Anchor MiniVox User manual

Owner’s Manual
MiniVox
ANCHOR Audio, Inc. [phone]
100-0074-000 / Revision A, 06/97
Having trouble with the sound system?
Condition Possible Solution
No sound (LED not lit): • turn POWER switch ON
• charge batteries
No sound (LED flashes): • turn microphone switch ON
• make sure all cables are completely plugged in
No sound when using CD input: • check for output from source
• make sure all cables are completely plugged in
Distorted sound: • lower system volume control
• replace or recharge batteries
Shortened battery life: • replace worn NiCad batteries
• ‘Cycle’ NiCad batteries (see page 6)
• reduce volume to eliminate distortion
Having trouble with the wireless system? (model PB-25W only)
Condition Possible Solution
No sound (LED solid): • turn up volume level
• plug microphone into bodypack transmitter.
No sound (LED flashes): • make sure transmitter power switch is ON
• set body pack transmitter switch to F1 or F2
• set receiver and transmitter to same channel
Frequent transmitter dropouts: • replace mic/transmitter battery
• move mic/transmitter closer to MiniVox
• make sure collar or headband mic cable is fully
plugged into transmitter.
Troubleshooting Guide

2
Problems?
Consult the
troubleshooting
section on the
back page of
this manual.
Blank Page
11
Quick Use Guide
Thank you for choosing an Anchor Audio portable sound system. Our products
incorporate state-of-the-art design and the finest quality of materials and
workmanship. We’re proud of our products and appreciate the confidence which
you have shown by selecting an Anchor system.
I hope you’ll take a few of minutes to review this manual. We’ve incorporated
several unique features into our products, and your knowledge of how to use
them will enhance the performance and your enjoyment of the system.
David Jacobs, President on behalf of all Anchor employees
MiniVox is a battery-operated handheld P.A. system that’s
easy to set-up and operate. Before using the MiniVox, you’ll
need to install the batteries as described on page 4.
If your unit is equipped with an RC-25 rechargeable battery kit,
you must charge the batteries completely before use (see page 6).
Here’s how easy it is to use:
1. Set the MiniVox in front of your audience.
2. Plug a microphone into the INPUT jack.
3. Turn the MiniVox power/volume control ON (the red
LED should begin flashing). Then turn the microphone
switch ON. Adjust the volume control until desired
volume is reached.
To operate the wireless mic system on model PB-25W see
“Wireless Operation” on pages 7 and 8. For complete usage
instructions, see the “Operation” section beginning on page 5
(see page 6 for instructions on using the signal alert option.)
To avoid
feedback, do not
position the
microphone in
front of the
speaker.

Specifications
10
Getting Started
Inspection and inventory of your system
Check unit carefully for damage which may have occurred
during transit. Each Anchor product is carefully inspected at
the factory and packed in a special carton for safe transport.
Inventory
• MiniVox sound system
• MIC-25 handheld microphone (not included with
models PB-25L or PB-25W)
• shoulder strap
• battery-holder tubes
• warranty and registration card
• wireless mic/transmitter (model PB-25W only)
All damage claims must be made with the freight carrier.
Notify the freight carrier immediately if you observe any
damage to the shipping carton or product. Repack the unit
in the carton and await inspection by the carrier’s claim agent.
Notify your dealer of the pending freight claim.
Returning your unit for service or repairs
Should your unit require service, contact your dealer or our
Customer Service Department at [phone] to obtain a
Return Authorization (RA) number. All shipments to Anchor
must include an RA number and must be shipped prepaid.
C.O.D. shipments will be refused and returned at your cost.
Warranty registration
Please fill out the warranty card and return it with a copy of
your invoice to Anchor’s Customer Service Department. This
will activate your limited two year warranty.
Save the
shipping carton
and packing
materials. They
were specially
designed to
ship your unit
safely.
3
MiniVox
Rated power output: 15 watts
Max SPL @ rated power: 108 dB @ 1 meter
Frequency response: 100 Hz – 12 kHz
Speaker type: 5 inch cone
CD ⁄ TAPE Input: line level, 3.5mm
Mic Input (phantom powered): Lo-Z, phantom powered, 3.5mm jack
Mic Input: Lo-Z, 1/4"-phone
Wireless Receiver: FM Superheterodyne
Sensitivity: 2µV at S/N 40 dB
Frequencies: pair #1: 169.445 and 170.245 mHz
pair #2: 171.105 and 171.845 mHz
Battery type: nine C-size, alkaline
Dimensions (HWD): 8 x 6.5 x 9.5", 20 x 17.5 x 24 cm
Weight: 5.2 lbs, 2.4 Kg
RC-25 Recharge Kit (optional)
Battery type: nine C-size, 1.5AH rechargeable NiCad
Charger: AC-25
AC-25 input: 120 VAC, 60Hz, 10 watts max
AC-25/220 input (for export): 220 VAC, 50Hz, 10 watts max
AC-25 output: DC taper charge
Shipping weight: 2.1 lbs, 1.0 Kg
Specifications subject to change without notice.

Installing the batteries
1. Turn the slotted fastener located on bottom of the
MiniVox 1/4-turn counter clockwise (use a coin or
flat screwdriver) and remove the battery cover.
2. Insert three size C batteries (alkaline-type work best)
into each cardboard battery-holder as shown.
3. Position the three battery tubes into the battery com-
partment with negative (flat) end contacting the
springs (as shown on compartment label).
4. Fit the tab of the battery cover into the slot at the back
of the battery compartment, close cover, then lock
fastener by turning 1/4-turn clockwise.
Accessories
9
Battery Installation
4
+-
For extended
service life and
greater output,
use alkaline
batteries.
RC-25 Rechargeable Battery Kit
Includes (9) rechargeable batteries and AC adapter/charger.
CC-25 Carrying Bag
Vinyl carrying bag with storage pocket for microphone.
CM-1000 Collar Microphone
Around-the-neck collar microphone. Plugs into the phantom-
powered mic input or the WL-1000 wireless transmitter
HBM-35 Headband Microphone
Plugs into the phantom-powered mic input or the WL-1000
wireless transmitter
MIC-25 Handheld Microphone
Handheld microphone with 6' coil cord. Unidirectional
pick-up pattern.
MIC-90P Handheld Microphone
Anchor’s dynamic, balanced, low impedance microphone
with a unidirectional pick-up pattern. It has a on/off switch
and comes with a 20' cable and mic clip.
WH-1000 Wireless Handheld Microphone
Handheld microphone with built-in transmitter for use with
Wireless MiniVox. Unidirectional pick-up pattern.

OFF
Solid = Transmitter On
CHARGER
MICROPHONE
(PHANTOM POWER)
MIC
model PB-25
CD⁄TAPE
(LINE LEVEL)
Headphones
Headphones
CD⁄TAPE
(LINE LEVEL)
Headphone output
jack of audio source CD ⁄ TAPE Input
jack of MiniVox
Shielded
patch
cable
model PB-25
OFF
CD⁄TAPE
(LINE LEVEL)
CHARGER
MICROPHONE
(PHANTOM POWER)
MIC
CD / TAPE Input
(mini jack, 3.5mm)
Microphone Input
with phantom power
(mini jack, 3.5mm)
AC-25 Charger Input
(sub-mini, 2.5mm)
MiniVox Control Panel
Power Switch and
Volume Control
Power Indicator
Lo-Z Mic Input
(1/4" phone jack)
CD⁄TAPE Input
Use the CD⁄TAPE input to play pre-recorded material through the
MiniVox. The volume control of the MiniVox controls both the
audio source and microphone when used simultaneously.
• Connect a mini-to-mini patch cable (3.5mm plugs) to
the ‘Headphone’ or ‘Line’ output of your audio
source and the CD ⁄ TAPE jack of the MiniVox.
• Turn the MiniVox ON and set the volume control to
about the 2 o’clock position. Then adjust the volume
control of the audio source to desired level.
Wireless Operation (model PB-25W only)
8
Operation
5
Replacing the transmitter battery
Note: The transmitter power switch must be in the OFF position!
HANDHELD: Unscrew the battery compartment cover on
the lower end of microphone. Install a fresh ‘AA’ alkaline
battery and replace the cover.
BODY-PACK: Open battery cover
on the side of the transmitter box
and insert a fresh 9 Volt alkaline
battery. Close the cover.
Operating the wireless microphone system
1. Set the MiniVox down and direct toward audience.
(Position the MiniVox in front of you while using the
wireless microphone to avoid feedback.)
2. Turn the MiniVox power/volume control ON about
halfway (red LED should begin flashing).
3. Turn the wireless microphone ON as follows:
Handheld: Set the switch to the top ON position and
begin speaking. The middle STANDBY position
functions as a mute switch.
CollarMic, Headband or Lapel Mic: Plug mic cable
into transmitter. Set power/frequency switch to the
frequency of the receiver (either F1 or F2) and begin
speaking.
NOTE: When the mic/transmitter is turned ON and
the transmitter frequency matches the receiver, the RF
Signal Indicator on the MiniVox should light steadily
(indicating signal is being received). If it does not light
steadily, review the instructions above and the
troubleshooting section on the back page.
4. Adjust volume control on MiniVox.
Caution: Harmful feedback may occur when walking in
front of a sound system or speaker with a wireless
microphone. Always point mic away from speakers.
Observe proper
polarity when
installing the
battery!

Wireless Operation (model PB-25W only)
7
Operation
6
Using the RC-25 rechargeable battery kit
For applications where the MiniVox is used frequently, the
RC-25 rechargeable battery kit is available. The kit includes
rechargeable batteries and an AC charging adapter. About
8-15 hours of operation can be expected per charge.
Using the RC-25 Recharge Kit
1. Install batteries as described on page 4.
2. Insert small plug on charger into CHARGER input on
the MiniVox and plug AC adapter into an outlet.
3. Note! Charge batteries for 24 hours before using
MiniVox for the first time. Typical charging time for
full recovery is 12-18 hours.
CAUTION: NEVER recharge other types of batteries.
Doing so can result in battery explosion. Use only
rechargeable Nickel Cadmium (NiCad) batteries.
4. Cycling the batteries: To extend battery life, we
recommend you fully charge the batteries once each
month during periods of infrequent use. Always
recharge batteries before storing.
Optional Signal Alert: Model PB-25SA
The Signal Alert button enables the MiniVox to produce a
siren-like tone. The momentary pushbutton switch on the
handle actuates the alert (the volume of the alert tone is not
affected by the MiniVox volume control).
Phantom Powered
Microphone Input
Use the phantom powered mic input (3.5mm jack) with electret
condenser microphones that require phantom power; such as
Anchor’s CM-1000 and HBM-35.
MICROPHONE
(PHANTOM POWER)
Recharge
batteries before
storing.
Do not charge
batteries for
more than 24
hours!
Setting up the wireless system
Set the frequency of the receiver.
The wireless receiver is mounted inside the MiniVox. and is
available with two different frequency pairs (this allows for
operation of up to 4 units simultaneously). A label on top of
the MiniVox indicates which 2 frequencies your system is
equipped with, and the desired frequency is selected via the
frequency switch.
1. Set the frequency of the receiver to either of the two
channels, F1 or F2.
If you experience ongoing interference problems with your
wireless system, the selected frequency may be incompatible
with other RF systems in your area. Try the other channel.
Set the frequency of the transmitter.
During use, make sure the transmitter you are using is set to
the same frequency as the receiver as set above.
HANDHELD: Set the frequency switch inside the
battery compartment to match the channel of the
receiver. Replace the cover—but don’t overtighten!
BODY-PACK: The power/frequency switch on the
transmitter determines the frequency. During use, set
the switch to match the frequency of the receiver.
169.445
170.245
Frequency Switch
frequency switch
label indicates frequency pair
F1 (MHz) F2 (MHz)
PB-25W-1: 169.445 170.245
PB-25W-2: 171.105 171.845
