Analog way SPU001 User manual

Thank you for choosing Analog Way and the Secure Power Unit. By following these simple steps, you will be able to
set up and use your external power supply secure unit. Dedicated to Analog Way’s LiveCore™ series (NeXtage 08,
NeXtage 16, SmartMatriX Ultra,Ascender 16, Ascender 32 &Ascender 48), the Secure Power Unit allows a redundant
supply and a protecon against power cuts or failures.
• 1 x Secure Power Unit 1 RU Frame (SPU001)
• 1 x LiveCore™ power supply (OPT-SPS)
• 1 x SPU baery (OPT-SPUBATTERY)
• 1 x SPU adaptator block with aached cable
• 1 x IEC power supply cable
• 1 x Grounding cable
• 1 x RS232 cable
• 1 x Rear rack rail kit
• 1 x Quick start guide*
* Quick start guide is also available on www.analogway.com
TEST buon Baery charge
PSU Status
SpeakON™
DC Power 12V Baery Power Supply Unit 2 Power Supply Unit 1
RS232 port
Ground
Secure Power Unit - Ref. SPU001
QUICK START GUIDE
WHAT’S IN THE BOX
PANELS DESCRIPTION
Go to our website to register your product(s)
and be noed about new rmware updates:
hp://bit.ly/AW-Register

THE TEST BUTTON
Pushing shortly the TEST buon performs a test of the Secure Power Unit. It enables a view of the Secure Power Unit
supply and of the baery charge without any LiveCore™ device connected (or in standby). A long press will perform a
forced charge of the baery if the baery charge is lower than 95% (only when the LiveCore™ device is in standby or
without any LiveCore™ connected).
The Secure Power Unit has been designed to replace the power supply of LiveCore™ devices. It provides a redundant
supply plus a baery.
If a power supply unit stops working, the other one supplies the device. If both stop working, the baery keeps the
device switched on for a duraon of 5-10 minutes to enable the device to be turned o properly or x the electrical
issue.
When a LiveCore™ device is powered on using the Secure Power Unit, the baery is automacally charging.
It is possible to charge the baery when no LiveCore™ device is running. (see Test Buon descripon).
To nd informaon about the Secure Power Unit on the Web RCS (Setup > Services > SPU), the Secure Power Unit has
to be connected to the LiveCore™ device through an RS232 cable.
PSU LED Status
These LEDs show the status of PSU 1 and 2 slots.
BATTERY CHARGE LEDS
These LEDs give the status of the charging rate.
When charging, the LEDs ash unl full charge
is reached. When discharging, LEDs indicate the
remaining charge (same color as charging).
Solid red:
Solid green:
Solid red:
Solid orange:
Solid green:
O:
Blinking red:
Stand-by mode
The PSU is OK
25% LED: the charge is lower than 25%
25% LED: the charge is upper or equal to 25%
50% LED: the charge is upper or equal to 50%
75% LED: the charge is upper or equal to 75%
100% LED: the charge is complete
50% LED: the charge is lower than 50%
75% LED: the charge is lower than 75%
100% LED: the charge is lower than 100%
Baery mode
Solid green:
Solid red:
O:
Blinking green:
Acve mode
The PSU is no longer working or not
connected to the mains power
The corresponding PSU is not present
Auto test mode
Buon color usage:
LED color usage:
LED color usage:
Test buon & PSU LED
OPERATION OVERVIEW
HOW DOES THE SECURE POWER UNIT WORK

Installaon steps are detailed hereaer for a rst installaon or a hot swap. Please make sure to carefully follow
instrucons.
First installaon:
Please take the usual safety measures against ESD.
All devices must be disconnected from the mains power.
When installing a new Secure Power Unit, the exisng power supply from the LiveCore™ device is moved to the Secure
Power Unit ; the second power supply is already installed in the Secure Power Unit.
Web RCS: Setup > Services > SPU
The rst step is to unplug the power supply unit from the
LiveCore™ device and to transfer it into the free slot of the
Secure Power Unit. This provide a second redundant power
supply.
The second step is to insert the head frame into the LiveCore™
device and connect the SpeakON™ connector to the Secure
Power Unit.
STEP #1 STEP #2
1 1
22
INSTALLING THE SECURE POWER UNIT

03/21/2016 - SPU001-QSG
Code: 140156
This Analog Way product has a 1 year warranty on parts and labor (except for the power supply, the frame head and
the baery that are under warranty only in case of “Dead On Arrival”). This warranty does not include faults resulng
from user negligence, special modicaons, electrical surges, abuse (drop/crush), and/or other unusual damage. In the
unlikely event of a malfuncon, please contact your local Analog Way oce for service.
Hot swap:
You may wish to replace defecve elements while the installaon is running.
To replace a defecve power supply unit while the LiveCore™ device is running, follow these steps (taking the usual
safety measures against ESD):
• Unplug the power cable from the mains,
• Unplug the power cable from the defecve Power Supply Unit and take it o,
• Fit the new Power Supply Unit,
• Plug the IEC power cable to the Power Supply Unit,
• Connect the power cable to the mains.
To replace the baery, put the LiveCore™ device in stand-by, replace the baery then turn on the LiveCore™ device.
The third step is to connect the Secure Power Unit to the
LiveCore™ through an RS232 cable. It will provide informaon
about the Secure Power Unit directly on the Web RCS
interface. Connect the ground between the Secure Power
Unit and the LiveCore™ device.
The last step is to power the Secure Power Unit. The LiveCore™
device is ready to run safely.
WARNING: In order to power the Secure Power Unit, plug IEC
cables rst in the Secure Power Unit then plug into the mains
power.
STEP #3 STEP #4
1
2
11 2
Take the usual precauons against ESD (electrostac discharge).
To ensure maximum life to the baeries used in the Secure Power Unit, some precauons of use are required.
1) In use on a Secure Power Unit:
The charging/discharging system in the Secure Power Unit automacally provides the best baery perfomance. No
acon is required.
2) Storage:
Like all baeries, when a lithium baery is not used, it is subject to a low self-discharge.
For storage periods longer than 6 months, you should monitor the level of charge and, if the baery is at 50% or less,
you must charge the baery using the "Forced charging" feature of your Secure Power Unit.
PRECAUTION OF USE AND STORAGE OF LITHIUM-ION BATTERIES
WARRANTY AND SERVICE
