Ampetronic Loopworks R1 User manual

5. Calibrate Receiver
Follow the on-screen instructions to
calibrate the receiver against your
iOS device’s settings.
This is an important function to allow
accurate meter readings to be taken.
6. Sign in to Loopworks
After successful calibration you will be prompted
to sign in when rst opening the app. If you have
not already created an account you can register
within the app at this stage. If you choose not
to sign in now, you can sign in via the settings
menu at any point. During sign in any existing
data will be synchronised to the app, you can
check the synchronisation status and manually
synchronise at any point from the projects
menu. Quick-Start Guide
& R1 Handbook
Measure
Design
Connect
Learn
UP18301-6

Handbook Contents
• Safety
• Introduction
• Overview of unit
• Operation of unit
• Troubleshooting
• Technical Specications
• Warranty & Calibration
• Declaration of Conformity
Box Contents
• 1 x Loopworks Measure R1
• 1 x Pouch
• 1 x Quick-Start Guide &
Handbook
This symbol is used to alert the user to important
operating or maintenance instructions.
The lightning bolt triangle is used to alert the user
to the risk of electric shock.
SAFETY
1.It is important to read these instructions, and to follow them.
2.Keep this instruction manual in an accessible place.
3.Clean only with a dry cloth. Cleaning uids may a󰀨ect the hardware.
4.Refer all servicing to qualied personnel. Servicing is required when the
apparatus has been damaged in any way, such as a power supply cord
or plug is damaged, liquid has been spilled or objects have fallen onto
the apparatus, the apparatus has been exposed to any rain or moisture,
does not operate normally or has been dropped.
5. WARNING – To reduce the risk of re or electric shock, do not
expose this apparatus to rain or moisture. The apparatus shall not be
exposed to dripping or splashing and no objects lled with liquids, such
as vases, shall be placed on the apparatus.
TO PREVENT ELECTRIC SHOCK REFER
SERVICING TO QUALIFIED PERSONNEL
Ampetronic R1 Handbook Page 1
R1 Handbook 3. Download the FREE App
If you haven’t done
so already, you will
need to download
the FREE Loopworks
Measure App from
the Apple App Store,
using your iOS
device.
TESTS
Background Noise
Filed Strength
Frequency Response
Live Signal
System Noise
Overspill
QUESTIONS
Signage
Sta Training
SIGNAL TYPES
Sine
Pink
Combi
Live
No Signal
System O
ACCEPTANCE
Good / Pass
Qualied Pass
Unacceptable / Fail
Help
Alignment Alert
MENU
Signal Menu
Capture
Meter
Certify
Settings
Reset
Results
Overall System Ver-
tics
Freq Noise
Field Results
4. Connect the Receiver
Start your new App and plug the Receiver into
the headphone socket of your iOS device to
activate it.
Follow the on-screen instructions to allow
access to the microphone and enter the label
number (digits only) printed on the side off the
Receiver.
Measure R1
www.ampetronic.com
FSM
Start Test Settings
Results
Test Points

1. Purchase Receiver
You will need an R1 Receiver to perform
any measurements in the app. The receiver
contains a telecoil and enables your iOS
device to
accurately
measure
magnetic
elds.
Purchase an
R1 Receiver
from the Ampetronic website
(www.ampetronic.com)
or through your local distributor.
Measure R1
www.ampetronic.com
Measure R1
www.ampetronic.com
INTRODUCTION
The Loopworks Measure R1 has been designed in conjunction with the
Loopworks Measure iOS App as a high quality piece of test equipment for
detection and evaluation of the performance of Audio Frequency Induction Loop
Systems (AFILS) to the international standard IEC 60118-4.
It is simple to use with all types of installation, from simple service point
applications through to low spill area coverage designs. Simply hold the
Loopworks Measure R1 in the same position the hearing aid will be in once the
system is operational: i.e. hold the unit at head height to take measurements:
either seated, or standing depending on the venue.
A headphone socket is provided to allow audible monitoring and subjective
testing of the system. Details of use are given in the Hearing Loop test and
commissioning procedure.
OVERVIEW OF UNIT
OPERATION OF UNIT
For full instructions on using the meter and app, download the Loopworks
Measure User Manual from the R1 product page at www.ampetronic.comm
Method of use
1. Download Loopworks Measure App to device
2. Unpack Loopworks Measure R1
3. Connect to the iOS device running the App
4. Insert the headphones into the socket on the top of the unit to monitor
received signal. Adjust the volume using the controls on the device
running the App.
5. Use as basic meter or sign in to Loopworks Measure to capture test
results and generate reports
Measure R1
www.ampetronic.com
Measure R1
www.ampetronic.com
Measure R1
www.ampetronic.com
Measure R1
www.ampetronic.com
3.5mm (1/8 inch)
Jack plug for
connection to iOS
device running
App
3.5mm (1/8 inch)
Headphone
socket
Top Bottom
Home Advanced
Background
Noise
Frequency
Response
Field
Strength
Test
PerimeterLoop
Unacceptable
-5.2 db
-22
0
+8
+2
1kHz/ 400 mA/m
+1
+3
+4
+5
+7
+6
-1
-2
-3
-4
-5
-12 -9
Instructions
FSM
MeasureR1
www.ampetronic.com
3030
3030
3030
3030
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.1
0
2.0
Standing = 1.7m
Seated = 1.2m
Listening Height (Meters)
0cm
100cm
50cm
150cm
200cm
170cm
0cm
-50cm
50cm
A
Distancefrom
counterprole
+Oset to loop
= 55cm
B
DE
Suggested
Oset
25cm
45˚
30cm
0cm
100cm
50cm
150cm
200cm
145cm
0cm
-50cm
50cm
B
Distancefrom
counterprole
+Oset to loop
= 55cm
0cm
100cm
50cm
150cm
200cm
120cm
0cm
-50cm
50cm
Distancefrom
counterprole
+Oset to loop
= 55cm
C
N.B. For most applications it is the
vertical component of the magnetic eld
that is received by the hearing aid, as
a result the Loopworks Measure R1 is
designed to be used while held vertically
as shown:
Home Advanced
Background
Noise
Frequency
Response
Field
Strength
Test
PerimeterLoop
Unacceptable
-5.2 db
-22
0
+8
+2
1kHz/ 400 mA/m
+1
+3
+4
+5
+7
+6
-1
-2
-3
-4
-5
-12 -9
Instructions
FSM
MeasureR1
www.ampetronic.com
3030
3030
3030
3030
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.1
0
2.0
Standing = 1.7m
Seated = 1.2m
Listening Height (Meters)
0cm
100cm
50cm
150cm
200cm
170cm
0cm
-50cm
50cm
A
Distancefrom
counterprole
+Oset to loop
= 55cm
B
DE
Suggested
Oset
25cm
45˚
30cm
0cm
100cm
50cm
150cm
200cm
145cm
0cm
-50cm
50cm
B
Distancefrom
counterprole
+Oset to loop
= 55cm
0cm
100cm
50cm
150cm
200cm
120cm
0cm
-50cm
50cm
Distancefrom
counterprole
+Oset to loop
= 55cm
C
Ampetronic R1 HandbookPage 2
2. Sign up for Loopworks™
Create a free account to access the
Loopworks online portal, and enable
increased functionality on the App. This
stage is optional, and you can use the App
in simple meter mode; however, you will
need an account to access the full range
of functions and to be able to save data or
record audio.
Create an account from within the app or at
loopworks.ampetronic.com

TROUBLESHOOTING
No Headphone signal
Check the headphones are plugged in, and the volume control is turned up.
Low magnetic eld strength
Check the loop system is running current.
If there is insu󰀩cient CURRENT, or excessive metal loss, the application may
require a special loop design to achieve acceptable performance, contact
Ampetronic for advice.
Background noise
Check all loop systems are switched o󰀨 and not running any current.
If the interference is still present with the loop system switched o󰀨, locate and
eliminate the source of the interference before switching the loop system back
on. Monitor with headphones whilst switching other electrical systems such as
power, lighting etc ON and OFF
See the full user manual, or the FAQs page within Loopworks for more
troubleshooting advice.
SPECIFICATIONS
PARAMETER VALUE
Magnetic eld measurement Coil orientation: Vertical when unit held upright
Reference level: 400mA/m (in eld strength mode)
Frequency response
50Hz to 8kHz ±0.25dB
40Hz to 10kHz ±0.5dB
30Hz to 15kHz ±0.3dB
Gain stability: Better than ±0.25dB over all conditions
Audio Inputs
3.5mm 4-pole jack plug for connection to Apple
iOS device
3.5mm 3-pole jack socket for monitoring with stereo
headphones
Calibration power < 100mW
Measurement power < 1mW
Dimensions 52.0 x 27.5 x 9.5mm
Weight 10g
Operating temp range -10 to +45°C (Storage -20 to +75°C)
Details of all products and services provided by Ampetronic can be found at our
website: www.ampetronic.com
Ampetronic R1 Handbook Page 3 Ampetronic R1 Handbook
Page 4
WARRANTY & CALIBRATION
This product carries a one year parts and labour warranty from date of shipment
from Ampetronic. The warranty could be invalidated if the instructions in this
handbook are not followed correctly, or if the unit is misused in any way.
The Loopworks Measure R1 is calibrated during manufacturing test, and is
valid until one year from the date the equipment leaves Ampetronic. Calibration
review is recommended one year from this date, however this period may be
extended depending on use and requirements.
DECLARATION OF CONFORMITY
Manufacturer: Ampetronic Ltd. Unit 2, Trentside Business Village
Farndon Road Newark United Kingdom NG24 4XB
Declares that the product:
Description: Field Strength Meter
Type name: R1
Conforms to the following Directive(s) and Norm(s):
Directive 2014/35/EU
EMC: EN55032:2015 Emission
EN55103-2 : 2009 Immunity
Directive: 2014/30/EU
Safety: EN 60065: 2002+A12:2011
Directive: 2011/65/EU RoHS
Part 15: This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.”
Date: May 2017,
J.R. Pieters, Managing Director, Ampetronic Ltd.
Contact information
Website: www.ampetronic.com, Portal: loopworks.ampetronic.com
Technical: [email protected], Sales: [email protected]
Tel: [phone]
