Amiko T765 User manual

1
CONTENTS
1. SAFETY.............................................................................................................................................................3
2. INTRODUCTION.............................................................................................................................................4
3. FEATURES........................................................................................................................................................4
4. REMOTE CONTROL......................................................................................................................................5
5. FRONT PANEL ................................................................................................................................................6
6. REAR PANEL...................................................................................................................................................6
7. CONNECTING YOUR SYSTEM ...................................................................................................................6
8. BASIC OPERATIONS .....................................................................................................................................8
8.1 TURN ON STB...................................................................................................................................................8
8.2 POWER..............................................................................................................................................................8
8.3 CHANNEL UP/CHANNEL DOWN........................................................................................................................8
8.4 VOLUME UP/VOLUME DOWN-..........................................................................................................................8
8.5 NUMBER...........................................................................................................................................................8
8.6 MUTE ...............................................................................................................................................................8
8.7 PAUSE...............................................................................................................................................................8
8.8 RECALL ............................................................................................................................................................8
8.9 FAVORITE.........................................................................................................................................................8
8.10 AUDIO...........................................................................................................................................................9
8.11 INFORMATION...............................................................................................................................................9
8.12 EPG..............................................................................................................................................................9
8.13 TV/RADIO.................................................................................................................................................10
8.14 CHANNEL LIST............................................................................................................................................10
8.15 SLEEP..........................................................................................................................................................11
8.16 PAGE UP/PAGE DOWN ................................................................................................................................11
8.17 TEXT .........................................................................................................................................................11
8.18 SUBTITLE ....................................................................................................................................................11
8.19 FIND............................................................................................................................................................11
8.20 ZOOM..........................................................................................................................................................11
8.21 TV/STB......................................................................................................................................................11
8.22 MENU..........................................................................................................................................................11
8.23 VIDEO FORMAT...........................................................................................................................................11
8.24 EXIT............................................................................................................................................................12
9. SERVICE.........................................................................................................................................................12
9.1 ORGANIZING SERVICE ....................................................................................................................................12
9.2 ORGANIZING FAVOURITES..............................................................................................................................14
10. INSTALLATION ............................................................................................................................................14
10.1 TERRESTRIAL INSTALLATION......................................................................................................................14
11. SYSTEM ..........................................................................................................................................................15
11.1 LANGUAGE .................................................................................................................................................15
11.2 A/V CONTROL ............................................................................................................................................15
11.3 TIME SETTING.............................................................................................................................................16
11.4 TIMER .........................................................................................................................................................17
11.5 PARENTAL CONTROL ..................................................................................................................................18
11.6 MISCELLANEOUS SETTINGS ........................................................................................................................19
11.7 SOFTWARE UPGRADE..................................................................................................................................19
11.7.1 Upgrade By USB ....................................................................................................................................19
11.7.2 Backup to USB........................................................................................................................................19
11.7.3 Upgrade By Terrestrial: .........................................................................................................................20
11.8 DEFAULT SETTING......................................................................................................................................20
11.8.1 Default Value:.........................................................................................................................................20
11.8.2 Delete All Channel: ................................................................................................................................20
11.8.3 Save default value...................................................................................................................................21
11.9 INFORMATION.............................................................................................................................................21
12. MEDIA (OPTIONAL) ....................................................................................................................................21

2
12.1 RECORD ......................................................................................................................................................21
12.2 MOVIE ........................................................................................................................................................21
12.3 MUSIC.........................................................................................................................................................22
12.4 IMAGE.........................................................................................................................................................23
12.5 PVR SETTING .............................................................................................................................................24
12.6 DISK MANAGE ............................................................................................................................................25
12.7 REMOVE USB DEVICE SAFELY!..................................................................................................................25
13. GAME (OPTIONAL)......................................................................................................................................25
13.1 TETRIS ........................................................................................................................................................26
13.2 SNAKE.........................................................................................................................................................26
13.3 OTHELLO ....................................................................................................................................................26
14. EPG...................................................................................................................................................................26
15. NEW FEATURES...........................................................................................................................................26
15.1 EQUALIZER .................................................................................................................................................26
15.2 TIME SHIFT .................................................................................................................................................26
15.3 RECORD ......................................................................................................................................................27
16. TROUBLE SHOOTING.................................................................................................................................28
17. SPECIFICATIONS.........................................................................................................................................29

3
1. SAFETY
This HD Receiver has been manufactured to satisfy the international safety standards.
Please read the following safety precautions carefully.
MAINS SUPPLY:100~240V AC, 50/60Hz
OVERLOADING: Do not overload wall outlet, extension cord or adapter as this may result in fire or
electric shock.
LIQUIDS: Keep liquids away from the HD Receiver. The apparatus shall not be exposed to dripping
or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
CLEANING: Disconnect the HD Receiver from the wall outlet before cleaning .Use a light damp cloth
(no solvents) to dust the HD Receiver.
VENTILATION: The slots on top of the HD Receiver must be left uncovered to allow proper airflow to
the unit. Do not stand the HD Receiver on soft furnishings or carpets. Do not expose the HD Receiver
to direct sunlight or do not place it near a heater. Do not stack electronic equipments on top of the HD
Receiver.
ATTACHMENTS: Do not use any attachments that are not recommended as these may cause
hazard or damage the HD Receiver.
LOCATION: Place the HD Receiver indoor in order not to expose to lightening, rain or sunlight.
European Union Directive on Waste Electrical and Electronic Equipment (WEEE)
This symbol applies to European countries only and indicates that the equipment
carrying this mark must NOT be thrown into trash. At the end of its useful life, always
dispose of E-waste in a manner which is consistent with local laws and regulations.
For more information on the EU WEEE Directive, please see
http://ec.europa.eu/environment/waste/weee_index.htm

4
2. INTRODUCTION
Thank you for purchasing the HD Receiver.
This HD Receiver is fully compliant with the international DVB standard and thus transmits digital
images, sounds, information guides and teletext directly to your TV through the satellite broadcasting.
Now you can comfortably see and receive digitally transmitted music, news, movie and sports satellite
broadcasts in your office or at your home. You can enjoy interesting games embedded in HD
Receiver.
In service search section, both the automatic service search method and the manual search mode
are provided. You can save up to 6000 TV and Radio services and work around with the favorite,
Lock, Delete, Move and Sort functions.
The menu is very modern and supports multiple languages. All functions can be carried out using the
remote control and some of the functions can also be carried out using the front panel. The HD
Receiver is easy to use and adaptable for future advances. Please be aware that new software may
change the functions of the HD Receiver.
If you have any difficulties concerning the operation of your HD Receiver, please refer to the relevant
section of this manual, including the ‘Troubleshooting’. This Manual will provide you with useful
information on using the HD Receiver.
3. FEATURES
⚫6000 channels (TV and Radio) programmable
⚫Multilingual menu text support
⚫Channel switching time less than 1 second
⚫Channel list editing
⚫Favorite channel list editing
⚫True-color On-Screen Display (OSD)
⚫Full Picture In Graphic (PIG) function
⚫Electronic Program Guide (EPG) for on screen channel information
⚫Subtitle supported
⚫Teletext supported by VBI insertion and software emulation
⚫Parental lock facility by channel and program event
⚫Exciting games embedded
⚫Dolby Digital Bit-Stream output via HD OUT
⚫HD OUT Full HD (1080p) Video/Audio Output
⚫USB 2.0 Host
⚫RTC (Real-Time-Clock)
⚫Time Shift
⚫Video Recording
⚫Recording one channel and TimeShifting another channel (optional)

5
4. Remote Control
POWER
To switch your receiver on from standby or standby to on.
MUTE
Used to enable or disable the audio
NUMERIC KEYS
Used to select channels or enter programming parameters
TV / RADIO
Receiver switches between TV and Radio mode.
(ZOOM)
Press key select zoom times, from X1 to X16.
(RECALL)
Return to the previous menu or status.
(AUDIO)
Audio channels setup, to select audio mode; Left, Right , Stereo,
Mono.
INFO
To display channel status or various programme information of
current service.
EPG(Electronic Programme Guide)
Display the Programmes guide on screen when available.
MENU
Displays the Main Menu on the screen, or return to the previous
menu or status.
EXIT
Cancel the user selection and return to the viewing mode from a
menu.
OK
To select menu option, or to updated on entry.
VOL-, VOL+ KEY
To adjust volume level, or to move cursor left or right in the menu.
CH-, CH+ KEY
To change channels, or to move cursor up or down in the menu.
PAGE+/PAGE-
To move up the cursor to the next or previous page
in the menu or channel list.
Red Key
Has different functions per menu.
TTX(GREEN KEY)
Shows teletext information of the current channel supports.
SUBTITLE(YELLOW KEY)
Subtitle Display.
(FIND)
Use to prompt find channels sort by character.
FAV(FAVOURITE)
To set receiver to the favourite server mode,
display the favourite channel.
Archive
Press this button to enter the File Manager menu directly.
Play
To play the MP3, JPEG or recording file, or start timeshift function.
Stop
To stop MP3/JPEG player, recording file , Time Shift, or playback.
Record
To start recording.
Fast Backward
To start Fast Backward function.
Fast Forward
To start Fast Forward function .
V.FORMAT
Press VFORMAT button to switch the display mode among "Auto-> by native TV<->1080i->1080p etc.
TV/STB
Receiver switches between TV and receive mode.

6
5. Front panel
Remote Sensor: Detects infrared signal from remote control unit.
POWER Indicator: Lit whilst the receiver is powered on and at standby mode.
Signal Indicator: When received signal is strong, the signal indicator is lit.
USB: USB 2.0 Host, connect to USB hard disk, or flash disk (on the right side of the receiver).
Display: (LED type) Indicates operating status of receiver
Buttons: (Standby, CH-, CH+) to operator the receiver.
6. Rear Panel
DC 5V:This is used to connect an external 5V adapter.
TV: This is used to connect your TV through SCART cable.
HD OUT: Audio and Video output socket for TV set with HDMI Input Jack only.
RF IN: This port is to connect the coaxial cable from Terrestrial/CableAntenna.
7. Connecting Your System
There are two ways to connect the receiver to your existing TV system. We recommend using one of
the following cases for the best result:
1. If you have a high definition television set, you should use a HDMI cable for best result, Plug one
end of the cable into the HD OUT socket on the receiver, and the other end into the matching socket
on your television. In this case, you do not have to make audio connections because the HD OUT
connector can output stereo audio or Dolby Digital audio.
2. Connect one end of SCART cable to the SCART jack on the back of the receiver and the other end
to a SCART jack on your TV.

7

8
8. Basic Operations
8.1 Turn on STB
First, connect to an external 5V adapter to turn on
the unit.
When the STB is first used, there will play the first
channel from the default Channel List. If the STB is not
first used, STB will play the same channel as last time
before turning off.
? Frequently Asked Question
Q: The power of my STB has been turned on and not
in Standby mode, but the TV screen showed
nothing:
A: Make sure the TV set has been set to the correct
video input (not the TV channels). For example, if you
have connected the unit with the Video1 input of the TV
set, the TV set has to be switched to Video1.
Q: The power of my STB has been turn on and not in
Standby mode, but the TV screen showed
nothing except one box with “No Signal”image.
A: That means the channel, which you select, is no
signal. It could be several causes:
1 The channel which you select is not in your signal.
The simply solution is to change channel.
2 The signal of current TV channel is too weak. You
can try to change channel to other strong signal
channels. If the problems still exist, please consult
your local dealer or other professionals for
technical service.
8.2Power
1 Press [Power] Key can enter the Standby state
2 In Standby state, press [Power] Key again can call
back the unit and go on play the previous channel
3 User can also disconnect the device’s main power
to end the Standby state.
8.3 Channel Up/Channel Down
In full screen, press [CH+/CH-] to change channel.
8.4 Volume Up/Volume Down-
In full screen, press [VOL+/VOL-] to adjust volume.
8.5Number
In full screen, use number key and press [OK] on the
Remote Control Unit to change channel.
8.6Mute
1 Press [MUTE] key to mute the sound and the
screen will show up mute OSD.
2 Press [MUTE] key again to restore sound.
8.7Pause
1 In playing mode, press [Pause] key, the picture will
be paused, but the sound of the channel will still
continues.
2 Press [Pause] key again, the screen’s picture will
skip over to the current playing picture, and the
sound of the channel will corresponding playing.
8.8 Recall
Press [RECALL] key will directly switch to the previous
channel that you played before current channel.
8.9 Favorite
1 In full screen, press [FAV] key, it will display a
window of “Favorite list” on the left of the screen,
which you can watch like below.
2 In the window of " Favorite list ", you can move
highlight by press [Channel Up/Channel Down]
key to select favorite Channels.
3 In the window of ” Favorite list ", you can press
[Left/Right] key to select favorite groups Pressing
[P-/P+] keys can implement the “Page up/Page
down”function
4 Press [Exit] key to exit the current window.
? Frequently Asked Question

9
Q: Why the screen displays “No Favorite Channel”,
after pressing [FAV] key?
A: It is because that you haven’t set any channels as
“favorite channel”. Please refer to Favorite
.
8.10 Audio
1 In full screen, press [AUDIO] key can open the
“Audio”window on the screen.
2 You can modify the audio track by press [Channel
Up / Channel Down] key and modify the audio
mode by press [left/right] key.
3 Mode: Left/Right/Stereo/Mono
8.11 Information
In full screen, press [INFO] key (press [INFO] key and
[RED] key) can open information screen, in the
window showsthe parameters of current channel.
8.12 EPG
1 The STB has an Electronic Program Guide (EPG)
to help you navigate channels through all the
possible viewing options. The EPG supplies
information such as channel listings and starting
and ending times for all available channels.
Press [EPG] key to display EPG screen.
2 Press [Red] key can select the channels by
different group, such as by
Favorite/Satellite/Provider/CAS etc.
3 Press [Green] key to select different display mode
among Now EPG, Next EPG, More and Schedule,
like the following picture:
4 Press [Yellow] key in EPG menu can set one
record timer or go to Timer List menu.
