Installation Guide
IS-SPX-1300 Inspired Signage XPress Player
Overview
The IS-SPX-1300 Inspired Signage XPress Player (FG1231-11) offers a simple way to
deliver digital signage solutions. The rich set of functionalities offered by the 
IS-SPX-1300 simplifies the implementation, management and maintenance of a range
of audio/visual communication solutions.
The IS-SPX-1300 is designed to satisfy the reliability needs of nonstop 24/7 service
and minimize maintenance costs. The IS-SPX-1300 contains no moving parts and is
engineered to be used wherever digital signage displays are utilized. Whether 
integrated behind displays, beneath a technical floor, or in a custom enclosure, the 
IS-SPX-1300 is ready to deliver with a small form factor and a low power draw.
The USB interface can be used to extend the internal storage through memory sticks
or externally powered hard drives. The same interface can support external devices
such as touch screen controllers or keyboards.
Specifications
Remote Monitoring
The IS-SPX-1300 implements an intuitive on-board web interface. By connecting to
the IP address of a unit with any web browser, the user can monitor the status of the
unit and even configure specific parameters.
To support the management of a large distributed network of IS-SPX-1300 devices,
native support for the SNMP protocol is provided. Through this standard protocol, the
devices can publish all their vital parameters, including storage level and CPU status.
Via this protocol, the IS-SPX-1300 can interface with any SNMP network 
management.
These tools can provide graphical frameworks for remote monitoring the status of an
individual IS-SPX-1300 unit or a complex network of units.
FIG. 1 IS-SPX-1300 Inspired Signage XPress Player
IS-SPX-1300 Specifications
Dimensions (HWD) 1.0” x 6.27” x 3.24” (25.4mm x 159.26mm x 82.30mm).
Weight 0.80 lbs (362.88 g).
Enclosure: Metal with black matte finish.
Power Supply: • 5V DC, typ. 0.6A
• 3 watts
Power Supply Input: • 100-240V 50-60 Hz
Real time clock: • Min. accuracy 1 minute/month free running, battery backed.
Storage: • Internal storage: 4GB solid state.
• External storage: Flash drives and hard disks via USB 2.0
port.
Formats, Codecs and Encoding Parameters
Audio file formats: AIFF, MP3, M4A (or MP4), WAV and WMA.
Video file formats: AVI, ASF, MOV, MP4, VOB and WMV
Audio codecs: • AAC - up to 6 channels input; the following AAC profiles are
supported: (MPEG-2 Part 7) Low Complexity Profile, (MPEG-4
Part 3) AAC Profile and High-Efficiency AAC Profile version 1
(HE-AAC v1).
Note: HE-AAC v1 requires firmware 2.2.5 or later. HE-AAC v2 is
not supported.
•MPEG-1/2 Layer III (MP3) - the previous versions: MPEG-1/2
Audio Layer II (MP2) and MPEG-1 Audio Layer I (MP1) are
supported as well
•Linear PCM (LPCM)
•ITU-T G.711 and G.726
•Windows Media Audio (WMA)
Video codecs: • H.264 (H.264/MPEG-4 Part 10 or AVC)
•MPEG-4 (Part 2) or MPEG-4 Visual
•MPEG-2 and MPEG-1
•Windows Media Video 9 (WMV3) - Simple and Main profiles,
Low and Medium levels;
Not supported: Main Profile @ High Level (MP@HL) and the
Advanced Profile (WVC1 / VC-1 Advanced Profile).
•Motion JPEG (MJPEG) - interlacing is not supported and for
QuickTime formats only MJPEG-A is supported (MJPEG-B is
not supported).
5V-DC Input
RS232 Interface
Ethernet RJ45 USB 2.0 Connector
Reset
Analog Video Out (VGA)
Analog Audio Out
DigitalVideoOut (HDMI)
Status LED
IS-SPX-1300 Specifications (Cont.)
Formats, Codecs and Encoding Parameters (Cont.)
Profiles and Levels: •MPEG-4 (Part 2): Simple and Advanced Simple (SP/ASP
up to level 5; reference: MPEG-4 levels) - resolution up to
720p.
•MPEG-2: Main profile and Main level (MP@ML; reference:
MPEG-2 profiles and levels) - resolution up to 720p.
•H.264 (aka MPEG4 Part 10): Constrained Baseline or Main
profile up to level 3 (reference: H264 levels) - resolution up
to SD.
•MJPEG - resolution up to SD.
•Windows Media Video 9 (WMV3): Simple and Main
profiles, Low and Medium levels - resolution up to SD.
Note: MPEG-4 is the most optimized codec to use on IS-SPX
Players.
Front Panel Components:
• Ethernet RJ45 Ethernet 10/100 Mbit/s (RJ-45), IEEE 802.3u, 802.3x.
• USB 2.0
Connector Used with Flash drives and hard disks for additional external storage; interactivity events via touch screen, keyboard and
mouse.
• Status LED LED displays status of device:
• Green LED flashing once per second (regular operation)
• Green LED flashing 4 times per second (recovery mode)
• Green LED on and flashing occasionally (booting up)
• Orange LED blinks steadily (Zeroconf link-local IP address
is assigned to device)
• LED alternates between red and orange (failure)
• Reset Reset button for rebooting device.
Rear Panel Components:
• DC Power Input 5V DC, typ. 0.6A (3W).
• HDMI HDMI (incl. digital audio), DVI via adapter.
• Analog Audio Out Line level, stereo, mini-jack 3.5mm
• Analog Video Out VGA (DB15 HD connector).
• RS232 Interface RS232, up to 115200 baud, mini-jack 3.5mm.
Digital Display Compatibility
• Aspect ratio • 16:9, 16:10, 4:3 (horizontal & vertical)
• Max resolution • 1280x720 (16:9), 1024x640 (16:10), 1024x768 (4:3)
• Video output • 720p (HD-Ready), 576p, 480p, VGA; 50 or 60 fps
• 1080p: 24/25 Hz
• Video connectors • HDMI (incl. digital audio), DVI via adapter. VGA (DB15 HD
connector). Simultaneous use of HDMI and VGA possible.
Certifications: • FCC
•CE
•RoHS
Operating Temp: • HDMI: 32ºF to 104ºF (0ºC to 40ºC); 10% to 90% RH
• VGA: 32ºF to 104ºF (0ºC to 40ºC); 10% to 90% RH
Storage Temp: -13ºF to 113ºF (-25ºC to 45ºC); 10% to 90% RH
Included 
Accessories • Power Source (3A-161WP05)
Other AMX 
Equipment • AC-SMB Surface Mount Bracket Accessory (FG525)
• IS-SPX-MNT Mount adapter (FG1231-71)
• IS-SPX-SERIAL Inspired XPress Serial Cable (FG1231-60)

For full warranty information, refer to the AMX Instruction Manual(s) associated with your Product(s).
6/13
©2013 AMX. All rights reserved. AMX and the AMX logo are registered trademarks of AMX.
AMX reserves the right to alter specifications without notice at any time.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082 • 800.222.0193 • fax [phone] • technical support 800.932.6993 • www.amx.com
93-1231-11 REV: C
Storage
The IS-SPX-1300 comes with 2 gigabytes of internal memory, but this may be
expanded by connecting to external hard drives, thumb drives, or other storage
options via the USB port on the front of the device. The USB port also allows 
connection to external control devices such as touch panels.
Configuration
The IS-SPX-1300 is configured via an intuitive web interface that can be accessed by
using AMX ZeroConfiguration technology or by entering the device’s IP Address into a
ZeroConfiguration-enabled browser. This interface allows the configuration of display
modes, network settings, time zone settings, firmware updates and other operational
parameters.
For more information, refer to the IS-SPX-1000 & IS-SPX-1300 Operation/Reference
Guide.
Connectivity
The IS-SPX-1300 connects to displays through on-board HDMI and VGA connectors.
Through the HDMI output, it is possible to support DVI displays via an adapter cable,
but in this case the digital audio is lost.
Both connectors are simultaneously active so that two displays can be supported 
without the need of additional splitters or distribution amplifiers. Where analog audio is
needed, an analog audio connector is provided.
The IS-SPX-1300 is a high-definition ready device: it can render content on digital 
displays with resolution up to 1280x720 at 60Hz (720p resolution).
The maximum resolution supported by the IS-SPX-1300 is:
• 1280x720 (16:9)
• 1024x640 (16:10)
• 1024x768 (4:3)
The IS-SPX-1300 connects to the network through a standard RJ-45 connector. Each
device has a unique MAC address that allows the network to identify the unit and thus
the associated display.
The IS-SPX-1300 supports 10/100BASE-T Ethernet via a standard RJ-45 connector.
Each unit has a unique MAC address and supports all the required protocols to 
connect to network file systems and retrieve media elements.
These include:
• Ethernet 10/100 Mbit/s,
• IPv4, DHCP or fixed address
• HTTP configuration server, password protected
• HTTP client for web content retrieval
• WebDAV server, password protected
• SNMPv1/v2c,
•NTP
The IS-SPX-1300 supports USB 2.0 Hi-Speed with a bandwidth up to 10 Mbps.
Installation of the IS-SPX-1300
The installation of an IS-SPX-1300 starts by plugging in two cables, the power cable
and the video cable (HDMI and/or VGA), to the display. As soon as it is connected to
the power cable, the device will boot in a few seconds and automatically select the
resolution supported by the associated digital display. Content rendering will begin in
approximately 1½ minutes.
When connected to a local network through the RJ45 connector, the IS-SPX-1300
supports both DHCP for automatic configuration of the network and manual 
configuration by specifying a static IP address and network properties.The unit can be
easily located near the display, as it does not put off significant heat nor does it contain
any moving mechanical parts.
Note: When installing the unit, be careful to avoid any water or high humidity

exposure.
Once installed, getting started with the IS-SPX-1300 is a matter of a few simple steps.
The following sections show how to connect one or more units to a network and how
to publish content from the AMX Inspired Signage XPress software to specific 
displays.
Powering up the IS-SPX-1300
To power up the IS-SPX-1300:
1. Check your digital display. The IS-SPX-1300 can drive a digital display through
HDMI or VGA connections. Make sure that your display supports at least one of
the two.
2. Connect the IS-SPX-1300 to the display. Simply plug the HDMI or the VGA
cable between the corresponding video connector on the IS-SPX-1300 and the
corresponding video input connector of your display.
3. Power up the display. Make sure to select the right video input.
4. Power up the IS-SPX-1300. Use the cables and the power converter 
provided in the IS-SPX-1300 package. Simply plug the power converter on one
side to a 110-220V outlet and on the other to the back panel DC jack. Shortly
after power up, the screen displays the AMX splash screen.
The first time the IS-SPX-1300 boots, the automatic configuration procedure takes
about 1½ minutes. The process will be reduced to less than 50 seconds when the 
IS-SPX-1300 is rebooted. During this booting process, the front panel LED shows
green and red activity. At the end of the boot process, the screen will start displaying
the animated AMX logo. This is the default content.
At this time,the green LED blinks regularly on andoff every second to indicatethat the
IS-SPX-1300 in operating normally.
If your system does not behave as described above, make sure that the digital 
displays are functional and powered and that the correct input has been selected
Some displays have multiple inputs and you may need to manually select the right
one.
Also, make sure that the Reset pushbuttonis not being pressed by some other system
component. If the set-up appears correct, try power-cycling the IS-SPX Player by
unplugging and replugging the power to the device.
Accessing the Configuration Pages
The IS-SPX Player automatically uses DHCP to assign an IP address to the device
when first configured, but this may be changed to a preassigned IP address. To
access the IP address for the IS-SPX Player:
1. In a Zero-Configuration-enabled application, such as NetLinx Studio or in a
ZeroConfiguration-enabled browser, look for the entry for the IS-SPX Player and
its assigned serial number.
This serial number may be found on the underside of the device.
2. Click on the entry to open the device’s Web-Based Configuration Pages.
For more information, refer to the IS-SPX-1000 & IS-SPX-1300 Operation/

Reference Guide.
3. In the Status page of the Information section, the IP address is displayed below
the serial number and firmware version.
Resetting the IS-SPX-1300 to Factory Default Settings
WARNING: The following procedure will delete all the content and configurations on
the IS-SPX Player.
To reinitialize the IS-SPX Player to its factory default settings:
1. Unplug the unit from the power.
2. Push the reset button and keep it pressed.
3. Power up the IS-SPX Player.
4. Wait with the reset button pressed for at least 8 seconds.
5. Release the reset button.
6. The IS-SPX Player will now boot in the factory default mode and will have the
factory default IP address.
Updating Firmware
To check if a new version of the firmware is available for your IS-SPX Player:
1. With a Zero-Configuration-enabled browser, connect to the HTTP server for the
IS-SPX Player to access the device’s Web-Based Configuration Pages.
2. Click on Firmware Update under the Administration menu on your left.
3. Check that the field Server URI is equal to:
"http://webservices.amx.com/InspiredSignage/IS-SPX-1300/updates/".
If this is not the case, click the Reset to Default button
4. In the Manual Update section, select the update source "From server" and click
the Check for Update button.
5. A new page will open. At the end of the check, the page reports the current
update status of your IS-SPX Player. Three cases are possible:
• No updates are available.
• Updates are ready to install (see step 6).
• The update failed. The most probable source of this error is that your IS-SPX
Player could not contact the update server. It is recommended to check your
internet connection and your network configuration.
Make sure that a Gateway and a DNS server are configured. If the IS-SPX
Player is not connected to the internet, you need to contact AMX Technical 
Support to check which update procedure is best suited to your configuration.
Please specify in your message if your IS-SPX Player(s) are in a location where
you can easily plug an USB key or if they have local network connectivity.
Fatal Error: If the update process reports a fatal error, please contact AMX
Technical Support to find how to restore the firmware of your IS-SPX Player.
6. If the check for updates procedure reported that updates are available for your
IS-SPX Player, click the Update Now button to start the update process.
Important: Do not power down the IS-SPX Player at any time during the update

process.
The IS-SPX Player will restart automatically once the update process is over. It is 
possible that the web page displays a time-out error during the update. However, this
has no influence on the update process itself.
At the end of this process, refresh your web browser to display the new firmware ver-
sion under the Current Versions section. If you click the Check for Update button
again, the page will report that no updates are available.
Additional Documentation
• Refer to the IS-SPX-1000 & IS-SPX-1300 Operation Reference Guide for more
information, including additional details on Formats, Codecs and Encoding
Parameters, as well as troubleshooting information.
• Refer to the InspiredSignage XPress Programming Guide for instructions on
using the XPress configuration tool with the IS-SPX Players.
