AMX RDA-PSM Assembly instructions

Installation Sheet
RDA-PSM 12 VDC 2.5 Amp Power Supply Module
The RDA-PSM Power Supply is a 30 W module providing an un-regulated
output of 12 VDC at 2.5 Amps. The power supply module is designed for
use with the RDA series of Radia enclosures. The RDA-PSM is used to
supply extra power to Radia control cards when the amount of power
required to drive the modules exceeds the 300 mA supply on each
controller. The module's voltage and current ratings are CE, UL, and C-UL
approved.
RDA-PSM UL and C-UL Ratings
• Output: 12 VDC @ 2.5 A output
• Input: 120 VAC
Specifications
• Dimensions (HW): 10.00" x 2.75" (25.40 cm x 6.99 cm)
• Non-phase dependant
• Use wires rated at 75°C (167°F)
• Torque terminals to 16 in-lbs. (1.84 N/M)
• Max. wire size: 10 AWG (4 mm²)
• Wire stripping length: 0.35" (9 mm)
• Fuse rating: GMA 1 A
• Weight: 2.0 lbs. (0.91 kg)
• BTU/hr: 17
• Provides 2500 mA to drive RDM modules
• Dual 2-pin connectors provided
Caution: Pre-Installation Notes
• All Class 1 wiring must be connected to proper terminals.
• Disconnect power while installing or connecting the unit.
• Keep top and bottom air vents clear at all times.
• Test loads for shorts before connecting.
• Use low-voltage wires with a 300 volt rating or greater.
• Use field installed copper conductors.
• All electrical ratings are for continuous duty.
• For indoor use only.
FIG. 1 RDA-PSM
Tr a n s fo r m e r
Line in (hot)
Neutral
High-voltage
connections
Mounting
points
External +12 V
power connector (optional)

AMX Corporation reserves the right to alter specifications without notice at any time.
For full warranty information, refer to the AMX Instruction Manual(s) associated with your Product(s).
043-019-2207 8/02 ©2002 AMX Corporation. All rights reserved.
The AMX logo is a trademark of AMX Corporation. AMX reserves the right to alter specifications without notice at any time.
3000 research drive, richardson, TX 75082 USA • 469.624.8000 • 800.222.0193 • fax [phone] • technical support 800.932.6993
Lighting Application Drawing
FIG. 2 RDA-PSM, 12 VDC 2.5 Amp Power Supply Module (Method A)
Method A
Each dimmed circuit should have
a seperate neutral
