proceeds, for the purpose of securing the obligations of
Buyer hereunder. Buyer authorizes Seller to execute on
Buyer’s behalf and file such financing statements as Seller
deems appropriate to perfect and notify Buyer’s creditors of
Seller’s security interest.
IV. VARIATIONS IN QUANTITY; CHANGES.
Buyer shall accept delivery of quantities greater or smaller than
the quantity specified in Order(s), provided that any such
variation shall not exceed 5% of the quantity originally
specified, or 2 units, whichever is greater. Seller shall not be
required to give notice of any such variations other than in the
applicable shipping notice and invoice. Seller reserves the
option to make changes to Products or Services which do not
affect form, fit, or function, and shall deliver Products to the
latest configuration part number at the time of delivery.
V. EXPORT CONTROLS; FCPA; ANTI-BOYCOTT
A. Buyer shall not make any disposition of the Products, by
way of transshipment, re-export, diversion or otherwise, except
as applicable U.S. export laws and regulations may expressly
permit, and other than in and to the ultimate country of
destination specified on Order(s) or declared as the country of
ultimate destination on Seller's invoices or in the End Use
Statement that Buyer supplies Seller. Seller shall not be named
as shipper or exporter of record or U.S. principal partyin-
interest (USPPI) unless specifically agreed to in writing by
Seller in which case, Buyer shall provide Seller with a copy of
the documents filed by Buyer for Export clearance purposes. At
Seller’s request, Buyer shall supply end-use and end-user
information to determine export license applicability. Failure of
Buyer to comply with this section shall constitute a material
default allowing Seller to cancel related Order(s) without
liability.
B. Buyer warrants that it shall not violate or cause the Seller to
violate the U.S. Foreign Corrupt Practices act of 1977 (FCPA),
as amended, the United Kingdom Bribery Act (UKBA) of 2010,
as amended, or their respective implementing regulations in
connection with Buyer’s sale or distribution of the Products
and/or Services, and that Buyer does not know or have reason
to believe that any consultant, agent, representative or other
person retained by Buyer in connection with the sale and/or
distribution of Products/Services has violated, nor caused
Seller to violate the FPCA and/or the UKBA. Where Buyer

270NH3.MAN.REVD.062019 Page 16 of 17
learns of or has reason to know of any violation of FCPA and/or
or UKBA in connection with the sale or distribution of
Products/Services, Buyer shall immediately advise Seller.
C. Buyer further warrants that Buyer shall not violate or cause
Seller to violate the U.S. Antiboycott Provisions of the U.S.
Export Administration Regulations issued pursuant to the U.S.
Export Administration Act of 1979, as amended, in connection
with Buyer’s purchase of Products/Services and that Buyer
shall not request or require Seller to make statements or
certifications against countries that are not subject to boycott
by the U.S.
VI. WARRANTIES
A. Seller warrants that Products manufactured by Seller, when
delivered, shall be free from defects in material/workmanship.
Seller warrants that Services shall be performed in accordance
with generally accepted industry practice. Seller's obligations
under this warranty shall be limited exclusively to repairing or
replacing, at Seller's option, any part of Products which, if
properly installed, used and maintained, proved to have been
defective in material or workmanship within 1 year from the
date of shipment or re-performing the Services. Seller warrants
for a period of 1 year from the date of shipment that software or
firmware, when used with Products, shall perform in
accordance with Seller’s published specifications. Seller makes
no warranty, express or implied, that the operations of the
software or firmware shall be uninterrupted or error-free, or that
functions contained therein shall meet or satisfy the Buyer’s
intended use/requirements. Buyer shall notify Seller of any
defect in the quality or condition of Products (including
software/firmware) or Services within 7 days of the date of
delivery or performance, unless the defect was not apparent on
reasonable inspection, in which case, within 7 days after
discovery of the defect. If Buyer does not provide such timely
notification, it shall not be entitled to reject Products (including
software/firmware) or Services, and Seller shall have no liability
for such defect.
B. Seller's warranty obligations shall not apply to Products
which (1) have been altered or repaired by someone other than
Seller, or (2) have been subjected to misuse, neglect, or
improper use or application, or (3) are normally consumed in
operation, or (4) have a normal life inherently shorter than the
warranty period stated therein.
C. No Products may be returned unless authorized in advance
by Seller, and then only upon such conditions to which Seller
may agree. Buyer must obtain a Return Material Authorization
(RMA) number from Seller prior to any return shipment, and
such RMA number must appear on the shipping label and
packing slip. Buyer shall be responsible for returned Products
until such time as Seller receives the same at its facility, and for
all charges for packing, inspection, shipping, transportation or
insurance associated with returned Products.
D. This section VI sets forth the exclusive remedies and
obligations for claims based upon defects in or nonconformity
of Products/Services, whether the claim is in contract, warranty,
tort (including negligence of any degree or strict liability) or
otherwise. THE FOREGOING WARRANTIES ARE IN LIEU OF
ALL OTHER WARRANTIES, WHETHER ORAL, WRITTEN,
EXPRESS, IMPLIED OR STATUTORY. NO IMPLIED OR
STATUTORY WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR PARTICULAR PURPOSE SHALL APPLY.
VII. PATENTS/INDEMNITY
If Buyer receives a claim that Products, or part thereof
manufactured by Seller infringes a patent, Buyer shall notify
Seller promptly in writing and give Seller information,
assistance and exclusive authority to evaluate, defend and
settle such claim. Where Buyer has furnished
specifications/designs for the manufacture of the allegedly
infringing Products, Buyer shall defend, indemnify and hold
harmless Seller against third-party claims for infringement
arising out of Seller’s use of such specifications/designs.
VIII. LIMITATION OF LIABILITY
The total liability of Seller on any claim, whether in contract, tort
(including negligence of any degree and strict liability) or
otherwise arising out of, connected with, or resulting from the
manufacture, sale, delivery, resale, repair, replacement or use
of any Products/Services, shall not exceed the price allocable
to the Products/Services or part thereof which gives rise to the
claim. IN NO EVENT, WHETHER AS A RESULT OF BREACH
OF CONTRACT, WARRANTY, TORT, (INCLUDING
NEGLIGENCE OF ANY DEGREE, STRICT LIABILITY OR
PATENT INFRINGEMENT) OR OTHERWISE, SHALL
SELLER, ITS AFFILIATES, SUBCONTRACTORS, OR
SUPPLIERS BE LIABLE FOR ANY LOSS OF PROFIT OR
REVENUES, LOSS OF USE OF THE PRODUCTS OR
SERVICES, OR ANY ASSOCIATED EQUIPMENT, COST OF
CAPITAL, COST OF SUBSTITUTE GOODS, FACILITIES,
SERVICES OR REPLACEMENT POWER, DOWNTIME
COSTS OR CLAIMS OF BUYER'S CUSTOMERS FOR
DAMAGES OR FOR ANY SPECIAL, PROXIMATE,
CONSEQUENTIAL, INCIDENTAL, INDIRECT OR
EXEMPLARY DAMAGES. If Buyer transfers title to, or leases
Products sold hereunder to, or otherwise permits or suffers use
by, any third party, Buyer shall obtain from such third party a
provision affording Seller and its subcontractors/suppliers the
protection of the preceding sentence. Any action against Seller
must be brought within 18 months after cause of action
accrues.
IX. EXCUSABLE DELAYS
A. Seller shall not be liable for delays in delivery or failure to
perform due directly or indirectly to causes beyond Seller's
reasonable control including but not limited to: acts of God;
war; terrorism; civil commotion; riots; embargoes; government
regulations, orders, instructions or priorities; port congestion;
acts of or failure to act on the part of Buyer or its
agents/employees; fires; floods; sabotage; nuclear incidents;
earthquakes; storms; epidemics; strikes; lockouts or other labor
difficulties; shortages of or inability to timely obtain proper
labor, materials, components, shipping space or transportation,
fuel, supplies or power at current prices; or due to limitations
imposed by the extent of availability of Seller’s normal
manufacturing facilities.
B. If a delay excused per the above extends for more than 90
days and the parties have not agreed upon a revised basis for
continuing providing Products/Services at the end of the delay,
including adjustment of the price, then either party (except
where delay is caused by Buyer, in which event only Seller)
upon thirty (30) days’ notice may terminate the Order with
respect to the unexecuted portion of the Products/Services,
whereupon Buyer shall promptly pay Seller its reasonable
termination charges upon submission of Seller's invoices
thereof.

270NH3.MAN.REVD.062019 Page 17 of 17
X. SOFTWARE/TECHNICAL/PROPRIETARY
INFORMATION
A. Buyer shall not acquire any rights to any software which may
be delivered with Products, except as granted in Seller’s
standard software license. Any software license granted in
connection with Products shall be an interim license, which
may be withdrawn, pending payment for Products in full.
B. The purchase of Products shall not include any right to
supply of technical information such as drawings or
specifications.
C. Proprietary information, including drawings, documents,
technical data, reports, software, designs, inventions and other
technical information supplied by Seller in connection herewith
(hereinafter called "Data"), shall remain Seller's sole property
and shall be held in confidence by Buyer. Data shall not be
reproduced, used or disclosed to others by Buyer without
Seller’s prior written consent. Upon completion of Order, Buyer
shall promptly return all Data to Seller together with all copies
or reprints thereof then in Buyer's possession or control, and
Buyer shall thereafter make no future use, either directly or
indirectly, of any Data or any information derived therefrom
without Seller's prior written consent. The foregoing shall in no
way obligate Seller to provide or supply Data.
XI. DIES, TOOLS, PATTERNS
Seller’s charges for dies, molds, patterns and the like represent
the Buyer’s proportionate cost thereof, it being expressly
understood that they remain the property of Seller.
Modifications made to dies, molds, patterns and the like in
order to manufacture Products shall be at the discretion of
Seller.
XII. GENERAL
A. The rights and obligations of the Buyer and Seller hereunder
shall be governed in all respects by the law of the
Commonwealth of Pennsylvania, U.S.A. The exclusive forum
for adjudication of any disputes shall be the federal or state
courts of the Commonwealth of Pennsylvania, and Buyer/Seller
hereby consent to personal jurisdiction and venue in such
courts in any proceeding. The United Nations Convention on
the International Sale of Goods shall not apply.
B. These Terms and Conditions of Sale together with any other
terms specifically agreed to in writing by Seller constitute the
entire agreement between Buyer and Seller and supersede any
prior or contemporaneous representations, agreements,
proposals, warranties, or understandings, oral or written,
express or implied. No waiver, modification, amendment,
rescission or other change to these Terms and Conditions of
Sale shall be binding unless specifically agreed to in writing by
an authorized representative of Seller.
C. The invalidity, of any part hereof shall not affect the validity
of the remainder. The failure of Seller to assert any right at any
time hereunder shall not prevent Seller's subsequent assertion
of the same or different rights.
D. Buyer may not assign this contract without the prior written
approval of the Seller.
XIII. PROHIBITION FOR HAZARDOUS USE
Products sold hereunder are not intended for application in,
and shall not be used by Buyer in construction or application of
a nuclear installation or in connection with use or handling of
nuclear material or for any hazardous activity or critical
application, where failure of a single component could cause
substantial harm to persons or property, unless Products have
been specifically approved for such activity or application.
Seller disclaims all liability for loss or damage resulting from
such unauthorized use and Buyer shall defend, hold harmless
and indemnify Seller against any such liability, whether arising
under breach of contract, warranty, tort (regardless of the
degree of fault or negligence), strict liability or otherwise.
Where Seller approves the application of the Products in a
nuclear facility, the Buyer shall, before such use or provision,
arrange for insurance or governmental indemnity protecting the
Seller against liability and hereby releases and agrees to
indemnify the Seller and its suppliers for any nuclear damage,
including loss of use, in any manner arising out of a nuclear
incident, whether alleged to be due, in whole or in part to the
negligence or otherwise of the Seller or its suppliers.
XIV. STATUTORY REQUIREMENTS
Seller reserves the right to make any changes in the general
specifications of the Products which are required for the
Products to conform to any statutory requirement.
XV. GOVERNMENT CONTRACTS
Only Federal Acquisition Regulation (“FAR”) supplement
clauses expressly accepted in writing by Seller shall be
included or incorporated by reference herein. Seller shall not
be bound by and makes no representation of compliance with
any FAR or FAR supplement clauses that Seller shall not have
expressly accepted in writing.
