Advantech DS-080 series User manual

DS-080
Ultra Slim
Digital Signage Player

DS-080 Series User Manual 2
Copyright
The documentation and the software included with this product are copyrighted 2015 by
Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make
improvements in the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or transmitted in any
form or by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements of
the rights of third parties, which may result from its use.。

DS-080 Series User Manual 3
Acknowledgements
Award is a trademark of Award Software International, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Corporation.
Intel® and ATOM® are trademarks of Intel Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
ESS is a trademark of ESS Technology, Inc.
UMC is a trademark of United Microelectronics Corporation.
SMI is a trademark of Silicon Motion, Inc.
Creative is a trademark of Creative Technology LTD.
CHRONTEL is a trademark of Chrontel Inc.
All other product names or trademarks are properties of their respective owners.
For more information about this and other Advantech products, please visit our
web-site at: http://www.advantech.com/ For technical support and service, please visit
our support website at: http://support.advantech.com.tw/support/

DS-080 Series User Manual 4
Product Warranty (24 months)
Advantech warrants to you, the original purchaser, that each of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been subject to
misuse, abuse, accident or improper installation. Advantech assumes no liability under the
terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of our
customers never need to use our repair service. If an Advantech product is defective, it will
be repaired or replaced at no charge during the warranty period. For outof-warranty repairs,
you will be billed according to the cost of replacement materials, service time and freight.
Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
–Collect all the information about the problem encountered. (For example, CPU speed,
Advantech products used, other hardware and software used, etc.) Note anything abnormal
and list any onscreen messages you get when the problem occurs.
–Call your dealer and describe the problem. Please have your manual, product, and
any helpful information readily available.
–If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return more quickly.
–Carefully pack the defective product, a fully-completed Repair and Replacement Order
Card and a photocopy of the proof of purchase date (such as your sales receipt) in a
shippable container. A product returned without proof of the purchase date is not eligible for
warranty service.
–Write the RMA number visibly on the outside of the package and ship it prepaid to your
dealer.

DS-080 Series User Manual 5
Declaration of Conformity
–FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.

DS-080 Series User Manual 6
Technical Support and Assistance
1. Visit the Advantech website at www.advantech.com/support where you can find the latest
information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service center for
technical support if you need additional assistance. Please have the following information
ready before you call:
Product name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application
software, etc.)
A complete description of the problem
The exact wording of any error messages
Warnings, Cautions and Notes
Warning! Warnings indicate conditions, which if not observed, can cause personal injury!
Caution!Cautions are included to help you avoid damaging hardware or losing data.
e.g. There is a danger of a new battery exploding if it is incorrectly installed. Do not
attempt to recharge, force open, or heat the battery. Replace the battery only with the
same or equivalent type recommended by the manufacturer. Discard used batteries
according to the manufacturer's instructions.
Note! Notes provide optional additional information.

DS-080 Series User Manual 7
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not
use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and
must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may
cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment from
overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to
the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the
power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be opened only by
qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service personnel:
The power cord or plug is damaged
Liquid has penetrated the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE
TEMPERATURE MAY GO BELOW -20°C (-4°F) OR ABOVE 60°C (140°F). THIS
COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A
CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.
REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE
MANUFACTURER, DISCARD USED BATTERIES ACCORDING TO THE
MANUFACTURER'S INSTRUCTIONS.
17. The sound pressure level at the operator's position according to IEC 704-1:1982 is no more

DS-080 Series User Manual 8
than 70 dB (A).
18. RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted
Access Area.
19. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims
all responsibility for the accuracy of any statements contained herein.

DS-080 Series User Manual 9
Packing List
Before installation, please ensure the following items have been shipped:
1 x DS-080 series player
1 x Driver/Utility Disk
1 x China RoHS Sheet
1 x Simplified Chinese User manual
1 x Traditional Chinese User manual
1 x Mounting kit

DS-080 Series User Manual 10
DS-080 Series Part Number:
DS-080GB-S8A1E
DS-080GF-S8A1E
DS-080GB-S9A1E
DS-080GF-S9A1E
DS-080GB-U2A1E
DS-080GF-U2A1E

DS-080 Series User Manual 11
Chapter 1
General Introduction
This chapter gives background
information on DS-080 series

DS-080 Series User Manual 12
1.1 Introduction
DS-080 series is powered by Intel®Core™ i7/i5/Celeron™ processors for Full HD video playback
performance. DS-060 series is a media player that delivers advanced graphics performance for all
your signage applications. DS-060 series has dual HDMI to provide multi display outputs
simultaneously. For better connectivity, it supports 2x LAN, internal 1 x Mini PCIe interface for add-on
functions such as wireless network and TV tuner cards to fulfill different requirements. And also
supports 4x USB 3.0, 1xCOM ports for system integration and applications.
1.2 Product Features
1.2.1 General
Supports Intel® Core ™ i7/i5/Celeron™ processors
Supports2 x HDMI、2 x GbE、4 x USB、1 x COM (RS-232)
Supports 2.5” SATA HDD drive bay (Height 7mm )
Built-in MiniPCIe slot for easy expansion
Ultra Slim Features, easy to install. Easy integration and easy maintenance
1.2.2 Display
Support up to 3940 x 2160 @ 30 Hz video playback performance (subject to the video
media format and playback software)
1.2.3 Power Consumption
Typical：4.34 W (5th Gen Intel®Core™ i5-5350U 1.8 GHz)
Max：15.59 W (5th Gen Intel®Core™ i5-5350U 1.8 GHz)
1.3 Hardware Specifications
CPU：5th Gen Intel®Core™ i7/i5/Celeron™ processors
System Chipset: Integrated in SOC
Graphic chipet: Integrated graphics built in Processor
BIOS AMI uEFI 128 Mbit
System Memory: 2 x 204pin SODIMM, support DDR3L 1600 MHz，Up to 8 GB single
DIMM
HDD: Supports 2.5” SATA HDD drive bay (Height 7mm)
Watchdog Timer：supported by Advantech SUSIAccess
IO Interfaces
–1 x RS-232/RS-422/RS-485 or 2 x RS-422/RS-485 with extension cable
–2 x HDMI
–4 x USB 3.0 compliant

DS-080 Series User Manual 13
–1 x (SPDIF/Line-out/ Mic-in), support Jack Sense
Ethernet Chipset: 1 x Intel I211; 1 x Intel I218
–Speed: 100/1000 Mbps
–Interface：2 x RJ-45 jacks with LED
–Standard：IEEE 802.3z/ab (1000 Base-T) 或IEEE 802.3u 100 Base-T compliant
Resolution:
–3840 x 2160 @ 30Hz (Core i7/i5)
–1920 x 1080 @ 60Hz (Celeron)
Expansion
–MiniPCIe：1 socket internal
1.4 Mechanical Specification
1.4.1 Dimension
180 x 190 x 19mm (L x W x H)
Figure1.1：Diemnsions
1.4.2 Weight
0.87 kg (1.92 lbs)

DS-080 Series User Manual 14
1.5 Power Requirements
1.5.1 System Power
Minimum power input: DC19V, 3.42A
1.5.2 RTC Battery
3V/200mAH BR2032
1.6 Environmental Specifications
1.6.1 Operating Temperature
0°C - 40°C (32~122°F)
1.6.2 Relative Humidity
95% @ 40°C ( Non Condensing )
1.6.3 Storage Temperature
-20 ~ 60°C (-4~140°F)
1.6.4 Vibration Loading During Operation
0.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis.
1.6.5 Shock During Vibration
20 G, IEC 60068-2-27, half sine, 11 ms duration
1.6.6 Safety
UL, BSMI, CCC
1.6.7 EMC
CE, FCC Class B, BSMI, CCC

DS-080 Series User Manual 15
Chapter 2
Hardware Installation
This chapter introduces external IO
and the installation of DS-080 series
Hardware

DS-080 Series User Manual 16
2.1 DS-080 Series I/O Connectors
Figure 2.1：Front View
Figure 2.2：Rear View
2.2 DS-080 Series External I/O Connectors
2.2.1 Power ON/OFF Button
DS-080 Series has a power ON/OFF button on the front side. Push this button to turn the
system ON and OFF. It also supports a 5 second delay soft power off.
Figure 2.3：Power Button
2.2.2 DC Input Connector
DS-080 Series supports 19VDC DC power in.
Figure 2.4：DC Input Connector
2.2.3 LAN Connector
DS-080 Series provides two RJ-45 LAN interface connector, fully compliant with

DS-080 Series User Manual 17
IEEE802.3u 10/100/1000 Base-T CSMA/CD standards. The Ethernet port provides a
standard RJ-45 jack connector with LED indicators to show its Active/Link status and
speed status.
Figure 2.5：LAN Connector
LAN Port Pin Assignments
Pin
Signal
1
MDI0+
2
MDI0-
3
MDI1+
4
MDI1-
5
GND
6
GND
7
MDI2+
8
MDI2-
9
MDI3+
10
MDI3-
11
VCC
12
ACT
13
+V3.3 & Link1000#
14
+V3.3 & Link100#
2.2.4 HDMI Connector
The HDMI (High-Definition Multimedia Interface) provides an all-digital audio/video
interface to transmit the uncompressed audio/video signals and is HDCP compliant.
Connect the HDMI audio/video device to this port. HDMI technology can support a
maximum resolution of 3940 x 2160 @ 30 Hz but the actual resolution supported depends
on the monitor being used.
Figure 2.6：HDMI Connector
HDMI Pin Assignments
Pin
Signal
1
TMDS Data 2+
2
TMDS Data 2 shield
3
TMDS Data 2-
4
TMDS Data 1+
5
TMDS Data 1 shield
6
TMDS Data 1-
7
TMDS Data 0+
8
TMDS Data 0 shield
9
TTMDS Data 0-

DS-080 Series User Manual 18
10
TMDS Clock+
11
TMDS Clock shield
12
TMDS Clock-
13
CEC
14
Reserved
15
SCL
16
SDA
17
DDC/CEC Ground
18
+5V
19
Hot Plug Detect
2.2.5 USB Connectors
DS-080 Series provides four USB interface connectors, which gives complete Plug & Play
and hot swapping capability for up to 127 external devices. The USB interface is compliant
with USB UHCI, Rev. 3.0. The USB interface supports Plug and Play, which enables you to
connect or disconnect a device without turning off the system.
Figure 2.7：USB Connector
USB Port Pin Assignments
Pin
Signal
1
VCC
2
USB Data-
3
USB Data+
4
GND
2.2.6 COM Connector
DS-080 Series provides one D-sub 9-pin connectors serial communication interface port.
The ports support RS-232/RS-422/RS-485 mode communications.
Figure 2.8：COM Connector
COM Port Pin Assignments
Pin
Signal
1
DCD
2
RxD
3
TxD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS

DS-080 Series User Manual 19
9
RI
2.2.7 Audio Connectors
DS-080 Series S/PDIF can be connected to Stereo speakers, earphone or surround
speakers.
Figure 2.9：Audio Connector

DS-080 Series User Manual 20
2.3 Hardware Installation
2.3.1 Attached HDD Thermal Pads
(1) Attached thermal pads on DS-080 HDD bracket
Figure 2.10.1：Attach HDD thermal pads
(2) Attached thermal pads on HDD
Figure 2.10.2：Attach HDD thermal pads
Caution! Don’t cover thermal pad over the a small hole in HDD enclosure (about
0.5 mm in breadth)
