ALARM’BOX
INDICATOR DISPLAY AND ALARMS UNIT WITH BATTERY
STARTING PROCEDURE
STANDARD UNIT
8 to 96 INPUTS MODULAR UNIT
Built with 1 to 3 stages
MANUFACTURED ON REQUEST
8 TO 32 INPUTS MODULAR UNIT,
With 2 Feedback contacts per inputs
2 stages
w
a
r
r
a
n
t
y
2
years
w
a
r
r
a
n
t
y

2
306
306
280
430 430
145
145 145
580 580
145 145
MODULAR UNIT
from 8 to 32 inputs
on 1 stage
MODULAR UNIT
from 8 to 64 inputs
on 2 stages
MODULAR UNIT
from 8 to 96 inputs
on 3 stages
MODULAR UNIT from 8 to 32 inputs
including 2 stages with
output relay cards
MODULAR UNIT from 8 to 32 inputs
including 1 stage with
output relay cards
STANDARD UNIT:
Manufactured on request
special unit
fitted up with relay cards

3
www.ami-control.com
A.M.I.
A.M.I.
A) ALARM’BOX PRESENTATION : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 4
A.1) Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 4
A.2) Composition of the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 4
B) MAIN FEATURES : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 5
B.1) Main bottom card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 5
B.2) Auxilary bottom card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 6
B.3) 8 inputs cards setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 7
B.3.1) Inputs selected in «basic led indicator» . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 7
B.3.2) Inputs selected in «Alarme mode» . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 7
B.3.3) Input «Blockage» . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 8
B.3.4) LED colour setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 8
B.3.5) Producing labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 9
C) ASSEMBLING : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 9
C.1) Unit dessassembling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 9
C.2) Battery assembling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 10
C.3) Connection of main & auxiliary cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 11
C.4) Reassembling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 12
D) STARTING PROCEDURE AND REPAIR : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 13
D.1) «Stand by» mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . p. 13
E) TECHNICAL FEATURES : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 13
F) CONNECTION EXAMPLE : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 14
G) TIMER OPTION : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 14
H) AKNOWLEDGMENT OPTION : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 14
Table of contents
ALARM’BOX STARTING PROCEDURE INSTRUCTIONS

4
580
145
306
ON DIP
12345
The ALARM’BOX allows clustering in a single point for effective protection and easy maintenance for industrial and
administrative sites.
- Important indicator displays : including in service/out of service, run/stop, and levels.
- Technical alarms : including trip outs, temperature alarms, levels and overspeeds, …)
The display can be regrouped by elements under control such as RUN/STOP/FAULT.
The ALARM’BOX was developped according to the strictest industrial standards.
With 8 to 96 inputs modulation on 1 to 3 stages this central unit is an IP65 weatherproof wall cabinet.
The ALARM’BOX is delivered with battery included and with a 230 Vac power supply.
- Each input can be selected in common indicator display or in alarm mode, with inputs NO or NC, with fittering of time delay.
- The inputs selected under alarm will be flashing and stored. They will activate the audible alarm (included) until the
operator acknowledgment.
- Acknowledgment and test button in front face are accessible throughout see through front door.
- Remote relay included.
It is also possible to group together the number of inputs needed in order to signal the whole condition of an under control
element (Start/Stop/PUMP Alarm).
It is possible to create special cabinets. This instructions manuel also shows a set with 2 feedback contacts per input.
Selection activation/desactivation of
input cards by switch
The system is made of :
- 1 unit with 1, 2 or 3 stages
- 1 to 12 pluggable cards of 8 inputs
- 1 battery with charger
- contacts connected to the terminal block
- 1 klaxon relay on terminal block
- 1 synthesis relay on terminal block per stage
- 1 battery alarm relay on terminal block
Battery
1 to 4, 8 inputs pluggable
cards
(max. 4 cards by stage)
Power supply 230Vac
Blocked
Free
Card 1
Card 2
Card 3
Card 4
Main
Blockage
«Battery Alarm»
Relay
Klaxon Relay
Synthesis Relay
Activation terminal block
for input cards blockage
Activation switch
for input cards blockage
Terminal Block
A) ALARM’BOX PRESENTATION:
A.1) Technical description :
A.2) Composition of the system :

5
1
S6 234
ON
Blocage
normal
OFF
ON DIP
12345
1
E1 E2
+COM CARTE VOIES 1 +COM CARTE VOIES 2 +COM CARTE VOIES 3 +COM CARTE VOIES 4
2345678 12345678 12345678 12345678 12345678
E3 E4
K
+BUZZER -
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
7
6
5
3
2
1
4
12
34
5
10 9
87
6
R44
R46
R
R R
R
R
R
R
R
R
R
R R
R
D41
D D D D D D D D
D42
D42
D38
D
Dz
Dz1
D
R43
R42
K1RSynth
K2RKL
K3Rbatt
KL SYNT
D49 D48
AlBatt
D47
D43 U5
C21
U8
U7
U6
F2
F3
CC19
C
G1
C18
CONNECTEURS D’ETAGE
FP
A1
B1 B2
A2
B3
A3
B4
A4
T 2,5A FUSE 5X20
F1
Batterie
ʥ+ʥ+
G2
ALIM
230Vac H
BLOCAGE
CARTE 1 BLOCAGE CARTE 2 BLOCAGE CARTE 3 BLOCAGE CARTE 4
Alarme
batterie
Général
Blockage
Activation Klaxon Relay Synchronising flashing light
Synthesis Relay Battery Alarm
(with positive secutrity)
The inputs can be treated in :
- Simple indicator : the selected input will switch on the led on fixed statement. The «contact direction» and the «input
temporization» functions are activated. The viewed input can deactivate the synthesis relay depending on the selection.
«Klaxon» relay and the buzzer are not activated. When the input disappears, the light switches off.
- Alarm : the activation of an input will switch on the led in flashing. The «contact direction», «input temporization» are
activated. The viewed input can activate the synthesis relay depending on the selection. «Klaxon» relay and the buzzer
are activated. An acknowledgment on «reset» button will stop the buzzer and «klaxon» relay, the LED will pass on fixed
statement. When the input goes back to normal, the light switches off.
The setting input by input can be done trough switches located on each input card. These cards are pluggable and connected
to a main bottom card.
«Reset»
button
«Test LEDs»
button
«Blocking»
led indicator
«Battery»
led indicator
«Power supply»
led indicator
B) MAIN FEATURES :
B.1) Main bottom card : (always located in the upper stage)

6
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
1
0
1
9
2
8
5
6
4
7
3
2
4
10
8
6
1
2
3
4
5
10
9
8
7
6
10
1
9
2
8
5
6
4
7
3
2
4
10
8
6
2
4
10
8
6
1
0
1
9
2
8
5
6
4
7
3
1
2
3
4
5
10
9
8
7
6
2
4
10
8
6
2
5
4
3
1
0
1
9
2
8
5
6
4
7
3
1
2
3
4
5
10
9
8
7
6
2
4
10
8
6
2
5
4
3
1
2
3
4
5
10
9
8
7
6
1
0
1
9
2
8
5
6
4
7
3
2
4
10
8
6
2
5
4
3
Carte
1 à 8 voies Carte 9 à 16 voies Carte 17 à 24 voies Carte 25 à 32 voies
Carte
1 à 8 voies
Carte de fond auxiliaire
Carte additive de 8 voies
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
101
92
8
56
47
3
1
2
3
4
5
10
9
8
7
6
10
1
9
2
8
5
6
4
7
3
2
4
10
8
6
1
0
1
9
2
8
5
6
4
7
3
1
2
3
4
5
10
9
8
7
6
2
4
10
8
6
2
5
4
3
1
0
1
9
2
8
5
6
4
7
3
1
2
3
4
5
10
9
8
7
6
2
4
10
8
6
2
5
4
3
1
2
3
4
5
10
9
8
7
6
1
0
1
9
2
8
5
6
4
7
3
2
4
10
8
6
2
5
4
3
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3 L4 L5 L6 L7 L8
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3 L4 L5 L6 L7 L8
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3 L4 L5 L6 L7 L8
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3 L4 L5 L6 L7 L8
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3
L4 L5 L6 L7 L8
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3
L4 L5 L6 L7 L8
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3
L4 L5 L6 L7 L8
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3
L4 L5 L6 L7 L8
Carte de 8 relais
COM
Carte de 8 voies
8 entrées
«contact»
8 contacts
de reports 8 contacts de reports
1
8
1
8
Klaxon relay : positive security relay for external audible alarm (ALARM’BOX has an internal buzzer).
Synthesis relay : positive security relay is falling in case of signalling or present alarms with a «synthesis» selection. This
relay will only go back to normal when all the inputs involved are deactivated.
Synchronization flashing light : flashes in continous indicating the normal synchronization of the leds.
Battery Alarm : positive security relay dropping in case of battery anomaly.
«Power supply» led indicator : switched on green = power supply indicated, switched off = no power supply.
«Battery» led indicator : usually switched off . Switched on red, an unusually battery discharge is indicated with no power
supply or a malfunction of the charger.
«Blocking» led indicator : no blocking. Switched on orange = blocking activated.
«Test LEDs» button : allows to test the leds.
«Reset» button : (or «acknowledgment») allows to stop the klaxon and to pass
on the flashing lights in fixed statement or to delete the disappeared alarms.
An auxiliary card allows to connect 1 to 32 additional inputs.
The «audible alarm» is common and unique, located in stage
1.
The main alarm relay or synthesis relay is selectable by stage
(1 relay for each stage).
The stage 2 and 3 contain relaying cards.
Each card is located under the input cards which represents it.
Principe :
Stage 1
Stage 1
Stage 2
Stage 2
Stage 3
8 relays cards
Auxilary bottom card
Additional 8 inputs cards
Cards
1 to 8 inputs
Cards
1 to 8 inputs Cards 9 to 16 inputs Cards 17 to 24 inputs Cards 25 to 32 inputs
8 feedback
contacts 8 feedback
contacts
8 inputs
contact 8 inputs card
B.2) Auxilary bottom card : (fitted in satge 2 and 3) for
standard units.
When units are fitted with 2 reports relay per input :

7
1
2
3
4
5
6
7
8
S2
S1
S3
S4
S5
S6
S7
S8
1 2 3 4
5 6 7 8
NO
NC
NO/NC S1
TEMPO
10mn S5
1mn
INDICATOR S2
ALARM
12345678
ON
SYNTHESIS
YES S4
NO
12345678
ON
12345678
ON
12345678
ON
INHIBIT
YES S3
NO
12345678
ON
Programming input-by-input can be done through switches
located on every input card.
- The «x» input is selected in basic led indicator mode with
S2x :
Depending on the direction of the input contact «x»
selected with S1x (Normally Open / Normally Closed) and
after delaying time has expired Tx, the Led «Lx» will be
lit up in fixe ( It is also possible to switch on a LED by the
opening of the contact if the selection is NO).
- The corresponding output «X» is activated (open collector
output, gives 0V).
- The «synthesis» relay Rs can be activated if the selection
S4x is programmed.
- The «audible alarm» relay RKL is not activated.
- As soon as the contact comes back to normal position,
the LED lights off.
- If the input blockage is activate before the LED lights-
up and the input is selected in blocking authorization
with S3, the display will be cancelled so will the fault
consideration.
Output «main alarm» or synthesis (RS) :
Output 1RT with galvanic isolation. The relay is with
«positive security». That is to say «normally energized».
The relay will be deactivated by each input selected with
S4x, whether the inputs are selected in basic indicator or
in alarm.
The relay will only be reactivated when all the selected
inputs would have disappeared.
- The input «X» is selected in alarm with S2x :
Depending on the direction of the input contact «x» selected with S1x (Normally Open / Normally Closed) and after
delaying time has expired Tx, the consideration of the alarm will be memorized.
The LED will be blinking.
- The corresponding output «x» is activated (open collector output, gives 0V).
- The «synthesis» relay Rs can be activated if the selection S4x is programmed.
- The «audible alarm» relay RKL is activated. (so is the buzzer if it is present).
- A push on the «acknowledgment button» on front face (or an activation of the acknowledgment by the rear terminal) stop
the buzzer and turns the LED in fixe if the alarm is still present or turns the LED off when back to normal. The «open
collector» output and the main alarm relay (if that one is selected by S4) will remain activated until the LED switches off.
Timer selection
Inputs setting
on the synthesis
relay
Inputs blockage
setting
Timer setting
0 - 1mn
1 - 10mn
Input selection
in signalling or
alarm mode
Contact selection
in NO/NC
LED colour
setting
B.3) 8 inputs cards programming :
B.3.1) Inputs selected in «basic led indicator
mode» :
B.3.2) Inputs selected in «Alarm mode» :

8
ON DIP
12345
OFF ON
Vert
Green 3
2
1
Rouge
Red 3
2
1
Jaune
Yellow 3
2
1
Magenta 3
2
1
Cyan 3
2
1
Blanc
White 3
2
1
Eteint
Off 3
2
1
Bleu
Blue 3
2
1
The blockage is used when inputs have to be cancelled during a
period. This period is established by the closure of an external contact
(day/night, start of cycles with inactive securities, technical services).
The blockage allows cancelling the consideration of some inputs
selected on each input card by the S3 switch. This function is valid
for inputs in basic indicator display or in alarm. This cancellation will
start when the external contact on the blockage input will be closed.
(Connected to the «+ COM»). When a LED is lit up (fixe or blinking)
and its blockage input is to be activated, the blockage will operate
after the LED switch off. If any blockage input is activated, the front
face LED «blockage» will light in orange.
Command blockage different possibilities :
- On each input card, an S3 switch allows the inputs of this card that are going to be blocked.
- The block terminal composed of 8 thresholds on the main card allows activating the 1 to 4 cards by 4 external contacts. A
fifth terminal block located on the upper block allows activating the general blockage of the ALARM’BOX stage by an external
contact.
- The front face «Blockage» light will light up orange when activating (contact closure) of the first of the four «blockage
inputs» or with the «main contact blockage».
- Five internal switches on the main card allow forcing the blockage without using external contact. This function can be used
for servicing. As with the «blockage inputs», it is also possible to block the whole stage of the ALARM’BOX (main blockage)
or each card one by one.
To block a input it is necessary :
- That the concerned input be selected in blockage with the S3 switch located on this input card.
- That the concerned card be selected in blockage with the S6 switch located on the main card or that the external contact on
the block terminal be closed.
Please note :
To block all the input cards at once, two solutions :
(The inputs must be blocked on the input card by the S3 switch)
- The S6 switch must have the first four guides (1, 2, 3, 4 ) in up position, or else the block terminal must have all its
thresholds wired on closed contacts. (Refer to diagram page 11).
- The S6 switch must have the fifth position ( general) up or the contact wired on external main blockage thresholds must be
closed.
Selection activation/desactivation
of input cards by switch
Blocked
Free
Card 1
Card 2 Card 4
General
blockage
Card 3
A choice of 7 colours of display is possible per LEDs, selectable using switches on the front.
Following the setting procedure, you have a choice of the following colours :
Red, Green, Yellow, Blue, White, Cyan, Magenta.
Changing LEDs is no longer necessary.
B.3.3) Input «Blockage» :
B.3.4) LED colour setting :

9
1
3
45
2
Labels are ordinary paper sheets that slid into
transparent pockets included in the thickness of the
front. A blank label is supplied with each unit. Labels can
be handmade or produced on a colour printer (laser or
ink-jet).
PC software is provided for free to create labels,
including images, to save and to duplicate the
productions.
(For high humidity countries printing on plastic sheets is
recommended).
Labels setting :
- Print and then cut the labels.
- Unscrew the plastic screws “cross-headed” on the
ALARM’BOX front face, disconnect the ribbon from the
label holder keypad making sure to note the direction
to reassemble.
- Slide the labels inside the slot on the thickness of the
label holder at the back of the front face, using it as a
cover
- Reassembling :
Put the ribbon back into the connector, place the front
face back in its location, and screw the 6 plastic screws.
(depending on the number of stages of your
ALARM’BOX).
Only after putting the unit on a table,
- Unscrew the plastic screws “cross-headed” (1), as well as
the those hidden by the doors (2).
- When opening the front face (3), disconnect the ribbon (4)
from the bottom circuit of the cabinet.
- Take the front part off, being careful of the ribbon (4)
connected to the front face (3).
Careful : before any manipulation, make sure the Alarm’Box is switched off.
Front face’s back
«Label holder»
B.3.5) Producing labels :
C) ASSEMBLING :
C.1) Unit dessassembling :

10
A1 A2
A3 A4
220mm
The battery tray is located behind the main iron sheet.
- To assemble the battery, you have to take off the main iron sheet fixed by 4 screws following A1, A2, A3 and A4 marks.
- Properly position the battery.
- Stick it with 2 double side seller-tape.
- Put the main iron sheet back.
-Tofinish, be carreful :
Connect the battery observing proper polarity.
- Mount the unit on the wall using spaces provided for this purpose.
1 stage = 235mm
2 stages = 385mm
3 stages = 535mm
Main
Iron sheet
BATTERY
2 double side
seller-tape
C.2) Battery assembling :

11
1
S6 234
ON
Blocage
normal
OFF
ON DIP
12345
1
E1 E2
+COM CARTE VOIES 1 +COM CARTE VOIES 2 +COM CARTE VOIES 3 +COM CARTE VOIES 4
2345678 12345678 12345678 12345678 12345678
E3 E4
K
+COM
vers Batterie vers Alim chargeuse
230Vac
230V vers
chargeur
Alarme
batterie
Synthèse
général
Blocage
général Alarme
sonore
Borniers
carte de fond ALARMBOX
H
K1 K2
J
I3
2
1
3
2
1
3
2
1
voie 1 à 8 voie 9 à 16 voie 17 à 24 voie 25 à 32
+COM
Général
Blocage
général
Blocage
carte 1
Blocage
carte 2
Blocage
carte 3
Blocage
carte 4
1
2
3
1
+COM
Acquit
0V
2
3
6
7
4
3A
8
2A
2B
5
1
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3 L4 L5 L6 L7 L8
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3 L4 L5 L6 L7 L8
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3 L4 L5 L6 L7 L8
Dz1
R1
BAC
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3 L4 L5 L6 L7 L8
Dz1
R1
CN4 CN3 CN2
A.M.I M0901-02-02
CN1
L1 L2 L3 L4 L5 L6 L7 L8
BAC
voie 1 voie 2 voie 3 voie 4 voie 5 voie 6 voie 7 voie 8
voie 1 voie 2 voie 3 voie 4 voie 5 voie 6 voie 7 voie 8
(NO)
COM
(NF)
The main card includes a number of connectors :
1. The power supply 230Vac (Terminal block 1-3 ).
2. The inputs terminal block (2 cables per contact). The connectors are grouped together on 4 groups of 2. Each group
correspond to an 8 channels card (the one located directly above ). In each group of 2 connectors, the first one (2A)
allows to power the contact. The other one (2B), corresponds to the input of the cards. The inputs contacts are directly
powered by the power station. The polarity «+» is already present on all the 2A connector terminal blocks. ( For other
wirings please contact us .
3. The inputs contact terminal block of external blockage (3A). Possibility to use an independent blockage for each 8
channels card (card blockage 1 to 4 ).
4. Auxiliary terminal block (Main external blockage, Synthesis feedback, Audible alarm).Each output is planned with an
exchange non-powered contact. Caution : The relays are with positive security. The contact swings to power on.
Example : The synthesis relay contact is closed in 4 and 5, when there is no signaling.
5. Auxiliary terminal block «Battery alarm».
6. Special use terminal block (please contact us).
7. Internal terminal block, link towards battery and «14V charger». When disconnecting this terminal block, the battery is
out of service. ( so is the whole Alarm’box).
8. Internal terminal block, link to the primary of the charger.
Connection of main and auxiliary card on stage 2 and 3 :
Refer to previous chapter.
Connect the inputs and the synthesis relay.
When equipped with reports relay : (connection in stage 2 and 3) :
Refer to previous chapter.
Connect the inputs and the synthesis relay.
+COM INPUT CARDS 1
Input 1 to 8 +COM INPUT CARDS 2 Input 9 to 16 +COM INPUT CARDS 1
Input 17 to 24 +COM INPUT CARDS 2 Input 25 to 32
Main
Blockage Blockage
card 1
Blockage
card 2
Blockage
card 3
Blockage
card 4
Genaral
synthesis Audible Alarm
Main
Blockage
Alarm’Box bottom
cards terminal block
To 230V
charger
Battery
alarm
To battery To loader power supply
C.3) Connection of main & auxiliary cards :

12
1
2
- Slide the labels into the front face.
- Put the front face back being careful to correctly connect the ribbon.
- Screw the plastic screws “cross-headed” (1) and (2)
(Depending on the number of stages of your Alarm’box).
C.4) Reassembling :

13
- Connect the battery.
- Connect the 230Vac main power on.
- Proceed to a «LEDS Test».
- Program the cards (see chapter B3).
Meaning of indicators :
State of «POWER SUPLLY» presence
indicator : Green : Power Supply present Off : Power Supply not present
State of «BATTERY» indicator : Off : Normal Red : Discharged battery with
supply absent or charger
anomaly
State of «BLOCKAGE» indicator : Off : No blockage Orange : Blockage activated
«Reset»
Button
«LEDs Test»
Button
«Blocage» presence
indicator
«Batterie»
indicator
«Power supply» presence
indicator
To set the ALARM’BOX in «standby» mode that is to say completely out of service :
- Switch the 230Vac main power off or disconnect the connector 1 (Refer to wiring diagram in chapter 3).
- Insulate the battery by disconnecting the connector 7 (Refer to wiring diagram in chapter 3).
Delivered in standard with red LEDs, other colours :
Green, Yellow, Blue.
General power 12Vdc 230Vac
Power supply tolerance -20/+30% -30/+30%
Consumption :
- Without input card
- By input card (standby )
- By input card (max.)
70mA
9mA
230mA
0,2A
9mA
230mA
Fuse : 2,5A (Main bottom card)
Input consumption 2,4mA
Line’s resistance admited on the contact 2kOhms
Time delays accuracy +/- 20%
Protection with cover IP65
Temperature (at nominal voltage) -10°C / +50°C
Contact relay (at positive security) 1RT 6A/12Vdc -
0,15A/240Vac
weight (with battery) 1 stage : 7kg
2 stages : 8,5kg
3 stages : 10kg
Number
of inputs Type 12Vdc without battery 220Vac without battery 220Vac with battery Standard Autonomy *
8 inputs
16 inputs
24 inputs
32 inputs
1 stage
AJ1900-01-11
AJ1900-01-12
AJ1900-01-13
AJ1900-01-14
AJ1900-05-11
AJ1900-05-12
AJ1900-05-13
AJ1900-05-14
AJ1900-05-11B
AJ1900-05-12B
AJ1900-05-13B
AJ1900-05-14B
85 h
76 h
67 h
60 h
40 inputs
48 inputs
56 inputs
64 inputs
2 stages
AJ1900-01-21
AJ1900-01-22
AJ1900-01-23
AJ1900-01-24
AJ1900-05-21
AJ1900-05-22
AJ1900-05-23
AJ1900-05-24
AJ1900-05-21B
AJ1900-05-22B
AJ1900-05-23B
AJ1900-05-24B
45 h
42,5 h
40 h
37,5 h
72 inputs
80 inputs
88 inputs
96 inputs
3 stages
AJ1900-01-31
AJ1900-01-32
AJ1900-01-33
AJ1900-01-34
AJ1900-05-31
AJ1900-05-32
AJ1900-05-33
AJ1900-05-34
AJ1900-05-31B
AJ1900-05-32B
AJ1900-05-33B
AJ1900-05-34B
31 h
30 h
29 h
28 h
8 inputs additional card AJ1900-01-10C
Additive 8 input card with connector for relay card : AJ1900-01-10CA
* Standard autonomy : The Alarm’ Box are delivered as standard with a 12V/7Ah battery.
The discharge time is the one that allows the following test after 24h of battery charge ( AC power present ) :
- Operational of the unit in standby mode ( AC power present ), without signaling or alarms.
- At the end of discharge time, detection and consideration of an alarm during minimum 1mn.
D) STARTING PROCEDURE AND REPAIR :
E) TECHNICAL FEATURES :
D.1) «Stand by» mode :

14
1
S6 234
ON
Blocage
normal
OFF
ON DIP
12345
1
E1 E2
+COM CARTE VOIES 1 +COM CARTE VOIES 2 +COM CARTE VOIES 3 +COM CARTE VOIES 4
2345678 12345678 12345678 12345678 12345678
E3 E4
K
PAN35-02-13
Présence
tension
Alarme
Alarme
batterie
Buzzer BP Acquit.
TL
1
2
3
–
+
1
+COM
Acquit
0V
2
3
1
+COM
Acquit
0V
2
3+COM
Synthèse
général Alarme sonore
K1 K2
–
Connection of an Alarm’Box with a MJ1900 report box fitted with a PAN35-02-13, with a buzzer and an acknowledgment
button.
Supply
Presence
Alarm
Alarm
battery
Activate the timer using the activation switch.
Select first of all your time range using the selector :
x1 : 1s to 1mn
x4 : 4s to 4mn
x8 : 8s to 8mn
x16 : 16s to 16mn
Then make your time range vary with the potentiometer to
reach the desired time range.
The timer option allows when an alarm appears, not to leave the buzzer ring out permanently.
When an alarm appears, the buzzer rings, if this one is not acknowledged, with the timer option on, the buzzer will switch off
after the programmed delay. It has to be noted that when a new alarm appears the buzzer will not ring.
Timer activation
switch
Programming
potentiometer
«Time delay»
selector
Buzzer Presence Led
and activated relay KL
Presence Led
of unacknowledge alarm
Supply
Presence
Alarm
Alarm
battery
Push Button
acknowledge
+COM INPUT CARDS 1 +COM INPUT CARDS 2 +COM INPUT CARDS 3 +COM INPUT CARDS 4
Genaral
synthesis Audible Alarm
F) CONNECTION EXAMPLE :
G) TIMER OPTION :

15
1
S6 234
ON
Blocage
normal
OFF
ON DIP
12345
1
E1 E2
+COM CARTE VOIES 1 +COM CARTE VOIES 2 +COM CARTE V
O
2345678 12345678 12345678 12345
6
E3
K
1
S6 234
ON
Blocage
normal
OFF
ON DIP
12345
1
E1 E2
+COM CARTE VOIES 1 +COM CARTE VOIES 2 +COM CARTE V
O
2345678 12345678 12345678 12345
6
E3
K
1
2
3
1
+COM
Acquit
0V
2
3
1
2
3
1
+COM
Acquit
0V
2
3
+COM
On an installation with several Alarm’Box, it is possible using the acknowledgment button on the front face, to acknowledge
concurrently all the Alarm’Box at once. To do so, you need to specify the acknowledgment option when ordering and to carry
out the wiring as below :
+COM INPUT CARDS 1 +COM INPUT CARDS 2
+COM INPUT CARDS 1 +COM INPUT CARDS 2
H) AKNOWLEDGMENT OPTION :

16
A.M.I.
A.M.I.
3, Rue de la Garenne - Z.I. de Vernon
27950 SAINT MARCEL - FRANCE
tél. : [phone]
Fax : [phone]
http://www.ami-control.com
: [email protected]
