INSTALLATION GUIDE
INSPIRED EXPERT PLAYER
IS-XPT-2100

IMPORTANT SAFETY INSTRUCTIONS
COPYRIGHT NOTICE
AMX© 2016, all rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of AMX. Copyright protection claimed
extends to AMX hardware and software and includes all forms and matters copyrightable material and information now allowed by statutory or judicial
law or herein after granted, including without limitation, material generated from the software programs which are displayed on the screen such as
icons, screen display looks, etc. Reproduction or disassembly of embodied computer programs or algorithms is expressly prohibited.
LIABILITY NOTICE
No patent liability is assumed with respect to the use of information contained herein. While every precaution has been taken in the preparation of this
publication, AMX assumes no responsibility for error or omissions. No liability is assumed for damages resulting from the use of the information
contained herein. Further, this publication and features described herein are subject to change without notice.
AMX WARRANTY AND RETURN POLICY
The AMX Warranty and Return Policy and related documents can be viewed/downloaded at www.amx.com.
1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Install in accordance with the manufacturer's instructions.
8. DO NOT install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding prong. The wider blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11. ONLY USE attachments/accessories specified by the manufacturer.
12. USE ONLY with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. UNPLUG this apparatus during lightning storms or when unused for long periods of time.
14. REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
15. DO NOT expose this apparatus to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on
the apparatus.
16. To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord plug from the AC receptacle.
17. Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.
18. DO NOT overload wall outlets or extension cords beyond their rated capacity as this can cause electric shock or fire.
The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons.
ESD Warning: The icon to the left indicates text regarding potential danger associated with the discharge of static electricity from an outside
source (such as human hands) into an integrated circuit, often resulting in damage to the circuit.
WARNING: To reduce the risk of f ire or electrical shock, do not expose this apparatus to rain or moisture.
WARNING: No naked flame sources - such as candles - should be placed on the product.
WARNING: Equipment shall be connected to a MAINS socket outlet with a protective earthing connection.
WARNING: To reduce the risk of electric shock, grounding of the center pin of this plug must be maintained.

Table o f Co nten ts
i
IS Expert 2100 Installation Guide
Table of Contents
IS XPert .............................................................................................................1
Overview ........................................................................................................................... 1
IS XPert - Components..................................................................................................... 1
Inspired Composer Software Application .............................................................................................. 1
Installing Inspired Composer ................................................................................................................ 1
Setting up Inspired Composer ............................................................................................................... 2
IS-XPT-2100 Inspired XPert Player ..................................................................3
Overview ............................................................................................................................ 3
Features............................................................................................................................. 3
Compatibility ..................................................................................................................... 3
Important Safety Markings ............................................................................................... 3
Product Specifications ..................................................................................................... 4
IS-XPT-2100 Installation ..................................................................................5
Overview ............................................................................................................................ 5
Wall Mounting the IS-XPT-2100 ....................................................................................... 5
Connect a USB Mouse and Keyboard to the IS-XPT-2100................................................ 6
Connect the HDMI Display(s) to the IS-XPT-2100............................................................ 6
Connecting to a Single Display ............................................................................................................... 6
Connecting to Two Displays ................................................................................................................... 6
Connect the IS-XPT-2100 to the Controller PC (via LAN) ................................................ 6
Apply Power to the IS-XPT-2100 ...................................................................................... 6
IS-XPT-2100 Player Configuration ...................................................................7
Overview ........................................................................................................................... 7
Diagnostic Screen ................................................................................................................................... 7
Accessing the Player Web Configuration Tool ................................................................. 7
Quick Wizard - Screen Configuration ................................................................................ 8
Quick Wizard - Network Configuration .............................................................................. 9
IS-XPT-2100 Networking Overview........................................................................................................ 9
Regional Configuration................................................................................................... 10
Restarting the IS-XPT-2100 ................................................................................................................. 10
Turning off the Diagnostic Screen and Changing the Password ................................... 10
Removing QuickTime from an XPT-2100 ....................................................................... 10
On the XPT-2100 .................................................................................................................................. 10
Using Two Monitors with the IS-XPT-2100.................................................................... 11
Appendix: Connecting the IS-XPT-2100 to a LAN via Link-Local Addressing 13
Overview ......................................................................................................................... 13

IS XPert
1
IS Expert 2100 Installation Guide
IS XPert
Overview
IS XPert is a simple, ready to deploy, Signage solution that provides the benefits of a full digital Signage system without the need
for consultants or design services.
IS XPert - Components
The following software applications and hardware components comprise the IS XPert solution (FIG. 1):
Inspired Composer Software Application
Inspired Composer is a content management application. It is installed on a Windows-based desktop or server and accessed
through a web browser, either directly in the case of the desktop version, or via a network. (FIG. 2).
Inspired Composer provides several key functions:
It allows end users to create, customize and publish content.
It allows Administrators to manage Users and User Groups as well as pools of content called Resource Pools.
It allows Administrators to manage a collection of Players.
It allows Managers/Administrators to approve content and playlist changes made by end users.
Composer enables taking Templates created by AMX's Graphic Design team, and creating Messages from these Templates, with
customized media and data. These Messages are then added to Playlists and published to the relevant Players, so that the new
content can be displayed on screen. Typically one Message corresponds to one digital sign. Composer can control a large number
of Playlists, each with its own set of Messages.
FIG. 1 IS XPert - Components
FIG. 2 Inspired Composer Web Application
Inspired Composer
access via web browser
IS-XPT 2100
Use Inspired Composer to create
and publish custom digital
Signage content
The IS-XPT-2100 Player runs
the "Player" application
(no user intervention required)
Custom Signage display
Custom content created with
the Inspired Composer software is
displayed on screen.

IS XPert
2
IS Expert 2100 Installation Guide
Installing Inspired Composer
Refer to the Composer Desktop Installation Guide or Composer Server Installation Guide as appropriate for installation instructions.
Setting up Inspired Composer
Composer needs to be setup in order to display content on the Player. Note that the operations described below must be carried
out in the correct order to avoid problems. Refer to the IS XPert 2100 Instruction Manual for instructions.
The process is as follows:
1. Import/Manually Configure your Player(s)
2. Add Player(s) to the Publish Point System (A hierarchical grouping of Players)
3. Import Template Packs and publish these Template Packs to Player(s)
4. Add a Layout Message to the Layout Playlist
5. Add content Messages to the Area Playlists
6. Publish changes to the Player(s)

IS-XPT-2100 Inspired XPert Player
3
IS Expert 2100 Installation Guide
IS-XPT-2100 Inspired XPert Player
Overview
The IS-XPT-2100 Inspired XPert Player (FG1232-100) is a self-contained solution for Inspired Signage software that delivers
content to a display. The Player runs the Babel and Player applications. FIG. 3 indicates the front and rear panel components of the
IS-XPT-2100:
Features
High-definition video output at up to 1080p
Small size
Serial port control for attached display or other device using supplied USB to serial port cable
Networked
Compatibility
Warning, the IS-XPT-2100 Inspired XPert Player is only compatible with Composer 4.8 or higher.
The running version of Composer is displayed in one of these locations:
Composer 4.8 - At the top of the main Composer screen in the blue status bar next to “Composer”
Composer 5 or higher - On the Dashboard at the bottom of the Welcome screen in the right pane in the “About Composer”
list.
Important Safety Markings
NOTE: Power supply cords shall have conductors with cross-sectional areas sufficient for the rated current of the equipment.
Conductors shall be sized based on the requirements in the National Electrical Code, ANSI/NFPA 70, and the Canadian Electrical
Code, Part I, CSA C22.1. The length of a power supply cord shall not exceed 4.5 m.
Product Specif ications
FIG. 3 IS-XPT-2100 Inspired XPert Player
IS-XPT-2100 Product Specif ications
Dimensions (HWD) 1.62” x 4.61” x 4.43” (41.15mm x 117.0mm x 112.52mm)
Power DC 19V, 65 Watt
Environment • Operating Temperature : 0 ~ +55°C (32 ~ 131°F)
• Storage Temperature : -20 ~ +70ºC (-4 ~ 158ºF)
Operating System Windows Embedded POSReady7 Operating System
Front Panel Component
USB Port 1 USB 2.0 Port can be used to connect a mouse/keyboard
Note: The Player is designed to be used without a keyboard and mouse; they are not required for normal
operation.
Rear Panel Components
Power connector • 65W (19V DC,3.42A)
• Input Voltage AC 100-240V 1.5A 50-60Hz
USB Ports 2 USB 2.0 Ports, can be used for connecting a mouse/keyboard
Ethernet Port RJ-45 Ethernet port provides Gigabit Ethernet communication between the Player and the Controller PC
(which runs the Inspired Composer application).
Connect the Ethernet port to the LAN
HDMI Ports Two HDMI output ports provide HD video output to one or two displays, via HDMI cable.
See page 6 for details on sending video to two displays.
front back

IS-XPT-2100 Inspired XPert Player
4
IS Expert 2100 Installation Guide
Certifications • UL/CSA 60950-1 / EN 60950-1
• IEC 60950-1 / NOM-019-SCFI-1998
•GOST-R/CISPR22
• CISPR 24 / FCC 47 CFR Part 15, Subpart B
• ICES-003 / EN 55022
• EN 55024 / EN 61000-3-2
• EN 61000-3-3 / IEC/EN 61000-4 Series
• VCCI V-3 / KN-22
•KN-24/CNS13438
• Europe RoHS / China RoHS
Included Accessories • One power adapter
• One USB to serial port cable for control of external devices with a serial port e.g. the Player’s monitor
• One VESA/wall mounting bracket
IS-XPT-2100 Product Specif ications

IS-XPT-2100 Installation
5
IS Expert 2100 Installation Guide
IS-XPT-2100 Installation
Overview
This section describes installing the IS-XPT-2100. Refer to the following sections for related instructions. For instructions on using
the Player Web Configuration tool to configure the IS-XPT-2100, refer to the IS-XPT-2100 Player Configuration section on page 7.
Wall Mounting the IS-XPT-2100
The IS-XPT-2100 includes a mounting plate and hardware to mount the player to a wall, as described below:
1. Orient the mounting plate so that the label This Way Up is visible and facing vertically upwards, see FIG. 4:
2. Use the mounting plate as a template to mark the location of the four corner holes on the mounting surface, and drill four
holes in the wall.
3. Use the supplied mounting screws to secure the mounting plate to the wall.
4. Attach two of the larger screws to the two midpoint holes on the base of the IS-XPT-2100, and slot the unit into the mounting
plate (FIG. 5):
FIG. 4 Orient the mount plate correctly on the wall
FIG. 5 Attach screws to the two midpoint holes on the IS-XPT-2100
Use the four corner holes
to secure the mounting
plate to the wall
2 large screws
attached to
base of the
IS-XPT-2100
The 2 large screws in the base
of the IS-XPT-2100 slot into the
2 mounting holes on the wallplate

IS-XPT-2100 Installation
6
IS Expert 2100 Installation Guide
5. The IS-XPT-2100 should now be firmly attached to the wall (FIG. 6):
Once the IS-XPT-2100 is mounted, you can connect cables to the device.
Connect a USB Mouse and Keyboard to the IS-XPT-2100
Two USB 2.0 ports on the rear panel of the IS-XPT-2100 can be used to connect a mouse/keyboard, which will be necessary to
navigate and configure the player.
Connect the HDMI Display(s) to the IS-XPT-2100
Two HDMI output ports on the rear panel of the IS-XPT-2100 provide HD video output to one or two displays:
Connecting to a Single Display
If connecting a single display, use an HDMI cable to connect the left-side HDMI connector to the HDMI display device.
Connecting to Two Displays
If connecting two displays, use two HDMI cables to connect each HDMI connector to a display device.
Some basic configuration is required when using both HDMI outputs - refer to the Using Two Monitors with the IS-XPT-
2100 section on page 11 for details.
Connect the IS-XPT-2100 to the Controller PC (via LAN)
NOTE: The term "Controller PC" refers to the PC that is running the Inspired Composer application.
An RJ-45 Ethernet port on the rear panel of the IS-XPT-2100 provides Gigabit Ethernet communication between the Player and the
Controller PC.
Use an Ethernet cable to connect the IS-XPT-2100 to the LAN on which the Controller PC is present.
Apply Power to the IS-XPT-2100
Use the provided power adapter to connect the Player to a power outlet.
When the IS-XPT-2100 is turned on for the first time, the Diagnostic screen is displayed (see FIG. 7 on page 7). This screen
displays important information about the Player: Network settings, Display settings (with Test Patterns), and NetLinx settings
(which allow you to control the content displayed on the Player using a NetLinx controller).
Once the IS-XPT-2100 is connected to the Controller PC, to a display device, and is receiving power, you can configure the player
via the Player Web Configuration tool. Refer to the IS-XPT-2100 Player Configuration section on page 7 for device configuration
instructions.
FIG. 6 IS-XPT-2100 Mounted via the Mounting Plate

IS-XPT-2100 Player Configuration
7
IS Expert 2100 Installation Guide
IS-XPT-2100 Player Conf iguration
Overview
The IS-XPT-2100 provides a built-in web console called the Player Web Configuration tool to configure the player. This section
describes how to use the Player Web Configuration tool to configure the IS-XPT-2100.
NOTE: The instructions in this section assume that the IS-XPT-2100 will be installed on a DHCP network. For instructions on installing
on a non-DHCP network, refer the Appendix: Connecting the IS-XPT-2100 to a LAN via Link-Local Addressing on page 13.
Diagnostic Screen
When the IS-XPT-2100 is powered on for the first time, the Diagnostic screen is displayed (see FIG. 7). This screen displays
important information about the Player: Network settings, Display settings (with Test Patterns), and NetLinx settings (which
controls the content displayed on the Player using a NetLinx controller).
NOTE: When displaying screen shots of the system as shown in FIG. 7, the clock time displayed in the bottom left corner using black
text shows when the screen shot was actually taken. The black clock text is not a live system clock. The actual live system clock is
displayed in green text in the Web Configuration tool menus.
Accessing the Player Web Conf iguration Tool
NOTE: The Player Web Configuration tool requires the Microsoft Silverlight plugin (http://www.microsoft.com/getsilverlight/Get-
Started/Install/Default.aspx). If it is not already installed, the Silverlight plugin will be downloaded automatically when you first
access the Player Web Configuration tool.
To access the Player Web Configuration tool, in order to configure the IS-XPT-2100, enter the following URL into Internet Explorer:
http://<Player IP>
for example, http://192.168.81.98
Note that the IS-XPT-2100’s IP address is indicated on the Diagnostics screen, under Network (FIG. 8):
IMPORTANT: Make a note of the Player IP address for future reference as this IP address is used when configuring the Player in
Composer.
Once connected to the Player Web Configuration tool, the Quick Wizard will guide you through configuring the new Player. The
Player Configuration Wizard consists of three pages:
Screen - Player display settings e.g. display resolution
Network - Player Network settings
Language - Player Date/Time and Locale settings
Complete each page and click next to continue to the next page in the wizard. These pages are described in the following sections.
FIG. 7 Default Player Screen - Diagnostic Screen
FIG. 8 Diagnostic Screen (Player IP Address)

IS-XPT-2100 Player Configuration
8
IS Expert 2100 Installation Guide
Quick Wizard - Screen Conf iguration
The first page of the Quick Wizard is the Screen Configuration page. The options on this page allow you to configure the display of
content output by the IS-XPT-2100 on the display devices. These settings include Screen (Output) Resolution, Aspect Ratio, and
Rotation Setting (FIG. 9).
1. The IS-XPT-2100 will attempt to select the best resolution for the attached display using the EDID (Extended Display
Identification) system. If your display does not support EDID or if you wish to use a different resolution, select an output
resolution from the standard resolution options provided in the Output Resolution drop-down menu.
If you want to specify a custom output resolution, select Custom from the menu. With Custom selected, the Custom Width
and Custom Height fields are enabled. Enter the desired resolution (width and height in pixels).
2. The IS-XPT-2100 will attempt to select a suitable aspect ratio for the attached display using the EDID system Alternatively you
can select an output aspect ratio from the standard aspect ratio options provided in the Aspect Ratio drop-down menu.
If you want to specify a custom aspect ratio, select Custom from the menu. With Custom selected, the Custom X and Custom
Yfields are enabled. Enter the desired aspect ratio.
3. If the display screen is mounted upside down or sideways, you may need to change the output orientation from the Player. To
rotate the output display, select the desired degree of counter-clockwise rotation from the Rotation (Counterclockwise)
drop-down menu.
The default setting is 0(zero = no rotation). Other settings are 90, 180, and 270.
Use the first and last of these settings if the Player is displaying portrait content or if the Player is mounted on its side.
Select 180 degrees if the display is mounted upside down.
4. This screen also contains a small number of settings for Player display logging (known as As-Run Logging). As run logging
enables users to log which messages play, for how long, and the contents of those messages. This data can be used to bill
another customer for advertising, or for data mining purposes.
To configure the IS-XPT-2100 to log what it displays, set the check box Enable As-Run Logging.
Once this setting is enabled the Player will log the names of the digital signs (called Messages in Composer) it displays and the
data that makes up the signs.
Note that this may result in excessively large log files. If you do not need the content data, and the name is sufficient, then set
the check box Exclude Template Data. Both of these settings can be changed later if you are not certain what is required.
However, be aware that data on what has been displayed is only available for signs (Messages) published to the Player after
this setting is enabled.
5. Click Next to proceed to the Network Configuration page.
FIG. 9 Quick Wizard - Screen Configuration page

IS-XPT-2100 Player Configuration
9
IS Expert 2100 Installation Guide
Quick Wizard - Network Configuration
The next page of the Quick Wizard is the Network Configuration page (FIG. 10). The options on this page allow you to configure the
IS-XPT-2100’s network settings.
NOTE: The instructions in this section assume that the IS-XPT-2100 will be installed on a DHCP network. For instructions on installing
on a non-DHCP network, refer the Appendix: Connecting the IS-XPT-2100 to a LAN via Link-Local Addressing on page 13.
IS-XPT-2100 Networking Overview
The IS-XPT-2100 must be connected to a network to allow it to be configured and to provide the ability to update the content
displayed on the Player. The IS-XPT-2100 requires the following permanent network connections:
A connection from the PC on which the Inspired Composer application is installed, for content updates
A connection to a server running IS XPort to provide feeds such as RSS, Flickr, etc. (optional)
The location of the Player in the network topology, and the choice of a PC to install the Inspired Composer content management
software should be determined accordingly.
NOTE: To ensure connectivity between the Inspired Composer application and the Player, it is important that the IP address of the
Player does not change.
Set the IS-XPT-2100’s Network settings as follows:
1. Enter a name for the Player in the Host Name field.
The Host Name is returned to Bonjour, to make it easy to identify Players in the Internet Explorer Bonjour plugin device list and
in Composer.
2. By default, DHCP is enabled for the Player, in which case all of the TCP/IP fields are disabled. AMX recommends using DHCP
and configuring a DHCP Server to prevent the Player IP address from changing.
To manually configure these settings, de-select DHCP and enter the desired Machine IP, Subnet Mask, Default Gateway and
Primary/Secondary DNS values in the respective fields. Ask your Network administrator for these values, and make a note of
the IP address for later reference.
3. Click Next to proceed to the Regional Configuration page.
FIG. 10 Quick Wizard - Network Configuration page

IS-XPT-2100 Player Configuration
10
IS Expert 2100 Installation Guide
Regional Conf iguration
Use the options in the Regional Configuration page to access the Time Zone, current Date & Time settings, and Locale for the IS-
XPT-2100 (FIG. 11):
1. Set the date for the IS-XPT-2100 by entering a date in the date field or by using the calendar icon.
2. Set the time by entering the time in 24 hour notation.
3. Set the locale using the Language drop down menu, this affects the way dates are displayed on the Player.
4. Select the appropriate time zone from the Time zone drop-down menu (FIG. 11).
Restarting the IS-XPT-2100
After setting the Time Zone, Date/Time, and Display settings, you will be prompted to restart the IS-XPT-2100 to apply the changes
you have made in the three sections of the Player configuration wizard.
NOTE: The web page will show that the Player has restarted after approximately 20 seconds.
Turning off the Diagnostic Screen and Changing the Password
1. To access the Player Web Configuration tool, enter the following URL into Internet Explorer:
http://<Player IP>
for example, http://192.168.81.98
2. Login to the Player:
a. Click the Login button in the left pane of the Player Web Configuration tool.
b. Enter the default username and password as follows:
User = Administrator
Password = administrator
3. Click Liveview in the left pane, and select Hide Diagnostics in the right pane. The Player should no longer display diagnostic
information on the screen.
4. Change the password for the Player by clicking Change Password in the left hand pane. Enter your current password and the
new password you wish to use. You are now ready to publish content to this Player using Composer.
Removing QuickTime from an XPT-2100
Due to security concerns, QuickTime have been removed from the XPT-2200s from the factory. To remove QuickTime from previous
players, follow these steps:
On the XPT-2100
1. Either VNC to the player, or log on directly.
2. Close the player with ALT+F4, Minimize the Caretaker application (using the minimize button in the top right).
3. Close all other application windows.
4. Press Start, goto Control Panel, and open Programs and Features
5. Select Quicktime, and Right-click on it, and then Uninstall.
6. You will be prompted for Administrator credentials, enter ISAdmin and normal password.
7. Follow the uninstall process.
FIG. 11 Quick Wizard - Regional Configuration page

IS-XPT-2100 Player Configuration
11
IS Expert 2100 Installation Guide
8. Next. reboot the Player for the new setting to take effect. Select the Power option on the left menu tree (FIG. 12).
FIG. 12 Live View - Power Option
9. Select Hard Reset at the top off the page and wait for the Player to reboot. As-Run Logging is now enabled.
NOTE: .Mov files will no longer play following the reboot.
Using Two Monitors with the IS-XPT-2100
The two HDMI output ports on the rear panel of the IS-XPT-2100 provide the ability to send HD video output to two displays. If
connecting two displays, use two HDMI cables to connect each HDMI connector to a display device. Some basic configuration is
required when using both HDMI outputs:
1. Connect a USB mouse and keyboard to the Player
2. Press Alt-F4 to stop playback on the Player (if necessary).
3. Right click on the desktop and select Graphics Properties (FIG. 13):
4. In the Intel HD Graphics Control Panel, select Displays > Multiple Displays (FIG. 14):
FIG. 13 Select Graphics Properties
FIG. 14 Select Multiple Displays
Select Power to Reset
Select Hard Reset

IS-XPT-2100 Player Configuration
12
IS Expert 2100 Installation Guide
5. Select Display Mode > Clone ( FIG. 15):
FIG. 15 Select Clone Display Mode

Appendix: Connecting the IS-XPT-2100 to a LAN via Link-Local Addressing
13
IS Expert 2100 Installation Guide
Appendix: Connecting the IS-XPT-2100 to a LAN via
Link-Local Addressing
Overview
By using the Player’s built-in Zeroconf feature and the Bonjour for Windows plug-in, users can install and configure the Player in a
network that does not have a DHCP Server via link-local addressing. Install the Bonjour for Windows plugin from apple.com/
support/downloads/bonjourforwindows.html.
To establish a network connection from a PC to the Player:
1. Directly connect a PC and the IS-XPT-2100 , and apply power to the IS-XPT-2100 .
2. Confirm that the PC has assigned itself an IP address:
a. If the PC's network interface is set to DHCP, wait several minutes to ensure the PC reverts to link-local addressing.
b. Confirm that the PC has assigned itself an IP by running ipconf ig from a CMD shell (FIG. 16).
The example in FIG. 16 shows the Ethernet adapter Local Area Connection: could not find a DHCP server and assigned itself
the IP address of 169.254.83.124 with Subnet Mask 255.255.0.0. This is a valid link-local address.
If the PC did not assign itself a 169.254.x.x address, or if the PC assigned itself the address 169.254.2.2 then proceed to Step
3. Otherwise, skip to Step 4.
3. Manually assign an IP address, via the Internet Properties (TCP/IP) Properties dialog (FIG. 17):
You may need to manually assign the IP on the PC if the PC does not support link-local addressing or if the PC assigned itself
the IP address of 169.254.2.2.
The Player assigns itself 169.254.2.2 by default when it reverts to link-local addressing.
Therefore, in order to avoid conflict the PC cannot be assigned IP address 169.254.2.2.
Manually set the PC's IP address to 169.254.1.1 and subnet mask to 255.255.0.0 (FIG. 17).
4. Launch Internet Explorer and select the Bonjour Plug-in.
5. Double-click the IS-XPT-2100 in the Bonjour Plug-in pane to start the Player Web Configuration Tool wizard.
NOTE: The Web Configuration Tool requires the Microsoft Silverlight plugin. The first time you access the Web Configuration Tool a
prompt will appear to install this plugin. You will need to be connected to the internet to install the Plugin.
FIG. 16 CMD shell (ipconfig)
FIG. 17 Manually assigning an IP address on the PC

© 2016 Harman. All rights reserved. Metreau, NetLinx, AMX, AV FOR AN IT WORLD, HARMAN, and their respective logos are registered trademarks of
HARMAN. Oracle, Java and any other company or brand name referenced may be trademarks/registered trademarks of their respective companies.
AMX does not assume responsibility for errors or omissions. AMX also reserves the right to alter specifications without prior notice at any time.
The AMX Warranty and Return Policy and related documents can be viewed/downloaded at www.amx.com.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 AMX.com | 800.222.0193 | 469.624.8000 | +1.469.624.7400 | fax [phone]
AMX (UK) LTD, AMX by HARMAN - Unit C, Auster Road, Clifton Moor, York, YO30 4GD United Kingdom • [phone] • www.amx.com/eu/
Last Revised:
6/03/2016
