AMSEC ESLAudit User manual

American Security Products ESLAudit Operating Instructions
!"#$%&'()
$**+,,)-./(0.1)"2,(+3)
45+06('/7)8/,(0%*('./,!
!
!
!
!

1
-./(+/(,)
Introduction!...................................................................................................................................!3!
Keyboard!........................................................................................................................................!3!
Login!...............................................................................................................................................!3!
Login!with!PIN/Key!.....................................................................................................................!3!
Login!with!PIN!Only!....................................................................................................................!4!
Login!with!Key!Only!(this!option!is!only!available!on!non-listed!versions)!.................................!4!
Open!Lock!.......................................................................................................................................!4!
Without!Time!Delay!...................................................................................................................!4!
With!Time!Delay!.........................................................................................................................!4!
Batteries!.........................................................................................................................................!4!
Changing!the!Batteries!...............................................................................................................!4!
Battery!Life!.................................................................................................................................!4!
Adjusting!Display!Brightness!..........................................................................................................!4!
Adjusting!Beeper!Volume!...............................................................................................................!5!
Changing!Language!........................................................................................................................!5!
Immediate!Lock!..............................................................................................................................!5!
Engaging!Immediate!Lock!...........................................................................................................!5!
Enabling!Immediate!Lock!(this!is!an!administrative)!..................................................................!5!
Download!an!Audit!.........................................................................................................................!5!
Controller!Settings!..........................................................................................................................!6!
Backing!Up!Controller!Settings!...................................................................................................!6!
Restoring!Controller!Settings!from!a!Backup!File!.......................................................................!6!
Change!PIN!.....................................................................................................................................!6!
User!Administration!.......................................................................................................................!7!
Adding!Users!(restricted!to!managing!user!levels)!.....................................................................!7!
Editing!a!User’s!Profile!(restricted!to!managing!user!levels)!......................................................!7!
Deleting!a!User!(restricted!to!managing!user!levels)!.................................................................!7!
Enabling/Disabling!a!User!(restricted!to!managing!user!levels)!.................................................!8!
Purging!All!Users!(restricted!to!higher!managing!user!levels)!....................................................!8!
Dual!Control!(restricted!to!Administrative!user!levels)!..................................................................!8!
Time!&!Date!Controls!.....................................................................................................................!8!
Setting!Time!Delay!(restricted!to!administrative!user!levels)!....................................................!8!
Time!Lock!(restricted!to!administrative!user!levels)!..................................................................!9!
Daylight!Savings!Time!(restricted!to!administrative!user!levels)................................................!9!
Changing!Date!and!Time!(restricted!to!managing!user!levels)!...................................................!9!
Holiday!Lockout!(restricted!to!managing!user!levels)!..............................................................!10!
Update!Software!..........................................................................................................................!10!

2
ESLConfig!......................................................................................................................................!10!
System!&!Lock!Setup!................................................................................................................!11!
Daylight!Savings!....................................................................................................................!11!
Duress!...................................................................................................................................!11!
Aux!Input!..............................................................................................................................!11!
Holidays!................................................................................................................................!12!
Lock!Setup!............................................................................................................................!12!
Lock!Type!..............................................................................................................................!12!
Door!Hold!Time!....................................................................................................................!12!
Door!Open!Time!...................................................................................................................!12!
Dual!Control!.........................................................................................................................!12!
Immediate!Lock!....................................................................................................................!12!
Time!Delay!............................................................................................................................!12!
Delay!Period!.........................................................................................................................!12!
Open!Period!.........................................................................................................................!12!
Time!Lock!.............................................................................................................................!13!
User!Setup!................................................................................................................................!13!
Edit!Users!.............................................................................................................................!13!
Types!of!Users!......................................................................................................................!13!
View!an!Audit!...............................................................................................................................!14!
!

3
8/(0.&%*('./)
The!AMSEC!ESLAudit!lock!is!a!flexible,!multi-featured!safe!lock!that!is!intended!for!one-!and!
two-door!safes.!Key!features!of!this!lock!system!include:!
• 2,000!secure!audit!records.!!
• 40!users!with!unique!security!privileges!and!authority!levels.!
• PC!application!for!managing!system!configuration!and!users.!
• USB!interface!for!quick!and!cost-effective!software!upgrades,!system!configuration!and!
Audits.!
• Ability!to!control!1!or!2!doors.!Safe!doors!can!be!configured!in!any!inner/outer!
arrangement.!
• Time!Delay!feature,!which!provides!1-99!minute!delay!and!1-99!minute!Open!Period!
with!cancel!feature!on!any!door.!
• Time!Lock,!which!allows!limited!door!opening!periods,!1-6!windows!per!day.!
• Authentication!options:!PIN!code!and/or!Dallas!Key!access!control.!
• Wrong!try!count!–!penalty!lockout.!
• Armored!car!(courier)!bypass!for!Time!Delay!and!Time!Lock.!
• Holiday!lockout!schedule!with!up!to!16!programmable!events!per!year.!
• Automatic!daylight!savings!adjustment,!selectable!and!configurable.!
• Dual!Control!mode!on!any!individual!door.!
• Audit!utility,!which!allows!PC-based!audit!storage!management,!data!filter!and!sorting.!
• High!contrast!4!lines!by!21!characters!backlit!graphics!display.!
• Optional!burglary!or!duress!alarm!output!with!AC!power!and!external!control!input.!
• Supports!English,!Spanish!and!French.!
9+2:.60&)
The!four!softkeys!located!below!the!display!perform!the!functions!that!are!shown!on!the!last!
line!of!the!display!above!the!applicable!key.!
!
The!MENU!button!brings!you!back!to!the!Main!Menu.!
!
The!YES/NO!key!is!used!to!toggle!settings!between!YES/NO,!ON/OFF!or!Enable/Disable!in!some!
setup!menus.!
!
The!QUIT!key!takes!you!back!to!the!previous!menu.!
!
The!ENTER/SAVE!key!is!used!to!save!changes!or!enter!data!after!data!entry.!
)
)
#.7'/)
#.7'/);'(<)=8>?9+2)
1. Present!key.!
2. Enter!PIN.!
3. Press!ENTER/SAVE!key.!

4
#.7'/);'(<)=8>)4/12)
1. Enter!PIN.!
2. Press!ENTER/SAVE!key.!
!
#.7'/);'(<)9+2)4/12)@(<',).5('./)',)./12)6A6'16:1+)./)/./B1',(+&)A+0,'./,C)
1. Present!key.!
!
45+/)#.*D)
E'(<.%()F'3+)G+162)
1. Login!
2. Press!the!softkey!located!below!the!display!on!the!left.!Open1!for!Door!#1!or!Open2!
for!Door!#2.!
3. After!you!hear!a!click,!open!door!within!4!seconds.!
!
E'(<)F'3+)G+162)
1. Login!
2. Press!the!softkey!located!below!the!display!on!the!left!Open1!or!Open2.!!
3. Wait!for!the!Time!Delay!counter!to!reach!the!preset!Time!Delay.!
4. Login!again.!
5. After!you!hear!a!click,!open!door!within!4!seconds.!
!
H6((+0'+,)
-<6/7'/7)(<+)H6((+0'+,)
The!battery!compartment!is!locked!on!the!bottom!of!the!controller!and!holds!two!9-volt!
batteries.!Pinch!the!release!catches!toward!the!center!on!either!side!to!release!the!tray.!
!
H6((+02)#'I+)
The!percentage!of!remaining!battery!life!is!displayed!on! the!LOCKED!screen.!To!reach!
the!LOCKED!screen,!press!any!key!when!the!lock!is!sleeping.!If!the!controller!is!awake,!
press!QUIT!until!the!LOCKED!screen!appears.!
!
!
$&J%,('/7)G',5162)H0'7<(/+,,)
The!Display!Brightness!screen!is!accessed!from!the!LOCKED!screen.!
!
1. Press!the!Menu!key!twice.!
2. Press!the!More!softkey!3!times.!
3. Use!the!!!and!¯!softkeys!until!the!backlight!bar!graph!is!blinking.!
4. Use!¬!and!® softkeys!to!adjust!brightness.!
5. Press!the!“OK”!key.!
!
!

5
$&J%,('/7)H++5+0)K.1%3+)
1. Press!the!Menu!key!twice.!
2. Press!the!More!softkey!3!times.!
3. Use!the!!!and!¯!softkeys!until!the!beeper!volume!bar!graph!is!blinking.!
4. Use!¬!and!® softkeys!to!adjust!volume.!
5. Press!the!“OK”!key.!
!
!
-<6/7'/7)#6/7%67+)
1. Press!the!Menu!key!twice.!
2. Press!the!More!softkey!3!times.!
3. Use!the!!!and!¯!softkeys!until!the!language!is!blinking.!
4. Use!¬!and!® softkeys!to!adjust!language.!
5. Press!the!“OK”!key.!
!
!
833+&'6(+)#.*D)
!/767'/7)833+&'6(+)#.*D)
This! feature! is! used! when! Time! Lock! is! enabled! and! the! safe! is! in! an! open! period.! If!
Immediate!Lock!is!selected,!the!safe!is!placed!in!a!one-Time!Lockout!until!the!next!open!
period.!!!
!
1. Login.!
2. Press!the!“1”!(I-Lock)!key!from!the!Main!Menu.!
3. Select!Open1!or!Open2!using!the!softkeys!below!the!left-hand!side!of!the!display.!
4. Enter!the!number!of!hours!that!you!want!the!system!to!remain!locked!out,!up!to!144!
hours.!
5. Press!ENTER.!The!system!will!display!the!time!and!date!when!the!lockout!period!will!
end.!Write!that!down!so!you!remember!it.!
!
!/6:1'/7)833+&'6(+)#.*D)(this!is!an!administrative))
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“3”!(Access).!
4. Press!“1”!(Door!Access).!
5. Press!“3”!(Im!Lock).!
6. Enable!or!disable!the!feature!for!Lock!1!with!the!“YES/NO”!key.!
7. Press!the!“OK”!softkey!to!save!the!change.!
8. If!applicable,!repeat!steps!6!and!7!for!the!second!lock.!
)
G.;/1.6&)6/)$%&'()
1. Login.!
2. Press!the!“2”!(Audit)!key!from!the!Main!Menu.!

6
3. Insert!the!USB!flash!drive!into!the!USB!connector!on!the!bottom!of!the!controller.!
4. Press!the!“OK”!softkey!located!beneath!the!display!on!the!right-hand!side.!
5. After!the!download!is!complete,!remove!the!USB!flash!drive.!
6. Audits!can!be!downloaded!onto!a!PC!with!the!use!of!“ESLDat”!software.!
!
-./(0.11+0)"+(('/7,)
H6*D'/7)L5)-./(0.11+0)"+(('/7,)
If! you! are! an! ESLAudit! lock! administrator,! it! is! recommended! that! you! back! up! the!
settings!of!each!lock!you!are!responsible!for!managing.!Each!time!you!change!a!setting!
on!the!lock,!you!will!be!asked!to!do!a!backup!by!inserting!a!USB!Flashdrive!into!the!USB!
connector.! If! you! are! managing! multiple! locations,! each! location! should! use! a! unique!
Flashdrive!to!avoid!over-writing!data!from!other!systems.!
!
1. Login.!
2. Press!“4”!(USB).!
3. Press!“1”!(Save!System).!
4. Insert!USB!flash!drive.!
5. Press!the!“OK”!softkey.!
!
M+,(.0'/7)-./(0.11+0)"+(('/7,)I0.3)6)H6*D%5)N'1+)
-6%('./O!Restoring!the!system!configuration!from!the!USB!Flashdrive!will!over-write!all!
current!system!settings.!If!you!have!made!any!changes!to!the!configuration!or!users!at!
the! Controller! without! saving! them,! then! the! backup! you! are! loading! will! cause! those!
changes!to!be!lost.!You!should!always!back!up!the!system!after!any!change,!and!use!that!
Backup!as!the!base!for!alterations!with!ESLConfig!and!restoration.!
!!
1. Login!
2. Press!“4”!(USB).!
3. Press!“2”!(Load!System).!
4. Insert!USB!flash!drive.!
5. Press!the!“OK”!softkey.!
6. Press!the!“OK”!softkey.!
!
-<6/7+)=8>)
1. Login!
2. Press!“3”!(Admin).!
3. Press!“1”!(PIN!chg).!
4. Enter!new!PIN.!
5. Press!the!“OK”!softkey.!
6. Enter!new!PIN!again.!
7. Press!the!“OK”!softkey.!

7
L,+0)$&3'/',(06('./)
$&&'/7)L,+0,)(restricted!to!managing!user!levels))
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“2”!(Users).!
4. Press!“1”!(Add).!
5. Select!User!Profile!with!softkeys.!
6. Press!ENTER/SAVE!key.!
7. Select!login!type!with!softkeys!(key/PIN,!PIN!only,!key!only).!
8. Press!ENTER/SAVE!key.!
9. If!applicable,!you!will!be!asked!to!present!the!key!to!the!key!reader.!
10. Enter!username.!
11. Press!the!ENTER/SAVE!key.!
!
If!you!enroll!a!new!key/PIN!user,!the!user!will!be!enrolled!with!an!initial!PIN!of!
1,1,1,1,1,1.!If!you!enroll!a!PIN-only!user,!the!initial!PIN!will!be!their!two!digit!user!
number!followed!by!six!1’s!(X,X,1,1,1,1,1,1).!The!user!will!be!required!to!enter!a!new!PIN!
upon!first!login.!PINs!that!are!in!use!by!another!user!or!that!are!deemed!too!simple!will!
not!be!allowed.!
!
Users!can!also!be!enrolled!with!the!use!of!a!PC!application!called!ESLConfig.!
!
!&'('/7)6)L,+0P,)=0.I'1+)(restricted!to!managing!user!levels))
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“2”!(Users).!
4. Press!“2”!(Edit).!
5. Use!¬!and!® softkeys!to!scroll!to!find!the!user!you!wish!to!edit.!
6. Press!the!ENTER/SAVE!Key!to!select!the!user.!
7. Select!a!user!profile!using!the!¬!and!® softkeys.!
8. Press!the!ENTER/SAVE!Key.!
9. Select!a!user!login!type.!
10. Press!the!ENTER/SAVE!key.!
11. Present!the!user’s!Dallas!key!to!the!reader!(if!applicable).!
12. Edit!the!username.!
13. Press!the!ENTER/SAVE!key!
!
G+1+('/7)6)L,+0)(restricted!to!managing!user!levels))
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“2”!(Users).!
4. Press!“3”!(Delete).!
5. Use!the!¬!and!® softkeys!to!scroll!to!find!the!user!you!wish!to!edit.!
6. Press!the!ENTER/SAVE!key!to!select!the!user.!

8
7. Confirm!your!wish!to!delete!the!user!with!the!“OK”!softkey.!
)
!/6:1'/7?G',6:1'/7)6)L,+0)(restricted!to!managing!user!levels))
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“2”!(Users).!
4. Press!“4”!En/Disable.!
5. Use!the!¬!and!® softkeys!to!scroll!to!find!the!user!you!want!to!enable/disable.!
6. Press!the!ENTER/SAVE!key!to!select!the!user.!
7. Confirm!your!wish!to!change!the!status!of!the!user!with!the!“OK”!softkey.!
!
=%07'/7)$11)L,+0,)(restricted!to!higher!managing!user!levels))
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“2”!(Users).!
4. Press!“5”!(Purge).!
5. Confirm!your!wish!to!purge!all!users!except!yourself!with!the!“OK”!softkey.!
!
G%61)-./(0.1)(restricted!to!Administrative!user!levels))
This!feature!requires!two!users!working!together!to!open!a!specified!door.!
!
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“3”!(Access).!
4. Press!“1”!(Door!Access).!
5. Press!“2”!(DualCnt).!
6. Enable!or!disable!the!feature!for!Lock!1!with!the!“YES/NO”!key.!
7. Press!the!“OK”!softkey!to!save!the!change.!
8. If!applicable,!repeat!steps!6!and!7!for!the!second!lock.!
!
F'3+)Q)G6(+)-./(0.1,)
"+(('/7)F'3+)G+162)(restricted!to!administrative!user!levels))
This!feature!delays!the!opening!of!a!specified!lock!for!a!specified!amount!of!time.!
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“3”!(Access).!
4. Press!“1”!(Door!Access).!
5. Press!“1”!(T!Delay).!
6. Each!lock!has!its!own!screen.!
7. Turn!feature!on/off!with!the!YES/NO!key.!
8. Scroll!to!other!fields!using!the!soft!arrow!keys.!
9. “Delay”!is!the!number!of!minutes!that!opening!will!be!delayed.!

9
10. “Open”!is!the!number!of!minutes!for!the!open!window.!Users!can!only!open!the!safe!
for!that!amount!of!time.!If!they!wait!longer!than!the!specified!amount!of!time,!they!
will!have!to!start!the!process!over.!
11. Press!the!“OK”!softkey!to!get!to!the!screen!for!the!second!lock,!if!applicable.!
12. Press!the!ENTER/SAVE!key!to!save!your!changes.!
!
F'3+)#.*D)(restricted!to!administrative!user!levels))
This!feature!establishes!windows!of!time!when!the!safe!can!be!opened.!The!open!windows!
can!only!be!programmed!with!the!use!of!the!PC!application!ESLConfig.!This!feature!can!be!
turned!on/off!by!a!user!with!the!appropriate!authority!at!the!controller.!
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“3”!(Access).!
4. Press!“1”!(Door!Access).!
5. Press!“2”!(Tm!Lock).!
6. Enable!or!disable!the!feature!for!Lock!1!with!the!“YES/NO”!key.!
7. Press!the!“OK”!softkey!to!save!the!change.!
8. If!applicable,!repeat!steps!6!and!7!for!the!second!lock.!
!
G621'7<()"6A'/7,)F'3+)(restricted!to!administrative!user!levels))
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“3”!(Access).!
4. Press!“2”!(Daylight!Savings).!
5. Enable!or!disable!this!feature!with!the!YES/NO!key.!
6. Press!the!“OK”!key.!
7. Set!the!beginning!time.!
8. Use!the!!!and!¯!softkeys!to!change!field!values.!
9. Use!the!¬!and!® softkeys!to!move!between!fields.!
10. Press!the!“OK”!key.!
11. Set!the!end!time.!
12. Use!the!!!and!¯!softkeys!to!change!field!values.!
13. Use!the!¬!and!® softkeys!to!move!between!fields.!
14. Press!the!“OK”!key.!
!
-<6/7'/7)G6(+)6/&)F'3+)(restricted!to!managing!user!levels))
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“3”!(Access).!
4. Press!“4”!(Date/Time).!
5. Use!the!number!keys!to!enter!data.!
6. Use!the!soft!arrow!keys!to!move!between!fields.!
7. Press!the!ENTER/SAVE!key!to!save!your!changes.!
!
!

10
!
R.1'&62)#.*D.%()(restricted!to!managing!user!levels))
This!feature!allows!users!with!certain!authorities!to!establish!a!holiday!schedule.!On!these!
established!days,!the!safe!cannot!be!opened.!There!are!a!maximum!of!eight!stored!holidays.!
!
1. Login.!
2. Press!“3”!(Admin).!
3. Press!“3”!(Access).!
4. Press!“3”!(Holiday!Lockouts).!
5. Use!the!number!keys!to!enter!data.!
6. Use!the!soft!arrow!keys!to!move!between!fields.!
7. Press!the!ENTER/SAVE!key!to!move!to!screen!2.!
8. Use!the!number!keys!to!enter!data!on!screen!2.!
9. User!the!soft!arrow!keys!to!move!between!fields.!
10. Press!the!ENTER/SAVE!key!to!save!your!changes.!
!
L5&6(+)".I(;60+)
1. Login.!
2. Press!“4”!(USB).!
3. Press!“3”!(Firmware!Update)!
4. Insert!the!USB!Flashdrive!into!the!USB!connector!located!on!the!bottom!of!the!
controller.!
5. Press!the!“OK”!softkey.!
6. Press!the!“OK”!softkey.!
7. The!system!will!now!reboot.!
8. Remove!the!USB!Flashdrive!when!complete.!
!
Note:!User!settings!and!system!configuration!are!not!changed!with!this!process.!
!
!"#-./I'7)
ESLConfig!is!a!PC!application!that!allows!users!to!modify!the!settings!of!an!ESLAudit!system.!To!
use!this!utility,!you!must!first!download!the!system!settings!from!the!applicable!controller!(see!
page!6).!After!the!ESLConfig!program!is!installed!on!a!PC!and!the!program!is!running,!insert!the!
flash!drive!into!the!PC’s!USB!port.!From!the!File!menu!on!the!top!left!of!the!screen,!select!Open,!
and! then! choose! the! appropriate! file! on! the! flash! drive.! The! name! of! the! file! saved! by! the!
controller!will!be!ESLAUDIT.EAS.!!
!
Backup! copies! of! system! configurations! can! be! saved.! To! save! a! backup! copy! of! the!
configuration,!select!File!at!the!top!left-hand!corner!of!the!window!and!choose!Save.!This!will!
save!a!backup!copy!with!the!file!name!of!the!controller!serial!number!followed!by!the!date!and!
time! the! file! was! saved! by! the! controller! (EAxxxxxxx.yy.mm.dd.hh.mm).! The! file! type! is! ESL!
Setup!(.EAS).!
!

11
To!move!a!copy!of!a!system!configuration!from!ESLConfig!to!a!controller,!select!File!at!the!top!
left-hand! corner! of! the! window,! choose! Output! to! Flash! Drive,! and! then! choose! All.! This! will!
save!the!configuration!file!with!the!name!ESLAUDIT.EAS.!!To!load!the!configuration!file!into!the!
controller,!see!page!6.!
!
Settings!are!modified!on!the!screens!that!are!shown!below:!
!
!
!
"2,(+3)Q)#.*D)"+(%5)
!
G621'7<()"6A'/7,)
Auto!Daylight!Savings!Enable!will!cause!the!system!clock!to!change!appropriately!on!the!
Sunday!morning!of!the!indicated!week.!
!
G%0+,,)
Duress! Alarm! Enable! will! activate! duress! codes.! Duress! codes! are! both! one! number!
higher!and!one!number!lower!than!any!PIN!value.!For!example,!if!your!PIN!is!515151,!if!
you!log!into!the!system!with!either!PIN!515152!or!515150,!a!duress!signal!will!be!sent!to!
the! monitoring! station! through! the! store’s! alarm! system.! For! this! feature! to! function,!
the!optional!AC!expansion!module!must!be!installed!and!connected!to!the!store’s!alarm!
system.!
!
$%S)8/5%())
Aux!Input)is!a!feature!that!allows!an!optional!switch!to!be!installed!into!the!optional!AC!
expansion! module.! If! this! feature! is! installed! and! enabled! and! Time! Lock! is! enabled,!

12
when! the! switch! is! pressed,! the! safe! is! put! into! immediate! lockout! the! Aux! Input! is!
opened!and!there!is!an!appropriate!Time!Lock!Open!Period.!
!
R.1'&62,)
Scheduled! holidays)are! days! that! the! safe! cannot! be! opened.! The! lockout! runs! from!
midnight!to!midnight.!
!
#.*D)"+(%5)
The! bottom! half! of! the! screen! is! used! for! lock! settings.! You! can! move! between! the!
settings!for!Lock!1!and!Lock!2!by!using!the!Prev.!and!Next!buttons!on!the!bottom!of!the!
screen.!
!
#.*D)F25+)
This!setting!is!currently!unused!at!this!time.!
!
G..0)R.1&)F'3+)
This!setting!controls!the!number!of!seconds!that!a!user!has!to!open!the!door!after!the!
appropriate!open!door!softkey!is!pressed.!
!
G..0)45+/)F'3+))
This!setting!controls!the!number!of!minutes!the!door!can!be!left!open!before!the!alarm!
goes!off.!
!
G%61)-./(0.1))
This!requires!two!users!to!open!the!specified!door.!
!
833+&'6(+)#.*D)
If! Immediate! Lock! is! enabled! and! Time! Lock! is! enabled,! when! a! user! with! the!
appropriate!permissions!presses!I-lock!(1)!from!the!Main!Menu!and!selects!a!door,!the!
selected!door!is!put!into!a!one-Time!Lockout!until!the!end!of!the!I-Lock!period.!
!
F'3+)G+162)
To!enable!this!feature,!check!the!Time!Delay!box!for!the!applicable!lock.!!
!
G+162)=+0'.&))
This! is! the! number! of! minutes! that! must! elapse! before! the! applicable! door! can! be!
opened.!Once!the!Delay!Period!has!passed,!the!user(s)!will!have!the!number!of!minutes!
in!the!Open!Period!to!log!in!and!open!the!applicable!door.!!
!
45+/)=+0'.&)
This!is!the!amount!of!time!a!user!has!to!log!in!and!open!a!door!after!the!Delay!Period!
has!passed.!If!the!Open!Period!passes,!users!will!have!to!log!in!and!wait!for!a!new!Delay!
Period!to!expire!before!they!will!be!given!the!opportunity!to!open!the!door.!
!

13
F'3+)#.*D)
The!Time! Lock!box! must!be!checked!to!enable! this!feature.! When!enabled,!a! lock!can!
only!be!opened!during!an!open!period.!Up!to!four!open!periods!can!be!defined!for!each!
day!of!the!week.!For!each!open!period,!the!starting!time!is!established!Open!Time!and!
the!duration!of!each!open!period!is!specified!in!hours.!Settings!are!established!for!each!
day!of!the!week.!
!
By!clicking!on!any!of!the!three!duplicate!display!setting!boxes,!you!can!copy!the!settings!
for!the!day!that!is!displayed!to!other!days.!!
!
L,+0)"+(%5)
!
The!second!tab!in!the!ESLConfig!program!is!the!User!Setup!tab.!
!
!
!
!&'()L,+0,)
To!edit!users,!scroll!through!the!user!numbers!with!the!Prev.!and!Next!buttons!located!
on!the!upper!right!of!the!User!Setup!screen.!The!Add!and!Del!buttons!are!used!to!add!or!
delete!a!user.!
)
F25+,).I)L,+0,)
There!are!eight!standard!user!profiles!with!predetermined!permissions:!
!
Door!1!User!
Door!2!User!
Door!1-2!User!

14
Manager!!
Auditor!
Regional!Manager!
Courier!
Super!User!
!!
You!can!review!the!specific!permissions!of!each!user!profile!by!looking!at!which!
permission!boxes!are!checked!after!a!particular!profile!is!selected.!You!can!give!a!user!
any!set!of!permissions!by!checking!the!custom!profile!box.!
!
You!should!assign!each!user!a!Username!so!it!shows!up!in!the!Audit!Trail.!
!
Access!modes!are!used!to!define!key!only,!PIN!only!and!key/PIN!users.!
!
You!can!save!the!file!for!later!use!with!ESLConfig!by!clicking!the!File!tab!and!then!
selecting!Save.!You!cannot!safe!a!file!to!be!uploaded!to!a!controller!with!this!method.!
!
On!the!File!tab,!select!Output!to!Flashdrive!and!then!All!to!save!a!file!that!can!be!
uploaded!into!a!controller.!The!name!of!this!file!will!be!ESLAUDIT.EAS.!
!
!
K'+;)6/)$%&'()
1. Install!the!program!ESLDat!onto!your!PC.!
2. Open!the!program!ESLDat.!
!
!
!
3. Select!Audit!Trail.!
4. Select!the!File!ESLAUDIT.EAA.!
!
!
