Analog way RC400T User manual

RC400T
Ref. RC400T
QUICK START GUIDE
Thank you for choosing Analog Way and the RC400T. By following these simple steps, you will be able to set
up and use your event controller for LivePremier™ 4K/8K mul-screen presentaon system within minutes.
• 1 x RC400T
• 1 x Power supply cord
• 1 x XLR lamp (oponal)
• 1 x Quick start guide*
* User manual and Quick start guides are also available on www.analogway.com
The RC400T event controller has been designed to greatly increase the level of operaonal eciency and
to give instant access to the crucial funconalies of the LivePremier™ image processor such as screens,
layers, sources and memories. The RC400T oers 56 user programmable buons, a high-resoluon T-bar
and a three-axis joysck for easy and fast programming (assign source in layers, load memories, etc.).
WHAT’S IN THE BOX
OVERVIEW
INSTALLATION
The RC400T has been designed to be used directly on a table. It is equipped with a wrist rest and four an-
slip rubber feet. The wrist rest can be removed for a recessed installaon of the RC400T.
• Recessed installaon - Remove the wrist rest
1. Turn the rear panel power switch o and disconnect the power supply.
2. Remove the screws of the wrist rest on both sides of the RC400T using a T10 Torx screwdriver.
3. Safely remove the wrist rest.
The RC400T is ready for recessed installaon. Before embedding the RC400T, connect all cables and turn
the rear panel power switch on or make sure they can be accessed.
RC400T dimensions:
- L 570 mm x H 122.5 mm x P 382 mm (W 22.44’’ x H 4.82’’ x D 15.04’’)
FIRMWARE UPGRADE
Download the RC400T updater and the latest LivePremier™ rmware on www.analogway.com
1. Put the updater le on a USB drive.
2. Connect the USB drive on the front panel.
3. The updater le is automacally detected. Otherwise, go to Console Control > Update from USB.
4. Extract the updater le.
5. Install the new rmware.
Go on our website to register your product(s)
and be noed about new rmware versions:
hp://bit.ly/AW-Register
Register
your product

CONTROLLER DESCRIPTION
• Top area
The top area is used mainly for conguring the RC400T (status, network, upgrade, factory reset, etc.).
Use the rotary encoder to move the selecon and use the buons to Conrm / Cancel the choices.
The Program/Preview key toggles between Program and Preview modes (this key is related to the Selec-
on area). Note that the three-axis joysck will be fully funconal in a future version.
• XLR lamp (oponal)
The XLR lamp is used to light the RC400T if needed.
To turn the lamp on, go to Front panel sengs and enable Power on light.
• Selecon area - Mul-purpose area
The Selecon area is used for Screen composion. Select Screens, Aux Screens, Layers, and assign Sources
or reload Memories. The Selecon area is composed of 4 idencal rows of keys. Each row is composed
of 12 LED keys with labels in OLED displays, one LCD key and one rotary encoder. Each row can display a
predened group of items depending on the mode selected by the user. Note that the Program/Preview
key aects the enre Selecon area.
• User keys area
The User keys area is composed of 8 LED keys, one OLED display, one LCD key and one rotary encoder.
This area has been designed to be evoluve and user customizable. The user keys are predened slots for
features or acons set by the user (remove a source content, set transion me, disable the T-bar, etc.).
More features will be coming in future versions and users are welcome to request new User keys features.
•Transion area
The Transion area is composed of one T-bar and 3 LED keys: Take Cut, Step Back and TAKE:
- Take Cut triggers an immediate transion from Preview to Program without eects or duraon.
- Step Back reloads the former Program to the Preview.
- TAKE triggers the transion from Preview to Program with eects, duraon, etc.
The T-bar is a manual Take triggered by the user for a smooth transion.
The transion applies only to Screens selected in the Selecon area.

GETTING STARTED
The RC400T controls LivePremier™ devices using standard Ethernet LAN networking.
• Connect and start the RC400T
1. Connect the power supply cord on the rear panel.
2. Connect the RC400T to the same network as the LivePremier™ unit.
3. Turn the RC400T on (rear and front On/O buons).
To turn the RC400T o, press the On/O buon on the front panel then conrm.
• Congure the RC400T network
1. On the front panel, go to Remote Device Network > Remote device LAN sengs.
2. Set the IP address of the LivePremier™ unit and Apply (192.168.2.140 by default).
3. Then go to Console Network.
4. Set the IP address of the RC400T and Apply (192.168.2.130 by default).
The connecon status is displayed on screen.
If the connecon is not starng:
• Check that both IP addresses are on the same network and subnet.
• Check that no device has the same IP address (prevent IP conicts).
• Check that all network conguraons have been applied.
• Check that the LivePremier™ unit and RC400T have the latest rmware version installed.
• Check the network cables. If connecng the RC400T and the LivePremier™ unit directly, make sure to
use an Ethernet crossover cable. If a hub or switch is involved, use straight or crossed Ethernet cables.
QUICK GUIDE
• Program and Preview modes
Press the Program/Preview key to toggle between Program and Preview modes.
- Program mode is enabled when the key is on with a red light.
- Preview mode is enabled when the key is o.
• Select a row mode
1. On the Selecon area, press the LCD key of a row. The row is on Mode selecon and the available
modes are displayed in the OLED screens.
2. Select a mode using the corresponding LED key. The row is now in the selected mode.
3. Use the rotary encoder to change the page if needed.
Note that the same mode can be selected in dierent rows. Here are some examples of conguraons:
Loading Master memories:
Row 1: Screens / Aux Screens
Row 2: Master memories 1 to 12 (page 1)
Row 3: Master memories 13 to 24 (page 2)
Row 4: Master memories 25 to 36 (page 3)
Assigning inputs to layers:
Row 1: Screens / Aux Screens
Row 2: Layers
Row 3: Inputs 1 to 12 (page 1)
Row 4: Inputs 13 to 24 (page 2)

QUICK GUIDE
• Assign a source to a layer
1. Select the Program or Preview mode.
2. On the Selecon area, press the LCD key of a row. The row is on Mode selecon.
3. Select the Screen / Aux Screens mode using the corresponding LED key. The row is on Screen mode.
4. Select the Screen using the corresponding LED key.
5. On another row, press the LCD key and select the Layers mode. The layers of the selected Screen are
displayed in the row.
6. Select one or mulple layers. Use the rotary encoder to change the page if needed.
7. On another row, press the LCD key and select a source (Inputs, Images or Background sets).
8. Select a source. Use the rotary encoder to change the page if needed.
The source is now assigned to the selected layers in the selected Screen.
• Load a Screen memory
Note: Follow this procedure using Mulviewer mode and memories to load a Mulviewer memory.
1. Select the Program or Preview mode.
2. On the Selecon area, press the LCD key of a row. The row is on Mode selecon.
3. Select the Screen / Aux Screens mode using the corresponding LED key. The row is on Screen mode.
4. Select the Screen using the corresponding LED key.
5. On another row, select the Screen memories mode.
6. Select a memory. Use the rotary encoder to change the page if needed.
The Screen memory is now loaded to the selected Screen.
• Load a Master memory
1. Select the Program or Preview mode.
2. On the Selecon area, select the Master memories mode.
3. Select a memory. Use the rotary encoder to change the page if needed.
The Master memory is now loaded to Screens as set in the Master memory.
•Screen selecon for Transions
Aer loading a memory in Preview, select / deselect the Screens to transion.
1. On the Selecon area, select the Screens / Aux Screens mode.
2. Select the Screens to transion.
3. On the Transion area, trigger the transion. The selected Preview Screens are sent to Program.
01-APR-2020
RC400T - QSG
Code : 140203
For complete details and operaons procedures, please refer to the LivePremier™ User Manual and our web-
site for further informaon: www.analogway.com
This Analog Way product has a 3 year warranty on parts and labor (back to factory). Broken connectors
are not covered by warranty. This warranty does not include faults resulng from user negligence, special
modicaons, electrical surges, abuse (drop/crush), and/or other unusual damage. In the unlikely event of a
malfuncon, please contact your local Analog Way oce for service.
