Analog Devices SHARC EZ-Extender User manual

a
SHARC®USB
EZ-Extender®Manual
Revision 2.1, August 2012
Part Number
82-000197-01
Analog Devices, Inc.
One Technology Way
Norwood, Mass. 02062-9106

Copyright Information
© 2012 Analog Devices, Inc., ALL RIGHTS RESERVED. This docu-
ment may not be reproduced in any form without prior, express written
consent from Analog Devices, Inc.
Printed in the USA.
Disclaimer
Analog Devices, Inc. reserves the right to change this product without
prior notice. Information furnished by Analog Devices is believed to be
accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use; nor for any infringement of patents or other rights of
third parties which may result from its use. No license is granted by impli-
cation or otherwise under the patent rights of Analog Devices, Inc.
Trademark and Service Mark Notice
The Analog Devices logo, CrossCore, EngineerZone, EZ-Extender,
EZ-KIT Lite, SHARC, and VisualDSP++ are registered trademarks of
Analog Devices, Inc.
All other brand and product names are trademarks or service marks of
their respective owners.

Regulatory Compliance
The SHARC USB EZ-Extender is designed to be used solely in a labora-
tory environment. The board is not intended for use as a consumer end
product or as a portion of a consumer end product. The board is an open
system design which does not include a shielded enclosure and therefore
may cause interference to other electrical devices in close proximity. This
board should not be used in or near any medical equipment or RF devices.
The SHARC USB EZ-Extender has been certified to comply with the
essential requirements of the European EMC directive 89/336/EEC
(inclusive 93/68/EEC) and, therefore, carries the “CE” mark.
The SHARC USB EZ-Extender had been appended to Analog Devices,
Inc. EMC Technical File (EMC TF) referenced “DSPTOOLS1” dated
December 21, 1997 and was declared CE compliant by an appointed
Notified Body (No.0673) as listed below.
Notified Body Statement of Compliance: Z600ANA1.026
Issued by: Technology International (Europe) Limited
60 Shrivenham Hundred Business Park
Shrivenham, Swindon, SN6 8TY, UK
The SHARC USB EZ-Extender contains ESD (electrostatic discharge)
sensitive devices. Electrostatic charges readily accumulate on the human
body and equipment and can discharge without detection. Permanent
damage may occur on devices subjected to high-energy discharges. Proper
ESD precautions are recommended to avoid performance degradation or
loss of functionality. Store unused extender boards in the protective
shipping package.

SHARC USB EZ-Extender Manual v
CONTENTS
PREFACE
Product Overview ....................................................................... viii
Purpose of This Manual ................................................................ ix
Intended Audience ........................................................................ ix
Manual Contents .......................................................................... ix
What’s New in This Manual ........................................................... x
Technical Support .......................................................................... x
Supported Products ....................................................................... xi
Product Information .................................................................... xii
Analog Devices Web Site ........................................................ xii
EngineerZone ......................................................................... xii
Related Documents ..................................................................... xiii
USB EZ-EXTENDER INTERFACE
USB EZ-Extender Setup ............................................................... 1-1
USB Software Documentation ................................................. 1-2
USB 2.0 Interface ......................................................................... 1-2

Contents
vi SHARC USB EZ-Extender Manual
USB EZ-EXTENDER HARDWARE REFERENCE
System Architecture ...................................................................... 2-1
Processor Select Jumper (JP1) ....................................................... 2-2
USB EZ-EXTENDER BILL OF MATERIALS
USB EZ-EXTENDER SCHEMATIC
INDEX

SHARC USB EZ-Extender Manual vii
PREFACE
Thank you for purchasing the SHARC®USB EZ-Extender®, Analog
Devices, Inc. extension board to the EZ-KIT Lite®evaluation systems for
ADSP-21262, ADSP-21364, and ADSP-21369 SHARC processors.
The SHARC processors are based on a 32-bit super Harvard architecture
that includes a unique memory architecture comprised of two large
on-chip, dual-ported SRAM blocks coupled with a sophisticated IO pro-
cessor, which gives a SHARC processor the bandwidth for sustained
high-speed computations. SHARC processors represents today’s de facto
standard for floating-point processor targeted for premium audio
applications.
The EZ-KIT Lites and SHARC USB EZ-Extender are designed to be used
in conjunction with the CrossCore®Embedded Studio (CCES) and
VisualDSP++®software development environments. The development
environment facilitates advanced application code development and
debug, such as:
• Create, compile, assemble, and link application programs written
in C++, C, and SHARC USB EZ-Extender assembly
• Load, run, step, halt, and set breakpoints in application programs
• Read and write data and program memory
• Read and write core and peripheral registers
• Plot memory

Product Overview
viii SHARC USB EZ-Extender Manual
To learn more about Analog Devices development software, go to
http://www.analog.com/dsp/tools.
Product Overview
The SHARC USB EZ-Extender is a separately sold extension board that
plugs onto the expansion interface of the ADSP-21262, ADSP-21364, or
ADSP-21369 EZ-KIT Lite evaluation system. The extension board aids
the design and prototyping phases of ADSP-21262, ADSP-21364, or
ADSP-21369 processor targeted applications.
The board extends the capabilities of the evaluation system by providing a
connection between the parallel port or asynchronous memory bus of the
SHARC processor and a USB 2.0 device.
• USB 2.0 interface
• PLX Technology’s NetChip 2272 device
• USB driver and application code
• USB logo certified
• No power supply required
• Derives power from EZ-KIT Lite
• CE certified
• Dimensions
• 3.13 in (H) x 3.6 in (W)
Before using any of the interfaces, follow the setup procedure in “USB
EZ-Extender Setup” on page 1-1.
Example programs are available to demonstrate the capabilities of the
SHARC USB EZ-Extender board.

SHARC USB EZ-Extender Manual ix
Preface
Purpose of This Manual
The SHARC USB EZ-Extender Manual describes the operation and con-
figuration of the components on the extension board. A schematic and a
bill of materials are provided as a reference for future SHARC processor
board designs.
Intended Audience
This manual is a user’s guide and reference to the SHARC USB
EZ-Extender. Programmers who are familiar with the Analog Devices
SHARC processor architecture, operation, and development tools are the
primary audience for this manual.
Programmers who are unfamiliar with Analog Devices processors can use
this manual but should supplement it with other texts that describe your
target architecture. For the locations of these documents, see “Related
Documents”.
Programmers who are unfamiliar with CCES or VisualDSP++ should refer
to the online help and user’s manuals.
Manual Contents
The manual consists of:
• Chapter 1, “USB EZ-Extender Interface” on page 1-1
Provides basic board information.
• Chapter 2, “USB EZ-Extender Hardware Reference” on page 2-1
Provides information on the hardware aspects of the board.

What’s New in This Manual
x SHARC USB EZ-Extender Manual
• Appendix A, “USB EZ-Extender Bill of Materials” on page A-1
Provides a list of components used to manufacture the
EZ-Extender board.
• Appendix B, “USB EZ-Extender Schematic” on page B-1
Provides the resources to allow EZ-KIT Lite board-level debugging
or to use as a reference design. Appendix B is part of the online
help.
What’s New in This Manual
This is revision 2.1 of the SHARC USB EZ-Extender Manual. The manual
has been updated to include CCES information. In addition, modifica-
tions and corrections based on errata reports against the previous manual
revision have been made.
For the latest version of this manual, please refer to the Analog Devices
Web site.
Technical Support
You can reach Analog Devices processors and DSP technical support in
the following ways:
• Post your questions in the processors and DSP support community
at EngineerZone®:
http://ez.analog.com/community/dsp
• Submit your questions to technical support directly at:
http://www.analog.com/support

SHARC USB EZ-Extender Manual xi
Preface
• E-mail your questions about processors, DSPs, and tools develop-
ment software from CrossCore Embedded Studio or
VisualDSP++:
Choose Help > Email Support. This creates an e-mail to
[email protected] and automatically attaches
your CrossCore Embedded Studio or VisualDSP++ version infor-
mation and license.dat file.
• E-mail your questions about processors and processor applications
to:
[email protected] or
[email protected] (Greater China support)
•IntheUSA only, call 1-800-ANALOGD (1-800-262-5643)
• Contact your Analog Devices sales office or authorized distributor.
Locate one at:
www.analog.com/adi-sales
• Send questions by mail to:
Processors and DSP Technical Support
Analog Devices, Inc.
Three Technology Way
P.O. Box 9106
Norwood, MA 02062-9106
USA
Supported Products
The SHARC USB EZ-Extender is designed as an extension board to the
ADSP-21262, ADSP-21364, and ADSP-21369 EZ-KIT Lite evaluation
systems.

Product Information
xii SHARC USB EZ-Extender Manual
Product Information
Product information can be obtained from the Analog Devices Web site
and the online help.
Analog Devices Web Site
The Analog Devices Web site, www.analog.com, provides information
about a broad range of products—analog integrated circuits, amplifiers,
converters, and digital signal processors.
To access a complete technical library for each processor family, go to
http://www.analog.com/dsp/tools. The manuals selection opens a list of
current manuals related to the product as well as a link to the previous
revisions of the manuals. When locating your manual title, note a possible
errata check mark next to the title that leads to the current correction
report against the manual.
Also note, myAnalog is a free feature of the Analog Devices Web site that
allows customization of a Web page to display only the latest information
about products you are interested in. You can choose to receive weekly
e-mail notifications containing updates to the Web pages that meet your
interests, including documentation errata against all manuals. myAnalog
provides access to books, application notes, data sheets, code examples,
and more.
Visit myAnalog to sign up. If you are a registered user, just log on. Your
user name is your e-mail address.
EngineerZone
EngineerZone is a technical support forum from Analog Devices. It allows
you direct access to ADI technical support engineers. You can search
FAQs and technical information to get quick answers to your embedded
processing and DSP design questions.

SHARC USB EZ-Extender Manual xiii
Preface
Use EngineerZone to connect with other DSP developers who face similar
design challenges. You can also use this open forum to share knowledge
and collaborate with the ADI support team and your peers. Visit
http://ez.analog.com to sign up.
Related Documents
For additional information about the product, refer to the following
publications.
Table 1. Related Processor Publications
Title Description
•ADSP-21261/ADSP-21262/ADSP-21266
SHARC Processor Data Sheet
•ADSP-21362/ADSP-21363/ADSP-21364/
ADSP-21365/ADSP-21366 SHARC Processor
Data Sheet
•ADSP-21367/ADSP-21368/ADSP-21369
SHARC Processor Data Sheet
General functional description, pinout, and
timing of the processor
•ADSP-2126x SHARC Processor Hardware
Reference
•ADSP-2136x SHARC Processor Hardware
Reference (Includes ADSP-21364)
•ADSP-2137x SHARC Processor Hardware
Reference (Includes ADSP-21369)
Description of the internal processor architec-
ture and all register functions
•ADSP-21160 SHARC DSP Instruction Set
Reference
•SHARC Processor Programming Reference
Description of all allowed processor assembly
instructions

Related Documents
xiv SHARC USB EZ-Extender Manual

SHARC USB EZ-Extender Manual 1-1
1 USB EZ-EXTENDER
INTERFACE
This chapter provides the setup procedures for both the SHARC USB
EZ-Extender and EZ-KIT Lite (ADSP-21262, ADSP-21364, or
ADSP-21369) and describes the USB interface the extender supports.
USB EZ-Extender Setup
It is very important to set up all of the components of the system contain-
ing the USB EZ-Extender before applying power to that system. The
following procedure is recommended for the correct setup.
Power your system when these steps are completed:
1. Read the applicable design interface section in this chapter—the
text provides an overview of the capabilities of the interface.
2. Read “System Architecture” on page 2-1 to understand the physical
connections of the extension board. For detailed information, refer
to “USB EZ-Extender Schematic” on page B-1.
3. Remove any rubber feet that may be attached to the EZ-KIT Lite.
In place of these rubber feet, install the four nylon feet and screws
provided with the USB EZ-Extender. Install the nylon feet in the
mounting holes of the EZ-KIT Lite’s printed circuit board (PCB).
Flip the EZ-KIT Lite upside down so that the three expansion
headers (J1–3) are facing up.

USB 2.0 Interface
1-2 SHARC USB EZ-Extender Manual
4. Set the jumper on the USB EZ-Extender board. Use the block dia-
gram in Figure 2-1 in conjunction with “Processor Select Jumper
(JP1)” on page 2-2.
5. Set the switches on the EZ-KIT Lite board. If not already, familiar-
ize yourself with the documentation and schematics of the EZ-KIT
Lite (see “Related Documents”). Compare the expansion interface
signals of the USB EZ-Extender board with the signals of the
EZ-KIT Lite board to ensure there is no contention. For example,
it may be necessary to disable other devices connected to the expan-
sion interface of the processor and disable the push buttons on the
EZ-KIT Lite.
6. Install the USB EZ-Extender on the EZ-KIT Lite via the
three-connector expansion interface.
USB Software Documentation
For information on the USB software (host-side and device-side), refer to
the readme text files in the Examples folder of the installation directory.
USB 2.0 Interface
The USB EZ-Extender allows you to connect a USB 2.0 chip to a SHARC
processor without any other programmable logic. PLX Technology’s
NetChip 2272 device ties directly to the parallel port or asynchronous
memory bank of the SHARC processor. You can read from and write to
the USB 2.0 controller by directly addressing the named memory bank.
You can reset the NetChip 2272 device by asserting LOW these flag pins:
•FLAG2 on the ADSP-21262 and ADSP-21364 processors
•FLAG0 on the ADSP-21369 processor

SHARC USB EZ-Extender Manual 1-3
USB EZ-Extender Interface
The USB interrupt request pin (IRQ) line of the extender connects to
FLAG1 on the ADSP-21262, ADSP-21364, and ADSP-21369 processors.
This flag pin may be used for push buttons or LEDs on the respective
EZ-KIT Lites; consequently, the user must make the proper changes to
that EZ-KIT Lite.
When writing to and reading from the USB device using the EZ-KIT
Lites, use memory addresses listed in Table 1-1.
Table 1-1. USB Device Memory
EZ-KIT Lite Starting Address Ending Address
ADSP-21262 0x0100 6C00 0x0100 6FE0
ADSP-21364 0x0100 6C00 0x0100 6FE0
ADSP-21369 0x0C00 0000 0x0C00 03E0

USB 2.0 Interface
1-4 SHARC USB EZ-Extender Manual

SHARC USB EZ-Extender Manual 2-1
2 USB EZ-EXTENDER
HARDWARE REFERENCE
This chapter describes the hardware design of the USB EZ-Extender. The
following topics are covered.
•“System Architecture” on page 2-1
Describes the extension board’s configuration.
•“Processor Select Jumper (JP1)” on page 2-2
Describes the configuration jumper’s functionality.
System Architecture
A block diagram of the SHARC USB EZ-Extender is shown in Figure 2-1.
Figure 2-1. Block Diagram

Processor Select Jumper (JP1)
2-2 SHARC USB EZ-Extender Manual
Processor Select Jumper (JP1)
Before using the SHARC USB EZ-Extender, follow the steps in “USB
EZ-Extender Setup” on page 1-1.
Figure 2-2 shows the location of the processor select jumper JP1. A
two-pin jumper can be placed on the respective jumper header for differ-
ent functionality.
Figure 2-2. JP1 Jumper Settings
