SERVICE AND PARTS MANUAL FOR
BLOWER MODEL
DR454RD – DR656RDNT
REMOTE DRIVE REGENERATIVE BLOWER
AMETEK Dynamic Fluid Solutions
100 East Erie St., Kent, Ohio 44240
Telephone: [phone] Fax: [phone]
email: [e-mail]
internet: www.ametekdfs.com

1 Revised – June 2016
W A R R A N T Y , I N S T A L L A T I O N , M A I N T E N A N C E A N D
TRO U B L E S H O O T I N G I N S T R U C T I O N S
AMETEK Dynamic Fluid Solutions
100 East Erie St., Kent, Ohio 44240
Telephone: [phone] Fax: [phone]
email: [e-mail]
internet: www.ametekdfs.com
1. AMETEK Rotron DR, EN and HiE regenerative direct drive blowers are guaranteed for one full
year from the date of installation (limited to 18 months from the date of shipment) to the original
purchaser only. Should the blower fail we will evaluate the failure If failure is determined to be
workmanship or material defect related, we will at our option repair or replace the blower.
2. AMETEK Rotron Minispiral, Revaflow, Multiflow, Nautilair, remote drive blowers, moisture
separators, packaged units, CP blowers, Nasty Gas™ models and special built (EO) products are
guaranteed for one full year from date of shipment for workmanship and material defect to the
original purchaser only. Should the blower fail, If failure is determined to be workmanship or
material defect related, we will at our option repair or replace the blower.
3. Parts Policy - AMETEK Rotron spare parts and accessories are guaranteed for three months from
date of shipment for workmanship and material defect to the original purchaser only. If failure is
determined to be workmanship or material defect related we will at our option repair or replace the
part.
Corrective Action - A written report will be provided indicating reason(s) for failure, with suggestions
for corrective action. Subsequent customer failures due to abuse, misuse, misapplication or repeat
offense will not be covered. AMETEK Rotron will then notify you of your options. Any failed unit that is
tampered with by attempting repair or diagnosis will void the warranty, unless authorized by the
factory.
Terms and Conditions - Our warranty covers repairs or replacement of regenerative blowers only,
and will not cover labor for installation, outbound and inbound shipping costs, accessories or other
items not considered integral blower parts. Charges may be incurred on products returned for reasons
other than failures covered by their appropriate warranty. Out-of-warranty product and in warranty
product returned for failures determined to be caused by abuse, misuse, or repeat offense will be
subject to an evaluation charge. Maximum liability will in no case exceed the value of the product
purchased. Damage resulting from mishandling during shipment is not covered by this warranty. It is
the responsibility of the purchaser to file claims with the carrier. Other terms and conditions of sale are
stated on the back of the order acknowledgement.
Installation Instructions for SL, DR, EN, CP, and HiE Series Blowers
1. Bolt It Down - Any blower must be secured against movement prior to starting or testing to
prevent injury or damage. The blower does not vibrate much more than a standard electric motor.
2. Filtration - All blowers should be filtered prior to starting. Care must be taken so that no foreign
material enters the blower. If foreign material does enter the blower, it could cause internal
damage or may exit at extremely high velocity.
Should excessive amounts of material pass through the blower, it is suggested that the cover(s)
and impeller(s) be removed periodically and cleaned to avoid impeller imbalance. Impeller

2 Revised – June 2016
imbalance greatly speeds bearing wear, thus reducing blower life. Disassembling the blower will
void warranty, so contact the factory for cleaning authorization.
3. Support the Piping - The blower flanges and nozzles are designed as connection points only and
are not designed to be support members.
Caution: Plastic piping should not be used on blowers larger than 1 HP that are operating near
their maximum pressure or suction point. Blower housing and nearby piping
temperatures can exceed 200ºF. Access by personnel to the blower or nearby piping
should be limited, guarded, or marked, to prevent danger of burns.
4. Wiring - Blowers must be wired and protected/fused in accordance with local and national
electrical codes. All blowers must be grounded to prevent electrical shock. Slo-Blo or time delay
fuses should be used to bypass the first second of start-up amperage.
5. Pressure/Suction Maximums - The maximum pressure and/or suction listed on the model label
should not be exceeded. This can be monitored by means of a pressure or suction gage (available
from Rotron), installed in the piping at the blower outlet or inlet. Also, if problems do arise, the
Rotron Field representative will need to know the operating pressure/suction to properly diagnose
the problem.
6. Excess Air - Bleed excess air off. DO NOT throttle to reduce flow. When bleeding off excess air,
the blower draws less power and runs cooler.
Note: Remote Drive (Motorless) Blowers - Properly designed and installed guards should be used
on all belts, pulleys, couplings, etc. Observe maximum remote drive speed allowable. Due to the
range of uses, drive guards are the responsibility of the customer or user. Belts should be
tensioned using belt gauge.
Maintenance Procedure
When properly piped, filtered, and applied, little or no routine maintenance is required. Keep
the filter clean. Also, all standard models in the DR, EN, CP, and HiE series have sealed
bearings that require no maintenance. Bearing should be changed after 15,000 to 20,000
hours, on average. Replacement bearing information is specified on the chart below.
Bearing
Part Number Size Seal Material Grease Heat Stabilized
510217
510218
510219
205
206
207
Polyacrylic
Nye Rheotemp 500
30% +/- 5% Fill Yes – 325 F
510449
516440
516648
203
202
307
Buna N Exxon Polyrex Grease NO
516840
516841
516842
516843
516844
516845
516846
516847
206
207
208
210
309
310
311
313
Buna N Exxon Polyrex Grease NO

3 Revised – June 2016
Troubleshooting
POSSIBLE CAUSE OUT OF WARRANTY REMEDY ***
IMPELLER DOES NOT
TURN
Humming Sound
1. * One phase of power line not connected
2. * One phase of stator winding open
3. Bearings defective
4. Impeller jammed by foreign material
5. Impeller jammed against housing or cover
6. ** Capacitor open
1. Connect
2. Rewind or buy new motor
3. Change bearings
4. Clean and add filter
5. Adjust
6. Change capacitor
No
Soun
d
1. * Two phases of power line not connected
2. * Two phases of stator winding open
1. Connect
2. Rewind or buy new motor
IMPELLER TURNS
Blown
Fuse
1. Insufficient fuse capacity
2. Short circuit
1. Use time delay fuse of proper
rating
2. Repair
Motor Overheated Or
Protector Trips
1. High or low voltage
2. * Operating in single phase condition
3. Bearings defective
4. Impeller rubbing against housing or cover
5. Impeller or air passage clogged by foreign material
6. Unit operating beyond performance range
7. Capacitor shorted
8. * One phase of stator winding short circuited
1. Check input voltage
2. Check connections
3. Check bearings
4. Adjust
5. Clean and add filter
6. Reduce system pressure/vacuum
7. Change capacitor
8. Rewind or buy new motor
Abnormal
Sound
1. Impeller rubbing against housing or cover
2. Impeller or air passages clogged by foreign
material
3. Bearings defective
1. Adjust
2. Clean and add filter
3. Change bearings
Performance
Below Standard
1. Leak in piping
2. Piping and air passages clogged
3. Impeller rotation reversed
4. Leak in blower
5. Low voltage
1. Tighten
2. Clean
3. Check wiring
4. Tighten cover, flange
5. Check input voltage
* 3 phase units
** 1 phase units
*** Disassembly and repair of new blowers or motors will void the Rotron warranty. Factory should be contacted
prior to any attempt to field repair an in-warranty unit.
Blower Disassembly:
WARNING: Attempting to repair or diagnose a blower may void Rotron’s warranty. It may also
be difficult to successfully disassemble and reassemble the unit.
1) Disconnect the power leads. CAUTION: Be sure the power is disconnected before doing any work
whatsoever on the unit.
2) Remove or separate piping and/or mufflers and filters from the unit.
3) Remove the cover bolts and then the cover. NOTE: Some units are equipped with seals. It is
mandatory that these seals be replaced once the unit has been opened.
4) Remove the impeller bolt and washers and then remove the impeller. NOTE: Never pry on the
edges of the impeller. Use a puller as necessary.
5) Carefully note the number and location of the shims. Remove and set them aside. NOTE: If the
disassembly was for inspection and cleaning the unit may now be reassembled by reversing the
above steps. If motor servicing or replacement and/or impeller replacement is required the same
shims may not be used. It will be necessary to re-shim the impeller according to the procedure
explained under assembly.

4 Revised – June 2016
6) Remove the housing bolts and remove the motor assembly (arbor/.housing on remote drive
models).
7) Arbor disassembly (Applicable on remote drive models only):
a) Slide the bearing retraining sleeve off the shaft at the blower end.
b) Remove the four (4) screws and the bearing retaining plate from the blower end.
c) Lift the shaft assembly far enough out of the arbor to allow removal of the blower end snap
ring.
d) Remove the shaft assembly from the arbor.
e) If necessary, remove the shaft dust seal from the pulley end of the arbor.
Muffler Material Replacement:
1) Remove the manifold cover bolts and them manifold cover.
2) The muffler material can now be removed and replaced if necessary. On blowers with fiberglass
acoustical wrap the tubular retaining screens with the fiberglass matting before sliding the muffler
pads over the screens.
3) Reassemble by reversing the procedure.
NOTE: On DR068 models with tubular mufflers it is necessary to remove the cover and
impeller accessing the muffler material from the housing cavity.
Blower Reassembly:
1) Place the assembled motor (assembled arbor assembly for remote drive models) against the rear
of the housing and fasten with the bolts and washer.
2) To ensure the impeller is centered within the housing cavity re-shim the impeller according to the
procedure outlined below.
3) If blower had a seal replace the seal with a new one.
4) Place the impeller onto the shaft making sure the shaft key is in place and fasten with the bolt,
washer and spacer as applicable. Torque the impeller bolt per the table below. Once fastened
carefully rotate the impeller to be sure it turns freely.
5) Replace the cover and fasten with bolts.
6) Reconnect the power leads to the motor per the motor nameplate.
Bolt Size Torque
Pound-Force-Foot
1/4-20 6.25 +/- 0.25
5/16-18 11.5 +/- 0.25
3/8-16 20.0 +/- 0.5
½-13 49.0 +/- 1
5/8 –11 90.0 +/- 2

5 Revised – June 2016
Impeller Shimming Procedure:
WARNING: This unit may be difficult to shim. Extreme care may be exercised.
Tools Needed: Machinist’s Parallel Bar
Vernier Caliper with depth measuring capability
Feeler gauges or depth gauge
Measure the Following:
Distance from the flange face to the housing (A)
Distance from the flange face to the motor shaft shoulder (B)
Impeller Thickness (C)
Measurements (A) and (B) are made by laying the parallel bar across the housing flange face and
measuring to the proper points. Each measurement should be made at three points, and the average
of the readings should be used.
Shim Thickness = B – (A+C)/2
After the impeller installation (step #4 above) the impeller/cover clearance can be checked with feeler
gauges, laying the parallel bar across the housing flange face. This clearance should nominally be
(A-C)/2.
C
B
A

ASSEMBLY DRAWING DR454 DR505 DR513 DR555 DR606 DR656 REMOTE DRIVE BLOWERS

Remote Drive 454/505/513/555/606/656 Service and Parts Manual
DR454RD DR454RDNT DR505RD DR513RD DR555RD DR606RDM
038201 080489
038204
038197 038198
038541
OBSOLETE
038076
OBSOLETE
Current models ------> 036437 038076 038542
Item
No.
Qty.
Req'd
1 4 120162 120162 120162 120162 120162 120065 2 6 155496 155496 155170 (10 pcs) 120214 155496 155496 3 2 510354 510354 510354 510354 510354 See Next Page 4 1 516410 516410 517460 529868 517460 516392 5 Not Used Not Used Not Used Not Used Not Used Not Used 6 4 515743 Not Used Not Used Not Used 515743 See Next Page
1 510362 Not Used Not Used Not Used 510362 See Next Page 1 510362 Not Used Not Used Not Used 510362 See Next Page
7 Not Used Not Used Not Used Not Used Not Used 529781 8 Not Used Not Used Not Used Not Used Not Used 529782
8A Not Used Not Used Not Used Not Used Not Used 529782
10 1 515675 551067 517433 See Next Page 516678 511272 11 1 551332 551410 See Next Page See Next Page 529210 See Next Page 12 1 515702 551065 517431 516559 516675 511274 13 6 155236 155129 155236 (8 pcs) 120255 (7 pcs) 155236 155236
14 * 510356 510356 510356 510356 510356 510356
* 510357 510357 510357 510357 510357 510357 * 510358 510358 510358 510358 510358 510358 * 510359 510359 510359 510359 510359 510359 * Not Used Not Used Not Used Not Used Not Used Not Used
15 1 510629 510629 510629 510629 510629 510629 16 1 510355 510355 510355 510355 510355 510355
17 1120203 120203 120203 120203 120203 120203
18 1 120214 120214 120214 120325 120262 See Next Page
Not Used Not Used Not Used Not Used Not Used Not Used
19 1 511446 511446 511446 511446 511446 511446
1 511440 511440 511440 511440 511440 511440
20 4 251791 251791 251791 251791 251791 251791 21 4 251787 251787 251787 251787 251787 251787 22 1 511442 511442 511442 511442 511442 511442 23 1 529191 529191 529191 529191 529191 529191 24 1 510217 510217 510217 510217 510217 510217 25 1 511444 511444 511444 511444 511444 511444 26 2 140004 140004 140004 140004 140004 140004 27 1 120247 120247 120247 120247 120247 120247 28 Not Used Not Used Not Used Not Used Not Used Not Used 29 1 511434 511434 511434 511434 511434 511434
Washer, Wave Spring Washer Arbor Bearing Outboard Bearing, Impeller End Shaft Ring Retainer Retainer Seal Screw, Hsg/Arbor Lockwasher, Hsg/Arbor Plate, Bearing Retainer Lockwasher Impeller Bolt, Impeller Spacer, Shaft/Impeller Seal, Shaft/Arbor Shim .020" Shim .030" Key, Shaft Inboard Washer Flat Impeller Screw, Cover Shim .002" Shim .005" Shim .010" Screw, Muffler Hsg/Hsg Impeller Housing Cover Screen, Muffler Retaining, Right (**) Screen, Muffler Retaining, Left (**) Eyebolt Screw, Muffler Hsg/Hsg Flange Manifold Screen Guard Muffler Material
Parts Breakdown
Description Screw, Flange Screw, Manifold
Model:
Part No.:
*As needed **Viewed looking at inlet/outlet ports 5/31/16 Rev. J

Remote Drive 454/505/513/555/606/656 Service and Parts Manual
DR454RD DR454RDNT DR505RD DR513RD DR555RD DR606RDM
038201 080489
038204
038197 038198
038541
OBSOLETE
038076
OBSOLETE
Current models ------> 036437 038076 038542
Item
No.
Qty.
Req'd
Parts Breakdown
Description
Model:
Part No.:
30 4 251207 251207 251207 251207 251207 251207 31 4 140009 140009 140009 140009 140009 140009
32 Not Used Not Used Not Used Not Used Not Used
Not Used
33 1
511443 511443 511443 511443 511443 511443
34
Not Used Not Used Not Used Not Used Not Used Not Used
35
Not Used Not Used Not Used Not Used Not Used Not Used
36
Not Used Not Used Not Used Not Used Not Used Not Used
38 1
511441 511441 511441 511441 511441 511441
Item
No.
11 11
10 11 10 11
3 6 6
11 18
3 5 6
11 18
DR656RDNT 80610
Quantity
1 1
1 1 1 1
DR513RDNT 038076 516557
551281
DR513RD 038197 516557
529209
DR505RDNT 036437 517466 DR505RD 038204 551333 DR454RDNT 080489 DR454RDM 038201
Item Part No.
Pipe Plug Heat Slinger Assembly Sleeve, Bearing Retainer
Special Parts Model Model Part No.
Lockwasher, Plate
Lip Seal, Shaft/Hsg
Key, Shaft Outboard Lube Fitting Screw, Plate
DR606RDM 038541 551280
529781
529872
529808 120325
2 4 2 1 1
DR606RDNT 038542 511480
511479
Not Used
529809 155101
1 each
1 0 1 1
*As needed **Viewed looking at inlet/outlet ports 5/31/16 Rev. J

DR656RDNT
080610 120255
(7 pcs) 155496
478341 551427 511479
Not Used Not Used Not Used Not Used Not Used Not Used
550305 551425 550249
(8 pcs) 155236
510356 510357 510358 510359
Not Used
510629 510355
120203 155101
Not Used
511446 511440 251791
Not Used
511442 529191 510217 511444 140004 120247
Not Used
511434
*As needed **Viewed looking at inlet/outlet ports 5/31/16 Rev. J

DR656RDNT
080610
251207 140009
Not Used
511443
Not Used Not Used Not Used
511441
*As needed **Viewed looking at inlet/outlet ports 5/31/16 Rev. J
