Ametrix ADY071478 User manual

1. To aim fixture, loosen both #10-32 x5/8" end scre s. When
both indicators are lined up, the slope of the lens face is 40-
degrees. Each subsequent notch is an additional +/- 10-
degrees
2. When fixture head is rotated to desired angle, retighten end
scre s to secure the position.
#10-32 x5/8"
End scre
Fixture head
indicator
Yoke arm
indicator
Warning: Before starting any ork ensure
that all sources of po er are turned off. All
ork must meet local/national codes and be
performed by a certified electrician. Do not
mount fixtures vertically.
Installation Instructions
Vault C-Scroll Roundel
These installation instructions are valid ith the above Ametrix styles.
1
3
2
Sheet 1 of 2
Small, INDOOR
CR
(Cantilever, Remote ballast)
Visor and Non-Visor
ADY071478 REV B (ECN80481)
E ploded View and part call-out
#8-32 x3/8"
Set scre
(2x)
Mounting
plate
Wiring the fi ture
#10-32 x5/8"
End scre
(2x)
Fixture head
Attention:
All cantilever fixture assemblies require additional
bracing/structure around J-box to support fixture.
J-box
(by others)
Fasteners
(by others)
(4x)
#8-32 x3/8"
Set scre
(2x)
Securing the fi ture to structure
1. Secure fixture head to pendant yoke using both #10-32 x5/8"
end scre s.
2. Feed fixture ire through pendant tube.
3. Remove both #8-32 x3/8" set scre s and slide canopy do n
pendant.
4. Run ires from pendant and j-box through iring holes in
mounting plate.
5. Use appropriate fasteners, secure mounting plate to structure
around J-box. Use additional bracing around J-bo to
support fi ture.
Aiming the fi ture
Use additional bracing around
J-bo to support fi ture
Fixture
ire
Wiring holes
1. After securing fixture to structure, attach appropriate ires
and ensure connections are properly matched.
2. Push ire connections into J-box and cover mounting plate
ith canopy.
3. Secure canopy ith both #8-32-3/8" set scre s.
#8-32-3/8"
Set scre s
(2x)

Use only GE and Sylvania
CFL lamps
Installation Instructions
Vault / visor C-Scroll / visor Roundel / visor
These installation instructions are valid ith the above Ametrix styles
Mounting Plate Dimensions In [mm]
Lamping Size Chart
(lamps provided by others)
Warning: Before starting any ork ensure
that all sources of po er are turned off. All
ork must meet local/national codes and be
performed by a certified electrician. Do not
mount fixtures vertically.
Small, INDOOR
CR
(Cantilever, Remote ballast)
Visor and Non-Visor
Sheet 2 of 2
ADY071478 REV B (ECN80481)
Side View Top View
5"
127
5"
127
4"
101.60
4"
101.60
1"
25.40
1"
25.40
1
4" (4x)
6.35
1
2"
12.70
1
2"
12.70
7
16 "
11.42 on order
Length dependant
FIXTURE SIZE
(inches/ mm) WATTAGE # OF LAMPS LAMP TYPE LAMP DESCRIPTION
10 3/4 / 273.05 39 W 1 T6 Ceramic Metal Halide
12 3/4 / 323.85 70 W 1 T6 Ceramic Metal Halide
12 3/4 / 323.85 150 W 1 T6 Ceramic Metal Halide
12
3/4
/ 323.85 26 W 1 4-Pin Triple
Tube Compact Fluorescent
12
3/4
/ 323.85 32 W 1 4-Pin Triple
Tube Compact Fluorescent
12
3/4
/ 323.85 42 W 1 4-Pin Triple
Tube Compact Fluorescent
10 3/4 / 273.05 100 W 1 T4 Halogen (Single Ended)
12
3/4
/ 323.85 150 W 1 T4 Halogen (Single Ended)
12 3/4 / 323.85 250 W 1 T4 Halogen (Single Ended)
LAMP
(not to scale)
