LIVARNO home 1105-W-UK User manual

LED ROPE LIGHT
IAN 390534_2201 CYNIIE
DE AT CH
LED-LICHTERSCHLAUCH
Bedienungs- und Sicherheitshinweise
GR CY
ΦΩΤΟΣΩΛΉΝΑΣ LED
Οδηγίες λειτουργίας και ασφαλείας
GB IE NI
LED ROPE LIGHT
Operating and safety information

GB IE NI
Before you start reading, please fold out the illustrations page and familiarise
yourself with all of the item’s functions.
GR CY
Πριν διαβάσετε, ξεδιπλώστε τη σελίδα με τις εικόνες και στη συνέχεια εξοικειωθείτε με όλες
τις λειτουργίες του άρθρου.
DE AT CH
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und
machen Sie sich anschließend mit allen Funktionen des Artikels vertraut.
GB/IE/NI Operating and safety information page 6
GR/CY Οδηγίες λειτουργίας και ασφαλείας σελίδα 12
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 19

A
B
1
1
7
2
6 5 4
3

5
Εισαγωγή ��������������������������������������������� 12
Επεξήγηση συμβόλων������������������������� 12
Προβλεπόμενη χρήση������������������������� 12
Περιεχόμενο συσκευασίας������������������ 13
Περιγραφή εξαρτημάτων ������������������� 13
Τεχνικά στοιχεία ���������������������������������� 13
Υποδείξεις ασφαλείας ������������������������� 13
Τοποθέτηση ����������������������������������������� 15
Θέση σε λειτουργία����������������������������� 16
Λειτουργία ������������������������������������������� 16
Καθαρισμός και αποθήκευση������������ 16
Αντιμετώπιση βλαβών ������������������������ 16
Απόρριψη �������������������������������������������� 17
Εγγύηση����������������������������������������������� 17
Σέρβις��������������������������������������������������� 18
DE AT CH
GB IE
Introduction������������������������������������������� 6
Explanation of symbols����������������������� 6
Intended use ����������������������������������������� 6
Included in package����������������������������� 7
Description of parts������������������������������ 7
Technical data��������������������������������������� 7
Safety information ������������������������������� 7
Mounting ����������������������������������������������� 9
First-time operation������������������������������ 9
Operation ���������������������������������������������� 9
Cleaning and storage ������������������������ 10
Troubleshooting���������������������������������� 10
Disposal����������������������������������������������� 10
Warranty��������������������������������������������� 10
Service ������������������������������������������������� 11
NI CY
Einleitung��������������������������������������������� 19
Zeichenerklärung ������������������������������� 19
Bestimmungsgemäße
Verwendung ��������������������������������������� 19
Lieferumfang��������������������������������������� 20
Teilebeschreibung������������������������������� 20
Technische Daten �������������������������������� 20
Sicherheitshinweise���������������������������� 20
Montage ���������������������������������������������� 22
Inbetriebnahme ���������������������������������� 22
Bedienung ������������������������������������������� 23
Reinigung und Lagerung ������������������� 23
Fehlerbehebung���������������������������������� 23
Entsorgung ������������������������������������������ 23
Garantie ���������������������������������������������� 24
Service ������������������������������������������������� 25
GR
CY

6GB/IE/NI/CY
LED Rope Light
zIntroduction
Congratulations on the purchase of
your new product� You have chosen
a high-quality product� Please read
these operating instructions thoroughly and
carefully� These instructions are an essential
part of the product and contain important
information on rst-time use and handling.
Always observe all safety instructions� If you
have any questions or are unsure how to
operate the product, please contact your
retailer or service centre� Please keep this
manual in a safe place and pass it on to
third parties where necessary�
zExplanation of symbols
Read the operating
instructions!
Issue date of instruction
manual (month/year)
Date of manufacture
(month/year)
Alternating current
Risk of fatal injury and
accidents for infants and
children!
Observe warning notices
and safety instructions!
Warning! Risk of electric
shock!
Danger of overheating!
Not suitable for room
lighting
Electrical devices that carry
this symbol are rated as
Protection Class II�
(Mains plug)
Protected against solid
foreign bodies with a
diameter of 12�5 mm or
more
(Product)
Protected against solid
foreign objects with a
diameter of ≥ 1.0 mm,
splash-proof
Colour temperature
(light colour)
With timer function
Network operation
Total length (excl� plug)
Dispose of packaging and
product in an
environmentally friendly
manner!
Packaging made of FSC
certied wood mix
With the CE label, the
manufacturer conrms that
this product complies with
the applicable European
directives
The LEDs are not replaceable
Separate network adapter
can be replaced by qualied
staff
zIntended use
The light is suitable for decorative use
indoors and outdoors* (*Only suitable for
outdoor use when the plug is connected to
mains power and protected from the
elements)� This product is intended for use in
private households only and it is unsuitable
for commercial use� Any type of use other
than that described above or any

7
GB/IE/NI/CY
modication of the product is prohibited and
likely to cause damage or even personal
injury� The manufacturer or retailer accepts
no liability for loss or damage that occurs as
a result of use other than intended or
incorrect use� This product uses a light source
with a Class F energy efciency rating.
zIncluded in package
1 LED rope light
20 Mounting clips
20 Cable ties
20 Screws
1 Instruction manual
zDescription of parts
1LED rope light
2Mains power cable
3Button
4Screw
5Cable tie
6Mounting clip
7Reel
zTechnical data
Model number: 1105-W-UK /
1105-K-UK
Power supply
voltage: 220-240 V ~ 50/60 Hz
Power
consumption: 22,5 W
Light source: LEDs (non-replaceable)
Ambient
temperature: -15 °C to +25 °C
Protection class: II
Protection rating: IP44 (Product)
IP20 (Mains Plug)
Total length
(excl� plug): 11,5 m
Colour
temperature: 2,700 K warm white (model: 1105-W-UK)
10,000 K cold white
(model: 1105-K-UK)
zSafety information
Safety information
WARNING!
RISK OF FATAL INJURY AND
ACCIDENTS FOR INFANTS AND
CHILDREN! Never leave children
unsupervised with the packaging material�
There is a danger of suffocation from the
packaging material� Children often
underestimate the dangers� Always keep
children away from the product�
This product may be used by children aged
8 years or above and by persons with
limited physical, sensory or mental
capabilities or lacking in experience and
knowledge if they are supervised or have
been instructed as to the safe use of the
product and understand the resulting risks�
Do not let children play with the product�
Cleaning and maintenance may not be
carried out by children without proper
supervision�
Keep children under the age of 8 away
from the product’s power cable�
Do not leave the product unattended while
in use�
Keep children away from the work area
during assembly� The product as supplied
includes a number of screws and other
small parts� These can be fatal if they are
swallowed or inhaled�
AVOID THE RISK OF FATAL
INJURY FROM ELECTRIC SHOCK!
Incorrect electrical installation or a
power supply voltage that is too high can
potentially cause electric shocks�
Always check the product for any damage

8GB/IE/NI/CY
before plugging it into the mains� Never
use the product if it has any signs of
damage�
Protect the mains from sharp edges,
mechanical stress and hot surfaces�
Never touch the uninsulated part of the
mains plug when plugging it in or out!
Never carry the product by the mains
power cable�
You should only connect the product to an
easily accessible power outlet socket so that
you can quickly disconnect it from the
power supply in the event of a fault�
Always unplug the mains plug before
assembling, dismantling or cleaning the
product�
Always plug out the product if it is not
going to be used for an extended period,
e�g� holiday, or if you want to set it up in a
different place�
Before using the product, make sure that the
mains voltage matches the supply voltage
required by the product (see “Technical
data”)�
Never tamper with or modify the product�
Do not immerse the product in water or any
other liquids�
Keep the product away from naked ames
and hot surfaces�
Never open any of the electrical
equipment, but leave the repair to
specialists� To that end you should contact
a specialist repairer�
No liability or warranty claims are
accepted in cases where repairs have been
carried out by unauthorised persons or the
product has been incorrectly wired or used�
The LEDs are not replaceable� Once the
light source reaches the end of its service
life, the product must be replaced�
Do not open or cut the LED rope light 1�
Do not mount using sharp clips or nails�
The control gear of this product may only
be replaced by the manufacturer, its
designated service technician, or a similarly
qualied person.
The power cable of this product cannot be
replaced; if it is damaged, the product must
be disposed of�
Never touch the mains plug or the LED rope
light 1(see Fig� A) if your hands are wet�
Fully unwind the cable before using the
product�
This product does not contain any parts that
can be maintained by the user�
DANGER OF OVERHEATING!
The LEDs in this product generate
heat as well as light�
Do not operate the product while
it is still inside the packaging or
rolled up�
Ensure that the product is mounted in
a way that allows sufcient heat circulation.
Do not cover the product with blankets,
cushions or similar heat-insulating
materials�
Only use the product with the parts outlined
in these user instructions�
Keep the product away from pools and
other water reservoirs� Install the product at
least 2 metres away from water containers�
Avoid locations at risk of ooding after
heavy rainfall�
Only suitable for outdoor use when the
plug is connected to mains power and
protected from the elements�
Ensure that the product is not led through
areas where lawnmowers, strimmers, shears
or similar cutting tools are used�
Do not pull the LED rope light 1�
If you have any questions regarding the
product or are unsure about anything, seek
the advice of an electronics specialist�
Do not use the rope light when covered or
recessed into a surface�
TRIPPING HAZARD! Ensure that
the power cable 2and the LED
rope light 1are positioned in such
a way that nobody can tread on or trip over
them�

9
GB/IE/NI/CY
Mounting safety
instructions
Ensure that the product is only mounted by
competent persons�
The product can be xed to any normally
ammable surface with the mounting
equipment included in the package�
RISK OF ELECTRIC SHOCK!
Decide where the product is to be
mounted prior to mounting�
Before mounting, check that the substrate is
suitable for the mounting equipment and
the weight of the product� If you are unsure
about anything, seek the advice of an
electronics specialist�
Do not use sharp and/or pointed objects
such as wire, nails or staples to mount the
product�
Do not hang any additional items on the
product�
Avoid excessive bending of the LED rope
light 1� This will damage the insulation�
The bend radius of the rope light must not
exceed 2 cm�
Avoid excessive heating of the product� No
more than two sections of rope should cross
one another or run parallel to one another�
zMounting
Please note: Take the product out of its
packaging and remove all packing material�
Check that all package contents are
present�
Check if the product or individual parts are
damaged� Should you detect damage, do
not use the product� Please contact the
retailer via the service address indicated�
Unwind the LED rope light 1from the reel
7(see Fig� B)�
Fix the LED rope light to the desired surface
using the cable ties 5provided (see Fig�
A)�
Alternatively, you can use the mounting
clips 6 included in the package to x the
product in place (see Fig� A)�
To do this, start by screwing the mounting
clips 6into a stable substrate with the
screws 4provided, using a Phillips
screwdriver (not included in package)�
Push the LED rope light into the openings of
the mounting clips 6 xed to the substrate.
If necessary, you can also x the LED rope
light to the mounting clips 6using the
cable ties 5�
zFirst-time operation
TRIPPING HAZARD! Ensure that
the power cable 2and the LED
rope light 1are positioned in such
a way that nobody can tread on or trip over
them�
Plug the mains plug into a socket that has
been correctly installed�
Only suitable for outdoor use when the
plug is connected to mains power and
protected from the elements�
zOperation
Press the button 3once to switch the
product on (see Fig� A)� Once the product
is switched on, the button will light up
green and the product will light up
permanently�
Press the button
3
again to activate the
timer function� When the timer function is
switched on, the product will remain
switched on for 6 hours and then switched
off for 18 hours� The button lights up yellow�
Press the button 3a third time to switch
the product off� Alternatively, unplug the
mains plug from the power outlet socket�

10 GB/IE/NI/CY
zCleaning and storage
RISK OF ELECTRIC SHOCK!
Always unplug the mains power
cable from the socket before
cleaning the product�
For reasons of electrical safety, the product
must never be cleaned with abrasive
cleaning agents or immersed in water�
Do not use any chemicals for cleaning�
Use only a dry, lint-free cloth for cleaning�
If the product is very dirty, dampen the
cloth slightly�
When the product is not in use, store in the
packaging in a dry place�
zTroubleshooting
= Fault
=Cause
= Solution
= The product fails to switch on�
= The product is switched off�
= Press the button 3to switch on the
product (see section “Operation”)�
= The product is not connected to the
mains�
= Connect the product to the mains
(see section “First-time operation”)�
= Individual LEDs are no longer lighting
up�
= The LEDs have reached the end of
their life cycle�
= The LEDs are not replaceable, the
entire product must be replaced�
zDisposal
Note the labels on the packaging
materials when sorting the waste;
they are marked with abbreviations
(a) and numbers (b) with the
following meanings:
1-7: Plastics
20-22: Paper and cardboard
80-98: Composite materials
You can nd out how to dispose of
the used product by contacting your
local district or city council�
In the interest of environmental
protection, when the product has
reached the end of its useful life, do
not dispose of it as general
household waste but have it
properly recycled� For information
on recycling centres and their
opening times, please contact your
local council�
You can nd an instruction manual for
disassembly of the LEDs by qualied
professionals at: www.citygate24.de
zWarranty
Dear customer, This product comes with a
3-year warranty from the date of purchase�
In the event that this product is faulty, you
have legal rights against the seller of the
product� These statutory rights are not
restricted by our warranty as set out below�
Warranty terms
The warranty period begins with the date of
purchase� Please keep the original receipt in
a safe place� It is required as proof of
purchase� If a material or manufacturing
defect occurs within three years of the date
of purchase, we will repair or replace the
product for you free of charge, or refund the
purchase price, at our discretion� This
warranty service is granted provided that the
faulty device and the proof of purchase
(receipt) are presented within three years,
along with a brief written description of the
fault and of when it occurred� If the fault is
covered by our warranty, we will return the
xed product or send you a new one. No
new warranty period shall begin upon repair
or replacement of the product�

11
GB/IE/NI/CY
Warranty period and statutory
warranty claims
The warranty period is not renewed after a
warranty service has been granted� This rule
shall also apply for any replaced or repaired
parts� Any damage or faults that already
existed when buying the product must be
reported immediately upon unpacking the
product� A fee is charged for any repairs
that are carried out after the end of the
warranty period�
Warranty scope
The device was carefully manufactured
according to the strictest quality guidelines
and thoroughly tested before delivery� The
warranty applies to material or
manufacturing defects� This warranty does
not apply to product parts that are subject to
normal wear and tear and can therefore be
regarded as wearing parts, or damage to
fragile parts, such as switches, rechargeable
batteries or parts that are made of glass�
This warranty is void if the product has been
damaged, improperly used or serviced� To
ensure proper use, all instructions included in
the manual must be followed carefully� All
uses and actions that users are discouraged
from or warned of in the manual must be
avoided under all circumstances� The product
is intended for private household use only,
and not for commercial activities�
The warranty is void, if the product is treated
inappropriately, if force is applied, and in
the case of any manipulation that is not
carried out by our authorised service branch�
Warranty processing
To ensure your request is handled swiftly,
please observe the following
Notes:
Please have the receipt and the article
number (e�g� IAN 123456) ready as proof
of purchase for all enquiries�
Please refer to the type plate on the
product, an engraving on the product, the
cover of the manual (bottom left) or the
sticker on the back or base of the product
to nd out the product number.
In the case of any malfunctions or other
defects, please call or email the service
department indicated below as a rst step.
After your product has been registered as
faulty, you can send it to the specied
service address, free of charge� Please
include the proof of purchase (receipt) and
information about the defect and about
when it occurred�
zService
GB
Service Great Britain
Tel� : 00800 80040044
E-Mail: administration@mynetsend�de
IE NI
Service Ireland
Tel� : 00800 80040044
E-Mail: administration@mynetsend�de
CY
Service Cyprus
Tel� : 00800 80040044
E-Mail: administration@mynetsend�de
IAN 390534_2201
Please have the receipt and the article
number (e�g� IAN 123456) ready as proof
of purchase for all enquiries�
You can nd an up-to-date version of the
operating instructions at: www�citygate24�de
You can download this and many other
manuals, product videos and installation
software at
www.lidl-service.com �
Scanning the QR code on the front page will
take you directly to the Lidl Service web
page (www�lidl-service�com) where you can
access the user instructions by entering the
item number (IAN) 123456_7890�
