Amphony iFinityr Manual

User and Installation
Guide
Digital Wireless
Indoor / Outdoor Speaker
iFini yt
TM
R

Contents:
Unpacking .......................................................................................
Connecting power ...........................................................................
Selecting the audio channel ...........................................................
Turning on speaker power ..............................................................
Pairing the speaker and transmitter ................................................
Setting the speaker volume and treble ...........................................
Troubleshooting ..............................................................................
Technical specifications ..................................................................
Safety information ...........................................................................
Limited warranty ............................................................................
1
1
3
4
5
6
7
8
9
11

Step 1 Connecting power
After placing the speaker in a safe environment, make sure that you
have not yet plugged the AC adapter into an outlet. Next, insert the
barrel-shaped plug of the supplied AC adapter into the opening at the
rear of the speaker which says “DC 36V“.
Ensure that you insert the plug straight into the opening (do not angle
it). Push it until it is inserted securely.
Next, plug the AC adapter into a power outlet.
Unpacking: Check that this package contains:
One speaker, one AC adapter (wallwart)
In order to operate your wireless speaker, you need
an Amphony iFinity audio transmitter (sold separately). If you have
purchased a full set, the transmitter is already part of the set and is
packaged separately. Please refer to the transmitter user guide for
operation instructions.
Important Note:
User and Installation Guide
R
Page 1
ATTENTION
Connect the supplied AC adapter
to the speaker connecting
the AC adapter to an outlet to avoid
spark generation.
BEFORE

DC 36 V
Power outlet
AC adapter
Left Right
Mono
Treble Volume Pairing
Network
DC 36V
Off On
iFini yt
TM
User and Installation Guide
R
Page 2
Connecting power

Left Right
Mono
Treble Volume Pairing
Network
DC 36V
Off On
iFini yt
TM
User and Installation Guide
R
Page 3
Step 2 Selecting the audio channel
Slide the audio-channel switch to the audio channel which you want
the speaker to receive. You can either receive the left audio channel,
the right channel or a mix between both channels (mono).
If you are using two wireless speakers in one room, you want to set
one speaker to receive the left channel and one speaker to receive
the right channel.
Channel-select switch

Left Right
Mono
Treble Volume Pairing
Network
DC 36V
Off On
iFini yt
TM
User and Installation Guide
R
Page 4
Step 3 Turning on speaker power
Turn the speaker volume control to the minimum position.
Next, slide the on/off switch into the “On“ position.
The network status light should start flashing.
On/Off switch
Network
status light
Volume control
Turn to
minimum

Left Right
Mono
Treble Volume Pairing
Network
DC 36V
Off On
iFini yt
TM
User and Installation Guide
R
Page 5
Step 4 Pairing the speaker and transmitter
To receive audio from the transmitter, set the transmitter into pairing
mode by pushing the transmitter pairing button.
Then, push the pairing button of the speaker within 5 minutes.
After the speaker is paired with the transmitter, the network status
light will stop flashing and light continuously and the speaker should
output the audio from the transmitter.
Pairing button
Network
status light

Left Right
Mono
Treble Volume Pairing
Network
DC 36V
Off On
iFini yt
TM
User and Installation Guide
R
Page 6
Step 5 Setting the speaker volume and treble
Now slowly increase the volume control.
Use the treble control to adjust the treble of your speaker.
Please follow the instructions in the transmitter user guide for
adjusting the transmitter properly to your audio source in order to
maximize the dynamic range of your speaker.
Treble control Volume control

User and Installation Guide
R
Page 7
Troubleshooting
Problem
No Sound - Network
status light is OFF
No Sound - Network
status light is
FLASHING
No Sound - Network
status light is ON
Possible Cause
AC adapter not
plugged in properly
Speaker not
switched on
No wireless signal
Speaker not paired
with transmitter
Strong interference
Volume control set
too low
No audio at
transmitter
Solution
Check AC adapter for
proper fit
Slide the speaker on/off
switch to the “On“ setting
Check if the transmitter is
active
Pair the speaker with the
transmitter
Try eliminating
interference at 2.4 GHz
(wireless LANs, cordless
phones), try relocating
the transmitter or speaker
to improve reception
Adjust the transmitter and
speaker volume control
Verify that audio is
supplied to the
transmitter, check the
audio connection to the
transmitter
Please check the network status light of the speaker and then choose
from the following problems:

User and Installation Guide
R
Page 8
Technical Specifications
Amplifier:
Amplifier Power:
Drivers:
Crossover:
Frequency response (-6 dB):
Amplifier distortion (THD):
Power efficiency:
Max. number of speakers
per transmitter:
Size:
Weight:
Standby power:
Bi-amplification: two separate
Class-D amplifiers
150W peak, 80W rms
5" woofer, 1" tweeter
Active
60 Hz - 18 kHz
0.06% @ 50 Watts
91%
4
8.5" (H) x 8.5" (W) x 8.3" (D)
4.8 lbs
< 3W

IMPORTANT SAFETY INFORMATION ATTENTION!
READ THESE SAFETY INSTRUCTIONS CAREFULLY
AND HEED ALL WARNINGS IN THIS MANUAL.
POWER SOURCE
To avoid product malfunction, and to protect against electric shock,
fire or personal injury, please observe the following:
• This product has been designed to work with 120-volt AC current
using the supplied AC adapters. Connection to a line voltage other
than that or use of non-compatible AC adapters may create a safety
and fire hazard and may damage the product.
• Do not run power cords under rugs or carpets or place heavy objects
on them.
• Damaged or deformed power cords are hazardous and should be
replaced immediately by a qualified service technician.
LOCATION
tures inside the unit. Do not place the speaker in
closed spaces, cover it, or otherwise block the vent.
• Do not place this product in direct sunlight, or near heat sources.
• Keep this product away from strong magnetic objects.
• Do not use this product in extremely wet conditions or in cars.
• An air vent is provided at the rear of the speaker to prevent
excessive tempera
VOLUME CONTROL
• Do not turn up the volume while listening to a portion with very low
level input or no audio signal to avoid damage to your speaker during
a peak level audio portion.
• Turn the speaker volume control to minimum prior to connecting or
disconnecting the transmitter and prior to switching audio sources as
this may cause loud clicks which can damage your speaker.
User and Installation Guide
R
Page 9

CARE
• Do not insert or drop anything into the speaker through the air vent
as this could cause serious damage, possibly resulting in fire.
• Do not place any object containing water or other liquids on this
product.
• Do not remove the cabinet. Touching parts inside the cabinet could
result in electric shock and damage to the product.
NON-USE PERIODS
• When the product is not being used for a long period of time, unplug
the AC adapter from the mains outlet.
CLEANING
• Unplug the product before cleaning.
• When the system gets dirty, wipe it with a clean, soft cloth. If
necessary, wipe it with a soft cloth, slightly dampened with soapy
water. Wipe dry immediately with a dry cloth.
• Never use benzene, aerosol cleaners, thinner, alcohol or any
volatile
cleaning agent.
• Do not use abrasive cleaners, as they may damage the finish.
SERVICE
• Do not open the cabinet of any components. Opening the cabinets
may present a shock hazard, and any modification to this product
will void your warranty.
• Do not attempt to service the unit yourself. If liquid or any metal
objects such as paper clips, wire or staples accidentally fall inside,
disconnect the product from the power source immediately, and
consult an authorized service center.
• Please refer any service to an authorized Amphony service center.
User and Installation Guide
R
Page 10

Limited warranty
WHAT YOUR WARRANTY COVERS
LABOR:
PARTS:
Note:
This warranty extends only to the original user of the equipment
(“you”, ”your”) and is limited to the purchase price of each part.
Amphony and its affiliated companies (”we”, ”our”, ”us”) warrant this
Wireless Speaker against defects in materials or workmanship as
follows.
For a period of ninety (90) days from the original date of
purchase, if we determine that the equipment is defective subject to
the limitations of this warranty, we will replace it at no charge for labor.
We warrant any such work done against defects in materials or
workmanship for the remaining portion of the original warranty period.
For a period of one (1) year from the original date of
purchase, we will supply, at no charge, new or rebuilt replacement
parts in exchange for parts we determine are defective subject to the
limitations of this warranty. We warrant any such replacement parts
against defects in materials or workmanship for the remaining portion
of the original warranty period.
”Parts” means items included in this package. It does
include other parts purchased separately.
not
WHAT YOUR WARRANTY DOES NOT COVER
This warranty consumer instruction, physical setup or
adjustment of any consumer electronic equipment, or signal
transmission problems.
This warranty cosmetic damage, damage due to the
affixing of any attachment not provided with the product, loss of parts,
connecting the product to any but the specified receptacles, lightning,
electrical surges, fire, flood, or other acts of God, accident, misuse,
abuse, repair or alteration by other than authorized service personnel,
negligence, commercial or institutional use, or improper or neglected
maintenance.
does not cover
does not cover

This warranty equipment sold AS IS or WITH ALL
FAULTS, equipment removal or reinstallation, shipping damage if the
equipment was not packed and shipped in the manner we prescribe,
nor equipment purchased, serviced, or operated outside the
contiguous United States of America.
REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
YOUR EXCLUSIVE REMEDY. WE SHALL NOT BE HELD LIABLE
FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR
BREACH OF ANY EXPRESSED OR IMPLIED WARRANTY ON THIS
EQUIPMENT, NOR FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF, OR INABILITY TO
USE, THIS EQUIPMENT. UNDER NO CIRCUMSTANCES SHALL
OUR LIABILITY, IF ANY, EXCEED THE PURCHASE PRICE PAID
FOR THIS EQUIPMENT, EXCEPT TO THE EXTENT PROHIBITED
BY APPLICABLE LAW. EXCEPT AS PROVIDED HEREIN, WE
MAKE NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. WE RESERVE THE RIGHT TO REFUSE
TO HONOR THIS WARRANTY IF WE DETERMINE ANY OF THE
ABOVE EXCEPTIONS TO HAVE CAUSED THIS EQUIPMENT NOT
TO HAVE PERFORMED PROPERLY. THIS WARRANTY SHALL BE
VOID IF ANY FACTORY-APPLIED IDENTIFICATION MARK,
INCLUDING BUT NOT LIMITED TO SERIAL NUMBERS AND
WARRANTY LABELS, HAS BEEN ALTERED OR REMOVED. THIS
WARRANTY SHALL ALSO BE VOID IF THE SPEAKER HAS BEEN
OPENED BY AN UNAUTHORIZED PERSON.
This warranty gives you specific legal rights which may vary from
state to state. Some states do not allow the exclusion or limitation of
incidental or consequential damages, or allow limitations on the
duration of an implied warranty, so those limitations may not apply to
you.
No responsibility is assumed for the presence of interference
outside of Amphony’s control which may prevent proper operation.
does not cover
LEGAL LIMITATIONS
Note:

Copyright (C) 2011 Amphony. All rights reserved.
FCC ID: PMJRX1
Caution:
The information contained herein is subject to change without
notice. Revisions may be issued to advise of such changes and/or
additions.
All product names, trade names, or corporate names mentioned in
this document are acknowledged to be the proprietary property of
the registered owners.
This device complies with part 15 of the FCC Rules. Operation is
subjected to the following two conditions: 1) This device may not
cause harmful interference and 2) this device must accept any
interference received, including interference that may cause
undesired operation.
Any changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority
to operate the equipment.
