Amico R-hma-vc-u110220 User manual

Installation Instructions

110V ~ 220V Voltage Converter

2 Amico Accessories Inc.

Preface

Important, Please Read Carefully

Thank you for your purchase with Amico.

This unit is designed for long lasting performance, providing the end user complies with assembly and maintenance

procedures. This Instruction Manual is your guide to ensure that you get the best performance out of the equipment.

Amico Accessories Inc. is not responsible for any damage as a result of (but not limited to) abuse and other problems

that may be a direct or indirect result of failure to comply with the instructions provided in this manual.

Please Note these Key Words and Symbols

WARNING: Steps where extra care should be taken to prevent injuries and damage.

NOTE: Steps that point out helpful information.

Medical Facility Responsibilities

Preventive maintenance checks must be performed regularly to maintain the quality and performance of this product.

Any parts that may be broken, missing, worn, distorted, or contaminated in any way should not be used and all

affected parts should be replaced immediately. Should the necessity of any repair be suspected; please contact your

local distributor or call 877-264-2697.

www.amico.com 3

Table of Contents

Section 1: Specifications 4

Section 2: Installation Preparation 4

Installation Tool Requirements 9

Section 3: Installation 5-8

Section 4: Troubleshooting, Preventative Maintenance, Storage, & Cleaning 9-10

Troubleshooting 9

Storage 9

Preventive Maintenance 9

Cleaning 10

Warranty Policy 11

4 Amico Accessories Inc.

Section 1: Specifications

Section 2: Installation Preparation

Maximum power: 180 watts

Input: 100 - 120V

Output: 220 - 240V

Frequency: 50/60Hz

Product size: 8.5" W x 6.0" D x 2.1" H (215 mm W x 153 mm D x 52 mm H) excluding cord

Product weight: 4 lbs (1.8 kg)

Installation Tool Requirements

NOTE: Please ensure that your contents match the list as outlined below. If not, please contact Amico

Accessories Inc. at 1-877-264-2697.

WARNING: It is the installer’s responsibility to ensure all components are properly assembled and installed

using the provided instruction manual.

WARNING: Always use locks on casters when equipment is not in use to prevent unwanted movement. The

list below includes all parts required for installation. Please check the contents of your package to ensure all

parts are included. If any hardware or parts are missing, please contact Amico Accessories Inc.

The pictures below show the box contents. Please note the pictures are for reference only. Content or layout may vary

depending on model selection.

Manufacturer Part Number Part Description Quantity

R-HMA-VC-U110220 UMI power convertor 1

R-HMW-AC-PWR-BAR-UNV-F Power cord 1

X-HMW-VC-UMI-CAP UMI voltage converter standoff - HMW 4

X-HMW-WT-MBASM-RS-CAP Reset switch cap 2

H-DUAL-LOCK-CN Dual lock square 16

www.amico.com 5

1. Open the battery compartment cover by placing the magnetic key to the designated spot and pull up the cover

(Figures 1 and 2). See Hummingbird Cart User Manual for details.

2. Disconnect the yellow Anderson 6331G8 connector. (Figures 3 and 4)

3. Unlock and flip open the work top to access the interior of the main bin. See Hummingbird Cart User Manual for

details.

Section 3: Installation

Figure 1 Figure 2

WARNING: The following steps must be performed by authorized personnel.

WARNING: The battery compartment should be accessed by Amico approved service personnel only.

Unauthorized access could result in injury or damage to the power system.

WARNING: Risk of explosion if the battery is operated incorrectly.

WARNING: Ensure that the key is turned counterclockwise before attempting to close the worksurface.

Failure to do so could lead to damage to the worksurface and/or the locking mechanism.

Figure 3 Figure 4

6 Amico Accessories Inc.

Section 3: Installation

4. Unplug the C13 connector from the power bar. (Figures 5 and 6)

5. Plug the C13 connector into the Voltage

Converter. (Figure 7)

6. Insert the main bin standoff caps into the slot into the work top. (Figures 8 and 9)

7. Tape the dual lock squares onto the main bin standoff caps. (Figures 10 and 11)

Figure 10 Figure 11

Figure 7

Figure 5 Figure 6

Figure 8 Figure 9

www.amico.com 7

8. Align the dual lock squares on the bottom of the Voltage Converter with the dual lock in the main bin. (Figure 12)

Put the Voltage Converter in a position as close as possible to the top (Figure 12) and press firmly to engage the

dual lock.

9. Turn on the power by pressing the switch on the back of the converter. (Figures 13 and 14)

10. Replace the adaptor cable on the universal power bar. (Figures 15 and 16)

Section 3: Installation

Figure 12

Figure 15 Figure 16

Figure 13 Figure 14

8 Amico Accessories Inc.

11. Estimate the position of the power bar. Put the dual lock on the side of the universal power bar. (Figure 17)

12. Put the universal power bar in position and press firmly to engage the dual lock.

13. Connect the power bar. (Figure 18)

14. Connect the yellow Anderson 6331G8 connector in the battery compartment. (Figure 19 and 20)

15. Place the battery compartment cover back and lock the compartment.

Section 3: Installation

Figure 19 Figure 20

Figure 17

Figure 18

www.amico.com 9

Section 4: Troubleshooting, Preventative Maintenance,

Storage, and Cleaning

Troubleshooting

Symptom Possible Cause Solution

No voltage output while the

indicator light is not on

Input power cord is not plugged in Plug in the power cord

Input power cord is damaged Change to a new power cord

Power switch is not turned on Turn on the switch

Tube fuse is damaged Replace with a new but same

type tube fuse

No voltage output while the

indicator light is on

Power cord of the appliance isn’t

plugged in Plug in the power cord

Output socket is damaged

Send the product back to

the original manufacturer to

replace the socket

Transformer overheating protection

The power will be automatically

restored after half an hour

when transformer cools down

The body shell becomes hot when

using for a while

The socket has no output voltage

The power of the appliance exceeds

the rated power of the transformer

Change for a higher rated

power transformer

Storage

Do not place the transformer in any damp place or position where it may be dripped on. It should be stored in a

ventilated and dry place.

Preventive Maintenance

WARNING: The intervals shown are recommended. Maintenance schedules should be more frequent for

higher use areas.

It is recommended that once every month connections and components be visually inspected for signs of product

wear and tear or damage. Check the product for looseness in the mount or orientation, and ensure the power cord

and power bar are secured in the main bin.

10 Amico Accessories Inc.

Section 4: Troubleshooting, Preventative Maintenance,

Storage, and Cleaning

Cleaning

WARNING: The cleaning chemicals and methods below are not meant for controlling any infections. It shall

be the responsibility of the hospital or the hospital’s infection control officer to sanitize the equipment.

WARNING: Please do not spray any chemicals directly onto the Voltage Converter. Apply onto a soft cloth and

wipe clean to prevent chemicals from getting into the internal components of the Voltage Converter.

The mounting assembly may be cleaned with most mild, non-abrasive solutions commonly used in the hospital

environment (e.g. diluted bleach, ammonia, or alcohol solutions). The surface finish will be permanently damaged

by strong chemicals and solvents such as acetone and trichloroethylene. Steel wool or other abrasive materials

should never be used. Damage caused by the use of unapproved substances or processes will not be warranted. It is

recommended that you test any cleaning solution on a small area of the Voltage Converter that is not visible to verify

compatibility. Never submerge the Voltage Converter and do not allow liquids to enter it. Wipe any cleaning agents off

of the Voltage Converter immediately using a water-dampened cloth. Dry the Voltage Converter thoroughly after.

No Acetone

Acetone is a colorless, mobile,

flammable liquid

No Trichloroethylene

Trichloroethylene is a chlorinated

hydrocarbon commonly used as an

industrial solvent

Acetone Trichloroethylene

www.amico.com 11

www.amico.com

Amico Accessories Inc. warrants all mounting accessories to be free from defects in material and workmanship for a period of

twelve (12) months from the date of shipment. Within this period Amico Accessories Inc. will repair or replace any part which is

proven to be defective.

Amico Accessories Inc. will warrant its materials to be free from defect for an additional period of four (4) years, (five [5] years from

the date of shipment). Within this period, Amico Accessories Inc. will replace any part which is proven to be defective, at no charge.

Shipping and Installation costs after the first twelve (12) months will be borne by the Customer.

This warranty is valid only when the product has been properly installed according to Amico Accessories Inc. specifications, used

in a normal manner and serviced according to factory recommendations. It does not cover products that are not manufactured by

Amico Accessories Inc. It does not cover failures due to damage which occurs in shipments or failures which result from accidents,

misuse, abuse, neglect, mishandling, alteration, misapplication or damage that may be attributable to acts of God.

Amico Accessories Inc. shall not be liable for incidental or consequential damages resulting from use of equipment.

All claims for warranty must first be approved by Amico Accessories Inc. A valid Return Goods Authorization (RGA) number must

be obtained from Amico Accessories Inc. prior to commencement of any service work. Warranty work, which has not been pre-

authorized by Amico Accessories Inc., will not be reimbursed.

AMICO ACCESSORIES INC. DOES NOT HONOR VERBAL STATEMENTS CONCERNING THE WARRANTY.

The distributor and/or dealer are not sanctioned to create verbal warranties about the product described in this agreement. Any

statements will not be honored or be made part of the agreement of sale. This document is the final complete and exclusive terms

of the agreement.

THIS WARRANTY IS INCLUSIVE AND REPLACES ALL OTHER WARRANTIES.

Amico Accessories Inc. shall not, under any circumstances be liable for incidental or consequential damages including, but not

limited to, profit, loss of sales or injuries to person(s) or property. Correction of noncompliance as noted above will result in

completion of all liabilities of Amico Accessories Inc., whether based on agreement, neglect or changed materials, designs or

specifications without notice.

All claims for warranty must first be approved by Amico Accessories Inc. Service Department: accessories@amico.com or

1.877.264.2697. A valid Return Goods Authorization number must be obtained from Amico Accessories Inc. prior to commencement

of any warranty claim.

Amico Accessories Inc. | 85 Fulton Way, Richmond Hill, ON L4B 2N4, Canada

Tel: 905.763.7778 | Fax: 905.763.8587

Warranty Policy - Equipment Mounting Solutions

AA-WARRANTY 08.16.2017
