Analytical Sales & Services LightOne Red Illuminator FS User manual

LightOne™ Red
Illuminator FS
Instruction Manual
Vers. 1.0

Section Page
I. Quick Start.............................................2
II. Buttons................................................3
III. Features ...............................................4
IV. Modes of Use ..........................................6
V. Advanced Users .......................................7
VI. Specications..........................................7
VII. Safety .................................................8
VIII. Maintenance & Cleaning ...............................8
IX Warranty ..............................................8
Contents
1LightOne Illuminator FT

• While on A1 well, press once. The whole row should light up.
Because the LEDs are in a loop, pressing again will light up A12 well.
• Light up the whole second row by navigating to B1 well with the directional
arrows and repeating the process etc.
2
How to Light up all 96 wells
• While on A1 well, press once and press once. All 96 wells will be illuminated.
How to light up a row
How to light up a column
• While on A1 well, press once. The whole column should light up.
Because the LEDs are in a loop, pressing again will light up H1 well.
• Light up the whole second column by navigating to A2 well with the
directional arrows and repeating the process etc.
How to change directions when using Tracking Mode
• To advance down, hold
until the blue LED next to it
lights up.
• To advance right, hold
until the blue LED below it
lights up.
LightOne Illuminator FT
1
2
3
Connection
Connect the LightOne Illuminator to
one of the two slots shown.
Insert the LightOne Foot Pedal cord
into the small jack.
Connect the distribution box to the AC
adapter, plug in the AC adapter and
you are ready to go!
1
3
2
• Most buttons have 2 functions accessed by pressing once or holding it down
• LEDs are formatted in a loop.
Quick Start

• Navigate up, down, left and right with these 4
directional arrows.
• Use these directional arrows to choose where you
want to start in Tracking Mode and Auto Mode.
For navigation in Manual Mode
3
Buttons:
LightOne Illuminator FT
POWER For changing intensity and entering Index Mode
• Press once to switch through each of the three intensities.
• Hold to enter Index Mode.
• Index Mode can be used for light sensitive reagents. The A-H and
1-12 index lights can be illuminated as the eld lights remains o.
POWER
POWER
SELECT For entering Auto Mode and setting time interval
• Press once to select Auto Mode.
• Hold to enter set time interval mode.
• Orange LED next to “Time”should light up.
• Use and to set the duration of the interval.
• Press once to exit set time interval mode.
** A1 - A10 is 1 - 10 seconds, B1 - B10 is 11 - 20 seconds etc.
SELECT
SELECT
SELECT
For Tracking Mode, Auto Mode,
Pause and Reset
GO
(reset)
• Press or once to enter tracking mode. (Auto LED is o)
• Press or once to start automatic advancement. (Auto LED is on)
• Press or to PAUSE and again to RESUME.
• Hold or to reset.
GO
(reset)
GO
(reset)
GO
(reset)
GO
(reset)

4
Go/Reset Button -
Press once to enter Tracking
Mode. Press once to initiate
Auto Mode and Hold to
reset
Directional Arrows -
Navigation through
Manual Mode
LightOne Viewing Stand
with 3 tilt angles
Water resistant, sealed
membrane surface
LightOne Illuminator FT
(LightOne Foot Pedal)

5
Select Button -
Press once to enter Auto
Mode and Hold to set time
intervals
Power Button -
Press once to change
brightness and Hold to
enter Index Mode
For half or unskirted plates,
add a LightOne Viewing Frame
to secure its position
Retainers are molded
in to hold your 96
well plate in place
(LightOne Viewing Frame)
LightOne Illuminator FT

• Chose direction of advancement and set time increments.
Then press or to start.
• The single or group of lights will automatically advance in the
direction you chose after the preset number of seconds.
• A trail of dim lights will show which wells have been done.
GO
(reset)
6
Modes of Use:
• Use to move a single well or rows/
columns in any direction.
• Move whole rows up and down.
• Move whole columns left and right.
• Shows you where you currently are.
Manual Mode: Maximum Flexibility
Auto Mode: Maximum Tracking
LightOne Illuminator FT
• Chose direction of advancement with or and press
or to start tracking.
• A trail of dim tracking lights are left behind to
signify which wells you have already done.
• Track with a single well, whole rows/columns or
partial rows/columns.
Tracking Mode: Flexibility with Tracking
GO
(reset)

7
Partial Row
Partial Column
Advanced Users
LightOne Illuminator FT
Reset
• Hold or to reset. A1 well should be illuminated on high intensity.
GO
(reset)
Specications
LightOne Viewing Stand
• LightOne Viewing Stand: Anodized (white) Aluminum
• Dimensions: 16(L) x 16(W) cm
• Weight: 120 g
• Three dierent tilt angles: 45°, 22°, 10°
LightOne Viewing Frames
• LightOne Viewing Frame: Acrylic
• Dimensions (outer): 12.5(L) x 8.5(W) x 0.3(H) cm
• Dimensions (inner): 10(L) x 6.5(W) x 0.3(H) cm
LightOne Illuminator FS
• LightOne Illuminator enclosure: Molded polycarbonate
• LightOne Foot Pedal: ABS Thermoplastic
• Dimensions: 15.5(L) x 15.5(W) x 1.5(H) cm
• Weight: 265 g
• Voltage Input: 100-240V, 50-60Hz
• LED: White, 96 in eld, 20 index
• Can light up single wells, whole rows/columns, all 96 wells and partial
rows/columns
• Built in retainers to secure plates
• Compatible with all 96-well format plates
• Hold and simultaneously and then release. The lights in the
whole row will blink.
• Use to deselect from the right and to deselect from the left. Determine
how many wells you want illuminated.
• Press and to conrm selection.
• Similarly, use and for a partial column.
Illuminate partial rows/columns

8
LightOne Illuminator FS Warranty Information
Date of Delivery: _____________________
Invoice Number: _____________________
Purchase Order: _____________________
The LightOne Illuminator FS is warranted to be free of defects in materials and
workmanship for a period of one year from the date of purchase. If defects are
found during this warranty period, Analytical Sales will replace the defective
parts at no charge, provided product is returned within the warranty period.
This warranty specically excludes:
Defects caused by improper operation. Damage caused by
improper handling or accidental misuse. Damage incurred during shipping.
This warranty is VOID if moisture is discovered inside the unit or if the unit has
been opened.
WARRANTY
SAFETY
Always wear protective gloves and safety glasses in the laboratory. The
LightOne Illuminator FS is intended for laboratory research use only. Power is
supplied to the LightOne Illuminator FS by the AC adaptor and is designed for
use with the LightOne Illuminator FS only. Do not attempt to use any other AC
adaptor with the LightOne Illuminator FS. The LightOne Illuminator FS should
not be modied or altered in any way. Analytical Sales is not responsible for
any injury or damage caused by improper use of this apparatus or by modi-
cations to the system not performed by Analytical Sales.
To clean, simply wipe down the smooth surface with a damp towel. The
LightOne Illuminator FS is water resistant, but not waterproof.
MAINTENANCE & CLEANING
LightOne Illuminator FT

9
With a LightOne Illuminator...
Start Bringing Condence, Well by Well
LightOne Illuminator FT
Cat. No. Description Dimensions
LOI-96FT LightOne Illuminator FS 100-240V
Includes: LightOne Viewing Stand, LightOne Viewing
Frame, and LightOne Foot Pedal
15.5 (L) x 15.5 (W) x 1.5 (H) cm
LOI-101 LightOne Viewing Stand 16 (L) x 16 (W) cm

Related Products
179 Route 206, Flanders, NJ 07836
Ph 973-616-0700 Fax [phone]
LightOneTM is a trademark of Embi Tec LightOneRed Manual
