Amica IH 17410 W User manual

IO-HOO-0283/2
(06.2019)
Kitchen extractor hood / kaminhaube /
kuchyňského odsavače / kuchynského odsávača
/ Hotte aspirante / Afzuigkap / Kuhinjska napa /
Kuhinjska napa
IH 17410 W / IH 17411 S
OPERATING INSTRUCTIONS EN
GEBRAUCHSANWEISUNG DE
NÁVOD K OBSLUZE CS
NÁVOD NA OBSLUHU SK
NOTICE D’UTILISATION FR
GEBRUIKSAANWIJZING NL
UPUTE ZA UPORABU HR
NAVODILA ZA UPORABO SL

- 2 -
NOTES ON SAFETY 6
UNPACKING 9
DISPOSAL OF OLD APPLIANCE 9
OPERATION 10
KITCHEN HOOD CONTROLS 10
CONTROL PANEL 10
OFF TIMER 10
REMOTE CONTROL 11
OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 12
CLEANING AND MAINTENANCE 13
MAINTENANCE 13
GREASE FILTER 13
ACTIVATED CHARCOAL FILTER 13
LIGHT 13
WARRANTY AND AFTER SALES SERVICE 14
WARRANTY 14
SICHERHEITSHINWEISE 16
AUSPACKEN 20
ENTSORGUNG VON ALTGERÄTEN 20
BEDIENUNG 21
STEUERUNG DER DUNSTABZUGSHAUBE 21
BEDIENFELD 21
TIMER (AUSSCHALTVERZÖGERUNG) 21
FERNBEDIENUNG 22
ANDERE WICHTIGE INFORMATIONEN ZUR BEDIENUNG DER DUNSTABZUGSHAUBE 23
REINIGUNG UND WARTUNG 23
WARTUNG 23
FETTFILTER 24
AKTIVKOHLEFILTER 24
BELEUCHTUNG 24
GARANTIE, NACHVERKAUF-SERVICE 25
GARANTIE 25
EN- Table of contents
DE- Inhaltsverzeichnis
BEZPEČNOSTNÍ POKYNY 27
VYBALENÍ 30
LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 30
OBSLUHA 31
OVLÁDÁNÍ ODSAVAČE 31
OVLÁDACÍ PANEL 31
ČASOVAČ (OPOŽDĚNÉ VYPNUTÍ MOTORU ODSAVAČE) 31
JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 33
ČIŠTĚNÍ A ÚDRŽBA 34
ÚDRŽBA 34
PROTITUKOVÝ FILTR 34
UHLÍKOVÝ FILTR 34
OSVĚTLENÍ 34
ZÁRUKA, POPRODEJNÍ SERVIS 35
ZÁRUKA 35
CS- Obsah

- 3 -
BEZPEČNOSTNÉ POKYNY POUŽÍVANIA 37
ROZBALENIE 41
LIKVIDÁCIA ZARIADENÍ 41
OBSLUHA 42
OVLÁDANIE ODSÁVAČA 42
OVLÁDACÍ PANEL 42
ČASOVAČ (ONESKORENÉ VYPNUTIE MOTORA ODSÁVAČA) 42
DIAĽKOVÝ OVLÁDAČ 43
INÉ DÔLEŽITÉ INFORMÁCIE TÝKAJÚCE SA POUŽÍVANIA ODSÁVAČA 44
ČISTENIE A ÚDRŽBA 45
KONZERVÁCIA 45
PROTITUKOVÝ FILTER 45
UHLÍKOVÝ FILTER 45
OSVETLENIE 45
ZÁRUKA, POPREDAJNÝ SERVIS 46
ZÁRUKA 46
INDICATIONS CONCERNANT LA SÉCURITÉ D'UTILISATION 48
DÉBALLAGE 52
ÉLIMINATION DES APPAREILS USAGÉS 52
EXPLOITATION 53
COMMANDE DE LA HOTTE 53
PANNEAU DE COMMANDE 53
TIMER (ARRÊT DIFFÉRÉ DU VENTILATEUR DE LA HOTTE) 53
TÉLÉCOMMANDE 54
AUTRES INFORMATIONS IMPORTANTES RELATIVES À L’UTILISATION DE LA HOTTE 55
NETTOYAGE ET ENTRETIEN 56
ENTRETIEN 56
FILTRE À GRAISSE 56
FILTRE À CHARBON 56
ÉCLAIRAGE 56
GARANTIE, SERVICE APRÈS-VENTE 57
GARANTIE 57
AANWIJZINGEN VOOR VEILIG GEBRUIK 59
UITPAKKEN 63
VERWIJDERING VAN GEBRUIKTE APPARATUUR 63
BEDIENING 64
BEDIENING VAN DE AFZUIGKAP 64
BEDIENINGSPANEEL 64
TIMER (UITGESTELDE UITSCHAKELING VAN DE MOTOR VAN DE AFZUIGKAP) 64
AFSTANDSBEDIENING 65
ANDERE BELANGRIJK INFORMATIE OVER DE BEDIENING VAN DE AFZUIGKAP 66
REINIGING EN ONDERHOUD 67
ONDERHOUD 67
ANTIVETFILTER 67
ACTIEVE KOOLFILTER 67
VERLICHTING 67
GARANTIE, SERVICE 68
GARANTIE 68
SK- Obsah
FR- Table des matières
NL- Inhoudsopgave

- 4 -
HR- Kazalo
SL- Sadržaj
SIGURNOSNE NAPOMENE 70
UKLANJANJE PAKIRANJA 73
ZBRINJAVANJE POTROŠENIH UREĐAJA 73
UPORABA 74
UPRAVLJANJE NAPOM 74
UPRAVLJAČKA PLOČA 74
TIMER (ODGODA ISKLJUČENJA VENTILATORA NAPE) 74
DALJINSKI UPRAVLJAČ 75
OSTALE VAŽNE INFORMACIJE O UPORABI NAPE 76
ČIŠĆENJE I ODRŽAVANJE 77
ODRŽAVANJE 77
FILTER PROTIV MASNOĆE 77
UGLJENI FILTER 77
RASVJETA 77
JAMSTVO, POSLIJEPRODAJNE AKTIVNOSTI 78
JAMSTVO 78
NAVODILA ZA ZAGOTAVLJANJE VARNOSTI UPORABE 80
RAZPAKIRANJE 83
ODSTRANJEVANJE IZRABLJENIH NAPRAV 83
UPORABA 84
UPRAVLJANJE S KUHINJSKO NAPO 84
PANEL ZA UPRAVLJANJE 84
TIMER (ZAKASNITEV IZKLOPA HITROSTI NAPE) 84
PILOT ZA DALJINSKO UPRAVLJANJE 85
DRUGE POMEMBNE INFORMACIJE GLEDE NAVODIL ZA UPORABO NAPE 86
ČIŠČENJE IN VZDRŽEVANJE 87
VZDRŽEVANJE 87
MAŠČOBNI FILTER 87
OGLENI FILTER 87
OSVETLITEV 87
GARANCIJA, POPRODAJNE STORITVE 88
GARANCIJA 88

- 5 -
Dear customer,
From now on, your daily housework will be easier
than ever before. Your appliance is excepon-
ally easy to use and extremely ecient. Aer reading
these Operang Instrucons, operang the appliance
will be easy.
Before being packaged and leaving the manufacturer,
the appliance was thoroughly checked with regard to
safety and funconality.
Before using the appliance, please carefully read
these Operang Instrucons. By following these
instrucons carefully you will be able to avoid any
problems in using the appliance. It is important to
keep these Operang Instrucons and store them in a
safe place so that they can be consulted at any me.
Follow these instrucons carefully in order to avoid
possible accidents.
Sincerely,

- 6 -
NOTES ON SAFETY
• Before using the appliance, please carefully read
this manual!
• The appliance is designed for household use only.
• The manufacturer reserves the right to introduce
changes, which do not aect operation of the ap-
pliance.
• The manufacturer shall not be liable for any dam-
age or re caused by the appliance resulting from
failure to follow instructions in this manual.
• Cooker hood is designed to remove cooking
odours. Do not use cooker hood for other pur-
poses.
• Connect the cooker hood operating in extraction
mode to a suitable ventilation duct (do NOT con-
nect the cooker to smoke or ue gas ducts, which
are in use). It requires installation of the air ex-
traction duct to the outside. The length of the
duct (usually a pipe of Ø 120 or 150 mm) should
not be longer than 4-5 m. An air extraction duct
is also required for telescopic and furniture hoods
in absorption mode.
• Cooker hood operating in air recirculation mode
requires the installation of an activated charcoal
lter. In this case, installing an extractor duct is
not required, however it is recommended to in-
stall an air guide vane (Mainly in chimney cooker
hoods).
• The cooker hood features independent lighting
and exhaust fan that can be operated at one of
several speeds.
• Depending on the type, the hood is designed to
be permanently attached to a vertical wall over
a gas or electric stove (chimney and universal
hoods); on the ceiling over a gas or electric stove
(island hoods); on the vertical built in furniture
over a gas or electric stove (telescopic and built-
in hoods). Before installing, make sure that the

- 7 -
wall/ceiling structure is strong enough to suspend
the hood. Some hoods are very heavy.
• For details of the installation distance above an
electric hob please refer to product technical
sheet If the installation instructions of the gas
cooker specify a greater distance, this must be
taken into account (Fig. 1).
• Do not leave an open ame under the hood.
When the pots are removed from the burner, set
the minimum ame. Always make sure that the
ame does not extend outside the pot, because it
causes unwanted loss of energy and a dangerous
concentration of heat.
• When cooking on fat, supervise the pans con-
stantly, because overheated fat can ignite.
• Unplug the appliance before any cleaning, replac-
ing the lter or repair work.
• Cooker hood grease lter should be cleaned at
least once a month, because the lter saturated
with fat is ammable.
• Ensure adequate ventilation (air ow) if other
equipment such as liquid fuel stoves or heaters
are operated in the room in addition the cooker
hood. When the cooker hood is simultaneously
operated with burning appliances requiring ade-
quate fresh air from the room to work properly,
their safe operation is possible if under pressure
around these appliances is a maximum of 0.004
mbar (this does not apply when the cooker hood
is used as an odour lter)
• Do not lean on the hood.
• The hood should be cleaned regularly both inside
and out (AT LEAST ONCE A MONTH, following the
indications concerning maintenance provided in
this manual)..Failure to adhere to the rules con-
cerning cleaning the hood and replacing lters
results in a re risk.
• If the power cord is damaged it should be re-
placed by a specialised service centre.
• Ensure that it is possible to disconnect the ap-

- 8 -
pliance from the mains by removing the plug or
switching o the bi-polar switch.
• This appliance is not intended for use by persons
(including children) with physical, mental or sen-
sory handicaps, or by persons inexperienced or
unfamiliar with the appliance, unless under su-
pervision or in accordance with the instructions
as communicated to them by persons responsible
for their safety.
• Particular attention should be paid not to allow
unaccompanied children to use the appliance.
• Make sure voltage indicated on the nameplate
corresponds to the local mains supply voltage.
• Before use, extend and straighten the power cord.
• Packaging materials (bags, polyethylene, poly-
styrene, etc.) should be kept away from children
during unpacking.
• Before connecting the hood to the mains power
supply always check that the power cord is prop-
erly installed and is not trapped by the appliance.
Do not connect the appliance to the mains until
assembly is complete.
• Do not operate your kitchen hood without the al-
uminium grease lters.
• It is strictly forbidden to cook dishes under on an
open ame (ambé) under your kitchen hood.
• Always strictly adhere to regulations issued by the
competent local authorities regarding the techni-
cal and safety requirements for fume extraction.
• Failing to tighten bolts and fasteners in accord-
ance with these instructions may endanger life
and health.
• Hanging kitchen hoods operate only in air circu-
lation / odour absorber mode
• WARNING! Failure to install the screws or xing
device in accordance with these instructions may
result in electrical hazards.

- 9 -
UNPACKING
During transportation, protective
packaging was used to protect the
appliance against any damage. Af-
ter unpacking, please dispose of all
elements of packaging in a way that
will not cause damage to the environ-
ment.
All materials used for packaging the
appliance are environmentally friendly; they are
100% recyclable and are marked with the appropri-
ate symbol.
Important! Packaging materials (bags, polyethyl-
ene, polystyrene, etc.) should be kept away from
children during unpacking.
DISPOSAL OF OLD APPLIANCE
In accordance with European Directive
2012/19/EU and local legislation re-
garding used electrical and electronic
goods, this appliance is marked with
the symbol of the crossed-out waste
container. This marking indicates that
the appliance must not be disposed of
together with other household waste
after it has been used.
The user is obliged to hand it over to waste collec-
tion centre collecting used electrical and electron-
ic goods. The collectors, including local collection
points, shops and local authority departments pro-
vide recycling schemes.
Proper handling of used electrical and electronic
goods helps avoid environmental and health haz-
ards resulting from the presence of dangerous com-
ponents and the inappropriate storage and process-
ing of such goods.

- 10 -
OPERATION
Kitchen hood controls
Control Panel is shown in Figure 4, for reference it is also shown below:
3 5
2 4
Control Panel
Touch one the sensors to enable the desired function:
1 Reduce fan speed If the fan is running, touch this sensor to turn it
o.
2 Increase fan speed If the hood is in standby mode, touch this sensor
to turn on the fan.
3 Fan speed display (the display is not a control). The fan can run at 4
speeds.*
4 O timer
5 Lighting on/o The lighting operates independently of hood fan.
Available fan speeds:*
- Low speed (1). Use this speed when cooking a little food with hardly
any fumes.
- Medium speeds (2 and 3*). Use this speed when cooking multiple
dishes at the same time with moderate amount of fumes.
- High speed (4*). Use this speed when frying or grilling, with large
amount of fumes.
*Some models feature speeds 1–3.
O Timer
Use o timer to turn o the hood after a specied time. Use o timer
to lter the fumes out of the air after cooking. Maximum delay time is
90 minutes. Press to cancel the o timer at any time. The number
will ash on the display. Then use and to select the delay in the
range 1–9 (multiply the number by ten to obtain delay in minutes, 1 –
10 minutes, 2 – 20 minutes ... 5 – 50 minutes). Press again to acti-
vate the function. The o timer is set a dot will ash on by the digit on
the display. Press to cancel the o timer. The hood fan will run at the
selected speed. Cancelling the o-timer does not turn o the lighting.
