DEMO MANUAL DC2543B
Rev. 0
DESCRIPTION
LTC7820EUFD
High Efficiency, Charge Pump
DC/DC Converter
Demonstration circuit 2543B is a high efficiency, high
density, open loop charge pump (inductorless) DC/DC
converter. This demo board is a voltage divider which
achieves a 2:1 step-down ratio from an input voltage from
36V to 60V. The output voltage is a fixed ratio of half of the
input voltage (VIN/2) and can supply a 10A load current.
This demo board has the option to deliver a 20A maximum
load with the addition of 15 chip capacitors. See Figure8
and Figure10 for the details.
The DC2543B provides a very high efficiency solution of
98.7% when converting 48VIN to 24VOUT at 10A as shown
in Figure3. When configured for a 20A output, an effi-
ciency of up to 98.4% is achievable for a 48VIN to 24VOUT
at 20A as shown in Figure8.
The demo board features the LT C
®
7820, a fixed ratio high
voltage high power switched capacitor/charge pump
controller in a 4mm × 5mm QFN package. Please see
LTC7820 data sheet for more detailed information.
PERFORMANCE SUMMARY
The DC2543B needs to be powered on with no load cur-
rent or a very small load current (less than 50mA) with
the default setup. Large load current can be applied after
VOis established. The board offers a disconnect FET
option which is controlled by the LTC7820 FAULT pin
to disconnect the load during startup as shown in the
schematic. Please refer to “Voltage Divider Prebalance
Before Switching”section in the LTC7820 data sheet for
more details regarding the startup of the voltage divider.
The board also features some protection functions
such as overcurrent and thermal shutdown to make it a
reliablesolution.
Design files for this circuit board are available at
http://www.analog.com/DC2543B
Specifications are at TA= 25°C
PARAMETER CONDITION VALUE
Input Voltage Range 36V to 60V
Output Voltage, VOUT VIN = 36 to 60V, IOUT = 0A to 10A VIN/2
Maximum Output Current, IOUT VIN = 36 to 60V, VOUT = VIN/2 10A
Typical Efficiency VIN = 48V, VOUT = 24V, IOUT = 10A 98.7%
Peak Efficiency VIN = 48V, VOUT = 24V 99%
Switching Frequency 200kHz
All registered trademarks and trademarks are the property of their respective owners.
NOTE: DC2543B demo manual includes a Schottky diode added across the output. This manual describes the demo
board entitled “Demo Circuit 2543B.” The DC2543B replaces the DC2543A.

2
DEMO MANUAL DC2543B
Rev. 0
QUICK START PROCEDURE
Demonstration circuit 2543B is easy to set up to evaluate
the performance of the LTC7820. Refer to Figure1 for
the proper measurement equipment setup and follow the
procedure below.
1. With power off, connect the input power supply to VIN
(36V to 60V) and GND (input return).
2. Connect the output loads between VOUT and GND
(Initial load: no load). Refer to Figure1.
3. Connect the DVMs to the input and output.
4. Check the default jumper/switch position:SW1 (RUN):
OFF; JP2 (BIAS): ON.
5. Turn on the input power supply and adjust voltage
to48V.
NOTE:Make sure that the input voltage does not
exceed60V.
6. Turn on the switches: SW1: ON.
7. Check for the proper output voltages from VO_SNS+to
VO_SNS–.
8. Once the proper output voltage is established, adjust
the loads within the operating range and measure the
efficiency, output ripple voltage and other parameters.
9. After completing all tests, adjust the load to 0A, power
off the input power supply.
Notes:
1. When measuring the output or input voltage ripple,
do not use the long ground lead on the oscilloscope
probe. See Figure3 for the proper scope probe tech-
nique. Short, stiff leads need to be soldered to the (+)
and (–) terminals of an output capacitor. The probe’s
ground ring needs to touch the (–) lead and the probe
tip needs to touch the (+) lead.
2. When doing the load step test with the on-board
dynamic load circuit, please make sure the load step-
up pulse duty cycle does not exceed 2% and the pulse
duration is less than 500µs so that the temperature
of the MOSFETs Q9, Q23 in the dynamic load circuit
stay in the safe region. Instead of using the on-board
dynamic load circuit, an electric load can also be used
for the load step test, which does not have the 2%
maximum duty cycle limit for the load step.
3. It is recommended to set the electronic load in CR (con-
stant resistance) mode for evaluation of the DC2543B
board. Some electronic loads draw negative current in
CC (constant current) mode when evaluating the output
overcurrent protection feature of DC2543B, which can
violate the absolute maximum voltage rating –0.3V for
VLOW pin.

3
DEMO MANUAL DC2543B
Rev. 0
QUICK START PROCEDURE
–
+–
+
+
VIN
36V to 60V
–
+
–
+
–
LOAD
DC2543B F01
+ –
VOUT GND
COUT
Figure1. Proper Measurement Equipment Setup
Figure2. Measuring Output Voltage Ripple
Note: It is recommended to set the electronic load in CR (constant resistance) mode for evaluation of
the DC2543B board. Some electronic loads draw negative current in CC (constant current) mode when
evaluating the output overcurrent protection feature of DC2543B, which can violate the absolute maximum
voltage rating –0.3V for VLOW pin.

4
DEMO MANUAL DC2543B
Rev. 0
QUICK START PROCEDURE
Figure3. Efficiency vs Load Current at VIN = 48V,
VOUT = 24V, fSW = 200kHz
OUTPUT LOAD CURRENT (A)
0
90
EFFICIENCY (%)
92
94
100
98
96
24 6 8 10
DC2543B F03
OUTPUT LOAD CURRENT (A)
0
23.0
23.2
23.4
23.6
VOUT (V)
23.8
24.0
24.6
24.4
24.2
24 6 8 10
DC2543B F04
Figure4. Load Regulation for 10A Design
at VIN = 48V, VOUT = 24V, fSW = 200kHz
Figure5. Output Voltage Ripple at VIN = 48V,
VOUT = 24V, IOUT = 10A, fSW = 200kHz
Figure6. Load Step at VIN = 48V, VOUT = 24V
2µs/DIV
VOUT
RIPPLE
20MHz BW
500mV/DIV
DC2543B F05
100µs/DIV
0A-5A-0A
LOAD STEP
VOUT
20MHz BW
500mV/DIV
DC2543B F06
Figure7. Thermal performance VIN = 48V, VOUT = 24V, IOUT = 10A,
TA= 23°C, No Airflow
Q1 Q3
Q6 Q7

5
DEMO MANUAL DC2543B
Rev. 0
QUICK START PROCEDURE
OUTPUT LOAD CURRENT (A)
0
92
EFFICIENCY (%)
93
94
100
98
96
95
99
97
26 10 14 48 12 16 18 20
DC2543B F08
OUTPUT LOAD CURRENT (A)
0
23.0
VOUT (V)
23.2
23.4
24.6
24.2
23.8
23.6
24.4
24.0
26 10 14 48 12 16 18 20
DC2543B F09
Figure8. Efficiency vs Load Current at VIN = 48V,
VOUT = 24V, fSW = 200kHz*
Figure9. Load Regulation for 20A Design
at VIN = 48V, VOUT = 24V, fSW = 200kHz*
Figure10. Thermal performance at VIN = 48V, VOUT = 24V, IOUT = 20A
TA= 23°C, No Airflow*
* Note:Additional C11, C12, C60, C61, C22-C25, C69-C72, C30, C31, and C36 (10µF/50V, MURATA GRM32ER71H106KA12L) are populated;
RS1 is changed to 2.5mΩ (WSL20102L500FEB18) for this test.
Q1
Q3
Q6
Q7

6
DEMO MANUAL DC2543B
Rev. 0
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 1 C1 CAP, 33µF 20% 80V ELEC PANASONIC EEHZA1K330P
2 8 C2, C3, C47, C49, C56, C57, C58, C59 CAP, 1210 2.2µF 10% 100V X7R MURATA GRM32DR72A225KA12
3 4 C4, C5, C15, C126 CAP, 0603 0.1µF 10% 100V X7R MURATA GRM188R72A104KA35D
4 2 C6, C7 CAP, 0805 4.7µF 10% 16V X7R MURATA GRM21BR71C475KA73K
5 1 C8 CAP, 0603 0.22µF 10% 25V X7R MURATA GRM188R71E224KA88D
6 2 C9, C26 CAP, 0603 0.47µF 10% 25V X7R MURATA GRM188R71E474KA12D
7 2 C17, C28 CAP, 0805 2.2µF 10% 50V X7R TDK C2012X7R1H225K125AC
8 11 C18, C19, C20, C21, C29, C66, C67 CAP, 1210 10µF 10% 50V X7R MURATA GRM32ER71H106KA12L
9 C68, C73, C74, C65
10 2 C27, C50 CAP, 0603 1µF 10% 50V X5R MURATA GRM188R61H105K
11 2 C52, C53 CAP, 1210 22µF 10% 25V X5R AVX 12103D226KAT2A
12 1 C54 CAP, 0603 47nF 10% 25V X7R AVX 06033C473KAT2A
13 1 C55 CAP, 0603 470pF 10% 50V X7R MURATA GRM188R71H471KA01D
14 3 D1, D2, D3 DIODE, SCHOTTKY CENTRAL SEMI. CMDSH-4E TR
15 1 D6* DIODE, SCHOTTKY ON SEMI, NRVTSAF5100E
16 2 D9, D10 DIODE, ZENER CENTRAL SEMI. CMHZ5236B TR
17 1 L2 IND, 68µH COILCRAFT., LPS6225-683MRB
18 1 Q1 XSTR, N-CHANNEL MOSFET INFINEON BSC027N06LS5
19 3 Q3, Q6, Q7 XSTR, N-CHANNEL MOSFET INFINEON BSC032N04LS
20 4 Q9, Q10, Q11, Q23 XSTR, N-CH 40V 14A TO-252 VISHAY SUD50N04-8M8P-4GE3
21 1 Q22 TRANSISTOR., SOT-23 FAIRCHILD., BSS123L
22 1 RS1 RES., CHIP, 0.005, 1%, 2010 VISHAY, WSL20105L000FEA
23 1 RS2 RES, 2010 0Ω JUMPER VISHAY WSL201000000ZEA9
24 2 R1, R7 RES, 0603 1kΩ 1% VISHAY CRCW06031K00FKEA
25 1 R2 RES, 0603 2.2Ω 5% YAGEO RC0603JR-072R2L
26 4 R5, R10, R24, R32 RES, 0603 0Ω JUMPER VISHAY CRCW06030000Z0EA
27 4 R9, R13, R17, R28 RES, 0603 10kΩ 1% NIC NRC06F1002TRF
28 1 R16 RES, 0603 60.4kΩ 1% VISHAY CRCW060360K4FKEA
29 1 R18 RES, 0603 100kΩ 1% VISHAY CRCW0603100KFKEA
30 1 R26 RES, 0603 154kΩ 1% YAGEO RC0603FR-07154KL
31 1 R27 RES, 0603 20kΩ 5% VISHAY CRCW060320K0JNEA
32 1 R29 RES, 0603 80.6kΩ 1% YAGEO RC0603FR-0780K6L
33 1 R30 RES. 2010 1Ω 1% 1W IRC LRC-LR2010-01-1R00-F
34 1 R31 RES, 0603 100Ω 5% VISHAY CRCW0603100R0JNEA
35 1 U1 IC, LTC7820EUFD, QFN 4mm × 5mm ANALOG DEVICES, ALTC7820EUFD#PBF
36 1 U2 IC, LTC3630AEMSE ANALOG DEVICES, LTC3630EMSE#PBF

7
DEMO MANUAL DC2543B
Rev. 0
PARTS LIST
Additional Demo Board Circuit Components
1 0 C10-C14, C16, C33, C34, C35, C36,
C60-C64, C51, C77
CAPACITOR, OPT
2 0 C30-C32, C22-C25, C69-C72, C127
3 0 Q2, Q4, Q5,Q8 OPT MOSFET, OPT
4 0 R6, R19, R2, R36, R8, R11, R12,
R20, R34, R35, R60
RESISTOR, OPT
Hardware: For Demo Board Only
1 9 E1, E2, E6-E8, E10, E12, E14, E15 TURRET MILL-MAX 2501-2-00-80-00-00-07-0
2 1 JP2 HEADER, 3 PIN 2mm WURTH ELEKTRONIK 62000311121
3 4 J1, J2, J3, J4 JACK, BANANA KEYSTONE, 575-4
4 2 J5, J6 CONN, BNC, 5 PINS CONNEX, 112404
5 1 SW1 SWITCH, SUBMINIATURE SLIDE C&K COMPONENTS, JS202011CQN
6 1 XJP2 SHUNT 2mm WURTH ELEKTRONIK 60800213421
7 4 STANDOFF STANDOFF, SNAP ON KEYSTONE 8833
*Note: D6 is for negative voltage clamping on VOUT of DC2543B board in output overcurrent test with electronic load. Some electronic loads draw negative
current in CC mode when evaluating the output overcurrent protection feature of DC2543B, which can violate the absolute maximum voltage rating –0.3V
for VLOW pin without D6 populated.

8
DEMO MANUAL DC2543B
Rev. 0
SCHEMATIC DIAGRAM
