SERVICE INFORMATION
XRS10P
POWERED LOUDSPEAKER
CONTENTS:
OPERATION MANUAL
SCHEMATIC DIAGRAM

XRS SERIES
POWERED AND PASSIVE LOUDSPEAKERS
INSTALLATION AND OPERATION MANUAL

1. Save the carton and packing material even if the equipment has
arrived in good condition. Should you ever need to ship the unit, use
only the original factory packing.
2. Read all documentation before operating your equipment. Retain
all documentation for future reference.
3. Follow all instructions printed on unit chassis for proper operation.
4. Do not spill water or other liquids into or on the unit, or operate
the unit while standing in liquid.
5. Make sure power outlets conform to the power requirements listed
on the back of the unit.
6. Do not use the unit if the electrical power cord is frayed or broken.
The power supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against them,
paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Always operate the unit with the AC ground wire connected to the
electrical system ground. Precautions should be taken so that the
means of grounding of a piece of equipment is not defeated.
8. Mains voltage must be correct and the same as that printed on the
rear of the unit. Damage caused by connection to improper AC voltage
is not covered by any warranty.
9. Have gain controls on amplifiers turned down during power-up
to prevent speaker damage if there are high signal levels at the inputs.
10 Power down and disconnect units from mains voltage before making
connections.
11. Never hold a power switch in the “ON” position if it won’t stay
there itself!
12. Do not use the unit near stoves, heat registers, radiators, or other heat
producing devices.
13. Do not block fan intake or exhaust ports. Do not operate equipment
on a surface or in an environment which may impede the normal flow
of air around the unit, such as a bed, rug, weathersheet, carpet,
or completely enclosed rack. If the unit is used in an extremely dusty
or smoky environment, the unit should be periodically “blown free”
of foreign matter.
14. Do not remove the cover. Removing the cover will expose you
to potentially dangerous voltages. There are no user serviceable
parts inside.
15. Do not drive the inputs with a signal level greater than that required
to drive equipment to full output.
16. Do not connect the inputs / outputs of amplifiers or consoles to any
other voltage source, such as a battery, mains source, or power supply,
regardless of whether the amplifier or console is turned on or off.
17. Do not run the output of any amplifier channel back into another
channel’s input. Do not parallel- or series-connect an amplifier output
with any other amplifier output. Australian Monitor is not responsible
for damage to loudspeakers for any reason.
18. Do not ground any “hot” (red) terminal. Never connect a “hot” (red)
output to ground or to another “hot” (red) output!
19. Non-use periods: the power cord of equipment should be unplugged
from the outlet when left unused for a long period of time.
20. Service Information Equipment should be serviced by qualified service
personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment
C. The equipment has been exposed to rain
D. The equipment does not appear to operate normally, or exhibits a
marked change in performance
E. The equipment has been dropped, or the enclosure damaged.
THIS SAFETY INFORMATION IS OF A GENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL
IMPORTANT SAFETY INFORMATION

PAGE 3XRS SERIES INSTALLATION AND OPERATION MANUAL
Building on the reliability and sonic quality of the very popular XR speaker
series, Australian Monitor brings you the AM Pro XRS two way injection moulded
speaker enclosures with more features and new aesthetic to suit both live
sound reinforcement and permanent installation. From Front of House to fold
back, the dance floor to background fill, the XRS series with both passive and
powered options are designed with flexibility and performance in mind.
The AM Pro XRS range includes 8”, 10” and 12” models all with high quality
compression drivers and represent a significant advancement in injection
moulded box design while maintaining excellent audio quality and great value
for money.
AUS, EUR, USA
REV A 24th Nov 2008
This symbol is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the products enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
This symbol is intended to alert the user to the presence of important
operational and maintenance (servicing) instructions in the literature
accompanying the appliance.
To prevent electric shock do not use this (polarised) plug with an extension
cord, receptacle or other outlet unless the blades can be fully inserted to
prevent blade exposure. To prevent electric shock, match wide blade of
plug to wide slot, fully insert.
Caution:
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK),
NO USER SERVICEABLE PARTS INSIDE,
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING!
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
INTRODUCTION 3
FRONT AND REAR PASSIVE PANEL 4
REAR POWERED PANEL 5
SPECIFICATIONS 6
INTRODUCTION AND CONTENTS

PAGE 4 XRS SERIES INSTALLATION AND OPERATION MANUAL
FRONT AND REAR PANEL PASSIVE VERSION
1High Frequecy Driver
Horn loaded compression driver. Directivity 90deg x 90deg.
Passive crossover in the XRS8/10/12.
XRS8/XRS8P 1.5”
XRS10/XRS10P 1.5”
XRS12/XRS12P 2”
Active crossover and power amp in XRS8P/10P/12P.
XRS8P 50W
XRS10P 50W
XRS12P 100W
2Low Frequency Woofer
Driver sizes:
XRS8/XRS8P 8”
XRS10/XRS10P 10”
XRS12/XRS12P 12”
Active crossover and power amp in XRS8P/10P/12P
.
XRS8P 100W
XRS10P 100W
XRS12P 300W
Note that the XRS8 ships as a pair.
1Speaker Input
The input connector is a 4 pole speakon compatible connector.
Pins 1+ and 1- are wired to the +ve and -ve respectively of
the speaker. The XRS10 and XRS12 have 2 connectors. They
are wired in parallel so either connector can be used as an
input, the other as a loop through.
Accessories:
XRS8/XRS8P
XR8PMA Pole mount adapter
XR8UMB Universal mounting bracket
XRS10/XRS10P
XR10CVR Heavy duty cover
AMISLSB1 Wall mount brackets
ATC303 Tripod speaker stand
ATC304 Heavy duty tripod speaker stand
ATC305 Winch up speaker stand
XR10-12UB Universal bracket
XRS12/XRS12P
XR12CVR Heavy duty cover
AMISLSB1 Wall mount brackets
ATC303 Tripod speaker stand
ATC304 Heavy duty tripod speaker stand
ATC305 Winch up speaker stand
XR10-12UB Universal bracket
1 12 XRS8 shown here

PAGE 5XRS SERIES INSTALLATION AND OPERATION MANUAL
REAR PANEL POWERED VERSION
15 13 14
10 11 12
789 246
5
3
1
1MIC IN
This is a balanced XLR microphone input.
2Mic SIGNAL
This is a green LED signal present
indicator for the Mic input. It indicates
signal present on the input and is not
affected by the level control.
3LINE IN
This is a balanced XLR line level input.
4Line SIGNAL
This is a green LED signal present
indicator for the Line input. It indicates
signal present on the input and is not
affected by the level control.
5LINE OUT
The LINE OUT is on an XLR connector.
This output can be connected to the LINE
IN on another XRS Powered speaker to
expand the system.
6Output CLIP
This is a red LED clip indicator for the
mixed mic and line audio signal. Some
flashing of red is acceptable on program
transients. Continuous flashing of red
could be placing undue stress on the
speaker and will sound distorted. Turn
down the input level until the clip LED is
no longer lit.
7Mic LEVEL
This controls the level of the MIC input
(1).
8Mic BASS
This is the bass control for the MIC input
(1). There is 12dB of cut and boost at
100Hz. This EQ is the shelving type.
9Mic TREBLE
This is the treble control for the MIC input
(1). There is 10dB of cut and boost at
10kHz. This EQ is the shelving type.
10 Line LEVEL
This controls the level of the LINE input.
(3)
11 Line BASS
This is the bass control for the LINE input
(3). There is 12dB of cut and boost at
100Hz. This EQ is the shelving type.
12 Line TREBLE
This is the treble control for the LINE
input (3). There is 10dB of cut and boost
at 10kHz. This EQ is the shelving type.
13 Power Switch
This switch turns the power on or off to
the unit.
14 IEC Mains Input Socket
This is a standard IEC 3 pin socket.
It accepts a standard IEC mains cable,
(provided). The fuse draw contains the
mains fuse and a spare.
The mains fuse is a time lag (slow blow)
HRC 20mm x 5mm ceramic or glass type
fuse.
XRS8P XRS10P XRS12P
2.5A 2.5A 5.0A
IMPORTANT: Always replace the
fuse with one of the same value and type.
NOTE: Always disconnect power to
the amplifier before replacing fuses.
15 Voltage Select Switch
This switch is used to select the mains
voltage for your region. Select either
230V or 115V.
IMPORTANT: Disconnect power to
the amplifier before operating this switch.
IMPORTANT: Make sure this setting
is correct before connecting the unit to
the mains.

PAGE 6 XRS SERIES INSTALLATION AND OPERATION MANUAL
SPECIFICATIONS
XRS8P XRS10P XRS12P
Drivers 1 x 8” woofer 1 x 10” woofer 1 x 12” woofer
1 x 1.5” HF driver 1 x 1.5” HF driver 1 x 2” HF driver
Frequency Response(-3dB) 65Hz-18kHz 55Hz-18kHz 50Hz-18kHz
Frequency Response(-10dB) 55Hz-18kHz 50Hz-18kHz 40Hz-20kHz
Peak Sound Level(dB 1m) 118dB 121dB 125dB
Tone controls
Bass control @ 100Hz 12dB 12dB 12dB
Treble control @ 10kHz 10dB 10dB 10dB
Output Power 100W(low) + 50W(high) 100W(low) + 50W(high) 300W(low) + 100W(high)
Distortion (THD)
Line 0.02% 0.02% 0.02%
Microphone 0.04% 0.04% 0.04%
Tweeter Dispersion(HxV) 90° x 90° 90° x 90° 90° x 90°
Input Impedance
Line 20kOhm 20kOhm 20kOhm
Microphone 10kOhm 10kOhm 10kOhm
Connectors XLR 3 XLR 3 XLR 3
Power Supply AC 115V/230V, 50/60Hz AC 115V/230V, 50/60Hz AC 115/230V, 50/60Hz
Dimensions(WxDxH) 277 x 265 x 407mm 325 x 308 x 478mm 415 x 391 x 600mm
Packing Dimensions(WxDxH) 355 x 325 x 470mm 375 x 355 x 535mm 465 x 435 x 680mm
Net Weight 8.6kg 10.5kg 23kg
Gross Weight 10.1kg 11.8kg 25.2kg

PAGE 7XRS SERIES INSTALLATION AND OPERATION MANUAL
SPECIFICATIONS
XRS8 XRS10 XRS12
Drivers 1 x 8” woofer 1 x 10” woofer 1 x 12” woofer
1 x 1.5” HF driver 1 x 1.5” HF driver 1 x 2” HF driver
Frequency Response(-3dB) 65Hz-18kHz 55Hz-18kHz 50Hz-18kHz
Frequency Response(-10dB) 60Hz-20kHz 50Hz-20kHz 40Hz-20kHz
Sensitivity(dB 1W 1m) 92 dB 95 dB 97 dB
Impedance 8 Ohm 8 Ohm 8 Ohm
Recommended Max Power(Wrms) 100 W 250 W 300 W
Max Sound Level(dB 1m) 118dB 125dB 128dB
Dispersion(HxV) 90° x 90° 90° x 90° 90° x 90°
Harmonic Distortion 1% 1% 1%
Speakon compatible connectors 1 2 2
Dimensions(WxDxH) 277 x 257 x 400mm 321 x 321 x 464mm 415 x 382 x 620mm
Packing Dimensions(WxDxH) 595 x 310 x 460mm 375 x 355 x 535mm 465 x 435 x 680mm
Net Weight 6.5kg 10kg 18kg
Gross Weight 15kg (pair) 12kg 20kg

SYDNEY
(NSW SALES)
1 Clyde Street
Silverwater
NSW 2128
Private Bag 149
Silverwater NSW 1811
Phone: [phone]
Fax: [phone]
Email:
[email protected]
CANBERRA
(ACT SALES)
1st Floor,
Campion Street
Deakin ACT 2600
PO Box 109
Deakin West ACT 2600
Phone: [phone]
Fax: [phone]
Email:
gordon.anderson@
hillssvl.com.au
MELBOURNE
(VIC & TAS SALES)
22/277
Middleborough Road
Box Hill VIC 3128
PO Box 151 Blackburn
South VIC 3130
Phone: [phone]
Fax: [phone]
Email:
[email protected]
BRISBANE
(QLD SALES)
42 Commercial Road
Fortitude Valley
QLD 4006
PO Box 2578 Fortitude
Valley BC QLD 4006
Phone: [phone]
Fax: [phone]
Email:
[email protected]
ADELAIDE
(SA & NT SALES)
31 Walsh Street
Thebarton
SA 5031
PO Box 157
Hindmarsh SA 5007
Phone: [phone]
Fax: [phone]
Email:
[email protected]
PERTH
(WA SALES)
3/11 Howe Street
Osborne Park WA 6017
PO Box 1281
Osborne Park BC
WA 6916
Phone: [phone]
Fax: [phone]
Email:
[email protected]
AUCKLAND
(NZ SALES)
9C Piermark Drive
Albany 0752
New Zealand
PO Box 300-512
Albany 0752
Phone: [phone]
Fax: [phone]
Email:
[email protected]
AUSTRALIA AND NEW ZEALAND
www.australianmonitor.com.au
EUROPE / ASIA / MIDDLE EAST
www.australianmonitor.com.au
INTERNATIONAL SALES
1 Clyde Street Silverwater NSW 2128 Australia
Private Bag 149 Silverwater NSW 1811
Phone: + 61 2 9647 1411
Fax: + 61 2 9748 2537
Email:
[email protected]

12345678
A
B
C
D
8
7654321
D
C
B
A
R3
30K
R4
30K
D1
1N4148
D3 1N4148 D2
1N4148
D4
1N4148
+15V
+15V
-15V
-15V
C5
22P
C6
22P
C7
10U/25V-NP
C1
10U/25V-NP
C3
10U/25V-NP
R15
10K
C15 22P
+15V
-15V
CV8
100U/50V
R9
30K
R10
30K
D5
1N4148
D7 1N4148 D6
1N4148
D8
1N4148
+15V
+15V
-15V
-15V
C12
22P
C13
22P
C14
10U/25V-NP
C8
10U/25V-NP
C10
10U/25V-NP
2
3
1
IC2A
JRC4560
6
57
IC1B
JRC4560
2
31
IC1A
JRC4560
R1
560
R2
560
R7
10K
R8
10K
C9
47P
R16
47
R17
47
C16
10U/25V-NP
C17
10U/25V-NP
12
3
CON1
5044
12
3
CON2
5044
1 2
3
CON3
5040
RP1-1
RP2-1
84
IC3C
JRC4560
84
IC1C
JRC4560
CV1
104
CV2
104
CV5
104
CV6
104
84
IC2C
JRC4560
CV3
104
CV4
104
R14
10K
R13
10K
RP1-3
RP2-3
C2
47P
R22
10K
OPT1
LCR0202
C22
22P
2
31
IC3A
JRC4560
R27
100K
+15V
R23
100K
R26
100
R25
3K3
R24
2K2
-15V
LED3
RED
IN2
Q2
2N5401
Q1
2N5551
C19
10U/25V-NP
R18
10K
C18
10U/25V-NP
R19
10K
IN1
6
5
7
IC2B
JRC4560
C20
10U/25V-NP
R21
10K
6
57
IC3B
JRC4560
R20
10K
1
2
3
4
5
CT01
5P*100MM(2.5MM)
-15V
+15V
-15V
GND
SIN-OUT
LIMIT
SIN-OUT
LIMIT
1
2
3
4
5
6
7
8
9
10
J1A
10PIN2.54mm
RP1-1
IN1
+15V
-15V
1
2
3
4
5
6
7
8
9
10
J2A
10PIN2.54mm
RP2-1
IN2
+15V
-15V
RP2-3 RP1-3
D10
IN4148
LED2
GREE
R6
5K1
R29
150K
R12
1K5
C11
473
Q4
2N5551
+15V
D9
IN4148
LED1
GREE
R5
5K1
R28
150K
R11
1K5
C4
473
Q3
2N5551
+15V
1
2
3
4
5
6
CT01A
6P*100MM(2.5MM)
-15V
GND
+15V
LIMIT
SIN-OUT
C21
22P
R3
10K
R1
10K
84
IC4C
JRC4560
2
31
IC4A
JRC4560
R4
15K
C1
22P
R2
15K
RP1-1
R7
15K
R8
15K
R10
10K
R9
1M
C4
103 C5 103
C3
472
R5
7K5
R6
7K5
C6
22P
RP2
B50K
RP3
B50K
TREBLE
BASS
6
57
IC4B
JRC4560
CV7
104
CV8
104
RP1-1
OUT1
+15V
-15V
-15V
+15V
1
2
3
4
5
6
7
8
9
10
J1
10PIN2.54mm
RP1-3
RP1-3
RP1
A50K
AC 1
V+ 2
AC
3
V-
4
BR1
KBU-806
CV23
6800U/50V
CV24
6800U/50V
CV17
1000U/35V
CV18
1000U/35V
CV19
220U/25V
CV20
220U/25V
CV21
104
CV22
104
-15V
GND
+15V
S-IN
LIMIT
-15V
+15V
JP1
~28V
JP2
~28V
JP3
GND
JP7
HIGH+
JP8
HIGH-
+15V
-15V
+35V
-35V
CV25
470U/50V
CV26
470U/50V
CV27
104
CV28
104
JP5
LOW+
JP6
LOW-
C15
153
C16
153
C17
153
C18
153
C4
123
C5
392
C6
123
C7
392
R26
8K2
R27
6K8
R28
8K2
R29
6K8
R9
15K
R10
15K R11
15K
R6
10K
R3
10K
C2
22P
C8
1U/50V
R12
15K
R13
47K
D2
1N4148
D1
1N4148
D3
1N4148
R14
10K
R15
10K
R16
1M
R17
1M
R18
10K
C9
1U/50V
R19
2K2
R20
1M
+15V
R30
5K6
R31
47K
D5
1N4148
D4
1N4148
D6
1N4148
R32
10K
R33
10K
R34
1M
R35
1M
R36
10K
C20
104
R37
2K2
C19
104
+15V
D7
1N4148
R8
15K
CV29
470U/50V
CV30
470U/50V
CV31
104
CV32
104
R1
10K R5
100K
C1
10U/25V-NP
CV1
104
CV2
104
CV3
104
CV4
104
CV5
104
CV6
104
+15V
-15V
JP4
Earth
Vin
1
GND
2
Vout 3
IC6
7815
Vin
2
GND 1
Vout 3
IC7
7915
STBY-GND
1
IN-
2
IN+
3
IN-GND
4
SUR
5
BOOTSTRAP
6
+VS
7
-VS
8
STAND-BY
9
MUTE
10
NC
11
NC
12
+PWVS
13
OUT
14
-PWVS
15
IC4
TDA7294
C10
474
C11
22U/50V
C12
22U/50V
C24 10U/50V
C25 10U/50V
R21
20K
R22
1K
R23 22K
R42
20K
R44
10K
R43 51K
D8
1N4148
+35V-35V
STBY-GND
1
IN-
2
IN+
3
IN-GND
4
SUR
5
BOOTSTRAP
6
+VS
7
-VS
8
STAND-BY
9
MUTE
10
NC
11
NC
12
+PWVS
13
OUT
14
-PWVS
15
IC5
TDA7294
C21
474
C22
22U/50V
C23
22U/50V
R38
20K
R39 1K2 R40 22K
+35V-35V
R45
10/1W
R24
10/1W
C13
104
C26
104
R41
5K1
1
2
3
4
5
CZ01
TJC3-5A
2
31
IC1A
TL072 6
57
IC1B
TL072
12
13 14
IC2D
TL074
10
98
IC2C
TL074
5
6
7
IC2B
TL074
3
2
1
IC2A
TL074
12
13 14
IC3D
TL074
10
98
IC3C
TL074
5
6
7
IC3B
TL074
3
2
1
IC3A
TL074
84
IC1C
TL072
V+ 4
V-
11
IC2E
TL074
V+ 4
V-
11
IC3E
TL074
Q1
2N5551
Q2
2N5551
R46
440
R47
440
C14
2.2U/100VJP9
HIGH A+
LIMIT
C3
NP-10uF/25V
R7
47K
R2
100K
R4
100K
1
2
3
CZ03A
XP3
1
2
3
CZ02A
XP3
+15V
-15V
INPUT+
INPUT-
DZ1
1N4007
C27
10U/50V
XRS10P
Australian Monitor
