Ampetronic PS3 User manual
Input power: 18 VA.
Fuse: T 80mA L for 230V or T 160mA L for 115V.
DC Output: 15V regulated
300mA max per voltage line, 9W total power
Short circuit protected.
Dimensions: Width:71mm Height:44mm Depth:118mm
Weight: 675g.
Safety Notice
The unit should be kept in a dry location away from extremes of temperature or
humidity. It could be dangerous to use the unit in locations or conditions for which it is
not intended. The PS3 is double insulated and does not require a safety earth
connection.
Warranty Information
This product carries a 5 year parts and labour warranty which could be invalidated if
these instructions are not followed correctly, or if the unit is tampered with in any way.
The 5 year warranty is dated from the time the equipment leaves Ampetronic and
NOT when it is installed.
The PS3 is designed and manufactured in England by Ampetronic Ltd.
DECLARATION OF CONFORMITY
Manufacturer: Ampetronic Ltd.
Address: Northern Road, Newark,
Nottinghamshire, NG24 2ET.
United Kingdom
.
Declares that the product:
Description: Power Supply
Type Name:PS3
Conforms to the following Directive(s) and Norm(s):
Directive 89/336/EEC
EMC: EN55103-1 (1997)
EN55103-2 (1997)
Directive 73/23/EEC
Safety: EN60065 (1995)
April 2001
L.A. Pieters
Managing Director,
Ampetronic Ltd
The PS3 is a power adapter designed to provide power to the Ampetronic range of
preamplifiers and accessories. The unit provides two regulated 15V DC supply
outputs at up to 9W total power on a 3-pin mini DIN plug, which is the Ampetronic
standard connector for auxiliary DC power.
1. Output Connection
Connect the PS3 to the input of the unit to be connected using the power cable
supplied.
Important:
Never plug the PS3 into the DC power output socket of any Ampetronic loop amplifier,
or both units could be damaged.
To meet EMC regulations, the maximum output cable length is 1 metre.
If the PS3 is used to power equipment via cables not supplied by Ampetronic, the
output connector is wired as in the diagram below. If the rated output current is
exceeded, the PS3 may not maintain regulation of the output voltage and/or may shut
down.
2. Power Input.
The unit should be plugged into a suitable AC power socket. Do not connect to an
unsuitable power supply. The AC power plug contains a 3A standard fuse (UK only).
Only replace this with a fuse of the same type and rating.
3. Internal Fuse
The unit has an internal fuse, see below for rating. To replace this fuse, unplug the AC
supply, unscrew the 3 cover screws and remove the cover. A TX10 torx screwdriver
will be required. The fuse holder is situated behind the mains connector. Only replace
with a fuse of the same rating and type. After replacing the fuse, replace and fasten
the cover before connecting to the AC power supply.
Specification
AC Input: 230V or 115V AC, 45-65Hz
Factory set voltage selection.
4. Power Supply Connector Wiring
Pin Function
No.
1 +15 V
2 - 15 V
3 0 V
PS3
Power Supply
UP13801-4
Ampetronic Ltd,
Northern Road, Newark,
Nottinghamshire, NG24 2ET
United Kingdom
Tel: +44 (0) 1636 610062 Fax: +44 (0) 1636 610063
Input power: 18 VA.
Fuse: T 80mA L for 230V or T 160mA L for 115V.
DC Output: 15V regulated
300mA max per voltage line, 9W total power
Short circuit protected.
Dimensions: Width:71mm Height:44mm Depth:118mm
Weight: 675g.
Safety Notice
The unit should be kept in a dry location away from extremes of temperature or
humidity. It could be dangerous to use the unit in locations or conditions for which it is
not intended. The PS3 is double insulated and does not require a safety earth
connection.
Warranty Information
This product carries a 5 year parts and labour warranty which could be invalidated if
these instructions are not followed correctly, or if the unit is tampered with in any way.
The 5 year warranty is dated from the time the equipment leaves Ampetronic and
NOT when it is installed.
The PS3 is designed and manufactured in England by Ampetronic Ltd.
DECLARATION OF CONFORMITY
Manufacturer: Ampetronic Ltd.
Address: Northern Road, Newark,
Nottinghamshire, NG24 2ET.
United Kingdom
.
Declares that the product:
Description: Power Supply
Type Name:PS3
Conforms to the following Directive(s) and Norm(s):
Directive 89/336/EEC
EMC: EN55103-1 (1997)
EN55103-2 (1997)
Directive 73/23/EEC
Safety: EN60065 (1995)
April 2001
L.A. Pieters
Managing Director,
Ampetronic Ltd
The PS3 is a power adapter designed to provide power to the Ampetronic range of
preamplifiers and accessories. The unit provides two regulated 15V DC supply
outputs at up to 9W total power on a 3-pin mini DIN plug, which is the Ampetronic
standard connector for auxiliary DC power.
1. Output Connection
Connect the PS3 to the input of the unit to be connected using the power cable
supplied.
Important:
Never plug the PS3 into the DC power output socket of any Ampetronic loop amplifier,
or both units could be damaged.
To meet EMC regulations, the maximum output cable length is 1 metre.
If the PS3 is used to power equipment via cables not supplied by Ampetronic, the
output connector is wired as in the diagram below. If the rated output current is
exceeded, the PS3 may not maintain regulation of the output voltage and/or may shut
down.
2. Power Input.
The unit should be plugged into a suitable AC power socket. Do not connect to an
unsuitable power supply. The AC power plug contains a 3A standard fuse (UK only).
Only replace this with a fuse of the same type and rating.
3. Internal Fuse
The unit has an internal fuse, see below for rating. To replace this fuse, unplug the AC
supply, unscrew the 3 cover screws and remove the cover. A TX10 torx screwdriver
will be required. The fuse holder is situated behind the mains connector. Only replace
with a fuse of the same rating and type. After replacing the fuse, replace and fasten
the cover before connecting to the AC power supply.
Specification
AC Input: 230V or 115V AC, 45-65Hz
Factory set voltage selection.
4. Power Supply Connector Wiring
Pin Function
No.
1 +15 V
2 - 15 V
3 0 V
PS3
Power Supply
UP13801-4
Ampetronic Ltd,
Northern Road, Newark,
Nottinghamshire, NG24 2ET
United Kingdom
Tel: +44 (0) 1636 610062 Fax: +44 (0) 1636 610063
