Amica SKZ 656 BBG User manual

IO-HOO-0575/1
(02.2018)
Kitchen extractor hood / Okap nadkuchenny /
Kuchyňského odsavače / Kuchynského odsávača /
Campana extractora de cocina / Exaustor de cozinha
OKC 645 S / OKC 655 S / OKC 655
SW / SKZ 656 BBG / SKZ 656 S
OPERATING INSTRUCTIONS EN
INSTRUKCJA OBSŁUGI PL
NÁVOD K OBSLUZE CS
NÁVOD NA OBSLUHU SK
MANUAL DE INSTRUCCIONES ES
MANUAL DE INSTRUÇÕES PT

- 3 -
NOTES ON SAFETY 7
UNPACKING 10
DISPOSAL OF OLD APPLIANCE 10
OPERATION - OKC 655 SW / OKC 655 S / SKZ 656 BBG 11
COOKER HOOD CONTROLS 11
CONTROL PANEL 11
OFF TIMER 11
OPERATION - OKC645S / SKZ 656 S 12
KITCHEN HOOD CONTROLS 12
CONTROL PANEL 12
OFF TIMER 12
OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 13
CLEANING AND MAINTENANCE 14
MAINTENANCE 14
GREASE FILTER 14
ACTIVATED CHARCOAL FILTER 14
LIGHT 14
WARRANTY AND AFTER SALES SERVICE 15
WARRANTY 15
WSKAZÓWKI DOTYCZĄCE BEZPIECZEŃSTWA 17
ROZPAKOWANIE 21
USUWANIE ZUŻYTYCH URZĄ DZEŃ 21
OBSŁUGA - OKC 655 SW / OKC 655 S / SKZ 656 BBG 22
STEROWANIE OKAPEM 22
PANEL STEROWANIA 22
TIMER (OPÓŹNIONE WYŁĄCZENIE SILNIKA OKAPU) 22
OBSŁUGA - OKC645S / SKZ 656 S 23
STEROWANIE OKAPEM 23
PANEL STEROWANIA 23
TIMER (OPÓŹNIONE WYŁĄCZENIE OKAPU) 23
INNE WAŻNE INFORMACJE DOTYCZĄCE OBSŁUGI OKAPU 24
CZYSZCZENIE I KONSERWACJA 25
KONSERWACJA 25
FILTR PRZECIWTŁUSZCZOWY 25
FILTR WĘGLOWY 25
OŚWIETLENIE 25
GWARANCJA, OBSŁUGA POSPRZEDAŻOWA 26
GWARANCJA 26
EN- Table of contents
PL- Spis treści

- 4 -
BEZPEČNOSTNÉ POKYNY POUŽÍVANIA 38
ROZBALENIE 42
LIKVIDÁCIA ZARIADENÍ 42
OBSLUHA - OKC 655 SW / OKC 655 S / SKZ 656 BBG 43
OVLÁDANIE ODSÁVAČA 43
OVLÁDACÍ PANEL 43
ČASOVAČ (ONESKORENÉ VYPNUTIE MOTORA ODSÁVAČA) 43
OBSLUHA - OKC645S / SKZ 656 S 44
OVLÁDANIE ODSÁVAČA 44
OVLÁDACÍ PANEL 44
ČASOVAČ (ONESKORENÉ VYPNUTIE ODSÁVANIA) 44
INÉ DÔLEŽITÉ INFORMÁCIE TÝKAJÚCE SA POUŽÍVANIA ODSÁVAČA 45
ČISTENIE A ÚDRŽBA 46
KONZERVÁCIA 46
PROTITUKOVÝ FILTER 46
UHLÍKOVÝ FILTER 46
OSVETLENIE 46
ZÁRUKA, POPREDAJNÝ SERVIS 47
ZÁRUKA 47
SK- Obsah
BEZPEČNOSTNÍ POKYNY 28
VYBALENÍ 31
LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 31
OBSLUHA - OKC 655 SW / OKC 655 S / SKZ 656 BBG 32
OVLÁDÁNÍ ODSAVAČE 32
OVLÁDACÍ PANEL 32
ČASOVAČ (OPOŽDĚNÉ VYPNUTÍ MOTORU ODSAVAČE) 32
OBSLUHA - OKC645S / SKZ 656 S 33
OVLÁDÁNÍ ODSAVAČE 33
OVLÁDACÍ PANEL 33
ČASOVAČ (OPOŽDĚNÉ VYPNUTÍ ODSAVAČE) 33
JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 34
ČIŠTĚNÍ A ÚDRŽBA 35
ÚDRŽBA 35
PROTITUKOVÝ FILTR 35
UHLÍKOVÝ FILTR 35
OSVĚTLENÍ 35
ZÁRUKA, POPRODEJNÍ SERVIS 36
ZÁRUKA 36
CS- Obsah

- 5 -
INDICACIONES RELACIONADAS CON SEGURIDAD 49
DESEMBALAJE 53
ELIMINACIÓN DE APARATOS USADOS 53
USO - OKC 655 SW / OKC 655 S / SKZ 656 BBG 54
CONTROL DE CAMPANA 54
PANEL DE CONTROL 54
TEMPORIZADOR (RETRASO DE LA DESACTIVACIÓN DEL MOTOR DE LA CAMPANA) 54
USO - OKC645S / SKZ 656 S 55
CONTROL DE CAMPANA 55
PANEL DE CONTROL 55
TEMPORIZADOR (RETRASO DE LA DESACTIVACIÓN DE LA CAMPANA) 55
OTRA INFORMACIÓN IMPORTANTE RELATIVA AL USO DE LA CAMPANA 56
LIMPIEZA Y CONSERVACIÓN 57
MANTENIMIENTO 57
FILTRO DE GRASA 57
FILTRO DE CARBÓN 57
ILUMINACIÓN 57
GARANTÍA, ATENCIÓN DE POST VENTA 58
GARANTÍA 58
CONSELHOS DE SEGURANÇA 60
DESEMPACOTAMENTO 64
ELIMINAÇÃO DE APARELHOS GASTOS 64
UTILIZAÇÃO - OKC 655 SW / OKC 655 S / SKZ 656 BBG 65
CONTROLO DO EXAUSTOR 65
PAINEL DE COMANDO 65
TIMER (DESLIGAMENTO ATRASADO DO MOTOR DO EXAUSTOR) 65
UTILIZAÇÃO - OKC645S / SKZ 656 S 66
CONTROLO DO EXAUSTOR 66
PAINEL DE COMANDO 66
TIMER (DESLIGAMENTO ATRASADO DO EXAUSTOR) 66
OUTRAS INFORMAÇÕES IMPORTANTES SOBRE A UTILIZAÇÃO DO EXAUSTOR 67
LIMPEZA E MANUTENÇÃO 68
MANUTENÇÃO 68
FILTRO DE GORDURA 68
FILTRO DE CARVÃO 68
ILUMINAÇÃO 68
GARANTIA, SERVIÇO PÓS-VENDA 69
GARANTIA 69
ES- Tabla de contenidos
PT- Índice

- 6 -
Dear customer,
From now on, your daily housework will be easier
than ever before. Your appliance is excepon-
ally easy to use and extremely ecient. Aer reading
these Operang Instrucons, operang the appliance
will be easy.
Before being packaged and leaving the manufacturer,
the appliance was thoroughly checked with regard to
safety and funconality.
Before using the appliance, please carefully read
these Operang Instrucons. By following these
instrucons carefully you will be able to avoid any
problems in using the appliance. It is important to
keep these Operang Instrucons and store them in a
safe place so that they can be consulted at any me.
Follow these instrucons carefully in order to avoid
possible accidents.
Sincerely,

- 7 -
NOTES ON SAFETY
• Before using the appliance, please carefully read
this manual!
• The appliance is designed for household use only.
• The manufacturer reserves the right to introduce
changes, which do not aect operation of the ap-
pliance.
• The manufacturer shall not be liable for any dam-
age or re caused by the appliance resulting from
failure to follow instructions in this manual.
• Cooker hood is designed to remove cooking
odours. Do not use cooker hood for other pur-
poses.
• Connect the cooker hood operating in extraction
mode to a suitable ventilation duct (do NOT con-
nect the cooker to smoke or ue gas ducts, which
are in use). It requires installation of the air ex-
traction duct to the outside. The length of the
duct (usually a pipe of Ø 120 or 150 mm) should
not be longer than 4-5 m. An air extraction duct
is also required for telescopic and furniture hoods
in absorption mode.
• Cooker hood operating in air recirculation mode
requires the installation of an activated charcoal
lter. In this case, installing an extractor duct is
not required, however it is recommended to in-
stall an air guide vane (Mainly in chimney cooker
hoods).
• The cooker hood features independent lighting
and exhaust fan that can be operated at one of
several speeds.
• Depending on the type, the hood is designed to
be permanently attached to a vertical wall over
a gas or electric stove (chimney and universal
hoods); on the ceiling over a gas or electric stove
(island hoods); on the vertical built in furniture

- 8 -
over a gas or electric stove (telescopic and built-
in hoods). Before installing, make sure that the
wall/ceiling structure is strong enough to suspend
the hood. Some hoods are very heavy.
• For details of the installation distance above an
electric hob please refer to product technical
sheet If the installation instructions of the gas
cooker specify a greater distance, this must be
taken into account (Fig. 1).
• Do not leave an open ame under the hood.
When the pots are removed from the burner, set
the minimum ame. Always make sure that the
ame does not extend outside the pot, because it
causes unwanted loss of energy and a dangerous
concentration of heat.
• When cooking on fat, supervise the pans con-
stantly, because overheated fat can ignite.
• Unplug the appliance before any cleaning, replac-
ing the lter or repair work.
• Cooker hood grease lter should be cleaned at
least once a month, because the lter saturated
with fat is ammable.
• Ensure adequate ventilation (air ow) if other
equipment such as liquid fuel stoves or heaters
are operated in the room in addition the cooker
hood. When the cooker hood is simultaneously
operated with burning appliances requiring ade-
quate fresh air from the room to work properly,
their safe operation is possible if under pressure
around these appliances is a maximum of 0.004
mbar (this does not apply when the cooker hood
is used as an odour lter)
• Do not lean on the hood.
• The hood should be cleaned regularly both inside
and out (AT LEAST ONCE A MONTH, following the
indications concerning maintenance provided in
this manual)..Failure to adhere to the rules con-
cerning cleaning the hood and replacing lters

- 9 -
results in a re risk.
• If the power cord is damaged it should be re-
placed by a specialised service centre.
• Ensure that it is possible to disconnect the ap-
pliance from the mains by removing the plug or
switching o the bi-polar switch.
• This appliance is not intended for use by persons
(including children) with physical, mental or sen-
sory handicaps, or by persons inexperienced or
unfamiliar with the appliance, unless under su-
pervision or in accordance with the instructions
as communicated to them by persons responsible
for their safety.
• Particular attention should be paid not to allow
unaccompanied children to use the appliance.
• Make sure voltage indicated on the nameplate
corresponds to the local mains supply voltage.
• Before use, extend and straighten the power cord.
• Packaging materials (bags, polyethylene, poly-
styrene, etc.) should be kept away from children
during unpacking.
• Before connecting the hood to the mains power
supply always check that the power cord is prop-
erly installed and is not trapped by the appliance.
Do not connect the appliance to the mains until
assembly is complete.
• Do not operate your kitchen hood without the al-
uminium grease lters.
• It is strictly forbidden to cook dishes under on an
open ame (ambé) under your kitchen hood.
• Always strictly adhere to regulations issued by the
competent local authorities regarding the techni-
cal and safety requirements for fume extraction.
• Failing to tighten bolts and fasteners in accord-
ance with these instructions may endanger life
and health.
• Hanging kitchen hoods operate only in air circu-
lation / odour absorber mode

- 10 -
UNPACKING
During transportation, protective
packaging was used to protect the
appliance against any damage. Af-
ter unpacking, please dispose of all
elements of packaging in a way that
will not cause damage to the environ-
ment.
All materials used for packaging the
appliance are environmentally friendly; they are
100% recyclable and are marked with the appropri-
ate symbol.
Important! Packaging materials (bags, polyethyl-
ene, polystyrene, etc.) should be kept away from
children during unpacking.
DISPOSAL OF OLD APPLIANCE
In accordance with European Directive
2012/19/EU and Polish legislation re-
garding used electrical and electronic
goods, this appliance is marked with
the symbol of the crossed-out waste
container. This marking indicates that
the appliance must not be disposed of
together with other household waste
after it has been used.
The user is obliged to hand it over to waste collec-
tion centre collecting used electrical and electron-
ic goods. The collectors, including local collection
points, shops and local authority departments pro-
vide recycling schemes.
Proper handling of used electrical and electronic
goods helps avoid environmental and health haz-
ards resulting from the presence of dangerous com-
ponents and the inappropriate storage and process-
ing of such goods.
