AMX AXB-IRS4 User manual

ir/serial interface
The AXB-IRS4 AXLink IR/Serial Interface connects up to four remote
infrared or serial devices to AMX Control Systems.
Each port in the AXB-IRS4 can store up to 200 programmed commands
to control IR or serial devices, such as audio and video cassette recorders,
compact disc players and tuners.
The AXB-IRS4 generates programmed commands specific to each device
by manufacturer, model number and function. Port-by-port programmability
means you can easily upgrade your system as technological advances are
made in audiovisual equipment.

C
AXB-IRS4 (front)
GND
SER SER
IR
GND
GND
GND
IR IR
GND
SER
IR
SER
GND
GND
GND
4321
AXlink / RS-232
AXM / RX AXP / TX
GND
PWR
12VDC
PWR
1.51
[38.4 MM]
AXB-IRS4 (rear)
5.450
5.55
[138.4MM]
[141.0 MM]
AXB-IRS4 (top)
ir/serial interface
ARGENTINA • AUSTRALIA • BELGIUM • BRAZIL • CANADA • CHINA • ENGLAND • FRANCE • GERMANY • GREECE • HONG KONG • INDIA • INDONESIA • ITALY • JAPAN
LEBANON • MALAYSIA • MEXICO • NETHERLANDS • NEW ZEALAND • PHILIPPINES • PORTUGAL • RUSSIA • SINGAPORE • SPAIN • SWITZERLAND • THAILAND • TURKEY • USA
ATLANTA • BOSTON • CHICAGO • CLEVELAND • DALLAS • DENVER • INDIANAPOLIS • LOS ANGELES • MINNEAPOLIS • PHILADELPHIA • PHOENIX • PORTLAND • SPOKANE • TAMPA
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • 469.624.8000 • +1.469.624.7400 • 469.624.7153 fax • www.amx.com
©2006 AMX. All rights reserved. AMX and the AMX logo are all trademarks of AMX. AMX reserves the right to alter specifications without notice at any time.
AXB-IRS4 (FG5914)
•Controls up to four IR or serial devices
•Stores up to 200 control commands in each port
(28K total memory)
•Supports 300–19,200 baud transmission rates for stand-alone
PC control
•Emulates four devices on the AXLink bus
•Stores control commands in non-volatile
(battery-protected) memory
FRONT PANEL
AXLink: Green LED indicator for AXLink data transmission
Device: 8-position device assignment DIP switch
Carrier/Baud: 8-position carrier and data transmission DIP switch
IR/Serial: Red LED indicators for IR or serial data transmission
ENCLOSURE
•Metal with black matte finish
DIMENSIONS (HWD)
•1.51" x 5.55" x 5.45"
(3.84 cm x 14.10 cm x 13.84 cm)
WEIGHT
•1.1 lbs (495.0 g)
POWER
•12 VDC at 125 mA
MEMORY
•28K (non-volatile)
REAR PANEL
Ports 1-4: IR or serial device connectors (4-pin male)
AXLink/RS-232: AXLink bus or RS-232 connector (4-pin male)
PWR: 12 VDC power supply connector (4-pin male)
ACCESSORIES INCLUDED
•Two IR or serial connectors (2-pin female)
•AXLink connector for remote device control (4-pin female)
OPTIONAL ACCESSORIES
•12 VDC power supply, 800 mA
•AC-RK AccessoryRack Kit
•CC-IRC cables (2)
•CC-SER cables (2)
1.51
[38.4 MM]
5.55
[141.0 MM]
5.45
[138.4 MM]
