Amseco EWP-202C User manual

20ft. Range
2~3ft.
Min.
EWP-202C
WIRELESS ANNUNCIATOR SYSTEM
Potter Electric Signal Co., LLC • St. Louis, MO •Cust Service: 866-240-1870 • Tech Support:866-956-1211• Canada 888-882-1833•www.pottersignal.com
A Brand
• Advanced dual-infrared beam and superior wireless technology
• Wireless multi-function receiver
• Dual channel receiver with status LED’s
• 20 ft. detection range across doorway
• Independent entry/exit counters
• 200 ft. wireless RF transmission in open eld
• 2 selective chime sounds per channel
• Chime volume control
• Resettable 6-digit counter (up to 999999)
• Power failure memory back-up
• Wireless push-button included
• 16 million I.D. codes system
The EWP-202C is a two channel wireless annunciator system designed with a superior dual counter and active infrared technology. It delivers
a pleasant chime along with a recorded count. It emits a continuous, invisible dual beam across the doorway to the reector. When either beam
is interrupted, it announces the entrance or exit of customers with a pleasant, distinguishable chime sound. Each event is counted, recorded, and
registered by the built-in digital counter and can be viewed and compared later in both modes. The annunciator is also equipped with an alert
mode that sounds the built-in siren when triggered, adding additional security. This is ideal for malls, ofce buildings, liquor stores, warehouses,
parking structures, medical ofces, and more.
Complete Kit Includes:
1 Infrared sensor/transmitter
1 Wireless receiver with built-in chime and counter
1 Wireless push-button
1 Reector
2 Power transformers (12V AC 20VA)
1 Long plastic bracket
1 Short metal bracket
2 Short plastic brackets
2 6 ft. power cords with in-line switch
6 3/4” sheet metal screws
1 1/2” bolt with locking washer
4 1 1/4” machine screws with washer and nut
2 1/2” sheet metal screws
Application
Wireless Receiver
Keeps count on all incoming and outgoing customers and retains
it in memory.
PAGE 1 OF 2
PRINTED IN USA
Stock number: 4130003
MKT. #8850052 - REV B
2/10

MKT. #8850052 - REV B
2/10
PAGE 2 OF 2
PRINTED IN USA
A Brand
Model EWPT-202 EWPP-202 EWPR-202
Description Infrared Sensor/
Transmitter
Wireless Push-
Button
Wireless
Receiver
Detection Method Active Infrared -RF
Detection Range 10 ft. JP2 = ON 20 ft.
JP2 = OFF (f.s.)
- -
Max. Transmission Range 200 ft. Open Field 200 ft. Open Field -
Power Source 12V AC 20 VA 12V DC
Battery Included
12V AC 20VA
Power Consumption
(Standby)
50mA -100mA
Power Consumption
(In Activation)
1 Amp -500mA
Volume Control - - 0-85dB
Chime Sounds Selectable -Dip Switch: 2 Dip Switch: 1
Response Time 4m/sec - -
Light Source Infrared Pulse
Beam 950nm
- -
Wireless
Frequency
315 Mhz 315Mhz 315Mhz
Chime Terminal
Output (-)
Ground - -
ChimeTerminal Output
(+V)
12V DC 1A - -
Chime Terminal
Output (OC)
Exit Output (-)
TR Output 1A
- -
Chime Terminal
Output (IC)
Entry Output (-)
TR Output 1A
- -
Terminal 1 & 2 12V AC Input -12V AC Input
Terminal 3 - - Relay Dry Contact
N.O. (2 sec)
Terminal 4 - - Relay Dry Contact
COM (2 sec)
Entry/Exit Time
Delay
- - JP1 ON = 30 sec
JP1 OFF = 60 sec
Alarm Sound
Duration
- - 50 Sec
Alarm Sound ON/OFF - - JP2 ON / JP2 OFF
Sensitivity JP2 ON = Min
JP2 OFF = Max
- -
Travel Direction SW1 Selectable - -
Blocked Infrared
Beam Warning
JP1 Selective:
OFF/10Sec/60Sec
- -
Counter Memory - - EEPROM
Installation Indoor Indoor Indoor
Operating
Temperature Range
14 - 122°F
(-10 - 50°C)
14 - 122°F
(-10 - 50°C)
14 - 122°F
(-10 - 50°C)
Specications
f.s. = Factory Setting
EWP-202C
WIRELESS ANNUNCIATOR SYSTEM
Integration to Security Devices
Protect restricted, unauthorized areas after hours by simply changing
the setting on your receiver from CHIME to ALERT MODE. This
feature provides a programmable entry/exit delay (30 or 60 seconds)
and a 50 second audible alarm when triggered. The EWP-202C alarm
relay output allows you to connect to any security control panel or
to a number of other devices such as: video event recorder, self-
contained siren, bell box, strobe, or any other device designed for
alarm signaling to provide additional security.
Alert Mode
Bell Box (ABB-1031)
Strobe (SL-401)
Siren (SSX-51)
Power Supply
12V DC 1A Video Recorder
Alarm Central
System Security
Control Panel
Alarm
Signal
Relay
Output
