AMX NXT-BP User manual

Quick Start Guide
NXT-BP and NXT-CHG Modero Power Pack and Power Station
For more detailed installation and operating instructions, refer to the touch
panel’s instruction manual, available on-line at www.amx.com.
Overview of the NXT-BP and NXT-CHG
The NXT-BP is a rechargeable Lithium-Ion "smart" battery used with the
Modero NXA-BASE/B Battery Base. This battery provides the user with an
on-board battery life indicator (FIG. 3).
The NXT-CHG Modero Power Station is a two bay, stand-alone battery
charger that is compliant with the Smart Battery System. This tabletop unit
can be used to recharge up to two NXT-BP batteries. The batteries are
charged in the order they are inserted into the NXT-CHG.
The NXT-CHG Slot 1 has the feature of being able to completely discharge
and recharge (Recalibrate) a battery. Refer to FIG. 2 for more information.
Specifications
Powering the NXT-CHG
The NXT-CHG uses an included power supply to provide power for charging
the batteries.
1. Connect the terminal end of the included power supply to the rear of
the NXT-CHG Charger.
2. Provide power to the unit by connecting the other end (plug) into a
power socket that meets the requirements outlined in the
Specifications section for the NXT-CHG.
Reading NXT-CHG LED Indicator
FIG. 2 shows the front connectors on the NXT-CHG Modero Power Station.
There is one LED indicator in front of each bay (FIG. 2) that conveys the
status of that bay as follows:
• Off: No battery detected
• Green Flashing: Fast charging
• Green Solid: Fully charged
• Yellow Flashing: Recalibration in process
• Yellow/Green: Recalibration complete
• Yellow Solid: Standby (waiting for other battery to charge)
• Red Flash: Error (problem with either the battery connection to the
internal slot or the battery itself)
Checking the NXT-BP Charge
1. Press the Battery Life Indicator button (FIG. 3) once to illuminate the
Battery Life LEDs and display the percent charge remaining on the
battery.
2. Repeat these steps for the remaining NXT-BP battery.
3. Charge the batteries by inserting them within the battery charger.
Refer to the following section for more detailed information on this
process.
AT T E N T I O N !
If the 25% LED indicator is blinking, this indicates there is less than 5% of a
charge remaining on the battery.
FIG. 1 Optional NXT-BP battery and NXT-CHG charger
Specifications
Dimensions (HWD):
NXT-BP
(FG2255-10)
NXT-CHG
(FG2250-50)
• 0.69" x 3.50" x 5.81" (1.75 cm x 8.89 cm x 14.76 cm)
• 2.02" x 4.89" x 6.89" (5.13 cm x 12.42 cm x 17.50 cm)
Power: • NXT-BP Battery Voltage - 11.1 Volts
• NXT-CHG: 90 - 264 VAC, 47-63 Hz, Single Phase
(using the included 24 VDC power supply)
Weight: • NXT-BP: 0.99 lbs (0.45 kg)
• NXT-CHG: 0.57 lbs (0.256 kg)
NXT-BP Features: • Battery Usage: 4 to 8 hours of continuous use (time is usage
dependant)
• Charge Capacity: 6300mAh
• Operating Environment: 10° C (50° F) to 35° C (95° F)
• Storage/Discharge Temperature: -20° C (-4° F) to +60° C (140° F)
NXT-CHG Features: • Charge Rate: 2.5 A @ 12 VDC
• 2-Bays: Sequential Charging
• LED: One LED indicator in front of each bay which conveys the status
of that bay. Refer to the Reading the NXT-CHG LED Indicator section
for more information.
• Recalibration Pushbutton: located between the bays to initiate
recalibration sequence in the left bay only.
• Charge time for two depleted batteries ~ 5 hours
• Recalibration Time: Less than 9 hours
Optional Accessories: • NXT-CHG Kit (FG2250-50K):
1 charger (FG2250-50) and 2 NXT-BP batteries (FG2255-10)
• NXT-BP batteries (FG2255-10)
• NXA-BASE/B Battery Base Kit (FG2255K)
1 battery base (FG2255) and 2 NXT-BP batteries (FG2255-10)
NXT-CHG Modero Power Station
NXT-BP Modero Power Pack FIG. 2 Component locations on the NXT-CHG Modero Power Station
FIG. 3 NXT-BP Modero Power Pack (showing Battery Life Indicator and button)
Left Slot
LED
Right Slot
LED
Right Slot
Left Slot
Recalibrate
Pushbutton
(Slot 1) (Slot 2)
Battery Life Indicator
Battery Life (Charge)
button
Its recommended to
fully charge the
batteries before their
initial use

AMX Corporation reserves the right to alter specifications without notice at any time.
For full warranty information, refer to the AMX Instruction Manual(s) associated with your Product(s).
036-004-2688 4/06 ©2006
AMX Corporation. All rights reserved. The AMX logo is a trademark of AMX Corporation. AMX reserves the right to alter specifications without notice at any time.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • fax [phone] • technical support 800.932.6993 • www.amx.com
93-2255-10 REV: D
Charging an NXT-BP using the NXT-CHG
1. Provide power to the charger.
2. Align the Battery connector with the corresponding charge slot within
each of the two NXT-CHG slots (FIG. 4).
3. Firmly insert the battery into the desired slot until the battery is both
securely located within the slot and there is activity from the
corresponding Slot LED. Refer to the previous section for LED
information.
Using the NXT-CHG Recalibration Pushbutton
The recalibration process increases the accuracy of the battery charge
level.
A microprocessor controls all functions of the charger so that sequencing
and adjustment of charge parameters occur automatically without user
intervention.
1. Place the battery (selected for recalibration) securely into Slot 1
(left slot) until there is activity from the corresponding LED.
2. Push the button located between the two bays to initiate recalibration
in the left bay only.
ATTENTION!
Recalibration of the batteries is only done upon request from the Modero
on-screen Battery Base page.
FIG. 4 Battery installation procedure
NXT-BP Modero Power Pack
NXT-CHG Modero Power Station
