Go Getter Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
MADE IN USA
SIX YEAR WARRANTY
A Message from the President
Congratulations on purchasing an Anchor Audio sound system, the choice
of thousands of satisfied customers including the White House, prestigious
universities, school districts nationwide, police and fire departments,
and all branches of the U.S. Military. Our products are made of the finest
materials and built with pride in the U.S.
We’ve incorporated the latest technology into your sound system yet
kept it simple to use. Just take a few minutes to review this manual to
ensure the maximum enjoyment of your Anchor system. Or, you can view
a demonstration video complete with a trouble shooting section at www.
anchoraudio.com.
Feel free to call our friendly customer support staff at 1-800-ANCHOR1
with any questions. We love to hear from our customers.
Janet Jacobs – President
on behalf of all Anchor Employees
CONTENTS
GETTING STARTED...................................................................................................................1
BASIC SYSTEM OPERATION / SPEAKER STAND SETUP / BACK PANEL ....................................... 2
CONNECTING MULTIPLE SOUND SYSTEMS / CONTROLLING FEEDBACK......................................3
USING THE BUILT-IN MP3/CD PLAYER ...................................................................................... 4
OPERATING THE BUILT-IN UHF WIRELESS RECEIVER ................................................................. 5
OPERATING THE WIRELESS MICROPHONE/TRANSMITTER .........................................................6
CARING FOR YOUR BATTERY ................................................................................................... 7
IMPORTANT SAFETY INSTRUCTIONS ........................................................................................ 8
HAVING TROUBLE WITH YOUR SOUND SYSTEM? / TECHNICAL SPECS ....................................... 9
GETTING STARTED
Please check your new unit carefully for any
damage which may have occurred during shipment.
Each Anchor product is carefully inspected at the
factory and packed in specially designed boxes for
safe transport.
Notify the freight carrier immediately of any damage
to the shipping box or product. Repack the unit
in the original box and wait for inspection by the
carrier’s claim agent. Notify your dealer of the
pending freight claim.
NOTE: All damage claims must be made with freight carrier!
RETURNING SYSTEMS FOR SERVICE
OR REPAIR
For service or repair, please contact the dealer
you purchased your system from or visit
www.AnchorAudio.com to fill out an
RA (Return Authorization) form. If your system is
still under warranty, you will receive an RA Number
with instructions to follow. All shipments to Anchor
Audio must include an RA number and must be
shipped prepaid. C.O.D. shipments and shipments
without an RA number will be refused and returned
at your expense.
IMPORTANT: Save the shipping box & packing materials,
they were specially designed to ship your unit!
1
The Go Getter sound system comes with a six year warranty,
CD/MP3 come with a two year warranty, and all Anchor Audio
batteries and wireless come with a two year warranty.

MADE IN USA
SIX YEAR WARRANTY
Go Getter Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
MIC 2
VOLUME
MIC 1
VOLUME
TREBLE
ON
WARNING: TOREDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS EQUIPMENTTO RAIN OR MOISTURE.
POWER JACK
POWER/LOW BATTERY
LINE OUT
LINE IN
LINE IN
MIC 1 MIC 2
LINE IN
VOLUME
SPEAKER OUT
VOLUME
VOLUME
BASS
POWER
Go Getter
www.anchoraudio.com
2
BACK PANEL OF GG-U2 (AC/DC)
BASIC SYSTEM OPERATION
NOTE: Fully Charge Batteries Before First Use!
IMPORTANT: Make all connections with shielded
cables to avoid hum, buzzing or interference.
1. Set all Input Level Controls to minimum
& Tones Controls to flat or the middle
setting before turning your system on
2. Plug a wired microphone into the MIC
1 or MIC 2 jacks and/or plug an audio
source into the LINE-IN jack
3. Switch POWER to ON, the BATTERY LED
will light
4. Slowly increase the Level Control for the
input jacks used to the desired volume
5. Adjust BASS & TREBLE controls to
desired sound quality
WIRELESS RECEIVERS 4
(see page 6)
POWER SWITCH
LINE IN - INPUT JACKS
The 1/8” (3.5 mm) jack
input is used to hook up an
iPod, a portable CD/ MP3/
tape player, laptop com-
puter, or similar external
audio source
The 1/4” unbalanced input
can be used for other
communication devices
including a mixer or daisy
chaining together multiple
Go Getter speakers
SPEAKER OUT -
OUTPUT JACK
Connect the system to a Go
Getter unpowered companion
speaker
CHARGE INDICATOR LIGHT
LINE IN LEVEL CONTROL
BATTERY LEVEL
INDICATOR LIGHT
TONE CONTROLS - BASS/TREBLE
WIRED MIC LEVEL CONTROLS
WIRED MIC INPUTS
LINE OUT - OUTPUT JACK
Balanced 1/4” – provides a combined
output of all active system inputs
Record your presentation or connect to
another powered sound system
RX INDICATOR LIGHTS FOR
WIRELESS RECEIVER 1
A solid red light on one of the
RX Indicator Lights indicates
that the sound system is getting
good reception with the wireless
microphone
A solid red light on both RX
Indicator Lights indicates that
the sound system is a optimum
reception with the wireless
microphone
WIRELESS MICROPHONE 1
LEVEL CONTROL
Adjust knob to control
wireless microphone levels
WIRELESS MICROPHONE 2
LEVEL CONTROL
SPEAKER STAND SETUP
1. Loosen the Lower Collar Knob
2. Separate the stand legs until the leg support Cross
Braces are parallel to the floor
3. Tighten the Lower Collar Knob
4. Loosen the Upper Collar Knob and extend the
center pole
5. Adjust height and retighten the Upper Collar Knob
6. Place your Anchor sound system on the stand
SPEAKER STAND ADAPTER
The 1.5” diameter Speaker Stand
Adapter lets you mount the Go
Getter on a speaker stand.
LOWER
COLLAR
KNOB
UPPER
COLLAR
KNOB
CROSS BRACES
1. Slide Speaker Stand Adapter
into slot on Go Getter bottom
2. Tighten screw to secure
adapter
3. Place unit on stand carefully
4. Tighten screw on Adapter
collar securing Go Getter on
stand
RX INDICATOR LIGHTS FOR
WIRELESS RECEIVER 2

MADE IN USA
SIX YEAR WARRANTY
Go Getter Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
3
CONTROLLING FEEDBACK
Feedback, a howling noise or shrill sound, is self-generated by the sound system. It’s caused by
a microphone picking up the sound coming from the speaker and then re-amplifying it. Once a
feedback loop starts it continues until the system is adjusted.
FEEDBACK CAUSES
• Microphone too close, pointing towards
or in front of speaker
• Volume setting is too loud for room
• Sound reflecting off hard surfaces
AVOIDING & ELIMINATING FEEDBACK
• Point microphone in a different direction
• Keep microphone away from the speaker
• Place speaker in FRONT of the microphone
• Reduce the sound system volume levels
CAUTION: Feedback can damage your equipment & may be hazardous to hearing.
CORRECT SYSTEM PLACEMENT WRONG SYSTEM PLACEMENT
CONNECTING TWO OR MORE GO GETTER SOUND SYSTEMS
USING A Go Getter UNPOWERED COMPANION SPEAKER (GG-01)
Connect one end of a speaker cable (SC-50NL) to the SPEAKER OUT jack on the back
of a powered Go Getter sound system. Connect the other end to the jack labeled IN
on the back of a Go Getter unpowered companion speaker.
NOTE: AC power is not required for an unpowered companion speaker.
USING 2 POWERED Go Getter SOUND SYSTEMS
This method uses the line-output feature of your Go Getter sound system. Connect
a speaker cable (1/4” phone) from the LINE OUT jack on the first powered Go Getter
to the LINE IN jack on the second powered Go Getter. Set the volume of the second
Go Getter to maximum so that full volume control will be at the first or primary sound
system.
NOTE: The line-output feature can also be used to send the signal to a sound
system in a different room or a separate recording device.
SETTING UP YOUR GO GETTER SOUND SYSTEM
We recommend placing your sound system between the audience and the pre-
senter, facing the audience and raised above their heads using a speaker stand
or table. This benefits listeners in the rear of the crowd, minimizes the risk of
overpowering those in the front and helps prevent feedback by keeping micro-
phone users behind the sound system.
SINGLE SYSTEM PLACEMENT
Place your unit along the least trafficked aisle pointing towards the center
of the audience.
MULTIPLE SYSTEM PLACEMENT
Place units along aisles pointing just off the audience center line, over the
crowds head. With the sound system placed properly it should provide
sufficient coverage.

MADE IN USA
SIX YEAR WARRANTY
Go Getter Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
USING THE BUILT-IN MP3/CD PLAYER PLAYER
POWER: Press once for ON or OFF
CD/USB/SD: Press to change the mode of operation
REV: Press to select the previous track. Press and hold to reverse track
F.WD: Press to select the next track. Press and hold to fast forward track
PLAY/PAUSE: Press once for PLAY or PAUSE
MUTE: Press once for mute ON and again to mute OFF
STOP/EJECT: Press once to stop playing music. Press twice to stop and eject disk
FOLDER : Select next folder (MP3 format only)
FOLDER : Select previous folder (MP3 format only)
SHU./ENTER: Press once to play tracks randomly. “SHUFFLE” will show on the LCD. When used with the PROGRAM function, it
acts as the confirmation key.
PROGRAM: Press to set the programming mode. Press once so the LCD shows “PROGRAM”. To navigate the different folders,
press the FOLDER buttons (MP3 format only), and to navigate the songs press the SKIP buttons. Press SHU./ENTER
to select the desired songs. When finished selecting, press PLAY/PAUSE. The LCD will show “MEMORY” and will
begin to play. To cancel the PROGRAM mode select PROGRAM again.
REPEAT: Press until the desired repeat playing function is displayed on the LCD. REPEAT 1 will repeat the present song
REPEAT ALL will repeat all songs. REPEAT FOLDER will repeat all the songs in the folder (MP3 format only). No LCD
display means the repeat playing function has been canceled.
REMOTE CONTROL
*Remote follows same functions
as MP3/CD player
Your MP3/CD player supports WMA and MP3 files, as well as CD, CD-R, CD-RW, and MP3 disks. Input slots for play are CD, USB,
SD card slot, and AUX port for other music player devices.
Turn on with the POWER button and then insert the memory card, USB or CD. Push CD/SD/USB button until your device is displayed.
The auxiliary port becomes active when the 3.5mm cable is inserted.
*The Go Getter built-in MP3/CD player comes with remote.
The LCD functions as used:
CDPOWER REPEAT
ENTER
R
SD/USB
SHUF MUTE
AUX IN
FOLDER
SD CARD
REW F.WD EJECT
STOPPROG.SKIP
PLAY
PAUSE
EJECT
PROG
1 2 3
4 5 6
7 8
0
9
RAN
REP
FOLDER
CD
USB/SD
4

MADE IN USA
SIX YEAR WARRANTY
Go Getter Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
5
CHANNEL SELECTION - BUILT-IN RECEIVER
Select a channel, set the built-in receiver & microphone transmitter
to that channel before using your wireless system.
1. Choose any available wireless channel from 1 thru 16
(see page 6 for transmitter instructions)
2. Set the Wireless Channel Selection Knob to the channel you
choose in step 1
WIRELESS 2
VOLUME CONTROL
WIRELESS 1 CHANNEL
SELECTION
WIRELESS 1 RX
INDICATOR LIGHTS
WIRELESS 2 RX
INDICATOR LIGHTS
WIRELESS 1
VOLUME CONTROL
WIRELESS 2 CHANNEL
SELECTION
DIVERSITY WIRELESS BY ANCHOR AUDIO
Anchor Audio UHF wireless is a 16 channel, diversity wireless system that receives signals with two independent antennae. With diversity
wireless the receiver processes the stronger signal, effectively minimizing dropouts and interference from other transmitting sources. The
antennae are mounted internally so there are no obstructions or risk of damage.
NOTE: Ongoing wireless interference? The frequency you selected may be in use by other systems in the area!
Change channels until you find a clear frequency!
If you have two wireless receivers repeat above for the second receiver.
Remember, each receiver/transmitter pair must be set to different
channels to avoid interference.
CERTIFICATION
This system conforms to part 74 and part 15 of the FCC rules, contact the FCC office for filling forms.
Frequency Range: 682 MHz - 698 MHz
WH-6000EU and WB-6000EU transmitters meet the essential requirements of the European R&TTE Directive 99/5/EC and are
eligible to carry the CE marking. CE 0336 !
European Frequency Range: 863.125 MHz - 864.875 MHz

MADE IN USA
SIX YEAR WARRANTY
Go Getter Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
NOTE: Transmitter power must be OFF when changing batteries! 6
USING YOUR WIRELESS MICROPHONES
After you have set the transmitter channel (see above) you are ready to use your wireless microphone:
1. Body-pack transmitter users must insert
the mic plug into the transmitter jack
marked MIC
2. Push the transmitter power button for two sec-
onds until ON (The red LED will stay on when
the mic is turned on. If the red LED flashes, the
battery is low)
3. Turn the Go Getter power switch to ON
4. The RX indicators will light
(only one indicator
will light at a time) when the wireless signal is
being transmitted and received
OPERATING THE WIRELESS MICROPHONE/TRANSMITTER
REPLACE BATTERY - HANDHELD TRANSMITTER
1. Unscrew battery cover on bottom of microphone
2. Replace old batteries with two fresh size ‘AA’
alkaline batteries
3. Replace battery cover and tighten firmly
CAUTION: Harmful feedback may occur when walking in front of a sound system or speaker with a wireless microphone. Always point microphone away from speakers!
CHANNEL SELECTION - HANDHELD TRANSMITTER
1. Unscrew battery cover on bottom of microphone
2. Set the CHANNEL SELECTOR dial to match the channel setting
of your receiver
3. Replace battery cover and tighten firmly
NOTE: When using dual wireless, each microphone must be set to a different channel!
CHANNEL SELECTION - BODY-PACK TRANSMITTER
1. The channel selection dial is located on the side of the transmitter
2. Set the CHANNEL selection dial to match the channel setting of the receiver
REPLACE BATTERY - BODY-PACK TRANSMITTER
1. Slide open battery cover on front of transmitter
2. Replace old batteries with two fresh size ‘AA’
alkaline batteries
3. Replace battery cover by sliding firmly into place

MADE IN USA
SIX YEAR WARRANTY
Go Getter Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
7
Waste electrical and electronic products must not be disposed
of with household waste. Please recycle where facilities
exist. Check with your Local Authority or Retailer for recycling
advice.
CARING FOR YOUR BUILT-IN BATTERY
An automatic charging system is built-in to your Go Getter Sound
System. It is designed to properly charge and maintain the
systems built-in battery.
CHARGING THE BATTERY
1. The Battery Level Indicator Green Light will dim and
eventually turn off when battery is low
2. To charge the battery, plug the AC power cord into the Go
Getter
3. Plug the other end of the cord into AC outlet
4. The Charge Indicator Light will show solid red light when
charging and turn off when charging is complete
To preserve the life of your battery it is recommended that it be
fully charged as soon as possible after every use regardless of the
length of operation. It takes approximately 8 hours to charge the
Go Getter battery.
NOTE: System Can Be Used While Battery Charges!
MIC 2
VOLUME
MIC 1
VOLUME
TREBLE
ON
WARNING: TO REDUCETHE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE.
POWER JACK
POWER/LOW BATTERY
LINE OUT
LINE IN
LINE IN
MIC 1 MIC 2
LINE IN
VOLUME
SPEAKER OUT
VOLUME
VOLUME
BASS
POWER
Go Getter
www.anchoraudio.com
BATTERY INDICATOR LED
GREEN LED
CHARGE INDICATOR LED
RED LED
IMPORTANT: Always Store Your System with Battery Fully Charged!
SYSTEM STORAGE & BATTERIES
Fully charge battery before storage. For extended periods of storage either leave system plugged into an
AC outlet or charge the system at least once each month for a minimum of 24 hours
BATTERY SERVICE TIME
Fully charged battery will yield approximately 6 – 8 hours of continuous music at medium volume level
(2 – 4 hours at full volume or longer for speech only) . However, service times vary depending on control
settings and use of accessories.
To replace your battery, you will need a Phillips screwdriver and follow these procedures:
1. Be sure the power switch is in the OFF position
2. Remove the four screws on the battery cover panel and remove the panel
3. Gently slide the battery out of the battery compartment and unclip the battery connection cables
4. Remove the old battery
5. Connect the new battery’s connection cables and gently slide the new battery into the battery
compartment
6. Replace the battery cover panel and the four screws
Battery Replacement
The battery may need to be replaced every 2 – 3 years depending on usage over time. Call Anchor
Audio at 800.262.4671 to order a new battery.

MADE IN USA
SIX YEAR WARRANTY
Go Getter Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
8
Important Safety Instructions
1) Read Instructions – All the safety and operation instructions should be read before the
product is operated.
2) Retain Instructions – The safety and operating instructions should be retained for future
reference.
3) Heed Warnings- All warnings on the product and in the operating instructions should be
adhered to.
4) Follow Instructions – All operating and use instructions should be followed.
5) Cleaning – Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
Exception: A product that is meant for uninterrupted service and that for some specific
reason, such as the possibility of the loss of an authorization code for the CATV converter,
is not intended to be unplugged by the user for cleaning or any other purpose, may
exclude the reference to unplugging the product in the cleaning description otherwise in
above 5).
6) Attachments – Do not use attachments not recommended by the product manufacturer
as they may cause hazards.
7) Water and Moisture – Do not use this product near water – for example, near a bath tub,
wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool;
and the like.
8) Accessories – Do not place this product on an unstable cart, stand, tripod, bracket, or
table. The product may fall, causing serious injury to a child or adult, and serious damage
to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting accessory recommended by the
manufacturer.
9) A product and cart combination should be moved with care. Quick stop, excessive force,
and uneven surfaces may cause the product and cart combination to overturn.
10) Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure
reliable operation of the product and to protect it from overheating, and these openings
must not be blocked or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This product should not be placed in
a build-in installation such as a bookcase or rack unless proper ventilation is provided or
the manufacturer’s instructions have been adhered to.
11) Power Sources – This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the operating instructions.
12) Grounding or Polarization – This product may be equipped with a polarized alternating-
current line plug (a plug having one blade wider than the other). This plug will fit into
the power outlet only one way. This is a safety feature. IF you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact
your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the
polarized plug.
13) Power-Cord Protection – Power-supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against them, paying particular
attention to cords at plugs, convenience receptacles, and the point where they exit from
the product.
14) Protective Attachment Plug – The product is equipped with an attachment plug having
overload protection. This is a safety feature. See Instruction Manual for replacement or
resetting of protective device. If replacement of the plug is required, be sure the service
technician has used a replacement plug specified by the manufacturer that has the same
overload protection as the original plug.
15) Outdoor Antenna Grounding – If an outside antenna or cable system is connected to
the product, be sure the antenna or cable system is grounded so as to provide some
protection against voltage surges and built-up static charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of
the mast and supporting structure grounding of the lead in wire to an antenna discharge
unit, size of grounding conductors, location of antenna-discharge unit, connection of
grounding electrodes, and requirements for the grounding electrode. See Figure A.
16) Lightning – For added protection this product during lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent damage to the product due to
lightning and power-line surges.
17) Power Lines – An outside antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them
might be fatal.
18) Overloading – Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
19) Object and Liquid Entry – Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that could result
in a fire or electric shock. Never spill liquid of any kind on the product.
20) Servicing – Do not attempt to service this product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
21) Damage Requiring Service – Unplug this product from the wall outlet and refer servicing
to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in damage
and will often require extensive work by a qualified technician to restore the
product to its normal operation.
e. If the product has been dropped or damaged in any way.
f. When the product exhibits a distinct change in performance – this indicates a
need for service.
22) Replacement Parts – When replacement parts are required, be sure the service
technician has used replacement parts specified by the manufacturer or have the same
characteristics as the original part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
23) Safety Check – Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper operation
condition.
24) Wall or Ceiling Mounting – The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
25 Heat – The product should be situated away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that produce heat.

MADE IN USA
SIX YEAR WARRANTY
Go Getter Sound System Owners Manual
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
ANCHOR AUDIO CUSTOMER SERVICE
800.262.4671
FOR ADDITIONAL INFORMATION
visit www.anchoraudio.com
9
GO GETTER TECHNICAL SPECIFICATIONS
Rated Power Output 75 watts AC / DC mode
Max SPL @ Rated Power 109 dB @ 1 meter
Frequency Response 60 Hz – 16 kHz
AC Power Reqs. 90 – 264 VAC, 50/60 Hz
Dimensions
(HWD) 18” x 11” x 9”
(46 x 28 x 23 cm)
Weight (AC/DC) 23 lbs / 10.4 Kg
Inputs
Microphone Lo-Z (1 k Ω) , balanced, XLR
(2 combo jacks) 12 VDC condenser mic phantom
pwr
Hi-Z (10 K Ω) , unbal, 1/4” phone
Auxiliary Hi-Z
(10 k Ω) , unbal, 1/8” & 1/4”
Sensitivity For Rated Output
Line -8.4 dBV (380 mVrms)
Mic (unbal & bal) -49 dBV (3.63 mVrms)
Outputs
Line (post fader) Lo-Z, buffered, 1/4” balanced
Speaker 4-pole Neutrik Speakon® jack
(Specifications Subject to Change Without Notice)
HAVING TROUBLE WITH YOUR SOUND SYSTEM?
CONDITION POSSIBLE SOLUTION
No Sound (power LED off) • turn POWER switch ON
• charge battery or plug in AC cord
• safely shut down if unit overheats, turn volume lower &
turn speaker ON
No Sound
(power LED on) • check for output from source
• make sure all cables are completely plugged in
• turn up volume control of input used
• remove plug from speaker output if not using external
speaker output
Shortened Battery Life • charge battery fully; if battery life continues to deteriorate,
contact Anchor Audio customer service: 800.262.4671
HAVING TROUBLE WITH YOUR WIRELESS SYSTEM? (Wireless Models Only)
CONDITION POSSIBLE SOLUTION
No Sound (RX Indicator: ON) • turn up WIRELESS volume control
• make sure mic is plugged into body pack transmitter
No Sound
(RX Indicator: OFF) • push mic power button
• turn Go Getter POWER switch on
• make sure transmitter power switch is on
• set receiver and transmitter to same channel
• replace battery in transmitter
Excessive Hum or Noise • use shielded cables
• use balanced microphone
Distorted Sound • lower system volume control
• lower input volume control
