Anbtek As201e User manual

GSM/GPS

ALARM

TRACKING KIT

AS201E USER’S GUIDE

Content Index

. Introduction..................................................................................................................................................3

.1 Instruction of Safety ...............................................................................................................................3

.2 Specification ...........................................................................................................................................3

.3 Typical Application .................................................................................................................................4

.4 Package Contents ...................................................................................................................................4

.4.1 Standard Package Contents.............................................................................................................4

.4.2 Optional Accessories .......................................................................................................................5

2. Knowlege Before Usage................................................................................................................................5

.1 How it works?.........................................................................................................................................5

.2 Factory Default Setting...........................................................................................................................6

.3 Power Supply..........................................................................................................................................6

.3.1 External Power and Internal Power.................................................................................................6

.3.2 Sleep Mode consumptions and how it works..................................................................................6

.4 Transmitter Operation............................................................................................................................7

.4.1 Transmitter Button functions ..........................................................................................................7

.4.2 Transmitter and wireless sensor Program to AS201E Box................................................................7

2.5 How to configure device (Configuration)................................................................................................8

.5.1 Configure by SMS commands ..........................................................................................................8

.5.2 Configure by PC tool “ AS201E Configurator” ................................................................................9

.6 I/O Introduction and Definition............................................................................................................10

.7 How to insert Simcard to AS201E..........................................................................................................11

. Functions and Operation............................................................................................................................11

.1 Arm/Disarm..........................................................................................................................................11

.2 Alarm Alert functions ...........................................................................................................................11

.3 Remote stop Oil/Power supply for engine (Immobilizer) .....................................................................12

.4 Power Saving ........................................................................................................................................13

.5 Shock Alert ,Crash accident alert and Crash accident data logger........................................................13

.6 Voice Listen-in ......................................................................................................................................15

.7 Switch ON/Off Siren .............................................................................................................................15

.8 iButton Probe Kit ..................................................................................................................................16

.9 Temperature detection ........................................................................................................................16

.10 Ultrasonic fuel senor configure ..........................................................................................................17

.11 Asset maintain notice .........................................................................................................................18

.12 Battery Low Alert................................................................................................................................18

.13 Recovery Factory Default ...................................................................................................................18

.14 Remote Reboot ..................................................................................................................................18

.15 Locate in parking Lot ..........................................................................................................................18

.16 GPS Tracking features.........................................................................................................................19

.16.1 Real Time Tracking.......................................................................................................................19

.16.2 Speed Limit Manage ....................................................................................................................20

.16.3 GEO Fencing Management ..........................................................................................................20

.13 Emergency Medical/Information Call to Center(Two way intercom) .................................................21

.14 Remote Door Lock/Unlock..................................................................................................................21

.15 Mute Output control for Original car Radio........................................................................................22

.16 Arm/Disarm Status LED Indicator .......................................................................................................22

.17 Wireless Sensor Detection..................................................................................................................22

.18 Daily Travel Mileage SMS report to Driver ( A authorization Phone No.) ...........................................23

.19 OTA firmware .....................................................................................................................................23

. APPENDIX ...................................................................................................................................................23

.Introduction

AS201E is a GSM/GPRS/GPS alarm tracking box for multi applications.

This small unit is equipped with Quad Bands GSM/GPRS module, Hi-sensitivity GPS receiver and 3D

Accelerometer. It’s also can be connected with optional wireless/wired accessories like fuel senor, RFID reader,

iButton Probe Kit, Temperature senor, RF Key Fob, Alarm siren and Relay for external electronics device control.

It supports both GPS tracking and backup LAC/CID tracking, which brings an idea solution with no blind tracking

both indoor and outdoor.

.1 Instruction of Safety



Do not disassemble the device more than it is allowed. If the device is damaged, the power supply cables are

not isolated or the isolation is damaged, before unplugging the power supply, do not touch the device.

All wireless data transferring devices produce interference that may affA ect other devices which are placed

nearby.



The device may be fitted only by qualified personnel.

The device must be firmly fastened in the predefined location.

The device is susceptible to water and humidity in environment with IP class greater than IP67.

Any installation and/or handling during a lightning storm is prohibited.

Ensure that the batteries are not immersed in water. When stored, keep the device in a cool and dry place.

Ensure that device and batteries are not exposed to hot surfaces or direct sunlight.

.2 Specification

Physical Specification:



Dimension: 92x64x24mm

Weight: 140g

Enclosure: Aluminum Metal Box

Connector:

Molex 18Pin Connector,6Pin Molex Connector and one 4Pin Molex Connector

SMA Connector for GSM/GPS antenna

Mini USB port for configuration and firmware update

Power Supply:



Voltage: 9-36V DC

Power Consumption:

0-150mA(All active)

Simple Sleep:<20mA (GSM ON, GPS Off, Alarm trigger active)

Deep Sleep: <5mA (GSM Off, GPS Off, Alarm trigger active)

Internal Battery:800mAH, 3.7V



GPS Navigation:



Antenna: External

Receiver: uBlox NEO 6M engine



Sensitivity: -162dBm

Navigation Update: 1Sec

TTFF: Cold Starts: 29s/Aided Starts: <1S/ Hot Starts: <1S

GSM:



Antenna: External

Modem: QUECTEL M35 /Quad Bands:850/900/1800/1900MHz

Radio Frequency:



Working frequency: 433MHz.

Code: 1527/2240 study

Working Voltage: 12V ( 27A 12V dry battery)

Control Distance: 20-50M

Environmental:



Working Temp.: -20

Humidity: 20-95%

℃~+75℃

.3 Typical Application



Car, truck, trailer and other special machinery like excavator and forklift)

Motor Homes

Boats & Yacht

.4 Package Contents

1.4.1 Standard Package Contents

) AS201E GPS Alarm Tracker x 1PC

) GSM Antenna x 1PC

) GPS Antenna x 1PC

) 18Pin Power+ I/O Wire harness x 1PC

) Panic Button x 1PC

) Engine Cut-off Relay x 1PC

) Microphone x 1PC

.4.2 Optional Accessories

Note:

Please kindly noted that optional accessories are not available in the standard package. But they are available for

purchase separately from manufacturer.

. Knowlege Before Usage

.1 How it works?

The AS201E mainframe works as a host box with multi input/outputs. The mainframe will process to get GPS

location and various working status from inputs and wireless sensors, and then send those information to preset

Phone Numbers or IP/Port Server via GSM network. Cell Phone or Server software can send commands to control

outputs action and also acquire different information by available commands.

.2 Factory Default Setting

---------------

Device SMS Command Password: 1234

IP/Port/APN: Empty

Alarm Alert Phone No.(A/B/C/D/G): Empty

Arm/Disarm Status: Disarmed

Speed Over Limit: Off

GEO Fence: Off

Data Transmit Mode: SMS Default when GPRS Parameter is not configured

Siren: ON

Automatic Immobilizer in Armed status: Disabled

Automatic Power supply switch from external to internal when external power low: Enabled

External Power low voltage Alert Level: less than 11.5V DC

Re-Arm: Disabled

Power Saving Mode: Simple Sleep

SMS Data Time Zone: GMT+0

Crash accident Logger and alert : Off

.3 Power Supply

2.3.1 External Power and Internal Power

AS201E works with two power supply mode: External Power and Internal Battery.

It's working normally with external power supply range from 9-36V DC. When the external power is disconnected

or with low voltage output, device will switch to work on internal battery automatically. And it also will send"

Circuit Cut Off" or "External power low voltage" Alert to preset Alerts Phone Numbers.

.3.2 Sleep Mode consumptions and how it works

Simple Sleep when Ignition Off:

GSM Sleep with SMS/Call Active, NO GPRS Connection and GPS shut down

All Alarms Detection working normally

Power Consumption in standby without alarm trigger: 10mA

Deep Sleep when Ignition Off:

GSM Shut down, NO SMS/Call active, GPS shut down

Alarms trigger detection: Off 6seconds, detect 2seconds in recycle

Average power consumption without alarm trigger: <5mA

NO sleep when Ignition Off:

GSM all ON with SMS/Call active, and GPRS connected with Server with continuously data sending

GPS ON

All alarm detection work normally

.4 Transmitter Operation

.4.1 Transmitter Button functions

Arm: Buzzer sound once, or direction light flash once

Disarm: Buzzer Sound Twice or direction light flash twice.

Mute Key: In siren sounding, press this button to stop the sounding.

In panic, Activate Siren to sound. Or in parking lot, press this button for car finding.

.4.2 Transmitter and wireless sensor Program to AS201E Box

If your transmitter is lost or damaged, or the transmitter battery is flat, the system can be overridden by

Ignition switch conjunction with Panic Button.

Please follow below process to finish the transmitter overridden operation:

)

Send SMS command to clear all existing transmitter code which stored in the system

Disarm the system by SMS command

Press and Hold Panic button

Switch Key from ACC off to ON position continuously 7times

Buzzer will sound once to indicating Overridden mode entered

Press any button of the transmitter

Buzzer sound twice again to indicate override success and exit overridden mode.

If system get into overridden mode, and no transmitter button was pressed or did not receive any incoming signal

during 20seconds, buzzer will sound bibibi three times and exit override mode

After you pressed the transmitter button during overridden mode, but system failed in accident due to unexpected

reason, system also will sound bibibi three times to indicate failure.

You can start the process again until you get it work success.

Note:

For other wireless sensor, like Door/window contact, Smoke and gas detectors follow the same process to

integrate them to system.

.5 How to configure device (Configuration)

AS201E box support configuration via SMS commands and also via PC program tool(Configurator) via

connect AS201E with PC through USB cable.

.5.1 Configure by SMS commands

For more commands information, please contact technical support or your seller!

Website: www.anbtek.com

mail: in[email protected]

.5.2 Configure by PC tool “ AS201E Configurator”

)

Connect AS201E with PC via USB cable:

Install CP2102 USB-Serial Driver:

Run AS201E configurator.exe and get into following interface:

.6 I/O Introduction and Definition

)

Main I/O ports Introduction:

)

I/O Pin slot Definition:

)

L1 18Pin Port Pin slot definition:

Wire Pin No.

Wire Color

Function/Specification Description

Description

Red/White

Black/White

Purple/White

Yellow

Power positive pole, 9-36VDC

GND

Power

Over speed Buzzer(=0V,Effect)

Siren/Hazard Light(12/24V, Effect)

Lock Door(=0V, Effect)

Unlock Door(=0V, Effect)

Mute-Control (=0V, Effect)

Engine Immobilizer (=0V, Effect))

Ignition status Detection(=0V, Off)

Door Status( =0V: Open)

Panic Button(=0V:effective)

ShortCall(=0V, Effective)

Temperature AD

Blue

Output

Blue/White

Brown/White

Grey/White

Red

L1 Molex

8Pin

Connector

White

Input

Orange/White

Blue/White

Black/White

Yellow/White

Orange

Arm/Disarm LED

Microphone

LED +

Mic+

Balck/White

Green/White

Black/White

Mic-

Speaker +

W Speaker

Speaker -

.7 How to insert Simcard to AS201E

. Functions and Operation

.1 Arm/Disarm

Arm/Disarm:

Arm: In armed status after ARM operation, any illegal events happened in I/O ports or Wireless sensor will trigger

Siren sound and SMS alerts.

Disarm: Opposite to Arm, user is free to do any operation but no alarm alert will be triggered.

Re-Arm:

Re-Arm is a function which is automatic arm again if the system was disarmed wrongly by mistakes and kids

press.

Trigger condition:

If in Armed status, the system was disarmed, and get no Door open or Ignition status operation within 60 Seconds,

system will automatic arm once.

AS201E system allow user to enable/disarm Re-arm function according user’s usage habit.

Re-Arm function Enable/Disarm Method:

Enable SMS command: *1234*REARMON#

Disable SMS command: *1234*REARMOFF#

.2 Alarm Alert functions

In Armed status, any illegal operation which happened in I/O ports and wireless sensor will trigger an alarm

action.

In alarm, the alarm siren will sound for 20seconds, and also send alarm alert via SMS and missed call to preset

phone numbers A/B/C.

Please check following alarm events alert system:

Alarm Siren

Sound

Functionality

Server

Shock alarm

External Power

Disconnection

Ignition ON

SMS Once SMS Once

SMS Once

20Seconds Sound

Yes

SMS Once

Yes

Panic Alarm

SMS Once SMS Once

GEO In/Out Alarm

Speed Buzzer==>>over timer

with siren/light warning and

immobilizer activated until

speed below limit

Speed Over Alarm

SMS Once SMS Once

SMS Once

Yes

Fuel stealing

SMS Once SMS Once

SMS Once

20Seconds Sound

Yes

Crash Accident Alert

External battery Low

Temperature

SMS Once SMS Once

SMS Once

Yes

iButton

Voltage

External Battery

SMS Once SMS Once

SMS Once

Yes

Charge Alert

Daily Travel Mileage

SMS Report

Call-IN Direct for

voice Listen-in

yes

Yes

Wireless sensor Trigger

Alert(Smoke, PIR, Gas,

Magnetic

SMS

SMS Once SMS Once

SMS Once

20Seconds Sound

Once

Door sensor)

Short-Call

Yes

.3 Remote stop Oil/Power supply for engine (Immobilizer)

)

Remote cut off Oil/Power supply for engine:

By SMS Command: *1234*STOP#

Operation from smart Phone App command

Operation from Server Platform Command

)

Release engine cut-off to allow start

By SMS Command: *1234*K#

Operation from smart Phone App command

Operation from Server Platform Command

)

Automatic Ignition starter lock in armed status

In Armed status, the system will keep Oil/Power supply in locked status. This is to protect burglar ignore alarm

alerts and start vehicle to drive away.

This function is default as Disabled. If the user want to activate this function, can use SMS command sent AS201E

inserted SIMCARD number to switch on and off this feature.

1234*AUTOCUTON#

1234*AUTOCUTOFF#

.4 Power Saving

The system is designed to have different sleep mode when ignition off. In different sleep mode, the power

consumption are different. Details please check <2.3.2 Sleep Mode consumptions and how it works>.

The user can use SMS command to configure device to be in different Sleep mode to save vehicle battery

consumption.Check <2.5.1 Configure by SMS commands >

.5 Shock Alert ,Crash accident alert and Crash accident data logger

AS201E box is with built-in 3D Acceleration sensor (G sensor) on board.

The device use this G sensor created three functions.

)

Shock Alarm

AS201E will detect all X,Y,Z acceleration always, any changes in all X,Y,Z axis will be calculated, every

changes

over 0.1G, system calculated for shocking once, every 5Seconds scan and calculate once.

We use 5seconds average shocking times as shocking sensitivity to generate Shock Alarm alerts in Armed

Status.

SMS commands for adjusting shocking sensitivity:

1234*VS*xxx#

xxx=001-200)

(

=most sensitive

00= Most insensitive.

Switch On/Off Shocking Alarm SMS commands:

1234*H# <Switch On shocking Alarm>

1234*N# <Switch Off Shocking Alarm>

)

Accident Alert for A/B/C Numbers

By configure AS201E installation position and X,Y,Z axils value to setup the accident alert value limit as

trigger conditions. AS201E provides two ways to configure:

Configure By SMS commands

1234*CS*m,x.x,y.y,z.z#

M for the custom direction value (1-6)

x.x corresponding to X axis value (0.0-8.0)

x.y corresponding to Y axis value (0.0-8.0)

x.z corresponding to Z axis value (0.0-8.0)

Note:

Check as following picture which we defined the X,Y,Z direction for the accelerator sensor. And M is the

movement sides serial NO. It can be any one as user self-define. Just make sure it’s the movement facing

side.

Configure by Configurator program:

Any axils exceed the configured G value, it will trigger the accident alert.

)

Crash accident data logger for before/After 15Seconds in accident time

AS201E will record recent 3Times Accident G varies truth in memory. And allow user to load out via USB

connection through the Configurator program. And recover back all details information via chart.

Check as following picture:

A. By click “Read Accident Log” button to download AS201E recorded Accident Data,

This process will take several minutes before download finish.

B. Display accident data log via chart with time frame and G value varies:

.6 Voice Listen-in

Call Center Number D and SMS center Service No. G call AS201E, the system will put through to Voice Listen-in

mode directly.

AS201E also provide other two methods to start Voice listen-in Operation:

)

By SMS command with correct password to AS201E box to get re-call back

1234*VMxxxxxxxx# <xxxxxxx is call back phone No. for system>

)

Via GPS tracking platform Voice Listen-in Command to start Re-call back for voice listen-in

For how to operate this please check 7-24tracking Platform User’s guide for reference.

.7 Switch ON/Off Siren

By SMS command, user can switch ON/Off siren remotely.

1234*SIRENON#

1234*SIRENOFF#

.8 iButton Probe Kit

AS201E support 1-Wire iButton Key/Probe Kit for driver Identification, via the AS201E Configurator to set

iButton Key , as following the picture :

By SMS command, user can activate or close this feature:

1234*AUTHENIDON#

1234*AUTHENIDOFF#

.9 Temperature detection

AS201E support temperature detection, provides two ways to configure:

-By GPRS command from our tracking platform

By SMS command :

1234*TMP:1, -10, +35#

1234*TMP:0#

< Activate temperature detection, temperature range is -50℃~ +150℃>

1234*TMP#

.10 Ultrasonic fuel senor configure

AS201E support Ultrasonic fuel senor.

How to install the Ultrasonic fuel senor please refer the <UF-141 Ultrasonic Fuel Sensor Installation Guide>

provides two ways to configure:

Set parameters by AS201E Configurator :

How to activate the fuel senor on platform please refer the <UF-141 Ultrasonic Fuel Sensor Installation Guide>

Set parameters by SMS commands :

1234*OILPARA:XXX1,YYY1;XXX2,YYY2;XXX3,YYY3;XXX4,YYY4;XXX5,YYY5;XXX6,YYY6;

XXX7,YYY7;XXX8,YYY8;XXX9,YYY9;XX10,YY10#

XXX is liters >

YYY is highly >

For example :

*1234*OILPARA:0,0;80,80;160,160#

Query the fuel parameters:

1234*OILPARA#

Response : OIL Parameters:0,0;80,80;160,160#

.11 Asset maintain notice

AS201E support send the asset maintain notice via SMS message,by send the SMS command to set the parameters

to to activate this feature.

SMS command:

1234*MAINTENANCE:X,Y#

X= mileage, maximum 10000Km

Y= engine running time, maximum 5000 hours

If both X and Y are 0,means this feature deactivated.

For example :

1234*MAINTENANCE:1000,0#

.12 Battery Low Alert

When AS201E detected external battery output is with lower than 11.5V (This voltage can be configured by the

AS201E Configurator, defaults to 11.5V), system will generate Battery low alerts to A/B/C Numbers. And stop

draw vehicle battery, will switch to user internal battery for work.

After internal battery is going to use out again, system will generate another alert to A/B/C, and system will go to

deep sleep to avoid killing vehicle battery dead. But keep all alarm detection alive for protection.

.13 Recovery Factory Default

By click the button

in the AS201E Configurator to be factory default setting.

By sending SMS command *1234*V# recover device to be factory default setting.

Be careful to use this command, because it will request you to re-configure the device again for working properly.

.14 Remote Reboot

By sending SMS command *1234*Z# reboot AS201E remotely.

This is to solve problem if any operation fail and do quick problem shooting.

.15 Locate in parking Lot

AS201E provides two methods for user to quick locate where the vehicle is by Siren sound and light flashing.

. By press Remote controller Siren button to make sound

. By send SMS command *1234*L# to get AS201E driving siren sound and light flashing.

.16 GPS Tracking features

.16.1 Real Time Tracking

)

Track by SMS command

1234*FIND#

1234*GPS#

)

Track by our GPS tracking platform

First ,you need to configure IP/Port/APN to the device .

Second , get a tracking account name and password.( Please contact your seller to got it)

Table of contents

Popular Security System manuals by other brands

Hafele

Hafele WTC 200 Mounting instructions

Radio Shack

Radio Shack 49-2534 owner's manual

KJB

KJB C1190 user manual

Velleman

Velleman CCTVPROM14 Quick installation guide

Avitech

Avitech Rainier-4a user manual

Vestil

Vestil BOL-G-24-3.5 Use and maintenance instructions

Cobra

Cobra 4693 QUICK REFERENCE USER MANUAL

ievo

ievo ultimate user guide

DARLEY

DARLEY SCREENGUARD Technical manual

Tunstall

Tunstall Belle user guide

Alderon Industries

Alderon Industries Versa'larm VA01A Operation, maintenance and installation manual

G4S

G4S SmartAlarm P5 user manual

Evolveo

Evolveo Alarmex Pro ACSALMBTZ manual

Samsung

Samsung SSA-S2100 Specifications

DEXAPLAN

DEXAPLAN TM 605 Operating and safety instructions

Extel

Extel link quick start guide

Raco

Raco AlarmAgent.com AA-102DC installation manual

Hornet

Hornet 732T installation guide

ANBTEK AS201E User manual

Popular Security System manuals by other brands
