Analog Devices SHARC ADSP-21375 User manual

ADSP-21375 EZ-KIT Lite®
Evaluation System Manual
Revision 1.1, September 2007
Part Number
82-000940-02
Analog Devices, Inc.
One Technology Way
Norwood, Mass. 02062-9106 a

Copyright Information
©2007 Analog Devices, Inc., ALL RIGHTS RESERVED. This document
may not be reproduced in any form without prior, express written consent
from Analog Devices, Inc.
Printed in the USA.
Limited Warranty
The EZ-KIT Lite evaluation system is warranted against defects in materi-
als and workmanship for a period of one year from the date of purchase
from Analog Devices or from an authorized dealer.
Disclaimer
Analog Devices, Inc. reserves the right to change this product without
prior notice. Information furnished by Analog Devices is believed to be
accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use; nor for any infringement of patents or other rights of
third parties which may result from its use. No license is granted by impli-
cation or otherwise under the patent rights of Analog Devices, Inc.
Trademark and Service Mark Notice
The Analog Devices icon bar and logo, VisualDSP++, the VisualDSP++
logo, SHARC, the SHARC logo, CROSSCORE, the CROSSCORE logo,
EZ-KIT Lite, and EZ-Extender are registered trademarks of Analog
Devices, Inc.
All other brand and product names are trademarks or service marks of
their respective owners.

Regulatory Compliance
The ADSP-21375 EZ-KIT Lite is designed to be used solely in a labora-
tory environment. The board is not intended for use as a consumer end
product or as a portion of a consumer end product. The board is an open
system design which does not include a shielded enclosure and therefore
may cause interference to other electrical devices in close proximity. This
board should not be used in or near any medical equipment or RF devices.
The ADSP-21375 EZ-KIT Lite has been certified to comply with the
essential requirements of the European EMC directive 89/336/EEC
amended by 93/68/EEC and therefore carries the “CE” mark.
The ADSP-21375 EZ-KIT Lite has been appended to Analog Devices,
Inc. Technical Construction File (TCF) referenced ‘DSPTOOLS1’ dated
December 21, 1997 and was awarded CE Certification by an appointed
European Competent Body as listed below.
Technical Certificate No: Z600ANA1.027
Issued by: Technology International (Europe) Limited
60 Shrivenham Hundred Business Park
Shrivenham, Swindon, SN6 8TY, UK
The EZ-KIT Lite evaluation system contains ESD (electrostatic discharge)
sensitive devices. Electrostatic charges readily accumulate on the human
body and equipment and can discharge without detection. Permanent
damage may occur on devices subjected to high-energy discharges. Proper
ESD precautions are recommended to avoid performance degradation or
loss of functionality. Store unused EZ-KIT Lite boards in the protective
shipping package.

ADSP-21375 EZ-KIT Lite Evaluation System Manual v
CONTENTS
PREFACE
Purpose of This Manual ................................................................ xiii
Intended Audience ........................................................................ xiii
Manual Contents ........................................................................... xiv
What’s New in This Manual ........................................................... xiv
Technical or Customer Support ....................................................... xv
Supported Processors ....................................................................... xv
Product Information ...................................................................... xvi
MyAnalog.com ......................................................................... xvi
Processor Product Information .................................................. xvi
Related Documents ................................................................. xvii
Online Technical Documentation ........................................... xviii
Accessing Documentation From VisualDSP++ ...................... xix
Accessing Documentation From Windows ............................ xix
Accessing Documentation From Web .................................... xx
Printed Manuals ........................................................................ xx
Hardware Tools Manuals ....................................................... xx
Processor Manuals ................................................................. xx
Data Sheets .......................................................................... xxi

CONTENTS
vi ADSP-21375 EZ-KIT Lite Evaluation System Manual
Notation Conventions ................................................................... xxi
USING ADSP-21375 EZ-KIT LITE
Package Contents ......................................................................... 1-2
Default Configuration .................................................................. 1-3
Installation and Session Startup ..................................................... 1-5
Evaluation License Restrictions ..................................................... 1-7
External Memory .......................................................................... 1-7
ELVIS Interface ............................................................................ 1-9
Analog Audio ............................................................................. 1-10
LEDs and Push Buttons .............................................................. 1-11
Example Programs ...................................................................... 1-13
Background Telemetry Channel .................................................. 1-13
ADSP-21375 EZ-KIT LITE HARDWARE REFERENCE
System Architecture ...................................................................... 2-2
External Port ........................................................................... 2-3
DAI Interface .......................................................................... 2-4
DPI Interface .......................................................................... 2-5
FLAG Pins .............................................................................. 2-6
External PLL ........................................................................... 2-7
Expansion Interface ................................................................. 2-7
JTAG Emulation Port ............................................................. 2-8
Switch Settings ............................................................................. 2-9
Boot Mode and Clock Ratio Select Switch (SW2) .................. 2-10

ADSP-21375 EZ-KIT Lite Evaluation System Manual vii
CONTENTS
Codec Setup Switch (SW3) .................................................... 2-11
Electret Microphone Select Switch (SW4) .............................. 2-12
UART Enable Switch (SW5) .................................................. 2-12
Loop-Back Test Switches (SW6 and SW14) ............................ 2-12
Push Button Enable Switch (SW7) ......................................... 2-13
ELVIS Oscilloscope Configuration Switch (SW1) ................... 2-13
ELVIS Function Generator Configuration Switch (SW13) ...... 2-14
AD1835A and Flash Disconnect Switch (SW15) .................... 2-15
LEDs and Push Buttons .............................................................. 2-15
General Purpose LEDs (LED1–8) .......................................... 2-16
Power LED (LED9) ............................................................... 2-16
Reset LED (LED10) .............................................................. 2-16
USB Monitor LED (ZLED3) ................................................. 2-16
Push Buttons (SW8–11) ........................................................ 2-17
Board Reset Push Button (SW12) .......................................... 2-17
Jumpers ...................................................................................... 2-18
VCO Select Jumper (JP1) ...................................................... 2-19
ELVIS Select Jumper (JP2) .................................................... 2-19
ELVIS Voltage Selection Jumper (JP3) ................................... 2-20
ELVIS Programmable Flag Jumper (JP4) ................................ 2-20
Connectors ................................................................................. 2-21
Expansion Interface Connectors (J1–3) .................................. 2-22
Audio In RCA Connector (J10) ............................................. 2-22
Audio Out RCA Connector (J5) ............................................ 2-22

CONTENTS
viii ADSP-21375 EZ-KIT Lite Evaluation System Manual
Headphone Out Jack (J9) ...................................................... 2-23
Power Jack (J4) ..................................................................... 2-23
S/PDIF Coax Connectors (J7 and J8) .................................... 2-24
DPI Header (P3) ................................................................... 2-24
DAI Header (P4) .................................................................. 2-24
JTAG Header (ZP4) .............................................................. 2-25
ADSP-21375 EZ-KIT LITE BILL OF MATERIALS
ADSP-21375 EZ-KIT LITE SCHEMATIC
Title Page ..................................................................................... B-1
ADSP-21375 Processor ................................................................. B-2
ADSP-21375 Processor 2 .............................................................. B-3
Memory ....................................................................................... B-4
Analog Audio ............................................................................... B-5
Audio Out 1 ................................................................................. B-6
Audio Out 2 ................................................................................. B-7
Audio In and Headphone Out ...................................................... B-8
External PLL, S/PDIF, and RS-232 ............................................... B-9
ELVIS Interface .......................................................................... B-10
Push Buttons, LEDs, and RESET ............................................... B-11
Expansion Interface .................................................................... B-12
Power ......................................................................................... B-13
INDEX

ADSP-21375 EZ-KIT Lite Evaluation System Manual ix
PREFACE
Thank you for purchasing the ADSP-21375 EZ-KIT Lite®, Analog
Devices, Inc. evaluation system for ADSP-21375 SHARC®processors.
The SHARC processors are based on a 32-bit super Harvard architecture
that includes a unique memory architecture comprised of two large
on-chip, dual-ported SRAM blocks coupled with a sophisticated IO pro-
cessor, which gives a SHARC processor the bandwidth for sustained
high-speed computations. SHARC processors represents today’s de facto
standard for floating-point processing, targeted toward premium audio
applications.
The evaluation system is designed to be used in conjunction with the
VisualDSP++®development environment to test the capabilities of the
ADSP-21375 SHARC processors. The VisualDSP++ development envi-
ronment gives you the ability to perform advanced application code
development and debug, such as:
• Create, compile, assemble, and link application programs written
in C++, C, and ADSP-21375 assembly
• Load, run, step, halt, and set breakpoints in application program
• Read and write data and program memory
• Read and write core and peripheral registers
• Plot memory

x ADSP-21375 EZ-KIT Lite Evaluation System Manual
Access to the ADSP-21375 processor from a personal computer (PC) is
achieved through a USB port or an optional JTAG emulator. The USB
interface gives unrestricted access to the ADSP-21375 processor and the
evaluation board peripherals. Analog Devices JTAG emulators offer faster
communication between the host PC and target hardware. Analog Devices
carries a wide range of in-circuit emulation products. To learn more about
Analog Devices emulators and processor development tools, go to
http://www.analog.com/dsp/tools/.
LThe ADSP-21375 EZ-KIT Lite installation is part of the Visu-
alDSP++ installation. The EZ-KIT Lite is a licensed product that
offers an unrestricted evaluation license for the first 90 days. For
details about evaluation license restrictions after the 90 days, refer
to “Evaluation License Restrictions” on page 1-7.
ADSP-21375 EZ-KIT Lite provides example programs to demonstrate the
capabilities of the evaluation board.
The board features:
• Analog Devices ADSP-21375 processor
D208-pin MQFP package
D266 MHz core clock speed
• Synchronous dynamic random access memory (SDRAM)
D2M x 16-bit x 4 banks
• Flash memory
D1M x 8-bit

ADSP-21375 EZ-KIT Lite Evaluation System Manual xi
Preface
• Serial peripheral interface (SPI) flash memory
D2Mbit
• Analog audio interface
DAD1835A codec
D4x2 RCA phono jack for 4 channels of stereo output
D2x1 RCA phono jack for 1 channel of stereo input
D3.5 mm headphone jack for 1 channel stereo output
• Universal asynchronous receiver/transmitter (UART)
DADM3202 RS-232 driver/receiver
DDB9 female connector
• National Instruments Educational Laboratory Virtual Instrumen-
tation Suite (ELVIS) Interface
DLabVIEW™-based virtual instruments
DMultifunction data acquisition device
DBench-top workstation and prototype board
•LEDs
D11 LEDs: 1 power (green), 1 board reset (red), 1 USB mon-
itor (amber), and 8 general purpose (amber)
• Push buttons
D5 push buttons: 1 reset, 2 connected to DAI,
2 connected to the FLAG pins of the processor

xii ADSP-21375 EZ-KIT Lite Evaluation System Manual
• Expansion interface (Type A)
DParallel port, FLAG pins, DPI, DAI
• Other features
DJTAG ICE 14-pin header
DTest points for processor current measurement
DDPI header
DDAI header
The EZ-KIT Lite board has a total of 1 MB of parallel flash memory and
2 Mbit of SPI flash memory. The flash memories can store user-specific
boot code, allowing the board to run as a stand-alone unit. For more
information, see “External Memory” on page 1-7 and “Boot Mode and
Clock Ratio Select Switch (SW2)” on page 2-10. The board has 16 MB of
SDRAM, which can be used at runtime or from which code can be
executed.
The DAI port of the processor connects to the AD1835A audio codec and
an external phase lock loop (PLL). The DAI interface facilitates develop-
ment of digital and analog audio signal-processing applications. See
“Analog Audio” on page 1-10 and for more information.
The DPI port of the processor connects to the UART interface and the
SPI interface. The UART interface can connect to a standard RS-232 con-
nection, while the SPI connects to the 2 Mbit of serial flash memory.
Additionally, the EZ-KIT Lite board provides access to all of the proces-
sor’s peripheral ports. Access is provided in the form of a three-connector
expansion interface. See “Expansion Interface” on page 2-7 for details.

ADSP-21375 EZ-KIT Lite Evaluation System Manual xiii
Preface
Purpose of This Manual
The ADSP-21375 EZ-KIT Lite Evaluation System Manual provides
instructions for installing the product hardware (board) and describes the
operation and configuration of the board components. The product soft-
ware component is detailed in the VisualDSP++ Installation Quick
Reference Card. The manual provides guidelines for running your own
code on the ADSP-21375 EZ-KIT Lite. Finally, a schematic and a bill of
materials are provided as a reference for future designs.
Intended Audience
The primary audience for this manual is a programmer who is familiar
with Analog Devices processors. This manual assumes that the audience
has a working knowledge of the appropriate processor architecture and
instruction set. Programmers who are unfamiliar with Analog Devices
processors can use this manual but should supplement it with other texts,
such as the ADSP-2136x SHARC Processor Programming Reference and
ADSP-21368 SHARC Processor Hardware Reference (includes
ADSP-21375) that describe your target architecture.
Programmers who are unfamiliar with VisualDSP++ should refer to the
VisualDSP++ online Help and the VisualDSP++ user’s or getting started
guides. For the locations of these documents, see “Related Documents”.

Manual Contents
xiv ADSP-21375 EZ-KIT Lite Evaluation System Manual
Manual Contents
The manual consists of:
• Chapter 1, “Using ADSP-21375 EZ-KIT Lite” on page 1-1
Provides information on the EZ-KIT Lite from a programmer’s
perspective and provides an easy-to-access memory map.
• Chapter 2, “ADSP-21375 EZ-KIT Lite Hardware Reference” on
page 2-1
Provides information on the hardware aspects of the evaluation
system.
• Appendix A, “ADSP-21375 EZ-KIT Lite Bill Of Materials” on
page A-1
Provides a list of components used to manufacture the EZ-KIT
Lite board.
• Appendix B, “ADSP-21375 EZ-KIT Lite Schematic” on page B-1
Provides the resources to allow modifications to the EZ-KIT Lite
or to use as a reference design.
LAppendix B now is part of the online Help. The PDF version of
the ADSP-21375 EZ-KIT Lite Evaluation System Manual is located
in the Docs\EZ-KIT Lite Manuals folder on the installation CD.
Alternatively, the schematic can be found on the Analog Devices
Web site at http://www.analog.com/processors.
What’s New in This Manual
The ADSP-21375 EZ-KIT Lite Evaluation System Manual has been
updated for the current revision of VisualDSP++.
Appendix B, “ADSP-21375 EZ-KIT Lite Schematic” on page B-1 have
been updated to reflect the latest revision of the board.

ADSP-21375 EZ-KIT Lite Evaluation System Manual xv
Preface
Technical or Customer Support
You can reach Analog Devices, Inc. Customer Support in the following
ways:
• Visit the Embedded Processing and DSP products Web site at
http://www.analog.com/processors/technicalSupport
• E-mail tools questions to
[e-mail]
• E-mail processor questions to
[email protected]m (World wide support)
[email protected] (Europe support)
[email protected] (China support)
• Phone questions to 1-800-ANALOGD
• Contact your Analog Devices, Inc. local sales office or authorized
distributor
• Send questions by mail to:
Analog Devices, Inc.
One Technology Way
P.O. Box 9106
Norwood, MA 02062-9106
USA
Supported Processors
The ADSP-21375 EZ-KIT Lite evaluation system supports the Analog
Devices ADSP-21375 SHARC processors.

Product Information
xvi ADSP-21375 EZ-KIT Lite Evaluation System Manual
Product Information
You can obtain product information from the Analog Devices Web site,
from the product CD-ROM, or from the printed publications (manuals).
Analog Devices is online at http://www.analog.com. Our Web site pro-
vides information about a broad range of products—analog integrated
circuits, amplifiers, converters, and digital signal processors.
MyAnalog.com
MyAnalog.com is a free feature of the Analog Devices Web site that allows
customization of a Web page to display only the latest information on
products you are interested in. You can also choose to receive weekly
e-mail notifications containing updates to the Web pages that meet your
interests. MyAnalog.com provides access to books, application notes, data
sheets, code examples, and more.
Registration:
Visit http://www.myanalog.com to sign up. Click Register to use MyAna-
log.com. Registration takes about five minutes and serves as means for you
to select the information you want to receive.
If you are already a registered user, just log on. Your user name is your
e-mail address.
Processor Product Information
For information on embedded processors and DSPs, visit our Web site at
http://www.analog.com/processors, which provides access to technical
publications, data sheets, application notes, product overviews, and prod-
uct announcements.

ADSP-21375 EZ-KIT Lite Evaluation System Manual xvii
Preface
You may also obtain additional information about Analog Devices and its
products in any of the following ways.
• E-mail questions or requests for information to
[email protected]m (World wide support)
[email protected] (Europe support)
[email protected] (China support)
• Fax questions or requests for information to
1-781-461-3010 (North America)
[phone] (Europe)
Related Documents
For information on product related development software and hardware,
see these publications:
Table 1. Related Processor Publications
Title Description
ADSP-21375: 266 MHz High Performance
SHARC Processor Preliminary Data Sheet
General functional description, pinout, and
timing
ADSP-21368 SHARC Processor Hardware Refer-
ence (Includes ADSP-21367, ADSP-21368,
ADSP-21369, ADSP-21371, ADSP-21375)
Description of internal processor architecture,
registers, and all peripheral functions
ADSP-2136x SHARC Processor Programming
Reference
Description of all allowed processor assembly
instructions
Table 2. Related VisualDSP++ Publications
VisualDSP++ User’s Guide Detailed description of VisualDSP++ features
and usage
VisualDSP++ Assembler and Preprocessor Man-
ual
Description of the assembler function and
commands

Product Information
xviii ADSP-21375 EZ-KIT Lite Evaluation System Manual
LIf you plan to use the EZ-KIT Lite board in conjunction with a
JTAG emulator, also refer to the documentation that accompanies
the emulator.
All documentation is available online. Most documentation is available in
printed form.
Visit the Technical Library Web site to access all processor and tools man-
uals and data sheets:
http://www.analog.com/processors/technicalSupport/technicalLi-
brary/.
Online Technical Documentation
Online documentation comprises the VisualDSP++ Help system, software
tools manuals, hardware tools manuals, processor manuals, the Dinkum
Abridged C++ library, and Flexible License Manager (FlexLM) network
license manager software documentation. You can easily search across the
entire VisualDSP++ documentation set for any topic of interest. For easy
printing, supplementary .pdf files of most manuals are provided in the
Docs folder on the VisualDSP++ installation CD.
Each documentation file type is described as follows.
VisualDSP++ C/C++ Complier Manual for
SHARC Processors
Description of the complier function and com-
mands for SHARC processors
VisualDSP++ Run-Time Library Manual for
SHARC Processors
Description of the run-time library functions
for SHARC processors
VisualDSP++ Linker and Utilities Manual Description of the linker function and com-
mands
VisualDSP++ Loader and Utilities Manual Description of the loader function and com-
mands
Table 2. Related VisualDSP++ Publications (Cont’d)

ADSP-21375 EZ-KIT Lite Evaluation System Manual xix
Preface
If documentation is not installed on your system as part of the software
installation, you can add it from the VisualDSP++ CD at any time by run-
ning the Tools installation. Access the online documentation from the
VisualDSP++ environment, Windows®Explorer, or the Analog Devices
Web site.
Accessing Documentation From VisualDSP++
To view VisualDSP++ Help, click on the Help menu item or go to the
Windows task bar and navigate to the VisualDSP++ documentation via
the Start menu.
To view ADSP-21375 EZ-KIT Lite Help, which is part of the Visu-
alDSP++ Help system, use the Contents or Search tab of the Help
window.
Accessing Documentation From Windows
In addition to any shortcuts you may have constructed, there are many
ways to open VisualDSP++ online Help or the supplementary documenta-
tion from Windows.
Help system files (.chm) are located in the Help folder, and .pdf files are
located in the Docs folder of your VisualDSP++ installation CD-ROM.
The Docs folder also contains the Dinkum Abridged C++ library and the
FlexLM network license manager software documentation.
File Description
.chm Help system files and manuals in Help format
.htm or
.html
Dinkum Abridged C++ library and FlexLM network license manager software doc-
umentation. Viewing and printing the .html files requires a browser, such as
Internet Explorer 6.0 (or higher).
.pdf VisualDSP++ and processor manuals in Portable Documentation Format (PDF).
Viewing and printing the .pdf files requires a PDF reader, such as Adobe Acrobat
Reader (4.0 or higher).

Product Information
xx ADSP-21375 EZ-KIT Lite Evaluation System Manual
Your software installation kit includes online Help as part of the Windows
interface. These help files provide information about VisualDSP++ and
the ADSP-21375 EZ-KIT Lite evaluation system.
Accessing Documentation From Web
Download manuals at the following Web site:
http://www.analog.com/processors/technicalSupport/technicalLi-
brary/.
Select a processor family and book title. Download archive (.zip) files,
one for each manual. Use any archive management software, such as Win-
Zip, to decompress downloaded files.
Printed Manuals
For general questions regarding literature ordering, call the Literature
Center at 1-800-ANALOGD (1-800-262-5643) and follow the prompts.
Hardware Tools Manuals
To purchase EZ-KIT Lite and in-circuit emulator (ICE) manuals, call
1-603-883-2430. The manuals may be ordered by title or by product
number located on the back cover of each manual.
Processor Manuals
Hardware reference and instruction set reference manuals may be ordered
through the Literature Center at 1-800-ANALOGD (1-800-262-5643),
or downloaded from the Analog Devices Web site. Manuals may be
ordered by title or by product number located on the back cover of each
manual.
