ProLights EclPar IPMFC User manual

USER MANUAL
English version
EclPar IPMFC
100W IP65 RGB+WW single source LED PAR
REV.01-08/23

Thank you for choosing PROLIGHTS
Please note that every PROLIGHTS product has been designed in Italy to meet quality and performance requirements
for professionals and designed and manufactured for the use and application as shown in this document.
Any other use, if not expressly indicated, could compromise the good condition/operation of the product and/or be
a source of danger.
This product is meant for professional use. Therefore, commercial use of this equipment is subject to the respectively
applicable national accident prevention rules and regulations.
Features, specications and appearance are subject to change without notice. Music & Lights S.r.l. and all afliated
companies disclaim liability for any injury, damage, direct or indirect loss, consequential or economic loss or any other
loss occasioned by the use of, inability to use or reliance on the information contained in this document.
Product user manual can be downloaded from the website www.prolights.it , or can be inquired to the ofcial
PROLIGHTS distributors of your territory (https://www.prolights.it/sales_network.html).
Scanning the below QR Code, you will access the download area of the product page, where you can nd a broad
set of always updated technical documentation: specications, user manual, technical drawings, photometrics,
personalities, xture rmware updates.
The PROLIGHTS Logo, PROLIGHTS names and all other trademark in this document pertaining to PROLIGHTS services
or PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its afliates, and subsidiaries.
PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc -
04026 - Minturno (LT) ITALY.
Visit the download area
of the product page

PROLIGHTS - EclPar IPMFC 01
INDEX
SAFETY INFORMATION 02
1 - PACKAGING 05
PACKAGE CONTENT..................................................................................................... 05
OPTIONAL ACCESSORIES............................................................................................. 05
2 - TECHNICAL DRAWING 06
3 - INSTALLATION 07
MOUNTING.................................................................................................................... 07
4 - CONNECTION TO THE MAINS SUPPLY 08
5 - START UP 08
CONNECT AND DISCONNECT POWER FROM THE PRODUCT.................................. 08
6 - PRODUCT OVERVIEW 09
7 - DMX CONNECTION 10
CONNECTION OF THE CONTROL SIGNAL: DMX LINE .............................................. 10
INSTRUCTIONS FOR A RELIABLE DMX CONNECTION ............................................... 10
CONNECTION DAISY CHAIN........................................................................................ 10
CONNECTION OF THE DMX LINE................................................................................ 10
CONSTRUCTION OF THE DMX TERMINATION ........................................................... 11
DMX ADDRESSING ........................................................................................................ 11
OPERATION AS A WIRELESS TRANSMITTER................................................................ 11
IN TO CRMX................................................................................................................... 12
OPERATION AS A WIRELESS RECEIVER........................................................................ 12
CRMX TO DMX (RX) ....................................................................................................... 12
8 - CONTROL PANEL 13
DISPLAY AND BUTTONS LAYOUT................................................................................. 13
9 - MENU STRUCTURE 14
10 - SHORTCUT 18
11 - RDM FUNCTIONS 19
13 - DMX CHARTS 23
RDM Personality ID List .................................................................................................. 23
RDM Model ID................................................................................................................ 23
14 - ERROR MESSAGES 31
15 - ACCESSORIES INSTALLATION 32
LENS ASSEMBLY (EPIPMLENS15 - 15° lens INCLUDE; EPIPMLENS30 - 30° lens
OPTIONAL; EPIPMLENS60 - 60° lens OPTIONAL;) ..................................................... 32
EPIPMLENS15................................................................................................................. 33
EPIPMLENS30................................................................................................................. 33
EPIPMLENS60................................................................................................................. 33
BARN DOOR (CODE AJP7ZIPBD - OPTIONAL)............................................................. 34
BARN DOOR (CODE AJP7ZIPBD - OPTIONAL)............................................................. 35
FULL SNOOT (CODE EPIPMFSNOOTBK - OPTIONAL)................................................. 36
HONEYCOMB LOUVRE (CODE EPIPMHLOUVREBK - OPTIONAL)............................... 37
CONCENTRIC LOUVRE (CODE EPIPMCLOUVREBK - OPTIONAL)............................... 38
LENS ASSEMBLY FROM INSIDE..................................................................................... 39
LENS ASSEMBLY FROM INSIDE..................................................................................... 40
16 - PERIODICAL CLEANING 41
17 - TEST OF IP65 RATING 42
18 - MAINTENANCE 43
MAINTENANCE AND CLEANING THE PRODUCT........................................................ 43
REPLACING THE FUSE................................................................................................... 43
VISUAL CHECK OF PRODUCT HOUSING ..................................................................... 43
TROUBLESHOOTING..................................................................................................... 44

PROLIGHTS - EclPar IPMFC02
SAFETY INFORMATION
WARNING!
• See https://www.prolights.it/product/ECLPARIPMFC#download for installation in-
structions.
• Please read carefully the instruction reported in this section before installing, powering,
operating or servicing the product and observe the indications also for its future handling.
This unit is not for household and residential use, only professional applications.
Connection to mains supply
• The Connection to the mains supply must be carried out by a qualied electrical
installer.
• Use only AC supplies 100-240V 50-60 Hz, the xture must be electrically connected
to ground (earth).
• Select the cable cross section in according with the maximum current draw of the
product and the possible number of products connected at the same power line.
• The AC mains power distribution circuit must be equipped with magnetic+residual
current circuit breaker protection.
• Do not connect it to a dimmer system; doing so may damage the product.
Protection and Warning against electrical shock
• Do not remove any cover from the product, always disconnect the product from AC
power before servicing.
• Ensure that the xture is electrically connected to ground (earth). And use only a
source of AC power that complies with local building and electrical codes and has
both overload and ground-fault (earth-fault) protection.
• Before using the xture, check that all power distribution equipment and cables are
in perfect condition and rated for the current requirements of all connected devices.
• Isolate the xture from power immediately if the power plug or any seal, cover, ca-
ble, or other components are damaged, defective, deformed or showing signs of
overheating.
• Do not reapply power until repairs have been completed.
• Refer any service operation not described in this manual to PROLIGHTS Service team
or an authorized PROLIGHTS service center.
Installation
• Make sure that all visible parts of the product are in good visible condition before its
use or installation.
• Make sure the point of anchorage is stable before positioning the projector.
• When suspending the xture above ground level, secure it against failure of primary
attachments by attaching a safety cable that is approved as a safety attachment for
the weight of the xture to the attachment point on the main frame of the product. ln
case the safety cable, enter in action, it needs to be replaced with a new one.
• Install the product only in well ventilated places.
• For non temporary installations, ensure that the xture is securely fastened to a load-
bearing surface with suitable corrosionresistant hardware.
• For a temporary installation with clamps, ensure that the quarter-turn fastener and/or
screws are turned fully, and secured with a suitable safety cable.
1,4 m Minimum distance of illuminated objects
• The projector needs to be positioned so that the objects hit by the beam of light are
at least 1,4 meters (4,7 ft) from the lens of the projector.

PROLIGHTS - EclPar IPMFC 03
T 45°C
a
Max operating ambient temperature (Ta)
• Do not operate the xture if the ambient temperature (Ta) exceeds 45 °C (113 °F).
T -20°C
a
Minimum operating ambient temperature (Ta)
• Do not operate the xture if the ambient temperature (Ta) is below -20 °C (-4 °F).
Protection from burns and re
• The exterior of the xture becomes hot during use. Avoid contact by persons and
materials.
• Ensure that there is free and unobstructed airow around the xture.
• Keep ammable materials well away from the xture.
• Do not expose the front glass to sunlight or any other strong light source from any an-
gle. Lenses can focus the sun’s rays inside the xture, creating a potential re hazard.
• Do not attempt to bypass thermostatic switches or fuses.
IP65
Outdoor (temporary) use
• This product is rated with an IP (Ingress protection) for temporary outdoor use when
used and serviced according to the instruction contained in this document.
• Never use the xture in places subject to vibrations or bumps.
• Make certain that no inammable liquids, water or metal objects enter the xture.
• Excessive dust, smoke uid, and particle build up degrades performance, causes
overheating and will damage the xture.
• Damages caused by inadequate cleaning or maintenance are not covered by the
product warranty.
T 75°C
c
Temperature of the external surface
• The surface of the xture can reach up to 75 °C (167 °F) during operation. Avoid
contact with people and materials.
Maintenance
• Warning! Disconnect the xture from AC mains power and allow to cool for at least
10 minutes before handling.
• Only technicians who are authorized by PROLIGHTS or Authorised service partners
are permitted to open the xture.
• Users may carry out external cleaning, following the warnings and instructions pro-
vided, but any service operation not described in this manual must be referred to a
qualied service technician.
• Important! Excessive dust, smoke uid, and particle build up degrades performance,
causes overheating and will damage the xture. Damages caused by inadequate
cleaning or maintenance is not covered by the product warranty.
Photobiological safety
• This device emits potentially dangerous optical radiation and is identied in the cat-
egory of Risk Group 2 according to EN 62471.
Do not stare at the operating light source
• Do not look directly at the LED source during operation. It can be harmful to the eyes
and skin.
• During Installation, operation and maintenance, be prepared for the xture to light
and move suddenly when connected to power.
• The device should be positioned so that prolonged staring into the luminaire at adis-
tance closer than 4 m (13,12 ft) is not expected.

PROLIGHTS - EclPar IPMFC04
Minimun
distance
Risk
Group 2
Risk
Group 1
0.2 m
0.7 ft
10.5 m
34.45 ft
Minimun
distance
Risk
Group 2
Risk
Group 1
0.2 m
0.7 ft
10.5 m
34.45 ft
Minimun
distance
Risk
Group 2
Risk
Group 1
0.2 m
0.7 ft
4,0 m
13,12 ft
Disposal
• This product is supplied in compliance with European Directive 2012/19/EU – Waste
Electrical and Electronic Equipment (WEEE). To preserve the environment please dis-
pose/ recycle this product at the end of its life according to the local regulation.
The products to which this manual refers comply with:
• 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD).
• 2014/30/EU - Electromagnetic Compatibility (EMC).
• 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS).
The products to which this manual refers comply with:
• UL 1573 + CSA C22.2 No. 166 - Stage and Studio Luminaires and Connector Strips.
• UL 1012 + CSA C22.2 No. 107.1 - Standard for power units other than class 2.
FCC Compliance:
• This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesired operation.
Other approvals

PROLIGHTS - EclPar IPMFC 05
1 - PACKAGING
PACKAGE CONTENT
• 1 x ECLPARIPMFC
• 1 x EPIPMLENS15
• 1 x ECLPARTPG
• 1 x 1,5 meters power cable (BARE END - SEETRONIC IP65 power connector)
• 1 x User Manual
OPTIONAL ACCESSORIES
• LECLPARIPM: Flight-case per contenere 6 pc serie ECLPARIPM
• EPIPMBAG1U: ABS case vuoto per contenere 1 pc serie ECLPARIPM
• ECLPARIPMBDBK: 8 alette direzionali per la regolazione del fascio di luce, ECLPARIPM, nero
• ECLPARTPG: Telaio porta gelatina per proiettori ECLPAR
• EPIPMRFFBK: Telaio porta gelatina circolare per ECLPARIPM series, nero
• ECLPARIPMWKBK: CRMX Timo Fx kit per serie ECLPARIPM, nero
• EPIPMLENS15: Lente a 15° per serie ECLPARIPM
• EPIPMLENS30: Lente a 30° per serie ECLPARIPM
• EPIPMLENS60: Lente a 60° per serie ECLPARIPM
• EPIPMFILT1040: Diffusore di luce per ECLPARIPM, asimmetrico 10°x40°
• EPIPMFILT1060: Diffusore di luce per ECLPARIPM, asimmetrico 10°x60°
• EPIPMFILT1090: Diffusore di luce per ECLPARIPM, asimmetrico 10°x90°
• EPIPMFILT3060: Diffusore di luce per ECLPARIPM, asimmetrico 30°x60°
• EPIPMFSNOOTBK: Visiera completa per serie ECLPARIPM, nero
• EPIPMHLOUVREBK: Filtro anti abbagliamento a nido d'ape per serie ECLPARIPM, nero
• EPIPMCLOUVREBK: Filtro anti abbagliamento concentrico per serie ECLPARIPM, nero
• SPGM10: Spigot 28mm per xtures, perno M10
• SPGM12: Spigot 28mm per xtures, perno M12
• UPBOX1UP5: Interfaccia aggiornamento rmware, USB IN, 5p XLR DMX OUT, USB OUT
• UPBOXPRO: Interfaccia aggiornamento rmware, USB IN, connettore XLR DMX OUT 5-pin
• TOUR53415L03: Cavo Dmx assembl. HC5340, CANC5MXX XLR 5p -> CANC5FXX XLR (f) 5p, L.3m
• TOUR53413L03: Cavo Dmx assembl. HC5340 CANC3MXX XLR 3p -> CANC3FXX XLR (f) 3p, L.3m
• 958025L03: Cavo TH07 3x2.5mm, PwCon FCA 3p 20A, PwCon FCB 3p 20A, L. 3m
• 9513FCAL03: Cavo Ass. TH07 3x2.5mm, spina CEE 3p 16A 230V, presa MENAC3FCA, L.3 m
• RSR0630B: Cavo di sicurezza acciaio per corpi sospesi, moschettone inox, L=60 cm, nero
• C6002B: Clamp in alluminio Slim, port.200Kg, tubi 48-51mm, perno M10, Black
• 9533FCAL03: Cavo Ass. TH07 3x2.5mm, spina SCHUKO, presa MENAC3FCA, L.3 m
• SPGM12: Spigot 28mm per xtures, perno M12
• UPBOX1UP5: Interfaccia aggiornamento rmware, USB IN, 5p XLR DMX OUT, USB OUT
• UPBOXPRO: Interfaccia aggiornamento rmware, USB IN, connettore XLR DMX OUT 5-pin
• TOUR53415L03: Cavo Dmx assembl. HC5340, CANC5MXX XLR 5p -> CANC5FXX XLR (f) 5p, L.3m
• TOUR53413L03: Cavo Dmx assembl. HC5340 CANC3MXX XLR 3p -> CANC3FXX XLR (f) 3p, L.3m
• 958025L03: Cavo TH07 3x2.5mm, PwCon FCA 3p 20A, PwCon FCB 3p 20A, L. 3m
• 9513FCAL03: Cavo Ass. TH07 3x2.5mm, spina CEE 3p 16A 230V, presa MENAC3FCA, L.3 m
• RSR0630B: Cavo di sicurezza acciaio per corpi sospesi, moschettone inox, L=60 cm, nero
• C6002B: Clamp in alluminio Slim, port.200Kg, tubi 48-51mm, perno M10, Black
• 9533FCAL03: Cavo Ass. TH07 3x2.5mm, spina SCHUKO, presa MENAC3FCA, L.3 m

PROLIGHTS - EclPar IPMFC06
119 mm
4,68 in
13 mm
0,51 in
263 mm
[10.3 in]
327 mm
[12.9 in]
Ø169 mm
[6.7 in]
213 mm
[8.4 in]
Ø457 mm
[18.0 in]
Fig. 01
Weight: 4,1Kg - 9,04 lbs
2 - TECHNICAL DRAWING

PROLIGHTS - EclPar IPMFC 07
Fig.02
3 - INSTALLATION
MOUNTING
Check that the supporting structure can safely bear the weight of all installed xtures, clamps, cables,
auxiliary equipment, etc. and complies with locally applicable regulations.
When suspending the xture above ground level, secure it against failure of primary attachments by
attaching a safety wire that is approved as a safety attachment for the weight of the xture to an anchor
point on the product main frame.
Do not use removable parts or weak anchors for secondary attachment.
Warning! When clamping the xture to a truss or other structure at any angle, use clamps of half-cou-
pler type. Do not use any type of clamp that does not completely encircle the structure when fastened.
RSR0670A/B
Steel security cable C6002 A/B clamp

PROLIGHTS - EclPar IPMFC08
5 - START UP
CONNECT AND DISCONNECT POWER FROM THE PRODUCT
To apply and disconnect power to the product:
• Check that the product is installed and secured as indicated in the Safety Informations, and that
personal safety will not be put at risk when the xture lights up.
• Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz).
• The product is then ready for its operations and can be controlled through the available input sig-
nals on board.
• To disconnect power from the product, disconnect the Mains from the socket.
4 - CONNECTION TO THE MAINS SUPPLY
WARNING: For protection from electric shock, the xture must be earthed!
The product is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz
AC power source from 100-240 Volts.
If you need to install a power plug on the power cable to allow connection to power outlets, install a
grounding-type (earthed) plug, following the plug manufacturer’s instructions. If you have any doubts
about proper installation, consult a qualied electrician.
The max power consumption is 112 W.
Core (EU) Core (US) Connection Plug terminal marking
Brown Black Live L
Blue White Neutral N
Yellow+green Green Earth

PROLIGHTS - EclPar IPMFC 09
9
7
4
4
5
6
10
1
2
3
8
9
1
3
11
2
6 - PRODUCT OVERVIEW
1. BRACKET for hanging safe.
2. BRACKET for oor positioning.
3. HOLDER CLIP for lter frame and barndoor accessory.
4. SAFETY EYE to attach safety cable.
5. USER INTERFACE with display and buttons for access to the control panel functions.
6. POWER IN: for connection to the Mains 100-240V~/50-60Hz.
7. DMX IN (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C.
8. DMX OUT (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C.
9. KNOB for bracket.
10.POWER OUT: power output for connection of multiple units in series.
11.ACCESSORY HOLDER for lter frame and barndoor accessory.
Fig 03

PROLIGHTS - EclPar IPMFC10
7 - DMX CONNECTION
CONNECTION OF THE CONTROL SIGNAL: DMX LINE
The product has XLR sockets for DMX input and output.
The default pin-out on both socket is as the following diagram:
Fig. 04
Pin1 : GND - Shield
Pin2 : - Signal
Pin3 : + Signal
Pin4 : N/C
Pin5 : N/C
DMX - OUTPUT
XLR socket
DMX - INPUT
XLR plug
INSTRUCTIONS FOR A RELIABLE DMX CONNECTION
Use shielded twisted-pair cable designed for RS-485 devices: standard microphone cable cannot trans-
mit control data reliably over long runs. 24 AWG cable is suitable for runs up to 300 meters (1000 ft).
Heavier gauge cable and/or an amplier is recommended for longer runs.
To split the data link into branches, use splitter-ampliers in the connection line.
Do not overload the link. Up to 32 devices may be connected on a serial link.
CONNECTION DAISY CHAIN
Connect the DMX data output from the DMX source to the product DMX input (male connector XLR)
socket.
Run the data link from the product XLR output (female connector XLR) socket to the DMX input of the
next xture.
Terminate the data link by connecting a 120 Ohm signal termination. If a splitter is used, terminate
each branch of the link.
Install a DMX termination plug on the last xture on the link.
CONNECTION OF THE DMX LINE
DMX connection employs standard XLR connectors. Use shielded pair-twisted cables with 120Ω im-
pedance and low capacity.
The following diagram shows the connection mode:
Fig. 05 - Example 20 DMX channels conguration
. . . . . . . . . . . .
DMX Address: 1 DMX Address: 60DMX Address: 20 DMX Address: 40
. . . . . . . . . . . .
DMX512 Controller
DMX IN DMX IN DMX IN DMX INDMX OUT DMX OUT DMX OUT DMX OUT

PROLIGHTS - EclPar IPMFC 11
DMX ADDRESSING
In order to start controlling the product via DMX, the rst step is to select a DMX address, also known
as the start channel, this is the rst channel used to receive instructions from a DMX controller. If you
wish to control the product individually, it is necessary to assign a different starting address channel to
each xture.
The number of channels occupied from the product depends on the DMX mode selected, so always
verify the DMX Mode in the MENU before start addressing.
If you assign two xtures the same address, they will be executing the same behaviour. Selecting the
same address to multiple xtures can be useful for diagnostic purposes and symmetrical control.
DMX addressing is limited to make it impossible to set the DMX address so high that you are left with-
out enough control channels for the product.
To set the xture’s DMX address:
1. Press ENTER to open the main menu.
2. Reach the addressing menu, then select the DMX ADDRESS settings.
3. Select the address from 1 to 512 using the navigation arrows/buttons and conrm by pressing
ENTER.
4. Press Menu to exit and return to the Home screen.
OPERATION AS A WIRELESS TRANSMITTER
ECLPARIPMFC can be used as wireless transmitter to transmit DMX signal to different wireless receiv-
ers. To use ECLPARIPMFC as wireless transmitter, please follow the procedure below:
1. Push ENTER button untill you show CONNECT on display, then press ENTER button to conrm.
2. Use UP/DOWN buttons for select WIRELESS, then press ENTER to conrm.
3. Push ENTER button on CRMX ON/OFF function and enable it to ON.
4. Select CRMX mode and set it on Transmitter (please note that CRMX mode will be available only if
CRMX ON/OFF is set to ON).
5. Ensure that the receiver units are not connected to any other transmitter. Please refer to "Reset the
receiver" paragraph.
6. Enable TX LINK to ON to link transmitter to receivers (please note that TX LINK will be available only
if CRMX mode is set to Transmitter).
• The transmitter scans for all unlinked receivers for a period of about 5 seconds.
• If the connection fails, check the position of the receiver.
• The wireless icon on the receiver display indicates the received signal strength.
CONSTRUCTION OF THE DMX TERMINATION
The termination is prepared by soldering a 120Ω 1/4 W resistor between pins 2 and 3 of the male XLR
connector, as shown in gure.
Fig. 06
Example:
5 pin XLR connector
4

PROLIGHTS - EclPar IPMFC12
Unlinking the transmitter
Follow the procedure below to unlink the transmitter from all receivers connected with the unit.
1. Push ENTER button untill you show CONNECT on display, then press ENTER button to conrm.
2. Use UP/DOWN buttons for select Wireless, then press ENTER to conrm.
3. Enable TX UNLINK to ON 8 (please note that TX UNLINK will be available only if CRMX mode is
set to Transmitter).
• All connected receivers will be unlinked.
IN TO CRMX
This function enable or disable the transmission throught wireless of the DMX signal from the transmit-
ter side to the receiver.
Any incoming signal (ArtNet, sACN or DMX) is retransmitted throught wireless.
It's possible to choose retransmission of Main Fixture or Pixel Engine.
If the ECLPARIPMFC protocol selected is ArtNet / sACN, the CRMX module will retransmit the DMX
values contained in the ArtNet / sACN signal received from the ECLPARIPMFC.
NOTE: Artnet and sACN have higher priority on DMX if they are connected to transmitter.
NOTE: Do not use IN TO CRMX and ETH TO DMX simultaneously, this will cause data conict on DMX
output signal.
OPERATION AS A WIRELESS RECEIVER
ECLPARIPMFC can be used as wireless receiver connected to a wireless transmitter.
To use ECLPARIPMFC as wireless receiver, please follow the procedure below:
1. Push ENTER button untill you show CONNECT on display, then press ENTER button to conrm.
2. Use UP/DOWN buttons for select Wireless, then press ENTER to conrm.
3. Push ENTER button on CRMX ON/OFF function and enable it to ON.
4. Select CRMX mode and set it on Receiver (please note that CRMX mode will be available only if
CRMX ON/OFF is set to ON).
5. Enable RX RESET to ON to reset the receiver (please note that RX RESET will be available only if
CRMX mode is set to Receiver).
6. On the transmitter, enable TX LINK to ON to link transmitter to the receivers.
7. If the connection is successful and DMX input is available the display the display on the receiver unit
will shows the DMX address. If DMX signal is not available, the display will shows "No signal" but
keeps the transmitter linked.
8. If the connection fails, check the position of the receiver.
9. The wireless icon on the receiver display indicates the received signal strength.
Reset the receiver
Follow the procedure below to reset the receiver.
1. Push MENU button untill you show CONNECT on display, then press ENTER button to conrm.
2. Use UP/DOWN buttons for select Wireless, then press ENTER to conrm.
3. Enable RX RESET to ON.
• The wireless icon on the receiver display indicates the received signal strength.
CRMX TO DMX (RX)
This function enable or disable the retransmission of the wireless DMX signal received throught the
DMX port on the receiver side.

PROLIGHTS - EclPar IPMFC 13
Fig. 07
8 - CONTROL PANEL
The product has a display and buttons for access to the control panel functions.
DISPLAY AND BUTTONS LAYOUT
The product has a display and buttons for access to the control panel functions:
1 • MODE / ESC: used to access the menu tree or to return a previous menu window.
2• ENTER: used to conrm the current menu or conrm the current function value
or option within a menu.
3• UP: browse upwards through the menu list and increases the numeric value dis-
played.
4• DOWN: browse downwards through the menu list and decreases the numeric
value displayed.

9 - MENU STRUCTURE
The following chart describes the MENU tree of the product, the terms shown in BOLD indicates the
default settings.
CONNECT ADDRESS VALUE
(1-512)
Set address used for Fixture.
DMX MODE UNO COLOR
TEMPERATURE /
COLOR MACRO /
MANUAL COLORS
Set DMX chart for Main Fixture.
For Uno and Duo mode selection of
CCT, Color Macro or Manual color
is available.
DUO
BASIC
BASIC 16BIT
STANDARD
EXTENDED
WIRELESS CRMX
ON/OFF
ON/OFF Enable/Disable the wireless card.
CRMX MODE TX CRMX Choose whether to set the wireless
card as Transmitter
or Receiver.
For Transmitter mode you can also
select which protocol to transmit.
CRMX mode is unlocked only if
CRMX ON / OFF is ON
TX G4S
TX G3
RECEIVER
TX LINK ON/OFF TX link unlock when the unit is set as
a transmitter.
TX UNLINK ON/OFF Disconnect the transmitter from all
receivers.
TX unlink unlocks only if CRMX mode
is on transmitter.
RX RESET ON/OFF Disconnect the transmitter from all
receivers.
TX unlink unlocks only if CRMX mode
is on transmitter
IN TO CRMX
(TX)
ON/OFF Enable/Disable the transmission of
the DMX from the transmitter to the
receiver via CRMX.
CRMX TO
DMX (RX)
ON/OFF Enable/Disable the retransmission
of the DMX from the receiver to the
other units connected by cable to the
receiver itself.
LINKING KEY When In RX Mode:
1. Insert 8 digit code
2. Ask for mode
(CRMX or CRMX²)
3. Ask for
universe (CRMX:
A,C,E,G | CRMX²:
A,B,C,D,E,F,G,H)
When in TX CRMX
Mode:
1. Insert 8 digit code
Linking key can be used as a simple
way to link receivers to a transmitter
without the need to initiate the
linking process on the transmitter.
This allows the user to just enter the
code into the receiver and it will be
linked to the transmitter with the
same code.
UNIVERSE
METADATA
In RX Mode:
1. RGB Color code
received from TX
2. Universe name
received from TX
In TX CRMX Mode:
1.RGB Color code
set from R,G,B
combo list
2. Universe name by
default takes rst 16
characters of Model
Name
CRMX transmitters may transmit
some universe metadata information
used to identify the received universe
on the receiver side. These are;
Universe name: A 16 character
string with a human readable name
identifying the universe.
Universe color: RGB code for an LED
that can easily be used to visually
identify the universe by color.
PROLIGHTS - EclPar IPMFC14

SET UP SCREEN BACKLIGHT ON/10S/20S/30S Allows you to select the timing after
that display will switch automatically
off when unactive.
FLIP DISPLAY ON/OFF Allows you to rotate the display by
180°.
KEY LOCK ON/OFF Allows you lock the buttons on the
control panel by a password. Press
following combinations (password) in
order to access to the user menu : UP,
DOWN, UP, DOWN.
TEMPERA-
TURE UNIT
°C/°F Choose Temperature unit.
TRANSFER
CONFIGURA-
TION
WITHOUT
DMX AD-
DRESS
To transfer the same menu settings
of one xtures to all the other in the
daisy chain, including or not the dmx
address.
WITH DMX
ADDRESS
ADVANCED DIMMER
CURVE
LINEAR Set Dimmer Curve for Main Dimmer
function.
S-CURVE
SQUARE
LAW
INVERSE
SQUARE LAW
DIMMER
SPEED
AUTO Linear dimmer behaviour.
FAST Dimmer curve adding long fade.
MEDIUM Dimmer curve adding medium fade.
SLOW Dimmer curve adding little fade.
OFF
SPEKTRA
CALIBRATION
ON ON: CCT and colors are fully cali-
brated, working in the common color
space denition set by Spektra. This
means that output of multiple xtures
will match with no visible differences.
Color Saturation is slightly reduced.
PURE
COLORS
PURE COLORS: CCT is calibrated,
giving perfect white matching across
multiple xtures, but primary and
secondary colors are calibrated to
their native color space which allows
maximum color saturation. The closer
you move towards white, the more
closely multiple xtures will match
each other's output. The further you
move away from white and the closer
you move towards saturated color,
the less closely multiple xtures will
match each other's output.
OFF
LED MODE HIGH
QUALITY
Set led operating mode.
HIGH
BRIGHTNESS
WHITE POINT 3200K Select CCT when RGBW@Full.
4000K
5600K
6000K
8000K
PROLIGHTS - EclPar IPMFC 15

DMX FAULT HOLD To choose the behaviour of xture in
case of dmx signal lost.
BLACKOUT
STANDA-
LONE
EMERGENCY
TUNGSTEN
EMULATION
ON Toggle Tungsten Emulation
OFF
OUTPUT
CONTROL
OFF Choose Output Control mode.
CONSTANT
DYNAMIC
FACTORY
RELOAD
ON/OFF Default of all parameters
INFORMA-
TION
DEVICE TIME FIXTURE
HOURS
TOTAL (READ) To check the total working hours of
the unit.
PARTIAL (READ AND
RESET)
CURRENT
HOURS
TOTAL (READ AND
RESET)
To check the current working hours
of the unit.
PARTIAL (READ AND
RESET)
SOURCE
HOURS
TOTAL (READ) To see the total operating hours of
the LED source.
PARTIAL (READ AND
RESET)
POWER ON
CYCLE
TOTAL (READ) To see the power cycles of the ma-
chine.
PARTIAL (READ AND
RESET)
MAINTENAN-
CE TIME
ELAPSED TIME (READ AND
RESET)
To choose and reset unit mainte-
nance warning hours.
ALERT PERIOD 10 – 750
POWER
CONSUMP-
TION
** W Show estimated power consumption.
TEMPERA-
TURE
NEAR
SOURCE
TEMP, DRIVER
PCB TEMP,
LED PCB
TEMP,…
To see the unit temperature.
WIRELESS
QUALITY
To see the wireless quality..
CHANNEL
VALUE
To see the dmx value of those chan-
nels.
ERROR
MESSAGE
To see any error messages
FIXTURE
MODEL
ECLPARIPMFC View informations about xture
model
DEVICE
LABEL
<RDM LA-
BEL>
View LABEL for the RDM control.
CALIBRATION MASTER Show calibration state.
SOFTWARE
VERSION
1U01
V1.1.00.0...
View informations about software
version.
CRMX MOD-
ULE VERSION
TimoFX:
Vx.x.xx
Show rmware version of TimoFX
module.
RDM UID (READ) View ID for the RDM control
STAND
ALONE
MASTER/
SLAVE
MASTER DMX Allow you to link and operating in
synk multiple units without a DMX
console. Choose a unit to perform as
the Master. Master No DMX: xture is
not broadcasting signal
MASTER NO
DMX
SLAVE
PROLIGHTS - EclPar IPMFC16

EFFECTS EFFECT 1 - 5 DIMMER <1-100> Effects modes allows creation and
editing of 5 effects maximum.
Each effect contains up to 20 colors,
a Main Dimmer and a Main Strobe.
COLOR section:
SWITCH is used to toggle On/Off the
color in the sequence.
DIMMER is used to individually DIM
the selected color.
STROBE is used to individually
STROBE the selected color.
HOLD TIME denes how long the co-
lor is hold on the output.
FADE IN/OUT TIME denes the ti-
mings of fading in/out.
The effects can be considered as
CHASE, once last color has nished
playing the sequence will start again
STROBE <1-100>
COLOR 1 SWITCH ON
OFF
DIMMER
STROBE
HOLD TIME 0 - 360s
(Step by 0.5s)
FADE IN
TIME
0 - 60s
(Step by 0.5s)
FADE OUT
TIME
0 - 60s
(Step by 0.5s)
COLOR
MACRO
Show list of
STATIC mode
List of Color Macro like per Static
Mode.
WHITE
PRESETS
Show list of
STATIC mode
List of White Presets like per Static
Mode.
MANUAL
COLORS
Show list of
STATIC mode
List of Manual Colors like per Static
Mode.
… …
COLOR 20 SWITCH ON
OFF
DIMMER
STROBE
HOLD TIME 0 - 360s
(Step by 0.5s)
FADE IN
TIME
0 - 60s
(Step by 0.5s)
FADE OUT
TIME
0 - 60s
(Step by 0.5s)
COLOR
MACRO
Show list of
STATIC mode
WHITE
PRESETS
Show list of
STATIC mode
MANUAL
COLORS
Show list of
STATIC mode
STATIC COLOR
MACRO
Check Color Macro
channel on DMX
Charts
Dimmer
<000-255>
WHITE
PRESETS
2700K Dimmer
<000-255>
G/M Point
<-025-025>
2800K
3200K
3500K
4000K
4500K
5000K
5600K
6000K
6500K
7000K
8000K
9000K
10000K
MANUAL
COLORS
RED <000-255>
GREEN <000-255>
BLUE <000-255>
WHITE <000-255>
PROLIGHTS - EclPar IPMFC 17

10 - SHORTCUT
Keys Mode Description
MENU + ENTER then
power on Clear All Clear all value of functions + factory default
UP + DOWN after
power on Flip Display Directly flip display without enter inside menu
PROLIGHTS - EclPar IPMFC18
