amzchef AZ-BG709S User manual

BRAND: amzchef
MODEL NO.: AZ-BG709S
Coffee Grinder
PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
RETAIN THIS MANUAL FOR FUTURE REFERENCE
Instruction Manual

Section I: Safety Instructions
Section II: Features
Section III: Operating Instructions
Section IV: Cleaning & Maintenance
Section V: Technical Information
Section VI: Warranty
1
3
4
8
9
10
Contents

Section I: Safety Instructions
IMPORTANT SAFEGUARDS
• Appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance. Keep the appliance and its cord out of reach of
children. Cleaning and user maintenance shall not be made by children without supervision.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• Switch off the appliance and disconnect from supply before changing accessories or
approaching parts that move in use.
Please read the safety instructions and the operating instructions in full. To avoid
danger you must follow the safety and operating instructions.
This appliances is designed to be used in households and for similar uses such as:
• In kitchens for employees in shops, offices and other commercial areas.
• In agricultural businesses.
• In motels, hotels and other residential facilities and in bed and breakfast guesthouses.
Please note the following information to avoid injuries caused by misuse:
1. The appliance must not be in a cupboard during use.
2. The appliance must be connected to a properly installed earthed socket.
3. The appliance must always be disconnected from the mains supply when left unattended
and before assembly, disassembly or cleaning.
4. Before use, make sure that there are no foreign objects in the bean container of the coffee
grinder.
Any other use is considered improper and can lead to personal injury and property
damage.
Manufacturer shall not be liable for damage resulting from improper use.
5. Do not remove the lid of the bean container until the grinder has come to a complete
stop.
6. Never place your fingers or hands near the grinder mechanism and/or ground coffee
chute when the grinder is in use.
7. Do not reach into the ground coffee chute during use.
8. Do not allow the power cord to come into contact with hot surfaces.
9. Do not use the appliance if the power cord is damaged.
10. Never immerse the appliance in water.
11. Do not clean parts that come into contact with food with aggressive detergents or
scouring milk. Remove detergent residues with clean water. Further information on
cleaning can be found under “Cleaning and Care”.
12. Do not clean parts of the coffee grinder in the dishwasher.
13. Always use a soft brush to clean the grinder mechanism. Do not use water or soap for
cleaning.
14. The appliance may be used by persons with reduced physical. Sensory or mental
abilities or lack of experience and/or knowledge if they are super-vised or have been
instructed in the safe use of the appliance and have understood the hazards involved.
15. Do not allow children to play with the appliance.
16. Replacement of the power cable and any other repairs must only be carried out by
manufacturer.
17. Use of accessories not recommended or sold by the manufacturer may result in fire,
electric shock, or personal injury.
18. The appliance must not be used by children. Keep the appliance and its power cord
away from children.
1

Please note the following information to avoid injuries caused by misuse:
1. The appliance must not be in a cupboard during use.
2. The appliance must be connected to a properly installed earthed socket.
3. The appliance must always be disconnected from the mains supply when left unattended
and before assembly, disassembly or cleaning.
4. Before use, make sure that there are no foreign objects in the bean container of the coffee
grinder.
5. Do not remove the lid of the bean container until the grinder has come to a complete
stop.
6. Never place your fingers or hands near the grinder mechanism and/or ground coffee
chute when the grinder is in use.
7. Do not reach into the ground coffee chute during use.
8. Do not allow the power cord to come into contact with hot surfaces.
9. Do not use the appliance if the power cord is damaged.
10. Never immerse the appliance in water.
11. Do not clean parts that come into contact with food with aggressive detergents or
scouring milk. Remove detergent residues with clean water. Further information on
cleaning can be found under “Cleaning and Care”.
12. Do not clean parts of the coffee grinder in the dishwasher.
13. Always use a soft brush to clean the grinder mechanism. Do not use water or soap for
cleaning.
14. The appliance may be used by persons with reduced physical. Sensory or mental
abilities or lack of experience and/or knowledge if they are super-vised or have been
instructed in the safe use of the appliance and have understood the hazards involved.
15. Do not allow children to play with the appliance.
16. Replacement of the power cable and any other repairs must only be carried out by
manufacturer.
17. Use of accessories not recommended or sold by the manufacturer may result in fire,
electric shock, or personal injury.
18. The appliance must not be used by children. Keep the appliance and its power cord
away from children.
2

Section II: Features
A. Coffee Bean Hopper lid
B. Coffee Bean Hopper
C. Coarseness Selector Knob
D. Button
E. Display
F. Function Selection Button
G. Ground Coffee Container
H. Ground Coffee Container lid
I. Removable Upper Burr Blade
3

Section III: Operating Instructions
4

Before First Use:
1. Remove all packaging.
2. All appliances are tested to ensure that they are in perfect working order during manu-
facture. As a result, ground coffee residues may remain in the appliances.
3. Wash hopper, ground coffee container, container lid in warm soapy water and dry
thoroughly. Wipe exterior of grinder with a soft damp cloth and dry thoroughly.
4. Place the appliance on a dry, level and stable surface.
5. Make sure that the mains voltage in your household corresponds to the information on
the product label on the base of the appliance.
6. Connect the appliance to the power supply.
Energy Saving Feature:
• The grinder will automatically switch off if not used for 15 minutes.
• To reactivate the machine while in POWER SAVING/SLEEP MODE, press any key on the
grinder control panel.
Using Your Coffee Grinder:
• The appliance has various features to ensure ease of use and the perfect coffee.
• These features are explained below.
Filling The Coffee Beans:
1. Remove the lid on the bean container (Fig①).
2. Fill the bean container with the required quantity of coffee beans (Fig②). The fill capacity
is approx. 300g.
3. Replace the lid on the bean container (Fig③).
Note: The coffee grinder is only suitable for grinding coffee beans. Make sure that
there are no other objects or food inside the appliance.
To ensure that the grinder works properly, do not use caramel coffee beans. Please
do not fill the bean container with ground coffee.
5

Method Espresso Pour Over,
Filter Coffee, Cold Brew French Press
Recommended grind
level
Grind level setting 1-8 9-21 22-30
Fine Medium Coarse
Set Grind Level:
Please refer to the following table for recommended settings:
Choosing A Grind Programme:
Filling The Coffee Beans:
1. Depending on your individual taste, up to 30 different grind levels can be set to suit the
required preparation method - e.g. espresso, filter coffee or French press.
2. To adjust the grind level, turn the bean container with light pressure to the required
position (Fig④).
3. Depending on the preparation method, select a grind level from fine (Fine) to coarse
(Coarse).
- time/cups selection
- increase time/cups
- reduce time/cups
- start/stop
6

Select The Grinding Time:
● There are 1-40 seconds select range. If set to 30, it will grind enough coffee to serve
approximately 12 cups. This should be used as a guide only, as it will vary depending upon
preferred taste, type and roast of bean and the grind selected.
● When setting the grinding level to Coarse, it is recommended that the grinding time does
not exceed 30 seconds.
● Press the key, the symbol appears on the display.
● With the key or the key you can set the grind time from 1 to 40 seconds. Hold the
button down to fast forward.
● Press the key, the grinding process starts.
● As soon as the preset grind time is reached, the grinder switches off. The grinding process
can be stopped at any time by press the key.
● The last grind time set remain stored even after unplugging from the main power supply.
Select The Grinding Cups:
● There are 1-12 cups select range. If set to 12, it will grind enough coffee to serve approxi-
mately 12 cups. This should be used as a guide only, as it will vary depending upon preferred
taste, type and roast of bean and the grind selected.
● Press the key and choose the cup programme, the symbol appears on the
display.
● With the key or the key you can set the number of cups from 1 to 12. Hold the button
down to fast forward.
● Press the key, the grinding process starts.
● As soon as the preset number of cups is reached, the grinder switches off. The grinding
process can be stopped at any time by press the key.
● The last number of cups set remain stored even after unplugging from the main power
supply.
Note: After use, the appliance must be unplugged. Remove the Ground Coffee
Container and use the grounds as you desire.
7

Section IV: Cleaning & Maintenance
ATTENTION: Always disconnect the mains plug before cleaning!
● For the best coffee results, we recommend that you clean the bean container, grinder and
ground coffee chute regularly. Clean when the grinder is completely empty.
● The bean container can be removed from the machine for cleaning. To do this, press and
hold the button at the bottom edge of the bean container in the open position. At the same
time, turn the bean container anti-clockwise until it stops and remove it from the machine.
Remove coffee residues from the bean container with a soft, damp cloth.
● The outer grinder ring can be removed to clean the grinding mechanism. To do this, lift the
clamp upwards and unlock the grinder ring by turning it anticlockwise. Remove the grinder
ring.
● Clean the grinding mechanism with the brush provided. Remaining coffee residues can be
shaken out or removed using a vacuum cleaner.
● Replace the grinder ring in the appliance and turn it clockwise until it locks into place. It is
completely locked when the grinder ring can no longer be pulled up and out.
● Ground coffee residues on ground coffee chute and on the housing can be removed with
the enclosed brush and/or a soft, damp cloth.
● To insert the bean container, place it on the appliance and turn clockwise until it clicks into
place. In this position, the markings on the housing and on the bean container are vertically
one above the other. The coffee grinder can only be used if the bean container is correctly
inserted.
● The ground coffee container and the lid of the bean container can be cleaned with a damp
cloth.
● Never clean the coffee grinder and its removable parts in the dishwasher.
● Fresh beans will yield the best flavor and aroma.
● Only fill the bean container with the quantity of coffee beans that you intend to use
in the near future.
● The required grind quantity depends on the coffee quantity and preparation
method. Different amounts are used for the different preparation methods.
● The actual grind size for a particular setting will vary depending on many factors,
including: degree of roast (light vs. dark), freshness, humidity, type of bean, oil
content, etc. With use, you will discover which setting best meets your taste, brewing
style and other personal coffee-making preferences.
8

Section V: Technical Information
● The appliance has an overload protection for the grinding mechanism, this protects against
damage by foreign objects. If you hear a loud, rattling, previously unknown noise during the
grinding process, press the on/off button and clean the grinding mechanism as described
under “Clean & Maintenance”.
● When the appliance is not in use it switches off after 15 minutes.
Product Name Coffee Grinder
Model AZ-BG709S
Rated Voltage 120V
Rated Frequency 60Hz
Rated Power 160W
Weight 1.98 KGS/4.4 LB
Manufacturer: Foshan Ultra Electrical Appliances Co.,Ltd
Add: No. 6 Road 11 Science & Technology Industrial Park, Xingtan, Shunde, Foshan, Guangdong, China
Contact：Emily Tel：[phone] E-Mail：[email protected]
9

10
