WASHING MACHINE
Please read this User Manual carefully before using the appliance!
INSTRUCTION MANUAL EN
WA 14661 W

2
CONTENTS
Basic Information.......................................................................................................................3
Notes on Safety..............................................................................................................4
Installing the Washing Machine...................................................................................................7
Understanding the symbols on clothes labels................................................................9
Description of control panel.........................................................................................10
Using the appliance................................................................................................15
Table of programmes.........................................................................................16
Troubleshooting..................................................................................................................19
Maintenance and Cleaning.......................................................................................19
Practical tips on washing.....................................................................................................20
Specification......................................................................................................23
Product Fiche........................................................................................................24
In accordance with European Directive 2012/19/UE and Polish legislation regarding
used electrical and electronic goods, this appliance is marked with the symbol of the
crossed-out waste container.
This marking means that the appliance must not be disposed of together with other
household waste after it has been used. The user is obliged to hand it over to a waste
collection centre collecting used electrical and electronic goods. The collectors, inclu-
ding local collection points, shops and local authority departments provide recycling
schemes. Proper handling of used electrical and electronic goods helps to avoid
environmental and health hazards resulting from the presence of dangerous components and the
inappropriate storage and processing of such goods.

3
BASIC INFORMATION
From today, washing will be easier than ever before. The Amica washing machine combines
exceptional ease of use with excellent effectiveness. Once you have read the instructions,
operating the washing machine will not be a problem.
Before being packed and leaving the factory, the safety and functions of this washing machine
were carefully tested. These tests may have resulted in some damp or traces of water being
left inside the machine.
We ask you to read the User Manual carefully before switching on the appliance. Following
the directions in this manual will protect you from any misuse.
Keep this User Manual and store it near at hand. The instructions should be followed carefully
to avoid any unfortunate accidents.
Important!
This washing machine is intended for purely domestic use to wash textiles and clothes
which are designed to be machine washed in a detergent bath.
Before plugging the washing machine into the mains, remove the safety packaging and
ensure the machine is level.
The manufacturer reserves the right to introduce changes which do not affect the operation
of the appliance.
Use
lThe machine should only be used after the instructions below have been read carefully.
lNever use the machine outdoors or anywhere the temperature may fall below freezing.
lThe machine should not be operated by children or anyone who has not read the instruc-
tions.
Important! Temperatures below 0°C can damage the washing machine! In the event of the
machine being stored or transported in sub-zero temperatures, it should be left to acclimatise
in a temperature above zero for 8 hours before being used.
Manufacturer’s Declaration
The manufacturer hereby declares that this product meets the requirements of the follo-
wing European directives:
lLow Voltage Directive 2014/35/EC,
lElectromagnetic Compatibility (EMC) Directive 2004/30/EC
lErP Directive 2009/125/EC
and has thus been marked with the symbol and been issued with a declaration of com-
pliance made available to market regulators.

4
NOTES ON SAFETY
lDetergents
lLoading
the Machine
lControl
Panel
Use only those detergents and additives which
are designed for automatic washing machines,
especially when using the COTTON
programme. Do not use any agents containing
solvents, as these may damage certain parts of
the machine, or cause them to emit poisonous
gases. There may also be a risk of ignition and
explosion.
Ensure no unwanted objects are put inside the
appliance. Completely empty all pockets in the
clothing to be washed and fasten buttons and
zips. Place small, loose objects in a washing
bag, or inside a pillow case, as they may be
destroyed or else damage the drum or internal
tank. Do not exceed the recommended maxi-
mum load of washing.
Protect the control panel from water spillage.
Do not put washed clothes on top of the ma-
chine!

5
lTransport
lData Plate
lBurns
NOTES ON SAFETY
Unplug the machine before preparing the
machine for transport. Do not transport the
washing machine if drum locking bolts are not
in place. See the chapter INSTALLING THE
MACHINE. Keep the appliance in upright po-
sition when transported.
Data plate indicating basic information about
the washing machine is located at the top part
of the rear casing.
The door glass of your washing machine is hot
during operation. Do not allow children in the
vicinity of the appliance.
Checking stability
Once the washing machine is in position and levelled, it must
be checked to ensure it rests rmly on all four legs.
In order to check this, press down each corner of the ap-
pliance in turn to see if it moves. Safe, long-term and relia-
ble operation of the washing machine depends on it being
correctly positioned and level.
If the power cord is damaged, it should be replaced by
the manufacturer or specialist repair centre or a quali-
ed person in order to avoid danger.

6
Important! Level the appliance, remove the drum loc-
king bolts and wait 3 hours before using the appliance
for the rst time.
Important! Incorrect levelling, especially instability,
may cause the washing machine to move around du-
ring operation.
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the ha-
zards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by chil-
dren without supervision.
Children of less than 3 years should be kept away unless
continuously supervised.
DISPOSAL OF THE APPLIANCE
To ensure safety, the washing machine must be rendered
unsuitable for use once its useful life comes to an end. First
unplug it and then cut off the power lead. Scrap the appliance
in line with local waste disposal legislation.
“The wool wash programme used in this wash-
ing machine has been approved by Woolmark
for washing garments made of wool. They can
be washed in this washing machine, provided
that the products are washed according to the instruc-
tions on the garment label and the washing machine
operating instructions. M14111”.
NOTES ON SAFETY

7
INSTALLING THE MACHINE
I. Remove the protection used for transporting the appliance (keep the locking bolts
for future use, e.g. when moving house).
lUnscrew the 4 locking bolts with a spanner.
lRemove the rubber and plastic transport
brackets from the sockets along with the wa-
shers and bolts.
The locking bolts MUST be removed before the washing machine is used!
lStop up the holes with the stoppers
enclosed in the accessories bag.
lDo not place the washing machine on a carpet!
lThe oor surface should not be either concave or sloping!
lAttention should be paid to the shape of the surface of the oor, so that the
entire weight of the appliance rests on its legs (not its body)!
II. Positioning and levelling the machine
After positioning and levelling the machine,
check that it is stable by pressing down each
corner and ensuring it does not move!
lPlace the washing machine on a solid, even surface.
lLoosen the plastic washer (2)
lLock with washers (2)
lLevel the machine by adjusting the legs (1)
1
2

8
The drain hose is at the back of the
machine. Fix the drain hose so that it
does not move while the machine is
in operation (use the elbow as shown
below). Do not place the hose too deep
into the outlet pipe!
III. Connecting the water supply
IV. Water drain
A water supply hose with seals is inside the drum of the machine.
lOnly plug the machine into a properly installed socket
with an earth pin!
lDo not connect to an adaptor or an extension cord!
lIn the event of the power lead being damaged, it must be
replaced by an authorised technician.
lThe electrical system to which the appliance is to be
connected must be protected with a 10 A fuse.
INSTALLING THE MACHINE
Water pressure min. 0,03 MPa (0,3 bar), max.1 MPa (10 bar). Supply the machine
with cold water
lafter connecting, make sure the hose is not twisted
lafter connecting the hose and the valve, check they are sealed tight
lregularly check the condition of the supply hose.
Use the new hoses sup-
plied with the machine.
Do not re-use old hoses.
lThe appliance’s mains connection (electrical wall socket)
should be in a visible and accessible place!
max 100 cm
min 60 cm
V. Connecting the electric power supply

9
Detergent Drawer
Drum
P u m p  l t e r
cover
Door
handle
Control panel
■■
■
■
■
DESCRIPTION OF THE APPLIANCE
UNDERSTANDING THE SYMBOLS ON CLOTHES LABELS
Always pay attention to the symbols on garments’ labels
when choosing a washing setting.
I. Washing
II. Chemical cleaning
III. Spin dryer
boiling
temp. 900
normal
temp 600C
normal
temp 400C
DO NOT
wash!
delicate handwash
all
solvents
all
except TRI
petrol
only
DO NOT
dry clean!
normal low high DO NOT
dry!
IV. Ironing
1100C1500C 2000CDO NOT
iron!
90

10
DESCRIPTION OF CONTROL PANEL
7
34 5 6
45
+
■■ ■■■
■
8
■
78
+
■
1. Programme selector dial
2. Display
3. Delay Start button
4. Temperature selector button
5. Spin Speed button
6. Rapid Wash button
7. Extra Rinse additional function button
8. Pre-wash additional function button
4+5. Acoustic Signal On/Off
7+8. Child Lock
12
■
■

11
DESCRIPTION OF CONTROL PANEL
2. Display
During washing machine operation, the display shows the approximate time remaining
to the end of the wash cycle and the set spin speed. The display also shows symbols indi-
cating the washing machine door locked , spin , programme phase
Child Lock , acoustic signal activation , time remaining until the end of washing cy-
cle and additional functions selected
The displayed time is an estimate and may differ from actual wash cycle time, depend-
ing on temperature, water pressure, load size, quantity of washing powder used etc.
The time is automatically updated during wash cycle. Displaying the same time for an
extended period or abrupt changes are normal.
When Delay Start is selected the display also shows the time until the start of the wash
cycle and the symbol.
When adjusting the Spin Speed the display shows the following values:
400 - 600 - 800 - 1000 -1200.
3. Delay Start button
Press this button to set the delay time for starting washing. The setting range available
is from 1-24 hours. Press the button to set the time after which washing is to commence.
NOTE: If there is a power outage during Delay Time, countdown will resume immediately
after the power is restored.
4. Temperature selector button
This button allows the washing temperature to be set in different programmes. Press
this button to display water temperature settings available for a given programme or
an option for washing in cold water (no heating). Depending on the program selected,
the display shows the following setting options: - - °C (cold water) - 20°C- 30°C - 40°C-
60°C - 90°C.
5. Spin speed selector button
Press this button to set the spin speed when water is being pumped out of the wash-
ing machine. Press the button to change the setting. Depending on the programme
selected, the display shows the following values: 0 (no spinning)
- 400 - 600 - 800 - 1000 - 1200 - 1400.
1. Programme selector dial
Choose the appropriate wash programme as required, depending on the degree of soil,
and type and amount of laundry loaded, which ensures better results and more effective
washing. Once the cleaning programme is started, turning the programme selector knob
to another position is indicated by an acoustic signal however it does not change the

12
DESCRIPTION OF CONTROL PANEL
6. Rapid Wash additional function button
The Rapid Wash function reduces the total wash time saving money while reducing en-
ergy consumption and water consumption.
The function is recommended when washing lightly soiled laundry.
NOTE 1: The Rapid Wash function is not available for all programmes (see Table of wash
programmes).
7. Extra Rinse additional function button
The function is especially useful when washing underwear and also clothes for people
with sensitive skin. Select this option to add an extra rinse to wash cycle.
8. Pre-wash additional function button
The Pre-wash function extends the wash cycle by approximately 20 minutes. The laundry
is prewashed before the main wash cycle begins. Use the Pre-wash to achieve excellent
washing results without the need to soak the laundry. Pre-wash is recommended when
washing heavily soiled laundry. Pre-wash is carried out at a temperature of 30°C.
Important! The Pre-wash function is not available for all programmes (see Table of
wash programmes).
Important! Pour suitable detergent to detergent drawer marked with " " symbol before
the Pre-wash function is activated.
START/PAUSE button
Press Start/Pause to start or pause a programme.
During the washing cycle the corresponding programme phase symbol is ashing. In
Pause mode, the symbols do not ash and are lit up continuously. The Pause mode
can be used to soak the laundry.
Once the selected programme has started wait for about 10 minutes and then press
the Start/Pause button. When the laundry is soaked as required, press the Start/
Pause button again to resume the programme. Soaking will improve washing results
for heavily soiled laundry.

13
DESCRIPTION OF CONTROL PANEL
4+5. Acoustic Signal On/Off
The Acoustic Signal On/Off is activated by simultaneously pressing and holding: Tempera-
ture selector and Spin Speed buttons for about 3 seconds.
7+8. Child Lock
This function locks function buttons to prevent settings being changed or operation inter-
rupted by children. Pres and hold Extra Rinse and Pre-wash button for 3 seconds to ac-
tivate the Child Lock during a washing cycle. To release Child Lock during the cycle, hold
the same buttons down once more for around 3 seconds.
Important! If the Child Lock function is activated, the display will show the symbol.
Important! When you turn off or unplug the washing machine or the washing cycle ends,
the Child Lock function will not deactivate.
Select a favourite programme
To set the Favourite programme turn the knob on any programme and set temperature,
spin speed and additional functions. Then, press and hold down the Spin Speed for
about 3 seconds to conrm the Favourite programme setting. The default is the program
Cotton.

14
SPECIAL PROGRAMS
1. Allergy Safe programmes:
This programme is designed for washing clothes of children and people with sensitive
skin. Main wash is carried out at a temperature of 30°C (temperature setting: 40/30/20/--
"cold water"), followed by two rinses.
2. Colour Wash:
Standard wash programme. The default temperature setting is "cold water", the default
spin speed is 1000 rpm. The programme can be used for simultaneous washing of col-
oured fabrics, cotton, synthetics and linen.
3. Quick Wash 15':
Use these programmes to refresh clothes. They include all three wash stages:
- main wash
- rinse
- spin

15
USING THE APPLIANCE
II. Set Delay Start
The delayed start function may be used when, for example, taking advantage of dis-
counted electricity tariffs.
Procedure:
1. Close the appliance door.
2. Set the programme selector knob to the desired programme (see the table further on).
3. Select additional functions or wash cycle parameters as required.
4. Press the Delay Start button.
5. Select time ranging from 1 to 24 hours. The display will show the setting from 1h to
24h.
6. Press the [Start/ Pause] button. The appliance will be set in delay mode. Washing will
commence immediately after the delay time has elapsed.
Note: If you set delay start, the display will show the time remaining to start the washing
program.
III. End of the wash cycle
1. End of the wash cycle is indicated by acoustic signal (if active). The display shows 0:00
and the door lock indicator light goes out.
2. Turn off the water valve
3. Switch the machine off
4. Unplug the appliance from the mains.
5. Open the door and remove laundry.
IV. Cancel or modify programme
Press the On/Off button to interrupt the programme. Then select the desired wash pro-
gram again and press the Start/Pause button.
I. Select Programme
1. Set the programme selector knob to the desired programme (see the table further on).
2. Change temperature, spin speed or activate available additional functions to modify
the programme to your individual needs.
3. Press the Start/ Pause button

16
TABLE OF PROGRAMMES
* - standard programmes for washing cotton fabrics at 60°C and 40°C.
These programmes are suitable for washing normally soiled cotton fabrics. These are the most effective programmes for wash-
ing these type of fabrics, taking into account the total energy and water consumption.
Note: Real water temperature may differ from the declared wash cycle temperature.
NOTE: Above mentioned time is an estimate and may differ from actual wash cycle time, depending on temperature, water pressure, load size, etc. The time is automatically updated during wash cycle. Displaying the same time for an extended period or abrupt changes are normal. Use detergent or fabric softener if necessary, lDetergent required, without which washing will be ineffective. xDo not use detergent or fabric softener.
Item Programme name Max. temp.
[°C]
Max. spin
speed
[RPM]
Max.
load
[kg]
Additional functions available Detergent drawer Time
[h:min]
Energy
consump-
tion
[kWh]
Water
consump-
tion
[l]
Number
of rinses
Type of laundry
Delayed start
Rapid Wash
Extra Rinse
Prewash Prewash Main
wash
Fabric softener
1Cotton* 60° 1400 8.0 Option - - -
 l 
2:53 0.71 54 2 Moderately or heavily soiled cotton
clothes, bed linen, table linen, under- garments, towels, linen fabrics.
2Hand wash Cold water 600 2.0 Option - Option Option
 l 
1:00 0.16 26 2 Very delicate fabrics.
3Sport 40° 1400 4.0 Option - Option Option
 l 
0:45 0.57 38 2 Sportswear.
4Quick Wash 15’ Cold water 800 2.0 Option - - -
xl 
0:15 0.16 26 2 Lightly soiled, sweaty cotton and linen
clothes. Note: Due to the extra short wash cycle, less detergent is required com- pared to other programmes. The door can be opened about 2 minutes after the wash cycle has ended.
5Delicate 30° 600 2.5 Option - Option -
xl 
0:50 0.35 29 2 Very delicate fabrics, e.g. silk.
6Wool 40° 600 2.0 Option - Option -
xl 
1:07 0.44 26 2 Note: Do not machine wash woollen
fabrics if the garment label prohibits it.
7Rinse - - - Option - Option -
x x 
0:20 0.06 20 1 Rinsing with laundry additives, includ-
ing anti-static or softening additives. Reduce the spin speed when wash- ing very delicate fabrics.
8Spin - - - Option - - -
x x x
0:12 0.05 - - Spin-drying after hand washing.
9Drain - - - Option - - -
x x x
0:01 0,01 - - Drain water only - no spinning.
10 Colour Cold water 1000 4.0 Option Option Option -
 l 
1:10 0.18 62 2
Lightly soiled delicate synthetics, or synthetic and cotton blends.
11 Jeans 40° 800 8.0 Option Option Option Option
 l 
1:13 0.14 62 2 Dirty cotton, synthetics, coloured laundry,
linen fabrics.
12 Towels 60° 800 8.0 Option Option Option Option
 l 
1:45 0.86 62 2 Heavily soiled clothing, or an moder-
ately soiled cotton and linen for chil- dren that requires boiling.
13 Antiallergic 30° 800 8.0 Option Option Option Option
 l 
1:20 0.55 62 2 The program is designed for washing
clothes of people with sensitive skin, eg. for children.
14 Synthetics 40° 800 4.0 Option Option Option Option
 l 
1:40 0.58 38 2 Dirty cotton, synthetics, coloured
laundry, linen fabrics.
15 Shirts 40° 800 8.0 Option Option Option Option
 l 
2:40 0.81 62 2 Dirty cotton, clothing made from
synthetic fabrics or natural-synthetic fabric blends (shirts, blouses).
16 Favourite Depending on the settings The user can choose the most
convenient or most frequently selected programme and save it in the washing machine memory as a Favourite.

17
TROUBLESHOOTING
Problem Probable cause/Solution
The washing machine is not
working
- Turn the tap on
Clean the mesh lter on the supply hose.
- Close the door of the appliance.
Press the [Start/ Pause] button.
Water leaks - Connect the water intake properly.
The load in the appliance has not
been spun
- Replace the load evenly in the drum, clean the pump lter.
Unpleasant smell in the drum - Run a hot wash cycle with detergent and no load.
No water in the drum - Turn on the tap with the water supply.
There is water left in the fabric
softener container.
- Firmly press the button in the middle container
Washing not properly rinsed - Use the correct amount of cleaning agent, depending on how dirty
the washing is and the hardness of the water (see the instructions on
the cleaning agent’s packaging).
- Clean the pump lter
The appliance does not ll with
water
- Turn on the water valve
- Check the programme setting
- Check the water pressure
- Reconnect the water supply hose.
- Close the door of the appliance.
- Check the water intake is not bent or blocked.
Simultaneous intake and draining
of water
- Check that the end of the outlet hose is higher than the level of the
water in the appliance (the hose should be at a height of 0.6m to 1m).
Water outow problems - Check the pump lter
- Check the outlet lead
- Check the height of the outlet hose, which should be 0.6m to1m
from the bottom of the washing machine.
Appliance is vibrating - Check that the transport safety devices have been removed.
- Level the appliance
- Secure the legs (tighten the nuts).
Foam from the detergent drawer - Reduce the amount of detergent used.
- Check the water hardness and amount of detergent used, as well
as the type of detergent used in the drum.
The operation of the appliance is
interrupted before the programme
has nished
- Check power supply, water supply and water outlet.
Noise caused by operation of
the outlet pump after water is
removed
- The water has been removed from the drum, but small amounts
remain in the pump and outlet lead. Constant operation of the outlet
pump causes air to be sucked in leading to the characteristic noise,
which does not mean that anything is wrong.
Short breaks during the wash
cycle
- The water in the appliance is being automatically relled.
- Pause caused by removal of excess foam.

18
TROUBLESHOOTING
The fault indicator lights
The washing machine has a system of CODES shown on the display, which helps to locate
minor operating faults and identify their cause.
Fault is indicated by the symbols:
Display
indication
Reason Solution
Low pressure, no
water in the machine
Unscrew the water valve, check the water inlet hose and
lter, check the water pressure.
Improper water
outow
Make sure that drain hose is not clogged, check the
pump and water lter.
Door ajar Check that the door is locked; check that laundry is not
jammed in the door.
Others Try to restart or contact the SERVICE CENTRE.

19
Pump
lter
MAINTENANCE AND CLEANING
I. Cleaning the pump lter
Clean the pump lter every 20 washes
or so.
Neglecting to clean the lter causes dif-
culties in emptying the machine of water!
Never clean the product’s casing or plastic parts using solvents or strong, abrasive cleaning
agents (e.g. washing powders or creams)! Only use delicate liquid cleaning agents and soft
cloths. Do not use sponges.
lUnplug the appliance from the
mains,
lTurn off the water valve,
lOpen the lter cover by hand
or using a at-head screwdriver.
lUnscrew the lter. lRemove and clean the lter.
To replace the lter
following the pro-
cedure in reverse
order.
II. Cleaning the water supply valve
lTurn on the water supply hose,
lUse forceps to grasp the lter mesh plunger,
lRemove and clean the lter (using a brush).
III. Cleaning the detergent drawer (at least once a month).
lRemove the drawer (while pressing
the stop).
lClean in running water (or using a
brush or piece of cloth).
lReplace the drawer.
To replace the lter
following the pro-
cedure in reverse
order.

20
It is recommended to use powder or liquid general purpose
detergents for all temperatures in a range as per the deter-
gent Producer’s recommendations indicated on the product
packaging.
Detergents
lPour the detergent into the drawer compartment marked
lPour the pre-wash detergent into the drawer compartment
marked
Liquid detergents
lInstall the supplied partition in the compartment (gure
below).
lPour liquid detergent into the drawer compartment marked
Fabric softeners added to the rinse
lPour the fabric softener into the drawer compartment marked
lDo not exceed the maximum level marked on the drawer com-
partment. This detergent will be used for the nal rinse.
Before washing for the rst time, put it through one high tempera-
ture cycle without a load, according to the following procedure:
lConnect the washing machine to the electricity mains
lTurn on the water valve
lSet the programme selector knob to high temperature wash.
lAdd the appropriate detergent and press the [Start/ Pause]
button.
I. Cleaning and
purifying agents
II. First wash
Reducing energy and water consumption
Garments which are only lightly soiled should be washed using the
appropriate wash programme, i.e. ULTRA SHORT The washing
machine detects partial load. For partial load, when using the To-
wels and Cotton programmes, washing machine will reduce water
and energy consumption and shorten the wash cycle.
IV. Conservation
Stubborn stains
Before washing garments, apply an additional stain remover ac-
cording to the instructions for use
Heavily soiled:
lOne-off washing of smaller amounts of clothes
lAdd more detergent
lAfter washing heavily soiled clothes (e.g. working clothes) or
garments which are shedding bres, it is recommended that the
washing machine is rinsed out by running a programme cycle
at a temperature of 60°C, e.g. COTTON, without a load. Lightly
soiled:
lSee pt. „Conservation”.
III. Soil
PRACTICAL ADVICE REGARDING WASHING
