Ammonite System LED SOLARIS NextGen User manual

MANUAL

UMBILICAL LIGHT

THANK YOU FOR CHOOSING
AMMONITE SYSTEM
We are hopeful that your experience with Ammonite System
products will be smooth and flawless. To ensure that please
read this manual and follow the rules within.
For any questions please check our website
www.ammonitesystem.com, contact us by e-mail or our
fanpage on Facebook.
PURPOSE
Ammonite System LED SOLARIS NG is a universal umbilical dive
light for use as the main light source during recreational diving,
technical diving and underwater works.
LED SOLARIS NG is designed for underwater use. However, it is
possible to use the headlight on the surface for a very limited
time in the LOW and OPERATIONAL modes.
Always avoid sudden cooling of LED SOLARIS NG light.
Do not immerse hot headlight in the water as it may cause
its damage.
Before using the LED SOLARIS NG, its tightness should be
checked,i.e.ifallthepartstightenedwiththeo-rings arecorrectly
screwed and whether the connecting cable is properly tightened.
O-rings cannot be soiled, any damage such as: scratches,
cracks and cuts may cause leaks and in the consequence lead
to the light damage.
The casing of the LED SOLARIS NG is made from aluminium and
polymer (Delrin®); tempered glass, PVC and NBR rubber were
used as auxiliary materials.
Electrical, electronic parts placed inside, might be also harmful
to the environment.
The symbol placed on the product or on its package indicates
that this product cannot be treated as household waste.
It should be handed over to the applicable
collection point for the used up electrical and
electronic equipment.
By providing a proper storage you may prevent
dangerous consequences to the environment and
human health.
Recycling helps to preserve natural resources.
For more information about recycling of this
product, please contact your local authorities
or authorities responsible for environment protection, your
household waste disposal service or the shop where the
product was purchased.
At the end of the use the battery should be placed in a special
container or brought to a collection point for the recycling of
electrical and electronic equipment.
In order to do this please read current environment protection
regulations.
LIGHT INTENSITY CONTROL
LED SOLARIS NG is equipped with the switch that enables to
regulate the light output and operating time.
LED SOLARIS NG is also equipped with battery discharge
warning system.
This enables optimal light output and operating time management
due to the water visibility and planned length of the dive.
It also extends the operating time when the battery is low
raising diving safety.
Before switching the light on you should connect the battery to
the head and then turn the knob.
When the knob changes its position, it can be felt like a
specific click. Switching the torch off should be done in a similar
way. The knob can be turned in both directions.

LED SOLARIS NG light has three output intensity levels of:
LOW – 20 % light output
the lowest energy consumption, the longest working time
OPERATIONAL –60% light output
optimal energy consumption and working time,
recommended in most conditions
BOOST – 100% maximum light output,
maximum energy consumption, the shortest working time
BATTERY DISCHARGE
WARNING SYSTEM
When the battery is discharged to the
10% level the light flashes repeatedly for
a few times and then, regardless of the
switch position, headlight operates only in LOW mode (20%
of light output).
In such case the battery needs to be changed or
recharged. Further use of LED SOLARIS NG in LOW
mode is possible until the battery is completely
discharged.
FASTENING OF THE HEADLIGHT
Ammonite System LED SOLARIS NG is intended to be kept in the
hand with or without Goodman’s handle.
Thanks to Goodman’s handle both hands are free during
diving. However, depending on the diver’s individual preferences,
a different way of fastening of the torch is possible.
You can attach a bolt snap to a dedicated slot on a Goodman’s
handle or you may also attach a bolt snap with a piece of a
string on the dedicated groove on the cable plug.
By default, the Ammonite System umbilical light accumulator
is on a standard basis fastened to a hip belt on the right side
of the harness.
Details concerning different ways of fastening and additional
handles are available on www.ammonitesystem.com

TRANSPORT
Ammonite System umbilical dive lights are recommended
to be transported with the headlight and battery apart.
This way potential fire hazard is prevented.
During air travels, it is suggested to carry the torch as hand
luggage. Ammonite System dry carry bag is recommended for
this purpose.
Transport of electric devices with rechargeable batteries is
regulated by separate regulations.
You are asked to familiarize yourself with them especially before
the air travel or to contact the carrier’s authorised representative.
CHARGING
To charge Ammonite System umbilical dive light do not use
chargers that were not originally delivered by Ammonite System.
Chargers delivered by Ammonite System are designed
for special types of batteries due to their capacity, voltage,
construction and the special type of cells.
Using the charger which is not designed for the specific battery
may cause its damage and the loss of warranty.
To charge the battery you should unscrew the cable’s plug from
the battery tank.
The charger should be plugged in the socket, the charger’s
cable should be connected to the Chinch type connection
terminal in the battery.
Permissible parameters of the mains and the type or capacity of
the batteries, which the charger is designed for, are described
in the attached charger manual.
PRECAUTIONS
The umbilical light is a very strong source of light!
Avoid looking directly into the beam.
The intensity of the beam may cause the damage of the eye retina.
The headlight is also the source of the UV radiation - avoid
prolonged exposure.
The headlight is not a toy! Keep out of reach of children!
Ammonite System guarantees the tightness of LED SOLARIS NG
to the pressure of ~309 PSI / 21 atm, which is equal
656,16ft / 200 m depth.
To ensure safety while diving observes depths limits and do not
dive beyond the limits you are authorised to.
While in operation, the headlight may reach high temperatures.
While in use above the surface, only for a very short time, be
careful, do not touch the glass after switching off, do not cool
down suddenly.
Leaving the headlight on without supervision or switching it on
accidentally may cause a fire.
Do not use the headlight in case of visible damage of the O-rings
sealing the casing or the connecting cable, damage of the
connecting cable, the glass of the head or any other damages.
Periodic monitoring of the o-rings condition in the headlight and
the tank is highly recommended.
O-rings of the headlight, connecting cable and accumulator,
unless the plug was unscrewed (f.e. during battery charging)
should be checked before every single diving.
There is no necessity to unscrew the connecting cable from the
headlight unless it is dictated by the necessity to change the
cable or the headlight.
Every few dives it is recommended to smear o-rings of the
connecting cable with silicone grease.
O-rings provide tightness, as long as they are not dirty or
damaged (scratched, cracked, dried–up).
Ammonite System ensures the tightness of the headlight only
in case of use of o-rings with the measurements specified by

the producer as proper for a particular type of torch.
Part of the electronics is protected by a special compound and
is not accessible to the user, which means it may be repaired or
changed only by Ammonite System authorised service.
Do not use the torch in case of water entering the
headlight or battery.
Water in the headlight indicates that the o-rings have been
dirty or damaged.
A cable connecting the headlight with the battery tank maybe
damaged as well.
In such a case, you should check the state of o-rings and the
connecting cable.
If necessary, o-rings should be replaced.
If the headlight, cable or battery is damaged despite the
replacement of o-rings, please contact Ammonite System for
proper service.
Protect the batteries from the temperature above
104 °F / 40 °C.
Do not charge in the sun or near the other sources of heat, do
not freeze and do not throw into the fire.
Ammonite System is not liable for any damage or
defects resulting from the usage of the dive light for other than
intended use.
GENERAL RULES FOR THE USE OF
AMMONITE SYSTEM DIVE LIGHT
Preparation:
• check the battery level before diving
• check for dirt or damage to the lamp head o-rings and the
terminals on the battery tank
• properly screw the cable to the headlight as well as to the
battery tank
• check if the lamp head works by switching it on and off
•always have an alternative light source (backup light)
Maintenance after diving:
•rinse the reflector and battery tank with fresh water
without unpluging batery tank from headlight
•dry the dive light set
•the head and battery must be absolutely disconnected
during storage and transport to prevent accidental switching on
•the cable plug should be disconnected from the battery side
while leaving it screwed to the headlight
•clean the equipment regularly
•wipe the front glass of the head with a soft, damp cloth
ATTENTION!
It is recommended to read additional information concerning
the safety regulations and use of Ammonite System dive
light equipment and the rules of safe diving with additional dive
lights on www.ammonitesystem.com
ACCU TYPE 9 3h 10’ 1h 55’
ACCU TYPE 10 3h 30’ 2h 05’
ACCU TYPE 14 4h 10’ 2h 30’
ACCU TYPE 24 8h 05’ 4h 50’
OPERATING TIME:
MODE OPERATIONAL BOOST

light intensity up to 4500 lm
light distribution 6°
type of optics 5 x reflectors
total power 50 W
light source 5 × LED CREE® XPL
colour temperature cool white
power source external
rechargeable battery
material hard annodised
aluminium /DELRIN®
magnetic switch
switch type 3 levels of light intensity
discharge warning message
backup mode
max. length 117 mm
max. diameter 61 mm
front glass 6 mm tempered
weight 340 g
weight in water 130 g
max.operation depth 200 m
SPECIFICATION:
