DEMO MANUAL DC2665B-B
Rev. 0
DESCRIPTION
LTM4638
20VIN, 15A Step-Down
µModule Regulator
Demonstration circuit 2665B-B features the LTM
®
4638
µModule
®
regulator, a high performance, high effi-
ciencystep-down regulator. The LTM4638 is a complete
DC/DC point-of-load regulator in a thermally enhanced
6.25mm × 6.25mm × 5.02mm BGA package. The
LTM4638 has an operating input voltage range of 3.1V to
20V and provides an output current up to 15A. The output
voltage is programmable from 0.6V to 5.5V and can be
remotely sensed. The stacked inductor design improves
thermal dissipation and significantly reduces the package
All registered trademarks and trademarks are the property of their respective owners.
area. Output voltage tracking is available through the
TRACK/SS pin for supply rail sequencing. External clock
synchronization is available through the SYNC/MODE pin.
For high efficiency at low load currents, select discon-
tinuous current mode(DCM) operation using the MODE
jumper (JP7) in less noise sensitive applications. Refer
to the LTM4638 data sheet in conjunction with this demo
manual for working on or modifyingthe DC2665B-B.
Design files for this circuit board are available.
BOARD PHOTO
Part marking is either ink mark or laser mark

2
DEMO MANUAL DC2665B-B
Rev. 0
QUICK START PROCEDURE
Demonstration circuit 2665B-B is an easy way to evaluate
the performance of the LTM4638EY. Refer to Figure1 for
test setup connections and use the following procedure.
1. With the power off, place the jumpers in the following
positions:
JP8 JP7 JP1 TO JP6
RUN MODE VOUT Select
ON CCM 1V
2. Before connecting the input supply, load, and meters,
preset the input voltage supply between 3.1V and 20V.
Preset the load current to 0A.
3. With the power off, connect the load, input voltage
supply and meters as shown in Figure1.
4. Turn on the input power supply. The output voltage
meters for each phase display the ±1.2% programmed
output voltage .
5. Once the proper output voltage is established, adjust
the load current in the 0A to 15A range and observe
the load regulation, efficiency, and other parameters.
Measure the output voltage ripple across the furthest
output cap with a BNC cable and oscilloscope from J2.
6. Place the MODE pin jumper (JP7) in the DCM position
to observe increased light load efficiency.
7. For optional load transient testing, an onboard
transient circuit is provided to measure transient
response. Place a positive pulse signal between the
IO_STEP_CLK (E10) pin and GND pin. The pulse
amplitude sets the load step current amplitude. Keep
the pulse width short (<1ms) and the pulse duty cycle
low (<15%) to limit the thermal stress on the load
transient circuit. Monitor the load step with a BNC
connected to J1 (5mV/A).
PERFORMANCE SUMMARY
Specifications are at TA= 25°C
PARAMETER CONDITIONS MIN TYP MAX UNITS
Input Voltage Range 3.1 20 V
Output Voltage, VOUT Jumper Selection on JP1
Jumper Selection on JP2
Jumper Selection on JP3
Jumper Selection on JP4
Jumper Selection on JP5
0.98
1.47
2.45
3.23
4.9
1.0
1.5
2.5
3.3
5.0
1.02
1.53
2.55
3.37
5.1
V
V
V
V
V
Maximum Continuous Output Current Derating Is Necessary for Certain Operating Conditions
(See Data Sheet for Details)
15 A
Default Operating Frequency 600 kHz
Efficiency VIN = 12V, VOUT = 1V, IOUT = 15A 85.3 %

3
DEMO MANUAL DC2665B-B
Rev. 0
Figure1. Test Setup of DC2665B-B
QUICK START PROCEDURE
NOTES:
1. To achieve the minimum output ripple voltage, optimize the operation frequency at different input and output volt-
ages. Suggested operation frequencies at different voltages are shown in Table1. Adjust the operation frequency
by changing the value of RfSET (R5). Refer to the LTM4638 data sheet for detailed calculation of RfSET (R5).
Table1. Suggested Operation Frequencies
3.3VIN 5VIN 12VIN
VOUT (V) 1 1.2 1.5 1.8 2.5 1 1.2 1.5 1.8 2.5 3.3 1 1.2 1.5 1.8 2.5 3.3 5
fSW (kHz) 500 500 500 500 500 600 600 600 800 800 800 600 600 800 800 1000 1000 1500
2. For applications that require small output voltage ripple, add shunt-through three-terminal capacitors on the output
at C41 and C42.

4
DEMO MANUAL DC2665B-B
Rev. 0
QUICK START PROCEDURE
Figure2. Measured Supply, CCM Efficiency vs Load Current
Figure3. Measured Thermal Capture at 12V
IN
, I
OUT
=15A at 25°C Ambient with No Airflow
(a) 3.3VIN (b) 5VIN (c) 12VIN
dc2665bb F02a
LOAD CURRENT (A)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
80
82
84
86
88
90
92
94
96
98
EFFICIENCY (%)
1VOUT, 500kHz
1.2VOUT, 500kHz
1.5VOUT, 500kHz
1.8VOUT, 500kHz
2.5VOUT, 500kHz
dc2665bb F02b
LOAD CURRENT (A)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
80
82
84
86
88
90
92
94
96
98
EFFICIENCY (%)
1VOUT, 600kHz
1.2VOUT, 600kHz
1.5VOUT, 600kHz
1.8VOUT, 800kHz
2.5VOUT, 800kHz
3.3VOUT, 800kHz
LOAD CURRENT (A)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
78
80
82
84
86
88
90
92
94
96
EFFICIENCY (%)
dc2665bb F02c
1VOUT, 600kHz
1.2VOUT, 600kHz
1.5VOUT, 800kHz
1.8VOUT, 800kHz
2.5VOUT, 1MHz
3.3VOUT, 1MHz
5VOUT, 1.5MHz
(a) 1VOUT, 600kHz (b) 5VOUT, 1.5MHz

5
DEMO MANUAL DC2665B-B
Rev. 0
Figure4. Load Transient (7.5A to 11.25A) Response Waveform at 12VIN
(a) 1VOUT
(b) 5VOUT
dc2665bb F04a
50μs/DIV
VOUT(PK-PK) = 55mV
VOUT
50mV/DIV
ILOAD
2A/DIV
dc2665bb F04b
50μs/DIV
VOUT(PK-PK) = 66mV
VOUT
50mV/DIV
ILOAD
2A/DIV
QUICK START PROCEDURE

6
DEMO MANUAL DC2665B-B
Rev. 0
Figure5. Tested VOUT AC Ripple at 12VIN, IOUT = 15A , VOUT Ripple Is Tested Across C12
QUICK START PROCEDURE
(a) 1VOUT, 600kHz, Full Bandwidth at 500MHz (b) 1VOUT, 600kHz, 20MHz Bandwidth
(c) 5VOUT, 1.5MHz, Full Bandwidth at 500MHz (d) 5VOUT, 1.5MHz, 20MHz Bandwidth
dc2665bb F05a
1μs/DIV
VOUT(PK-PK) = 37mV
VOUT
(FULL BW)
10mV/DIV
dc2665bb F05b
1μs/DIV
VOUT(PK-PK) = 5.6mV
VOUT
(20MHz BW)
10mV/DIV
dc2665bb F05c
1μs/DIV
VOUT(PK-PK) = 36.8mV
VOUT
(FULL BW)
10mV/DIV
dc2665bb F05d
1μs/DIV
VOUT(PK-PK) = 7.2mV
VOUT
(20MHz BW)
10mV/DIV
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 3 C1, C6, C31 CAP., 2.2μF, X7R, 10V, 20%, 0603 TDK, C1608X7R1A225M080AC
2 3 C2, C3, C38 CAP., 22μF, X5R, 25V, 10%, 1206 AVX, 12063D226KAT2A
3 1 C33 CAP., 1μF, X7R, 25V, 10%, 0603 TDK, C1608X7R1E105K080AB
4 4 C5, C11, C12, C30 CAP., 220μF, X5R, 6.3V, 20%, 1206 MURATA, GRM31CR60J227ME11L
5 1 C7 CAP., 0.1μF, X7R, 25V, 10%, 0603 AVX, 06033C104KAT2A
6 1 C8 CAP., 100pF, X7R, 25V, 5%, 0603 AVX, 06033C101JAT2A
7 1 C10 CAP., 220μF, ALUM HYB, 35V, 20% SUN ELECTRONIC, 35HVH220M
8 1 C18 CAP., 1μF, X7R, 10V, 20%, 0603 AVX, 0603ZC105MAT2A
9 1 C29 CAP., 0.022μF, X7R, 50V, 10%, 0603 KEMET, C0603C223K5RAC7867
10 1 C34 CAP., 1μF, X7R, 6.3V, 10%, 0402 MURATA, GRM155R70J105KA12D

7
DEMO MANUAL DC2665B-B
Rev. 0
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
11 1 R3 RES., 10k, 1%, 1/10W, 0603 VISHAY, CRCW060310K0FKEAC
12 1 R4 RES., 90.9k, 0.5%, 1/10W, 0603 SUSUMU, RG1608P-9092-D-T5
13 1 R6 RES., 40.2k, 0.5%, 1/10W, 0603 SUSUMU, RG1608P-4022-D-T5
14 1 R14 RES., 13.3k, 0.5%, 1/10W, 0603 SUSUMU, RG1608P-1332-D-T5
15 1 R15 RES., 19.1k, 0.5%, 1/10W, 0603 SUSUMU, RG1608P-1912-D-T5
16 1 R24 RES., 8.25k, 0.5% 1/10W 0603 SUSUMU, RG1608P-8251-D-T5
17 2 R8, R16 RES., 100k, 1%, 1/10W, 0603 STACKPOLE ELECTRONICS, RMCF0603FG100K
18 2 R9, R10 RES., 0Ω,5%, 1/16W, 0402 ROHM, SFR01MZPJ000
19 1 R17 RES., 0Ω, 1/10W, JUMPER, 0603 YAGEO, RC0603FR-070RL
20 1 R7 RES., 150k, 5%, 1/10W, 0603 YAGEO, RC0603JR-07150KL
21 1 Q1 XSTR, MOSFET, N-CH, 40V, TO-252 (DPAK) VISHAY, SUD50N04-8M8P-4GE3
22 1 RS2 RES., SENSE, 0.005Ω, 1%, 1W, 2512 VISHAY, WSL25125L000FEA
23 1 U1 IC, 20V, 15A STEP-DOWN μModule REG ANALOG DEVICES, INC. LTM4638EY#PBF
Additional Demo Board Circuit Components
24 0 C4, C9, C15, C19, C36, C43, C44 CAP., OPTION, 0603 OPTION
25 0 C16, C22-C24 CAP., OPTION, 0805 OPTION
26 0 C17, C20, C21 CAP., OPTION, 1206 OPTION
27 0 C25-C28 CAP., OPTION, 1210 OPTION
28 0 C39 CAP., OPTION, 0805, 3-PC Pad MURATA, NFM21PC104R1E3D
29 0 C40 CAP., OPTION, 1206, 3-PC Pad TDK, YFF31HC2A104MT000N
30 0 C41 CAP., OPTION, 0603, 3-PC Pad MURATA, NFM18CC223R1C3D
31 0 C42 CAP., OPTION, 1206, 3-PC Pad MURATA, NFM31PC276B0J3L
32 0 R18 RES., OPTION, 0805 OPTION
33 0 C35 CAP., OPTION, 0805 OPTION
34 0 R21-R23 RES., OPTION, 0402 OPTION
35 0 R1, R2, R5, R11-R13, R19, R20 RES., OPTION, 0603 OPTION
36 0 L1 IND.,OPTION,1812 OPTION
37 0 L2 IND.,OPTION, 4mm × 4mm, AEX-Q200 COILCRAFT, XEL4020-800MEC
Hardware: For Demo Board Only
38 10 E1, E3, E5, E6, E8-E12, E14 TESTPOINT, TURRET 0.064" MILL-MAX, 2308-2-00-80-00-00-07-0
39 4 E2, E4, E7, E13 JACK, BANANA KEYSTONE, 575-4
40 2 J1, J2 CONN, BNC, 5 PINS AMPHENOL RF, 112404
41 5 JP1-JP6 HEADER, 1×2, 2mm SULLINS, NRPN021PAEN-RC
42 1 JP7 HEADER, 2×3, 2mm SULLINS, NRPN032PAEN-RC
43 1 JP8 HEADER, 1×3, 2mm SAMTEC, TMM-103-02-L-S
44 4 MP1-MP4 STAND-OFF, NYLON 0.5" KEYSTONE, 8833 (SNAP ON)
45 3 XJP1, XJP7, XJP8 SHUNT, 2mm SAMTEC, 2SN-BK-G
PARTS LIST

8
DEMO MANUAL DC2665B-B
Rev. 0
SCHEMATIC DIAGRAM
5 5
4 4
3 3
2 2
1 1
D D C C B B A A
CLKIN
CCM
DCM
3.1V - 20V
NOTES: UNLEES OTHERWISE SPECIFIED,
1. ALL RESISTORS AND CAPACITORS ARE 0603.
ON
OFF
OPT EMI FILTER
REVISION HISTORY
DATEDESCRIPTION
S J
REV APPROVED
PRODUCTION
01
ECO
11/15/22
OPT
OPT
OPT
OPT
OPT
20V STEP-DOWN µMODULE REGULATOR
LTM4638EY#PBF
- A
VERSION
LTM4626EY#PBF
- B
8.25k
40.2k
R15R4
90.9k
40.2k 19.1k
R14 R24R6U1
19.1k
*
- C
90.9k 13.3k
LTM4657EY#PBF 60.4k 31.1k 15k
13.3k 10.7k
8.25k 6.65k
VOSNS-
VOSNS+
VIN
VOSNS-
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY T O ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIF Y PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. CO MPONENT SUBSTITUTION AND PRINTED CIRCUIT BO ARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILIT Y. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
ANALOG
DEVICES
11
AN Sun J.
LTM46XXEY DC2665B
710-DC2665B_REV 01
N/A Tuesday, November 15, 2022
<Variant Name>
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY T O ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIF Y PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. CO MPONENT SUBSTITUTION AND PRINTED CIRCUIT BO ARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILIT Y. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
ANALOG
DEVICES
11
AN Sun J.
LTM46XXEY DC2665B
710-DC2665B_REV 01
N/A Tuesday, November 15, 2022
<Variant Name>
DATE:
SHEET OF
TITLE: SCHEMATIC
APPROVALS
PCB DES. APP ENG.
SIZE:
SCHEMATIC NO. AND REVISION:
CUSTOMER NOTICE
THIS CIRCUIT IS PROPRIETARY T O ANALOG DEVICES AND
SUPPLIED FOR USE WITH ANALOG DEVICES PARTS.
SKU NO. IC NO.
ANALOG DEVICES HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIF Y PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. CO MPONENT SUBSTITUTION AND PRINTED CIRCUIT BO ARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILIT Y. CONTACT ANALOG DEVICES APPLICATIONS ENGINEERING FOR ASSISTANCE.
ANALOG
DEVICES
11
AN Sun J.
LTM46XXEY DC2665B
710-DC2665B_REV 01
N/A Tuesday, November 15, 2022
<Variant Name>
E13
GND
E14
GND
C1 2.2uF 10V
C41
1 3
2
C40
*U1
FREQ
E1
PHMODE
G5
TSENSE+ A6
TRACK/SS E2
COMPa D1
RUN
B4
PGOOD B5
VOUT A2
GND
C4 INTVCC B3
CLKOUT F2
MODE/CLKIN
D2
VIN
G4 VOUT1 G1
VOUT A3
VOUT1 G3 VOUT1 F3
GND
C6
GND
C7
GND
D5
GND
D7
GND
E5
GND
E6
GND
D6
GND
E7
GND
F5
GND
F6
GND
F7
GND
G6
GND
G7
GND
B6
GND
C5
VOUT A1
VIN
E4
VIN
F4
GND
C3
VIN
E3
VIN
D3
VIN
D4
VOUTS- C2
VOUTS+ B1
FB C1
COMPb F1
TSENSE- A7
SW B7
SGND
B2
VOUT A4 VOUT A5
VOUT1 G2
C19
OPT
C7 0.1uF
25V
C2
22uF 25V
1206
C15 OPT
E2
VIN
TP2
VIN EMI
L1 OPT
1812
JP7
MODE
1 2 3 4 5 6
R18
OPT
0805
C38 22uF 25V 1206
JP2
1.5V
*R6
C35
OPT
0805
C23 OPT
C20
OPT
1206
C6 2.2uF 10V
TP3
GND EMI
C25 OPT 1210
E8
TRACK
R17 0
E4
GND
C17
OPT
1206
*R4
C21 OPT 1206
C3 22uF 25V 1206
E10
IO STEP CLK
J2
VOUT
1
2
3
4
5
C26
C29
0.022uF
0603
50V
R21 OPT
Q1
SUD50N04-8m8P
2
1
3
E9
VOSNS-
E11
GND
E3
CLKIN
C39
1 3
2
C16 OPT 0805
+
C10 220uF 35V
E6
VIN
C28 OPT
*R15
C33 1uF 25V
JP8
RUN
1 3 2
R7 150k
R8 100k
JP5
5.0V
C8 100pF 25V
C31 2.2uF 10V
*R14
R5
OPT
C42
R2
OPT
C12 220uF 6.3V 1206
R19 OPT
R10
0
C44
OPT
C5 220uF 6.3V 1206
C34 1uF 0402 6.3V X7R
R3
10k
C9
OPT
C4
OPT
0603
C22
JP3
2.5V
JP6
SET
R20
OPT
C24
0805
C30 220uF 6.3V 1206
R1
OPT
*R24
C11 220uF 6.3V 1206
R11 OPT 0603
R22
OPT
0402
E5
PGOOD
L2
C43
OPT
R12
OPT
C18 1uF 10V
JP1
1.0V
RS2
0.005
1W
2512
1%
E1
CLKOUT
R16 100k
R13
OPT
C27 OPT 1210
E12
VOSNS+
R9
0
J1
IO STEP
1
2
3
4
5
R23 OPT
E7
VOUT
C36 OPT
JP4
3.3V
VOUT
VOSNS+ VOSNS-
CLKOUT
VIN
VIN
VIN
VOUT

9
DEMO MANUAL DC2665B-B
Rev. 0
Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications
subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
REVISION HISTORY
DEMO BOARD
REV
DEMO MANUAL
REV DATE DESCRIPTION PAGE NUMBER
DC2665A-B 0 02/19 Initial Release. —
DC2665B-B 0 12/22 DC2665B-B replaces DC2665A-B for low HF VOUT ripple. —

10
DEMO MANUAL DC2665B-B
Rev. 0
 ANALOG DEVICES, INC. 2023
2/23
www.analog.com
ESD Caution
ESD (electrostatic discharge) sensitive device. Charged devices and circuit boards can discharge without detection. Although this product features patented or proprietary protection
circuitry, damage may occur on devices subjected to high energy ESD. Therefore, proper ESD precautions should be taken to avoid performance degradation or loss of functionality.
Legal Terms and Conditions
By using the evaluation board discussed herein (together with any tools, components documentation or support materials, the “Evaluation Board”), you are agreeing to be bound by the terms and
conditions set forth below (“Agreement”) unless you have purchased the Evaluation Board, in which case the Analog Devices Standard Terms and Conditions of Sale shall govern. Do not use the Evaluation
Board until you have read and agreed to the Agreement. Your use of the Evaluation Board shall signify your acceptance of the Agreement. This Agreement is made by and between you (“Customer”)
and Analog Devices, Inc. (“ADI”), with its principal place of business at One Technology Way, Norwood, MA 02062, USA. Subject to the terms and conditions of the Agreement, ADI hereby grants to
Customer a free, limited, personal, temporary, non-exclusive, non-sublicensable, non-transferable license to use the Evaluation Board FOR EVALUATION PURPOSES ONLY. Customer understands and
agrees that the Evaluation Board is provided for the sole and exclusive purpose referenced above, and agrees not to use the Evaluation Board for any other purpose. Furthermore, the license granted
is expressly made subject to the following additional limitations:Customer shall not (i) rent, lease, display, sell, transfer, assign, sublicense, or distribute the Evaluation Board;and (ii) permit any Third
Party to access the Evaluation Board. As used herein, the term “Third Party”includes any entity other than ADI, Customer, their employees, affiliates and in-house consultants. The Evaluation Board is
NOT sold to Customer;all rights not expressly granted herein, including ownership of the Evaluation Board, are reserved by ADI. CONFIDENTIALITY. This Agreement and the Evaluation Board shall all
be considered the confidential and proprietary information of ADI. Customer may not disclose or transfer any portion of the Evaluation Board to any other party for any reason. Upon discontinuation of
use of the Evaluation Board or termination of this Agreement, Customer agrees to promptly return the Evaluation Board to ADI. ADDITIONAL RESTRICTIONS. Customer may not disassemble, decompile
or reverse engineer chips on the Evaluation Board. Customer shall inform ADI of any occurred damages or any modifications or alterations it makes to the Evaluation Board, including but not limited
to soldering or any other activity that affects the material content of the Evaluation Board. Modifications to the Evaluation Board must comply with applicable law, including but not limited to the RoHS
Directive. TERMINATION. ADI may terminate this Agreement at any time upon giving written notice to Customer. Customer agrees to return to ADI the Evaluation Board at that time. LIMITATION OF
LIABILITY. THE EVALUATION BOARD PROVIDED HEREUNDER IS PROVIDED “AS IS”AND ADI MAKES NO WARRANTIES OR REPRESENTATIONS OF ANY KIND WITH RESPECT TO IT. ADI SPECIFICALLY
DISCLAIMS ANY REPRESENTATIONS, ENDORSEMENTS, GUARANTEES, OR WARRANTIES, EXPRESS OR IMPLIED, RELATED TO THE EVALUATION BOARD INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTY OF MERCHANTABILITY, TITLE, FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF INTELLECTUAL PROPERTY RIGHTS. IN NO EVENT WILL ADI AND ITS
LICENSORS BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES RESULTING FROM CUSTOMER’S POSSESSION OR USE OF THE EVALUATION BOARD, INCLUDING
BUT NOT LIMITED TO LOST PROFITS, DELAY COSTS, LABOR COSTS OR LOSS OF GOODWILL. ADI’S TOTAL LIABILITY FROM ANY AND ALL CAUSES SHALL BE LIMITED TO THE AMOUNT OF ONE
HUNDRED US DOLLARS ($100.00). EXPORT. Customer agrees that it will not directly or indirectly export the Evaluation Board to another country, and that it will comply with all applicable United States
federal laws and regulations relating to exports. GOVERNING LAW. This Agreement shall be governed by and construed in accordance with the substantive laws of the Commonwealth of Massachusetts
(excluding conflict of law rules). Any legal action regarding this Agreement will be heard in the state or federal courts having jurisdiction in Suffolk County, Massachusetts, and Customer hereby submits
to the personal jurisdiction and venue of such courts. The United Nations Convention on Contracts for the International Sale of Goods shall not apply to this Agreement and is expressly disclaimed.
