AMX X1 User manual
Using wired earphones
Box Contents
10
Box Contents
X1 Wireless Earphone
X1 Wireless Earphone
USB charging cable
3.5mm detachable cable with MMCX connector
User manual
User manual
Chipset: 8645 with aptXTM
Usage time 6H~
Charging
Pairing
• Plug the micro USB cable into the micro USB port as mentioned in diagram (2) and
connect the other end of the cable to either a computer USB port or to a USB-compatible
car or wall charger.
• While charging, the LED indicator turns red.
• When charging is complete, the LED light will turn blue. Charging time is
approximately 1-2 hours.
NOTE: Battery status will be indicated next to the bluetooth icon in apple devices.
• For pairing new devices, While powered off, Press and hold the power button for 6-10
seconds until the LED indicator blinks rapidly with Blue & Red light.
NOTE: If your earbuds are already turned on, you must first power off the
earbuds before completing the above step.
• On your Bluetooth-enabled smartphone, tablet or media player, navigate to the
Bluetooth settings menu, turn on the Bluetooth and search for new devices.
• After a few seconds you will see “ X1 ” listed.
• Tap “ X1 ” to select it. The LED will begin to slowly blink blue, and the earbuds will
emit a tone to indicate that it has been successfully paired with your device.
NOTE: If your device asks for a password to connect to the earbuds, enter “0000”
Play
• Connect your device to the earbuds via Bluetooth (see “Pair &
Connect with a New Device”).
• Open your favorite music app and press play.
• Control the music, track & volume from your device, or control them from the in-line
controls on the earbuds. Press the “Power” button once to
play/pause music & answer calls, or press it twice to re-dial the last call you made.
• Press the “^” or “ ” button once raise/lower the volume on the earbuds. Press and
hold briefly to skip to the next/previous track. Note: Volume on your device and on
the earbuds are controlled separately.
• All audio, including music, games, videos, and notifications will be routed through
“ X1 ”.
Troubleshooting
No power Recharge your earbuds using the included micro USB cable.
Try using a different micro USB cable.
Make sure your Bluetooth device has A2DP profile.
Check if both devices are paired and connected over
Bluetooth. Restart the earbuds to reconnect your
Bluetooth device.
Navigate to your Bluetooth settings menu on your
Bluetooth device, tap “ X1 ”, and
select “Forget”. Now follow the steps to pair your
device again.
Music is not playing
over Bluetooth
Bluetooth device
fails to connect.
^
3.5mm detachable cable with MMCX connector
Using Wired Earphones
Button functionality is not guaranteed.
Play/Pause: Press once gently.
Next track: Press twice
Answer or Hang up:Press and release once to Answer or
Hang up a call.
Reject Call: Press and hold for 2-3 seconds to reject a call.
Voice Command: Press and Hold until voice command is
activated (Device dependant).
Previous track: Press thrice
10
AMX
comfort.
1. Keep the product away from direct sunlight, high temperature and humidity. This
may shorten the lifespan of X1 wireless earphones or battery or the internal circuit board.
2. Do not try to take the product apart as it may void the warranty and lead to damage of the
product.
3. Do not clean the product with any detergent or chemical. Remove dirt with a damp cloth.
4. Keep away from magnets.
5. Do not pull the wire as it may damage the earphone, Instead hold the wire plug and pull
out to disconnect.
6. Power o headset when not in use and store in the pouch provided to prolong the lifespan
of the product.
7. Always detach the earbuds gently while switching the wires.
Thank you for your purchase of the AMX wireless earphones. This product comes with a 12 months
warranty from the date of original purchase directly from AMX or from AMX authorised distributors for
We will answer your email within 48 hours. For more information, please visit www.amxlabs.in
The warranty will stand cancelled if the product is damaged resulting from misuse or mishandling of
the product or if you are unable to provide the original invoice.
12
Disclaimer:
Bluetooth(R) is a registered trademark of Bluetooth SIG Inc.
CSR aptX(TM) is a registered trademark of Qualcomm Technologies International, Ltd.
Table of contents
