Analog Devices ADSP-21161N User manual

ADSP-21161N EZ-KIT Lite®
Evaluation System Manual
Revision 2.1, March 2004
Part Number
82-000530-01
Analog Devices, Inc.
One Technology Way
Norwood, Mass. 02062-9106 a

Copyright Information
© 2004 Analog Devices, Inc., ALL RIGHTS RESERVED. This docu-
ment may not be reproduced in any form without prior, express written
consent from Analog Devices, Inc.
Printed in the USA.
Limited Warranty
The EZ-KIT Lite evaluation system is warranted against defects in materi-
als and workmanship for a period of one year from the date of purchase
from Analog Devices or from an authorized dealer.
Disclaimer
Analog Devices, Inc. reserves the right to change this product without
prior notice. Information furnished by Analog Devices is believed to be
accurate and reliable. However, no responsibility is assumed by Analog
Devices for its use; nor for any infringement of patents or other rights of
third parties which may result from its use. No license is granted by impli-
cation or otherwise under the patent rights of Analog Devices, Inc.
Trademark and Service Mark Notice
The Analog Devices logo, VisualDSP++, the VisualDSP++ logo, SHARC,
SHARC logo, CROSSCORE, the CROSSCORE logo, and EZ-KIT Lite
are registered trademarks of Analog Devices, Inc.
All other brand and product names are trademarks or service marks of
their respective owners.

Regulatory Compliance
The ADSP-21161N EZ-KIT Lite evaluation system has been certified to
comply with the essential requirements of the European EMC directive
89/336/EEC (inclusive 93/68/EEC) and, therefore, carries the “CE”
mark.
The ADSP-21161N EZ-KIT Lite evaluation system had been appended to
the Technical Construction File referenced “DSPTOOLS1” dated
December 21, 1997 and was awarded CE Certification by an appointed
European Competent Body as listed below.
Technical Certificate No: Z600ANA1.005
Issued by: Technology International (Europe) Limited
41 Shrivenham Hundred Business Park
Shrivenham, Swindon, SN6 8TZ, UK
The EZ-KIT Lite evaluation system contains ESD
(electrostatic discharge) sensitive devices. Electro-
static charges readily accumulate on the human
body and equipment and can discharge without
detection. Permanent damage may occur on devices
subjected to high-energy discharges. Proper ESD
precautions are recommended to avoid performance
degradation or loss of functionality. Store unused
EZ-KIT Lite boards in the protective shipping
package.

CONTENTS
iv ADSP-21161N EZ-KIT Lite Evaluation System Manual

ADSP-21161N EZ-KIT Lite Evaluation System Manual v
CONTENTS
PREFACE
Purpose of This Manual ................................................................. xiv
Intended Audience ......................................................................... xiv
Manual Contents ............................................................................ xv
What’s New in This Manual ............................................................ xv
Technical or Customer Support ...................................................... xvi
Supported Processors ...................................................................... xvi
Product Information ...................................................................... xvi
MyAnalog.com ........................................................................ xvii
DSP Product Information ........................................................ xvii
Related Documents ................................................................ xviii
Online Documentation ............................................................ xix
Printed Manuals ....................................................................... xix
VisualDSP++ Documentation Set ......................................... xix
Hardware Manuals ................................................................ xx
Data Sheets ........................................................................... xx
Contacting DSP Publications ..................................................... xx
Notation Conventions .................................................................... xxi

CONTENTS
vi ADSP-21161N EZ-KIT Lite Evaluation System Manual
GETTING STARTED
Contents of EZ-KIT Lite Package ................................................. 1-1
PC Configuration ......................................................................... 1-3
Installation Tasks .......................................................................... 1-3
Installing VisualDSP++ and EZ-KIT Lite Software .................. 1-4
Installing and Registering VisualDSP++ License ....................... 1-4
Setting Up EZ-KIT Lite Hardware .......................................... 1-5
Installing EZ-KIT Lite USB Driver ......................................... 1-6
Windows 98 USB Driver .................................................... 1-7
Windows 2000 USB Driver .............................................. 1-11
Windows XP USB Driver ................................................. 1-12
Verifying Driver Installation .................................................. 1-14
Starting VisualDSP++ ........................................................... 1-16
USING EZ-KIT LITE
EZ-KIT Lite License Restrictions .................................................. 2-2
Memory Map ............................................................................... 2-2
Using SDRAM Memory ............................................................... 2-3
Using FLAG Pins ......................................................................... 2-5
Using Interrupt Pins ..................................................................... 2-6
Using Audio Interface ................................................................... 2-6
Example Programs ........................................................................ 2-8
Using Flash Programmer Utility .................................................... 2-8
Using EZ-KIT Lite VisualDSP++ Interface .................................... 2-9

ADSP-21161N EZ-KIT Lite Evaluation System Manual vii
CONTENTS
Boot Load ............................................................................... 2-9
Target Options ........................................................................ 2-9
While Target is Halted and On Emulator Exit Options ...... 2-10
Other Options .................................................................. 2-10
Core Hang Conditions .......................................................... 2-11
Hardware Breakpoints ........................................................... 2-12
Common Hardware Breakpoint Attributes ......................... 2-13
Global Hardware Breakpoint Options ................................ 2-13
Data Hardware Breakpoints ............................................... 2-15
Instruction Hardware Breakpoints ..................................... 2-16
Other Breakpoints ............................................................. 2-17
Tips and Tricks Using Hardware Breakpoints ..................... 2-18
Latency ......................................................................... 2-18
Restrictions ................................................................... 2-18
Setting a Breakpoint on a Single Address ........................ 2-18
Restricted Software Breakpoints ............................................. 2-19
EZ-KIT LITE HARDWARE REFERENCE
System Architecture ...................................................................... 3-2
External Port ........................................................................... 3-3
Host Processor Interface (HPI) ................................................ 3-3
SPORT Audio Interface ........................................................... 3-3
SPI Audio Interface ................................................................. 3-4
Breadboard Area ...................................................................... 3-4
JTAG Emulation Port .............................................................. 3-5

CONTENTS
viii ADSP-21161N EZ-KIT Lite Evaluation System Manual
Jumper Settings ............................................................................ 3-5
SDRAM Disable Jumper (JP1) ................................................ 3-5
SPDIF Selection Jumper (JP2) ................................................ 3-5
MCLK Selection Jumper (JP3) ................................................ 3-6
FLAG0 Enable Jumper (JP4) ................................................... 3-7
FLAG1 Enable Jumper (JP5) ................................................... 3-7
Sample Frequency Jumper (JP6) .............................................. 3-7
ADC2 Input Mode Selection Jumpers (JP7–8) ......................... 3-8
MIC Gain Selection Jumpers (JP9–10) .................................... 3-8
ADC1 Input Selection Jumper (JP11) ...................................... 3-9
Processor ID Jumper (JP19) .................................................. 3-10
Boot Mode Selection Jumper (JP20) ...................................... 3-10
Clock Mode Selection Jumper (JP21) .................................... 3-11
~BMS Enable Jumper (JP22) ................................................. 3-12
AD1836 Control Selection Jumper (JP23) ............................. 3-12
SW1 Enable Jumper (JP26) ................................................... 3-12
SW2 Enable Jumper (JP27) ................................................... 3-12
LEDs and Push Buttons .............................................................. 3-13
Reset LEDs (LED1 and LED8) ............................................. 3-14
FLAG LEDs (LED2–7) ......................................................... 3-14
VERF LED (LED9) .............................................................. 3-14
USB Monitor LED (LED10) ................................................. 3-15
Power LED (LED11) ............................................................ 3-15
Programmable FLAG Push Buttons (SW1–4) ........................ 3-15

ADSP-21161N EZ-KIT Lite Evaluation System Manual ix
CONTENTS
Interrupt Push Buttons (SW5–7) ........................................... 3-15
Board Reset Push Button (SW8) ............................................ 3-16
Connectors ................................................................................. 3-16
USB Connector (P2) ............................................................. 3-16
Audio Connectors (P4–8, P17) .............................................. 3-18
External Port Connector (P9) ................................................ 3-18
Host Processor Interface Connector (P10) .............................. 3-19
JTAG Connector (P12) .......................................................... 3-19
Link Port Connectors (P13–14) ............................................. 3-19
SPORT1 and SPORT3 Connector (P15) ............................... 3-20
Power Connector (P16) ......................................................... 3-20
Specifications .............................................................................. 3-21
Power Supply ........................................................................ 3-21
Board Current Measurements ................................................ 3-21
BILL OF MATERIALS
INDEX

CONTENTS
x ADSP-21161N EZ-KIT Lite Evaluation System Manual

ADSP-21161N EZ-KIT Lite Evaluation System Manual xi
PREFACE
Thank you for purchasing the ADSP-21161N EZ-KIT Lite®, Analog
Devices (ADI) evaluation system for SHARC®processors.
The SHARC processors are based on a 32-bit super Harvard architecture
that includes a unique memory architecture comprised of two large
on-chip, dual-ported SRAM blocks coupled with a sophisticated IO pro-
cessor, which gives SHARC the bandwidth for sustained high-speed
computations. SHARC represents today’s de facto standard for float-
ing-point DSP targeted for premium audio applications.
The evaluation system is designed to be used in conjunction with the
VisualDSP++®development environment to test the capabilities of the
ADSP-21161N SHARC processors. The VisualDSP++ development envi-
ronment gives you the ability to perform advanced application code
development and debug, such as:
• Create, compile, assemble, and link application programs written
in C++, C, and ADSP-21161N assembly
• Load, run, step, halt, and set breakpoints in application program
• Read and write data and program memory
• Read and write core and peripheral registers
• Plot memory
Access to the ADSP-21161N processor from a personal computer (PC) is
achieved through a USB port or an optional JTAG emulator. The USB
interface gives unrestricted access to the ADSP-21161N processor and the

xii ADSP-21161N EZ-KIT Lite Evaluation System Manual
evaluation board peripherals. Analog Devices JTAG emulators offer faster
communication between the host PC and target hardware. Analog Devices
carries a wide range of in-circuit emulation products. To learn more about
Analog Devices emulators and DSP development tools, go to
http://www.analog.com/dsp/tools/.
ADSP-21161N EZ-KIT Lite provides example programs to demonstrate
the capabilities of the evaluation board.
LThe VisualDSP++ license provided with this EZ-KIT Lite evalua-
tion system limits the size of a user program to 5K words of
internal memory.
The board features:
• Analog Devices ADSP-21161N processor
D100 MHz Core Clock Speed
DCore Clock Mode Jumper Configurable
• Analog Devices AD1836 96 kHz Audio Codec
DJumper Selectable Line-In or Mic-In 3.5 mm Stereo Jack
DLine-Out 3.5 mm Stereo Jack
D4 RCA Jacks for Audio Input
D8 RCA Jacks for Audio Output
• Analog Devices AD1852 192 kHz Auxiliary DAC
• Crystal Semiconductor CS8414 96 kHz SPDIF Receiver
DOptical and Coaxial Connectors for SPDIF Input
• Flash Memory
D512K x 8-bits

ADSP-21161N EZ-KIT Lite Evaluation System Manual xiii
Preface
• Interface Connectors
D14-Pin Emulator Connector for JTAG Interface
DSPORT Connectors
DLink Port 0 and Link Port 1
DExternal Port Connectors (not populated)
• General-Purpose IO
D4 Push Button Flags
D3 Push Button Interrupts
D6 LED Outputs
• Analog Devices ADP3338 and ADP3339 Voltage Regulators
• Breadboard area with typical SMT footprints
The EZ-KIT Lite board has a Flash memory device that can be used to
store user-specific boot code. By configuring the jumpers for EPROM
boot, the board can run as a stand-alone unit. The ADSP-21161N
EZ-KIT Lite package contains a Flash programmer utility, which allows
you to program the flash memory. The “Using Flash Programmer Utility”
is described on page 2-8.
SPORT0 and SPORT2 connect to the audio codec, facilitating creation of
audio-signal processing applications. SPORT1 and SPORT3 connect to
off-board connectors of other serial devices.
Additionally, the EZ-KIT Lite board provides un-installed expansion con-
nector footprints that allow you to connect to the processor’s External
Port (EP) and Host Processor Interface (HPI).

Purpose of This Manual
xiv ADSP-21161N EZ-KIT Lite Evaluation System Manual
Purpose of This Manual
The ADSP-21161N EZ-KIT Lite Evaluation System Manual provides
instructions for using the hardware and installing the software on your
PC. The text includes guidelines for running your own code on the
ADSP-21161N EZ-KIT Lite. The manual also describes the board’s con-
figuration and components. Finally, a schematic and a bill of materials are
provided as a reference for future ADSP-21161N board designs.
Intended Audience
This manual is a user’s guide and reference to the ADSP-21161N EZ-KIT
Lite evaluation system. Programmers who are familiar with the Analog
Devices SHARC processor architecture, operation, and programming are
the primary audience for this manual.
Programmers who are unfamiliar with Analog Devices SHARC processors
can use this manual in conjunction with the ADSP-21161 SHARC Proces-
sor Hardware Reference and ADSP-21160 SHARC Processor Instruction Set
Reference, which describe the DSP’a architecture and instruction set. Pro-
grammers who are unfamiliar with VisualDSP++ should refer to the
VisualDSP++ online Help and the VisualDSP++ user’s or getting started
guides. For the locations of these documents, see “Related Documents” on
page -xviii.

ADSP-21161N EZ-KIT Lite Evaluation System Manual xv
Preface
Manual Contents
The manual consists of:
• Chapter 1, “Getting Started” on page 1-1
Provides software and hardware installation procedures, PC system
requirements, and basic board information.
• Chapter 2, “Using EZ-KIT Lite” on page 2-1
Provides information on the EZ-KIT Lite from a programmer’s
perspective and provides a simplified memory map.
• Chapter 3, “EZ-KIT Lite Hardware Reference” on page 3-1
Provides information on the hardware aspects of the evaluation
system.
• Appendix A, “Bill Of Materials” on page A-1
Provides a list of components used to manufacture the EZ-KIT
Lite board.
• Appendix B, “Schematics” on page B-1
Provides the resources to allow EZ-KIT Lite board-level debugging
or to use as a reference design.
The appendix is not part of the online Help. The online Help
viewers should go the PDF version of the ADSP-21161N EZ-KIT
Lite Evaluation System Manual located in the Docs\EZ-KIT Lite
Manuals folder on the installation CD to see the schematics.
What’s New in This Manual
This is the third edition of the ADSP-21161N EZ-KIT Lite Evaluation
System Manual. The new edition includes the updated installation and
license registration procedures.

Technical or Customer Support
xvi ADSP-21161N EZ-KIT Lite Evaluation System Manual
Technical or Customer Support
You can reach DSP Tools Support in the following ways.
• Visit the DSP Development Tools website at
www.analog.com/technology/dsp/developmentTools/index.html
• Email questions to
[email protected]
• Phone questions to 1-800-ANALOGD
• Contact your ADI local sales office or authorized distributor
• Send questions by mail to
Analog Devices, Inc.
One Technology Way
P.O. Box 9106
Norwood, MA 02062-9106
USA
Supported Processors
The ADSP-21161N EZ-KIT Lite evaluation system supports Analog
Devices ADSP-21161N SHARC processors.
Product Information
You can obtain product information from the Analog Devices website,
from the product CD-ROM, or from the printed publications (manuals).

ADSP-21161N EZ-KIT Lite Evaluation System Manual xvii
Preface
Analog Devices is online at www.analog.com. Our website provides infor-
mation about a broad range of products—analog integrated circuits,
amplifiers, converters, and digital signal processors.
MyAnalog.com
MyAnalog.com is a free feature of the Analog Devices website that allows
customization of a webpage to display only the latest information on
products you are interested in. You can also choose to receive weekly email
notification containing updates to the webpages that meet your interests.
MyAnalog.com provides access to books, application notes, data sheets,
code examples, and more.
Registration:
Visit www.myanalog.com to sign up. Click Register to use MyAnalog.com.
Registration takes about five minutes and serves as means for you to select
the information you want to receive.
If you are already a registered user, just log on. Your user name is your
email address.
DSP Product Information
For information on digital signal processors, visit our website at
www.analog.com/dsp, which provides access to technical publications, data
sheets, application notes, product overviews, and product announcements.
You may also obtain additional information about Analog Devices and its
products in any of the following ways.
• Email questions or requests for information to
[email protected]
• Fax questions or requests for information to 1-781-461-3010
(North America) or [phone] (Europe)

Product Information
xviii ADSP-21161N EZ-KIT Lite Evaluation System Manual
Related Documents
For information on product related development software, see the follow-
ing publications.
Table 1. Related DSP Publications
Title Description
ADSP-21161N DSP Data Sheet General functional description, pinout, and
timing
ADSP-21161 SHARC Processor Hardware Refer-
ence
Description of internal processor architecture,
registers, and all peripheral functions
ADSP-21160 SHARC Processor Instruction Set
Reference
Description of all allowed processor assembly
instructions
Table 2. Related VisualDSP++ Publications
Title Description
VisualDSP++ 3.5 User’s Guide for 32-Bit Proces-
sors
Detailed description of VisualDSP++ 3.5 fea-
tures and usage
VisualDSP++ 3.5 Assembler and Preprocessor
Manual for SHARC Processors
Description of the assembler function and
commands for SHARC processors
VisualDSP++ 3.5 C/C++ Complier and Library
Manual for SHARC Processors
Description of the complier function and com-
mands for SHARC processors
VisualDSP++ 3.5 Linker and Utilities Manual
for 32-Bit Processors
Description of the linker function and com-
mands for the 32-bit processors
VisualDSP++ 3.5 Loader Manual for 32-Bit
Processors
Description of the loader function and com-
mands for the 32-bit processors

ADSP-21161N EZ-KIT Lite Evaluation System Manual xix
Preface
The listed documents can be found through online Help or in the Docs
folder of your VisualDSP++ installation. Most documents are available in
printed form.
LIf you plan to use the EZ-KIT Lite board in conjunction with a
JTAG emulator, refer to the documentation that accompanies the
emulator.
Online Documentation
Your software installation kit includes online Help as part of the Win-
dows®interface. These help files provide information about VisualDSP++
and the ADSP-21161N EZ-KIT Lite evaluation system.
To view VisualDSP++ Help, click on the Help menu item or go to the
Windows task bar and select Start –>Programs –>Analog Devices–>Visu-
alDSP++ for 32-bit Processors –>VisualDSP++ Documentation.
To view ADSP-21161N EZ-KIT Lite Help, which now is a part of the
VisualDSP++ Help system, go the Contents tab of the Help window and
select Manuals –>Hardware Tools –>EZ-KIT Lite Evaluation Systems.
For more documentation, please go to
http://www.analog.com/technology/dsp/library.html.
Printed Manuals
For general questions regarding literature ordering, call the Literature
Center at 1-800-ANALOGD (1-800-262-5643) and follow the prompts.
VisualDSP++ Documentation Set
Printed copies of VisualDSP++ manuals may be purchased through Ana-
log Devices Customer Service at 1-781-329-4700; ask for a Customer
Service representative. The manuals can be purchased only as a kit. For
additional information, call 1-603-883-2430.

Product Information
xx ADSP-21161N EZ-KIT Lite Evaluation System Manual
If you do not have an account with Analog Devices, you will be referred to
Analog Devices distributors. To get information on our distributors, log
onto www.analog.com/salesdir/continent.asp.
Hardware Manuals
Printed copies of hardware reference and instruction set reference manuals
can be ordered through the Literature Center or downloaded from the
Analog Devices website. The phone number is 1-800-ANALOGD
(1-800-262-5643). The manuals can be ordered by a title or by product
number located on the back cover of each manual.
Data Sheets
All data sheets can be downloaded from the Analog Devices website. As a
general rule, printed copies of data sheets with a letter suffix (L, M, N, S)
can be obtained from the Literature Center at 1-800-ANALOGD
(1-800-262-5643) or downloaded from the website. Data sheets without
the suffix can be downloaded from the website only—no hard copies are
available. You can ask for the data sheet by part name or by product
number.
If you want to have a data sheet faxed to you, the phone number for that
service is 1-800-446-6212. Follow the prompts and a list of data sheet
code numbers will be faxed to you. Call the Literature Center first to find
out if requested data sheets are available.
Contacting DSP Publications
Please send your comments and recommendations on how to improve our
manuals and online Help. You can contact us at
[email protected].
