ANALOX Ax60+ Multi-Gas User manual

Analox Limited
15 Ellerbeck Court, Stokesley Business Park,
North Yorkshire, TS9 5PT, UK
UK/RoW T: [phone] F: [phone]
US T: [phone]
W: www.analox.net E: [e-mail]
Copyright © 2015 Analox Ltd. All Rights Reserved.
Ax60+ Multi-Gas
Service Manual

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 3 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
Contents
1Introduction..................................................................................................................... 5
1.1 Warnings, Cautions and Notes.................................................................................................................................................................. 5
1.2 Safety information.......................................................................................................................................................................................... 5
1.3 Other information........................................................................................................................................................................................... 5
1.4 Alarm terminology (CO2) ............................................................................................................................................................................. 6
1.5 Alarm terminology (O2) ................................................................................................................................................................................ 6
2Configuring sensors ........................................................................................................ 7
2.1 Hardware setting............................................................................................................................................................................................. 7
3Software Overview.......................................................................................................... 8
3.1 Powering up...................................................................................................................................................................................................... 8
4Menu options................................................................................................................. 11
4.1 Read-only menus..........................................................................................................................................................................................12
4.2 List Alarm points (Displayed as List Alrm pnts)................................................................................................................................14
4.3 List Alarm descriptions (Displayed as List Alrm descs)..................................................................................................................16
4.4 Testing relays (Displayed as Test relays).............................................................................................................................................18
5Calibrating Ax60+ sensors ........................................................................................... 19
5.1 CO2sensor calibration proof test...........................................................................................................................................................19
5.2 CO2sensor calibration adjustment........................................................................................................................................................20
5.3 O2sensor calibration proof test..............................................................................................................................................................24
5.4 O2sensor calibration adjustment...........................................................................................................................................................25
6Calibrating Ax60+ Kiosk sensors................................................................................. 29
6.1 CO2sensor calibration proof test...........................................................................................................................................................29
6.2 CO2sensor calibration adjustment........................................................................................................................................................30
6.3 O2sensor calibration proof test..............................................................................................................................................................33
6.4 O2sensor calibration adjustment...........................................................................................................................................................33
7Electrochemical sensor replacement........................................................................... 34
8Central Configuration (Displayed as Central Config) ............................................... 35
8.1 Attached snsrs................................................................................................................................................................................................35
8.2 Sensor Display Option (Displayed as Snr Display Opt).................................................................................................................36
8.3 Set Evacuation................................................................................................................................................................................................37
8.4 Relay configuration......................................................................................................................................................................................38
9Sensor Configuration (Displayed as Sensor Config) ................................................. 44
9.1 Enable alarms .................................................................................................................................................................................................44
9.2 Enable Evacuation (Displayed as Enable Evac) .................................................................................................................................45
9.3 Alarm Direction..............................................................................................................................................................................................46
9.4 Enable Sounder..............................................................................................................................................................................................47
9.5 Enable Strobe .................................................................................................................................................................................................48
9.6 Alarms Latching/Non Latching (Displayed as Alarms Latching) ...............................................................................................49
9.7 Alarm set-points (Displayed as Alrm set-pnts).................................................................................................................................50
10 Ax60+ Kiosk Option................................................................................................... 52
11 Fault finding................................................................................................................ 53
11.1 Fault codes.......................................................................................................................................................................................................53
11.2 Data Output Module fault indication...................................................................................................................................................54
12 Appendix A –Default Central Unit configuration settings ................................... 55
13 Appendix B –Default CO2sensor configuration settings ..................................... 56
14 Appendix C –Default Kiosk CO2sensor configuration settings ........................... 57
15 Appendix D –Default O2sensor configuration settings ....................................... 58

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 4 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
16 Appendix E –Data Output Module MODBUS detail.............................................. 59
16.1 MODBUS communications protocol ....................................................................................................................................................59
16.2 MODBUS register map ...............................................................................................................................................................................60
16.3 Changing DOM Node Addresses...........................................................................................................................................................62

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 5 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
1Introduction
This Service Manual explains how to service and calibrate the Ax60+. It is intended for system installers and service
engineers. For information on installation and operation, refer to the Ax60+ User Manual P0159-800, downloadable from
Analox.
1.1 Warnings, Cautions and Notes
WARNINGS ARE USED IN THIS MANUAL TO INDICATE POTENTIALLY HAZARDOUS SITUATIONS
WHICH COULD RESULT IN SERIOUS INJURY OR DEATH.
CAUTIONS ARE USED IN THIS MANUAL TO INDICATE POTENTIALLY HAZARDOUS SITUATIONS
WHICH COULD RESULT IN EQUIPMENT DAMAGE OR LOSS OF DATA.
NOTES ARE USED IN THIS MANUAL TO INDICATE SUPPLEMENTARY INFORMATION THAT IS NOT
HAZARD RELATED.
1.2 Safety information
WARNING: READ THE SAFETY INFORMATION IN THIS MANUAL BEFORE SERVICING THE AX60+.
WARNING: DO NOT TEST THE ALARM WHEN IT IS CLOSE TO THE EARS. IT HAS A HIGH VOLUME
SOUNDER WITH A SOUND LEVEL OF 88 DECIBELS AT A DISTANCE OF 3 METRES.
WARNING: DO NOT TEST THE ALARM WHEN IT IS CLOSE TO THE EYES. IT HAS A HIGH VISIBILITY
STROBE LIGHT WITH A LUMINOUS INTENSITY OF 100 CANDELA.
WARNING: DO NOT OPEN THE CENTRAL DISPLAY, SENSORS OR ALARMS IF THEY ARE CONNECTED
TO THE POWER SUPPLY. FIRST DISCONNECT AND ISOLATE THEM FROM LIVE HAZARDOUS
VOLTAGE.
1.3 Other information
NOTE: THE DATA OUTPUT MODULE DOES NOT REQUIRE ANY ON-SITE SERVICING, HOWEVER,
THE DATA OUTPUT MODULE DOES CHECK FOR A NUMBER OF FAULT CONDITIONS, SEE SECTION
11.2 FOR DETAILS ON FAULT INDICATIONS

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 6 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
1.4 Alarm terminology (CO2)
Alarms will display in priority order, in the order of AL4 to TWA
Display name for
users
Alarm description
Identification by
software
Default
setpoint
Notes
TWA
Time weighted
average over 8
hours
Alarm 1 or A1
0.5% CO2
Fixed alarm. At present it is not possible to
change a TWA alarm set-point.
AL1
High
alarm
Alarm 2 or A2
1.5% CO2
This alarm must be set lower than Alarm 3
(it may be set to 0.5% to give a pre-alarm
condition).
CO2
High-high alarm
Alarm 3 or A3
3.0% CO2
This alarm must be set higher than Alarm
2.
AL4
High-high alarm
Alarm 4 or A4
3.5% CO2
Alarm is disabled by default.
•The time-weighted average alarm is displayed to users as ‘TWA’ and identified by the software as ‘A1’ or
‘Alarm 1’and is announced by the Central Display only.
•The high alarm is displayed to users as ‘AL1’ and identified by the software as ‘A2’ or ‘Alarm 2’and triggers
the Alarm strobe once every 2 seconds, sounder is disabled by default, but if enabled by the user it will also
sound once every 2 seconds.
•The high-high alarm is displayed to users as ‘CO2’ and identified by the software as ‘A3’ or ‘Alarm 3’and
triggers the Alarm strobe/sounder once every second.
•The fourth alarm level ‘AL4’ is disabled by default; this is identified by the software as ‘A4’ or ‘Alarm 4’. If
enabled the Alarm strobe and sounder would trigger once every second.
1.5 Alarm terminology (O2)
Alarms will display in priority order, in the order of AL4 to AL1
Display name for
users
Alarm description
Identification by
software
Default
setpoint
Notes
AL1
Low
alarm
Alarm 1 or A1
19.5% O2
Alarm is disabled by default.
AL2
Low
alarm
Alarm 2 or A2
19.5% O2
This alarm must be set lower than Alarm 3.
AL3
High-high alarm
Alarm 3 or A3
23.0% O2
This alarm must be set higher than Alarm
2.
AL4
Low-low
alarm
Alarm 4 or A4
18.0% O2
This alarm must be set lower than Alarm 2.
•The first low or high alarm ‘AL1’AL1is disabled by default; this is identified by the software as ‘A1’ or ‘Alarm
1’. If enabled the Alarm strobe and sounder would trigger once every 2 seconds.
•The low-level alarm is displayed to users as ‘AL2’ and identified by the software as ‘A2’ or ‘Alarm 2’and
triggers the Alarm strobe once every 2 seconds, sounder is disabled by default, but if enabled by the user it
will also sound once every 2 seconds.
•The high-high alarm is displayed to users as ‘AL3’ and identified by the software as ‘A3’ or ‘Alarm 3’and
triggers the Alarm strobe/sounder once every second.
•The low-low alarm is displayed to users as ‘AL4’ and identified by the software as ‘A4’ or ‘Alarm 4’and
triggers the Alarm strobe/sounder once every second.

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 7 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
2Configuring sensors
2.1 Hardware setting
In a standard Ax60+ system (not including the Kiosk option) each sensor must have its jumper link set to a different
location e.g. Sensor 1=location 1; Sensor 2=location 2.
The Sensor has a hardware setting that is factory configured for a system with only one Sensor. If a system includes two,
three, or four Sensors then the hardware must be reconfigured by moving a jumper link ( ) in each Sensor installed
in the system.
WARNING: DISCONNECT AND ISOLATE THE AX60+ SYSTEM FROM THE MAINS POWER SUPPLY
BEFORE OPENING THE CO2SENSOR ENCLOSURES.
To access the jumper link, open the Sensor enclosure. The printed circuit board (PCB) has a SENSOR LOCATION selector
with one link, factory installed in LOCATION 1.
The image to the right shows the jumper link in position
1 (Factory default).
For a system with only one Sensor, the jumper link
should be retained in LOCATION 1.
For a system with two Sensors, the first Sensor’s
jumper link should be in LOCATION 1 and the second
Sensor’s link in LOCATION 2.
For a system with three Sensors, the first Sensor’s link
should be in LOCATION 1, the second Sensor’s link in
LOCATION 2 and the third Sensor’s link should be in
LOCATIONLOCATION 3.
For a system with four Sensors, the first Sensor’s
jumper link should be in LOCATION 1, the second
Sensor’s link in LOCATION 2, the third Sensor’s link in
LOCATION 3 and the fourth Sensor’s link should be in
LOCATION 4.

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 8 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
3Software Overview
NOTE: THIS SECTION SPECIFICALLY RELATES TO THE AX60+ STANDARD OPTIONS, HW AND
QC. HOWEVER, A CENTRAL DISPLAY CAN BE TEMPORARILY CONNECTED TO THE AX60+ KIOSK
SENSOR TO ENABLE A SERVICE ENGINEER TO RECONFIGURE THE SYSTEM (SEE SECTION 10).
3.1 Powering up
When you power up the Ax60+, the software performs an automatic power-on-self-test (POST) which takes about 30
seconds. The results are shown on the Central Display.
Operator input
Software response
Central Display text
Optional text / notes
Switch on power
supply to Ax60+
Displays vendor name and
website (default is Analox Ltd)
Vendor name may vary,
depending on contract

No further operator
input is required.
The POST is an
automatic process
Performs a checksum
configuration check

Performs a software validation
check

Checks the Sensor(s) have been
calibrated

No sensors are configured
Confirms top line of LCD OK, no
pixels are missing

Confirms bottom line of LCD
OK, no pixels missing

Confirms buzzer is off and
green LED switches on

Confirms green LED is off and
yellow switches on


Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 9 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
Operator input
Software response
Central Display text
Optional text / notes
Confirms yellow LED is off and
red switches on

Confirms red LED is off and
buzzer switches on

Displays current software.
Buzzer switches off

Displays unique serial number
of the unit

Wait for Sensors to
warm up…
This screen may display for a
few seconds to show Sensor
warm-up status. It is for
information only. It requires
no operator input

CAUTION: EACH SENSOR MUST HAVE ITS JUMPER SET TO A DIFFERENT LOCATION (E.G. SENSOR 1
= LOCATION 1; SENSOR 2 = LOCATION 2), OTHERWISE THE CENTRAL DISPLAY WILL ANNOUNCE A
FAULT.REFER TO SECTION 2 FOR JUMPER SETTINGS INFORMATION.

Wait for system
status screen...
Displays system status screen.
Each Sensor is represented by
‘OK’ in the top line. For
In this example - The CO2
concentration is by default
displayed in ppm (parts per

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 10 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
Operator input
Software response
Central Display text
Optional text / notes
example, a system with two CO2
Sensors displays >OK OK. The
‘>’ character identifies which
Sensor is highlighted (Sensor 1
is highlighted by default)
million). The example shown
here displays 450 PPM, which
is equal to 0.045%.
NOTE: THE SYSTEM STATUS SCREEN DISPLAYS UP TO FOUR SENSORS. A SPARE
SENSOR LOCATION DISPLAYS AS: ‘- - -’
The bottom line displays the
concentration of measured gas
at the Sensor

Press Cycle
Displays Sensor 2 details (if
installed) and the current level
of measured gas
In this example, Sensor 2 is
not installed

Press Cycle
Displays Sensor 3 details (if
installed) and the current level
of measured gas
In this example, Sensor 3 is
not installed

Press Cycle
Displays Sensor 4 details (if
installed) and the current level
of measured gas
In this example, Sensor 4 is
not installed

Press Cycle
Redisplays the system status
screen

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 11 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
4Menu options
To display the Top-level Menu options, press and hold Cancel + Cycle for at least 6 seconds.
NOTE: IF THERE IS NO USER ACTIVITY FOR 60 SECONDS THE MENU WILL TIME OUT.

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 12 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
4.1 Read-only menus
The Show config option enables you to view read-only information about the system configuration. It displays
information on Sensor connections and relay configuration.
NOTE: NOTE: THE Show config OPTION PROVIDES READ-ONLY INFORMATION THAT CAN
NOT BE CHANGED. IF YOU WANT TO SET UP OR CONFIGURE THE Ax60+, USE THE Top-level Menus,
Central Config OPTION.
4.1.1 Show configuration (Displayed as Show config)
1] To display the Top-level Menu Show config option, press and hold down the Cancel + Cycle
buttons for at least 6 seconds.
2] Press Accept/Test to display the Show Config? option
3] Press Cycle to cycle through each of the config options
NOTE: TO RETURN TO THE SYSTEM STATUS SCREEN AT ANY TIME PRESS Cancel. THE Cancel
BUTTON REDISPLAYS THE PREVIOUS MENUS, ONE AT A TIME.

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 13 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
4.1.2 Show Sensor configuration (Displayed as Show Sensor config)
The Show Sensor config option enables you to view read-only information about the sensor configuration. It displays
information on Sensor alarms, sounders and strobes.
NOTE: THE Show Sensor Config OPTION PROVIDES READ-ONLY INFORMATION THAT CAN
NOT BE CHANGED. IF YOU WANT TO SET UP OR CONFIGURE THE Ax60+, USE THE Top-level Menu,
Sensor Config OPTION.
1] To display the Top-level Menu Show config option, press and hold down the Cancel +
Cycle buttons for at least 6 seconds.
2] Press Accept/Test, then press Cycle six times to display the Show Sensor Config?
option
3] Press Accept/Test to enter the menu, then press Cycle to view each config
item
NOTE: TO RETURN TO THE SYSTEM STATUS SCREEN AT ANY TIME PRESS Cancel. THE Cancel
BUTTON REDISPLAYS THE PREVIOUS MENUS, ONE AT A TIME.

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 14 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
4.2 List Alarm points (Displayed as List Alrm pnts)
4.2.1 List Alrm pnts (CO2 example)
The Top-level Menu, List Alrm pnts option enables you to view read-only information about the alarm setpoints
configured for each Sensor.
NOTE: THE List Alrm pnts OPTION PROVIDES READ-ONLY INFORMATION THAT CAN NOT BE
CHANGED. IF YOU NEED TO SET UP OR CONFIGURE THE ALARM SETPOINTS, USE THE Top-level
menu, Sensor Config, Alrm set-pnts OPTION.
1] To display the Top-level Menu List Alrm pnts option, press and hold down the
Cancel + Cycle buttons for at least 6 seconds. Then press the Cycle button once.
2] Press Accept/Test to go to the Select Sensor screen, this displays the Sensors
and highlights Sensor 1
3] Press Cycle to highlight other sensors
4] Press Accept/Test to select the sensor that you want to view alarms on, then
press Cycle to cycle through the alarms
5] Press Cancel to exit the Alarm screen and return to Select another sensor or
press Cancel to return to the Top-level Menu, List Alrm pnts

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 15 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
4.2.2 List Alrm pnts (O2 example)
The Top-level Menu, List Alrm pnts option enables you to view read-only information about the alarm setpoints
configured for each Sensor.
NOTE: THE List Alrm pnts OPTION PROVIDES READ-ONLY INFORMATION THAT CAN NOT BE
CHANGED. IF YOU NEED TO SET UP OR CONFIGURE THE ALARM SETPOINTS, USE THE Top-level
menu, Sensor Config, Alrm set-pnts OPTION.
1] To display the Top-level Menu List Alrm pnts option, press and hold down the
Cancel + Cycle buttons for at least 6 seconds. Then press the Cycle button once.
2] Press Accept/Test to go to the Select Sensor screen, this displays the Sensors
and highlights Sensor 1
3] Press Cycle to highlight other sensors
4] Press Accept/Test to select the sensor that you want to view alarms on, then
press Cycle to cycle through the alarms
5] Press Cancel to exit the Alarm screen and return to Select another sensor or
press Cancel to return to the Top-level Menu, List Alrm pnts

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 16 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
4.3 List Alarm descriptions (Displayed as List Alrm descs)
4.3.1 List Alrm descs (CO2example)
The Top-level Menu, List Alrm descs option enables you to view read-only information about the alarm descriptions
configured for each Sensor.
NOTE: THE List Alrm descs OPTION PROVIDES READ-ONLY INFORMATION THAT CAN NOT BE
CHANGED. IF YOU NEED TO SET UP OR CONFIGURE THE ALARM SETPOINTS, USE THE Top-level
menu, Sensor Config, Alrm set-pnts OPTION.
1] To display the Top-level Menu List Alrm descs option, press and hold down the Cancel +
Cycle buttons for at least 6 seconds. Then press the Cycle button twice.
2] Press Accept/Test to go to the Select Sensor screen, this displays the CO2 Sensors and
highlights Sensor 1
3] Press Cycle to highlight other sensors
4] Press Accept/Test to select the sensor that you want to view alarms on, then press Cycle to
cycle through the alarms
5] Press Cancel to exit the Alarm screen and return to Select another sensor or press Cancel to
return to the Top-level Menu, List Alrm descs

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 17 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
4.3.2 List Alrm descs (O2example)
The Top-level Menu, List Alrm descs option enables you to view read-only information about the alarm descriptions
configured for each Sensor.
NOTE: THE List Alrm descs OPTION PROVIDES READ-ONLY INFORMATION THAT CAN NOT BE
CHANGED. IF YOU NEED TO SET UP OR CONFIGURE THE ALARM SETPOINTS, USE THE Top-level
menu, Sensor Config, Alrm set-pnts OPTION.
1] To display the Top-level Menu List Alrm descs option, press and hold down the Cancel +
Cycle buttons for at least 6 seconds. Then press the Cycle button twice.
2] Press Accept/Test to go to the Select Sensor screen, this displays the CO2 Sensors and
highlights Sensor 1
3] Press Cycle to highlight other sensors
4] Press Accept/Test to select the sensor that you want to view alarms on, then press Cycle to
cycle through the alarms
5] Press Cancel to exit the Alarm screen and return to Select another sensor or press Cancel to
return to the Top-level Menu, List Alrm descs

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 18 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
4.4 Testing relays (Displayed as Test relays)
The Test relays option is used to switch Relays 1 and 2 to check they are functioning.
WARNING: DURING A RELAY TEST, ANY CONNECTED DEVICES OR CIRCUITS WILL OPERATE.
DISCONNECT AND ISOLATE ANY DEVICES OR CIRCUITS CONNECTED TO THE RELAYS BEFORE
TESTING THEM.
NOTE: IF YOU FORGET TO SWITCH OFF THE RELAYS DURING THE TEST THEY WILL
AUTOMATICALLY SWITCH OFF WHEN YOU EXIT THE MENU OR WHEN THE SOFTWARE TIMES OUT
AFTER 60 SECONDS.
NOTE: RELAYS ARE NOT TRIGGERED WHEN CARRYING OUT THE ‘ALARM TEST’ FUNCTION.
1] To display the Top-level Menu Test relays option, press and hold down the Cancel+Cycle
buttons for at least 6 seconds. Then press the Cycle button three times.
2] Press Accept/Test to go to the Activate Rly 1 screen, Press Accept/Test to activate the relay
3] Press Cycle to go to Activate Rly 2 screen, Press Accept/Test to activate the relay
4] Press Cycle to go to Rlys inactive screen, Press Accept/Test to deactivate the relays
NOTE: YOU WILL HEAR CLICKS FROM THE CENTRAL DISPLAY DURING TESTING OF RELAYS
5] Press Cancel to return to Top-level Menu, Test relays

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 19 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
5Calibrating Ax60+ sensors
5.1 CO2sensor calibration proof test
The Ax60+ CO2Sensors can be checked to ensure that they accurately measure carbon dioxide and displays the correct
reading. Analox can supply the following check kit:
Ax60+ CO2Check Kit comprising:
Part number
Description
Gas type
Contact Analox or source
locally
110-litre pure air (20.9% oxygen, balance nitrogen)
CO2 Low Check
Contact Analox or source
locally
110-litre 3.0% carbon dioxide, balance nitrogen
CO2 High Check
Contact Analox or source
locally
0.5-litre/minute regulator to fit 110-litre bottle
1817-5000
2-metre neoprene tubing
8000-0910A
Push-in flow adaptor
Checking CO2Sensors is an easy task that does not require software input. This procedure is suitable for the standard
Ax60+ option only. Follow the procedure below:
NOTE: IF THE OPTIONAL SENSOR SPLASHGUARD IS FITTED, REMOVE IT BEFORE CHECKING
AND/OR CALIBRATING THE SENSORS.
1] Ensure the Ax60+ is powered on and operating normally.
2] Fit the neoprene tubing (1817-5000) to the flow adaptor (8000-910A).
3] Fit the flow adaptor into the aperture on the CO2 Sensor (see below, left).
Step [3] Fit the flow adaptor into
the aperture on the CO2Sensor
Step [4] Fit the regulator to the CO2low
check gas bottle

Ax60+ Multi-Gas
Service Manual Int. Approved
Document ref: P0159-803-11 September 2019 Page 20 of 62
Copyright © 2015 Analox Ltd. All Rights Reserved.
Commercial in Confidence
4] Fit the regulator to the CO2 low check gas bottle (see above, right).
5] Carefully open the regulator valve and allow the CO2 low check gas to flow across the sensor.
Do not block the exit of the flow adaptor.
6] Ensure that the Ax60+ display reading is between 400ppm and 550ppm
7] Close the regulator valve, acknowledge the alarm and ventilate the area.
8] Repeat the procedure using the CO2 high check gas bottle to check the display reading shows
between 30000 –30150ppm CO2
5.2 CO2sensor calibration adjustment
The Ax60+ CO2Sensor(s) can be recalibrated to ensure they accurately measure carbon dioxide at the specified levels.
Analox can supply the following calibration kit:
Ax60+ CO2Calibration Kit comprising:
Part number
Description
Gas type
Contact Analox or source
locally
110-litre pure air (20.9% oxygen, balance nitrogen)
CO2 Zero
Contact Analox or source
locally
110-litre 3% carbon dioxide, balance nitrogen
CO2 Span
Contact Analox or source
locally
0.5-litre/minute regulator to fit 110-litre bottle
1817-5000
2-metre neoprene tubing
8000-0910A
Push-in flow adaptor
Recalibrating CO2Sensors is a similar task to checking but it also requires software input.
Calibration adjustment is a two-point process: a ‘zero calibration adjustment’ and a ‘span calibration adjustment’.
NOTE: ZERO CALIBRATION ADJUSTMENT MUST BE PERFORMED BEFORE SPAN CALIBRATION
ADJUSTMENT.
5.2.1 CO2sensor zero calibration (Displayed as Zero cal.)
NOTE: THE SENSOR THAT IS BEING CALIBRATED IS AUTOMATICALLY DISABLED DURING
CALIBRATION. THE OTHER SENSORS CONTINUE TO OPERATE.
NOTE: CALIBRATION MODE AUTOMATICALLY TIMES OUT AFTER TEN MINUTES.
To zero calibrate a CO2Sensor, follow the procedure below (in both text and menu map):
1] Ensure the Ax60+ is powered on and operating normally.
2] Press and hold Cancel+Cycle for 6 seconds to display Top-level Menu.
3] Press Cycle four times to display Calibration. Press Accept/Test to display Zero cal.
4] Press Accept/Test to show the Select sensor screen, press Cycle to select the Sensor you want
to calibrate.
5] Press Accept/Test to select the Sensor. The Zero level (#) screen displays.
6] Fit the neoprene tubing (1817-5000) to the flow adaptor (8000-
0910A).
