Ancona AN-1317 Manual

®
BNL430 and BNL436
Range Hood
28 in. and 36 in.
User Manual
&
Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS
Carefully read the important information
regarding installation, safety and maintenance.
Keep these instructions for future reference.
MAAN1316-01
2019-07-19

— 2 —
INSTALLERS - Start Here
Safety Instructions are on pages 4 and 5 and
Installation Instructions are on pages 8 to 13.
Please perform these steps:
1. Read the safety instructions.
2. Read all instructions in the Installation section of
this manual BEFORE installing the range hood.
3. Remove all packing materials.
4. When nished, make sure to leave these instructions with the consumer.
5. Installation is to be done by a qualied technician only. However, the
ultimate responsibility for proper installation falls to the owner.
6. Product failure due to improper installation is not covered under the Warranty.
CONSUMERS - Start Here
Safety Instructions are on pages 4 and 5 and Operating Instructions are
on pages 14, 15, 16 and 19.
Please perform these steps:
1. Read the safety instructions.
2. Read all instructions in the manual BEFORE operating the range hood.
3. Remove all packing materials.
4. Installation is to be done by a qualied technician only. However, the
ultimate responsibility for proper installation falls to the owner.
5. Product failure due to improper installation is not covered under the Warranty.
Before You Begin
Hardware Note: For safety reasons, range hood mounting screws and anchors will not be
included due to the variation of cabinetry constructions and wall material. Please consult your
installation specialist regarding the optimal type of mounting screws and wall anchors to suit your
home’s construction.

— 3 —
Before You Begin............................................................................................................................... 2
Table of Contents .............................................................................................................................. 3
Important Safety Information ............................................................................................................ 4
Included Parts ................................................................................................................................... 6
Range Hood Dimensions .................................................................................................................. 7
Specications.................................................................................................................................... 7
Installation......................................................................................................................................... 8
Step 1 - Read the Safety Instructions............................................................................................ 8
Step 2 - Unpack Range Hood and Prepare Tools.......................................................................... 8
Step 3 - Plan Desired Location ...................................................................................................... 8
Step 4 - Test Unit Functions .......................................................................................................... 8
Step 5 - Venting Installation Guidelines ......................................................................................... 9
Step 6 - Preparations................................................................................................................... 11
Step 7 - Preparing the Cabinet .................................................................................................... 11
Step 8 - Attaching Damper .......................................................................................................... 11
Step 9 - Installing the Hood ......................................................................................................... 12
Step 10 - Venting ......................................................................................................................... 12
Step 11 - Connect to AC.............................................................................................................. 12
Step 12 - Install Filters ................................................................................................................. 13
Operation ........................................................................................................................................ 14
Lamps (with 3 luminance setting + auto mode) ........................................................................... 14
Auto Night-Light........................................................................................................................... 14
Power ........................................................................................................................................... 14
Fan (with 3 speed setting)............................................................................................................ 14
Timer ............................................................................................................................................ 14
Troubleshooting............................................................................................................................... 15
Maintenance.................................................................................................................................... 16
Replacing the Light Pucks ........................................................................................................... 16
Cleaning Filters ............................................................................................................................ 16
Range Hood Assembly ................................................................................................................... 17
Assembly......................................................................................................................................... 18
Circuit Diagram ............................................................................................................................ 18
Blower Assembly ......................................................................................................................... 18
Electrical Assembly...................................................................................................................... 18
Use and Care Information............................................................................................................... 19
Table of Contents

— 4 —
Important Safety Information
• Theinstallationinthismanualisintended
for qualied installers, service technicians or
persons with a similar qualied background.
Installation must be done by qualied
professionals and in accordance with all
applicable codes and standards, including
re-rated construction.
• The range hood may have very sharp
edges; please wear protective gloves if it is
necessary to remove any parts for installing,
cleaning or servicing.
• Activating any switch to ON position before
completing installation may cause damage or
electric shock.
• Duetothesizeofthisrangehood,atwo-
person installation is recommended.
To reduce the risk of re, electric shock, or
injury to persons:
• Forgeneralventilatinguseonly.DO NOT use
toexhausthazardousorexplosivematerials
and vapours.
• WARNING: To Reduce The Risk Of Fire Or
Electric Shock, Do Not Use This Fan With Any
Solid-State Speed Control Device.
• Thecombustionairowneededforsafe
operation of fuel-burning equipment may be
affected by this unit’s operation. Follow the
heating equipment manufacturer’s guideline
and safety standards such as those published
by the National Fire Protection Association
(NFPA), and the American Society of Heating,
Refrigeration and Air Conditioning Engineers
(ASHRAE), and other local code authorities.
• Beforeservicingorcleaningtheunit,switch
power off at service panel and lock the service
disconnecting means to prevent power from
being switched on accidentally. When the
service disconnecting means cannot be
locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
• Cleangrease-ladensurfacesfrequently.To
optimizeperformanceandtodisperseair
properly, make sure to vent air outside. DO
NOT vent exhaust into spaces between walls,
crawl spaces, ceilings, attics or garages.
• Ducted fans MUST always be vented to
the outdoors.
• ThisunitMUSTbegroundedandusedwith
metal ductwork only.
• Sufcientairisneededforpropercombustion
and exhausting of gases through the duct to
prevent back drafting.
• Whencuttingordrillingintowallorceiling,be
careful not to damage electrical wiring or other
hidden utilities.
• Allelectricalwiringmustbeproperlyinstalled,
insulated and grounded.
• Old ductwork should be cleaned or replaced
if necessary to avoid the possibility of a
grease re.
• Check all joints on ductwork to ensure
proper connection; all joints should be
properly taped using a certied aluminum
or foil tape.
• Usethisunitonlyinthemannerintended
by the manufacturer. If you have questions,
contact the vendor.
READ AND SAVE THESE
INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Read and follow all instructions before using the range hood to prevent the risk of re, electric shock,
personal injury, or damage when using the range hood or appliances with the range hood. This guide
does not cover all possible conditions that may occur. Always contact your service technician or
manufacturer about problems that you do not understand.

— 5 —
Important Safety Information
WARNING: TO REDUCE RISK OF A RANGE
TOP GREASE FIRE:
a) Never leave surface units unattended at high
settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on
low or medium settings.
b) Always turn range hood ON when cooking at
highheatorwhenambéingfood(i.e.Crepes
Suzette,CherriesJubilee,etc.).
c) Clean ventilating fans frequently. Grease should
not be allowed to accumulate on fan or lter.
Before servicing or cleaning unit, unplug and
disconnect the hood from the power supply.
d)Useproperpansize.Alwaysusecookware
appropriateforthesizeofthesurfaceelement.
WARNING: TO REDUCE RISK OF INJURY TO
PERSONS IN THE EVENT OF A RANGE TOP
GREASE FIRE, OBSERVE THE FOLLOWING *
a) S MOTHER FLAMES with a close-tting
lid, cookie sheet, or metal tray, then turn
off the burner. BE CAREFUL TO PREVENT
BURNS.Iftheamesdonotgoout
immediately, EVACUATE AND CALL THE
FIRE DEPARTMENT.
b) NEVER PICK UP A FLAMING PAN - You may
be burned.
c) DO NOT USE WATER, including wet dishcloths
or towels - a violent steam explosion will result.
d) Use an extinguisher ONLY if:
1) You know you have a Class A, B, C
extinguisher, and you already know how to
operate it.
2) The re is small and contained in the area
where it is started.
3) The re department is being called.
4) You can ght the re with your back to an exit.
*Based on “Kitchen Fire Safety Tips”
published by NFPA
To reduce the risk of injury to persons in the
event of a gas leaks:
• Extinguishanyopename.
• DO NOT turn on the lights or any type of appliance.
• Openalldoorsandwindowstodispersethe
gas. If you still smell gas, call the gas company
and re department.
Your safety and the safety of others is very
important. We have provided many important
safety messages in this manual and on your
appliance. Always read and obey all safety
messages. All safety messages outline any
potentialhazards,howtoreducethechanceof
injury, and possible risks if the instructions are not
followed.
READ AND SAVE THESE
INSTRUCTIONS

— 6 —
Included Parts
2 Filters (28 in.)
3 Filters (36 in.)
Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to
the variation of cabinetry constructions and wall material. Please consult your installation specialist regarding
the optimal type of mounting screws and wall anchors to suit your home’s construction.
Range Hood
Damper 4 + 1 pieces mounting
screws for vent/damper

— 7 —
Range Hood Dimensions
Specications
Body Design Stainless Steel
Power Rating 120V/60Hz(cULusCertied)
Total Input Power 215 W (210 W + 2 x 2.5 W)
Motor Input Power 210 W
Amperage 1.8 A
Speed Control Levels 3 Speeds
Interference Protection Radio Frequency Interference Protected
Motors Single Motor
Control Electronic control panel
Filtration Aluminum Filter
Illumination 2 x 2.5 W LED
VentingSize Top, 6 inches (15.3 cm) Round
10 in.
(25.4 cm)
27.5 in. (70 cm) / 35.4 in. (90 cm)
25.99 in. (66 cm) / 33.8 in. (86 cm)
Ø 5.9 in. (15 cm)
17.7 in. (45 cm) / 25.6 in. (65 cm)
10.2 in. (26 cm)
11.6 in. (29.6 cm)
0.4 in.
(1 cm)

— 8 —
STEP 1
Read the Safety Instructions
• It is very important to read the safety instructions on pages 4 and 5.
IMPORTANT: It is the installer’s responsibility to comply with installation clearances.
STEP 2
Unpack Range Hood and Prepare Tools
• Carefully unpack the range hood and parts. Make sure all parts are included as shown on page 6.
• DO NOT remove the protective lm covering the appliance until the installation is fully completed.
• Consult a qualied and trained installer or check local codes for makeup air requirement, if any.
STEP 3
Plan Desired Location
• Plan a desirable location that ts all requirements in the Safety and Installation sections of this manual. Plan where
and how the ductwork will be installed.
• A straight or short duct run will allow the unit to perform most efciently. Long duct runs, elbows and transitions
will reduce the performance of the unit. Each elbow is equivalent to 5 to 10 feet (1.5 m to 3 m) of straight run.
• If ductwork is already installed: ensure ductwork is free from debris.
STEP 4
Test Unit Functions
• Plug the unit in and test all of the functions before installing.
• Placetherangehoodonaat,stablesurface.Connecttherangehoodtoadesignatedstandardoutlet(120-Volt,60Hz)
and turn on the range hood. Verify all operations of the range hood by referring to Range Hood Operations.
• Turn power On in control panel.
• Check all lights and fan operations.
WARNINGS:
• PleasemakesuretoreadALLsafetyinstructionsonpages4and5.
• Usetwoormorepeopletomoveandinstallrangehood.
• Failuretofollowtheseinstructionscanresultinseriousinjury.
Installation

— 9 —
Installation
STEP 5
Venting Installation Guidelines
• The following steps are for exterior ventilation.
Height and Clearance
IMPORTANT:
• Vent system must terminate to the outside (roof or side wall).
• DONOT terminate the vent system in an attic or other
enclosed area.
• DONOTuse4in.(10.2cm)laundry-typewallcaps.
• Usemetal/aluminumventonly.Arigidmetal/aluminum
vent is recommended.
• DONOTuseaplasticvent.
• Alwayskeeptheductcleantoensureproperairflow.
• Calculatethefollowingfiguresbeforeinstallation:
1. Distance from the floor to the ceiling
2. Distance between the floor and the countertop/stove
3. A distance of 24 in. to 30 in. (61 cm to 76.2 cm) is
recommended between stove top and the bottom of
range hood. 30 in. (76.2 cm) minimum is required for
gas stove tops.
4. Height of hood and duct cover.
For the most efficient and quiet operation:
• Itisrecommendedthattherangehoodbevented
vertically through the roof through 6 in. (15.3 cm) or
bigger round metal/aluminum vent work.
• Thesizeoftheventshouldbeuniform.
• Usenomorethanthree90°elbows.
• Make sure there is a minimum of 24 in. (61 cm) of
straight vent between the elbows if more than one
elbow is used.
• DONOTinstalltwoelbowstogether.
• The length of vent system and number of elbows should be
kept to a minimum to provide efficient performance.
• Theventsystemmusthaveadamper.Ifrooforwall
cap has a damper, you may remove damper flaps from
damper to increase air flow.
• Onlyoneflangeisneededintheairductsystem,either
on top of the motor or outside.
• Use silver tape or duct tape to seal all joints in the
vent system.
• Use caulking to seal exterior wall or roof opening
around the cap.
24 in. (610 mm) Min / 30 in. (762 mm) Max

— 10 —
IMPORTANT:
• A minimum of 6 in. (15.3 cm) round or 3-1/4 x 10 in. (8.3 cm
x 25.4 cm) rectangular duct (purchased separately) must be
used to maintain maximum airflow efficiency.
• Alwaysuserigidtypemetal/aluminumductsifavailableto
maximizeairflowwhenconnectingtoprovidedduct.
• PleaseuseDuctRunCalculationbelowtocompute
total available duct run when using elbows, transitions
and caps.
• ALWAYS,whenpossible,reducethenumberor
transitions and turns. If long duct run is required,
increaseductsizefrom6in.(15.3cm)to7in.(17.7
cm) or 8 in. (20.3 cm). If a reducer is used, install a
long reducer instead of a pancake reducer. Reducing
ductsizewillrestrictairflowanddecreaseairflow,thus
reduceductsizeasfarawayfromopeningaspossible.
• Ifturnsortransitionsarerequired,installasfaraway
from opening and as far apart, between two (2), as
possible.
• Minimummountheightbetweenstovetoptohood
bottom should be no less than 24-inch (61 cm) for
electric cook tops and minimum of 30-inch (76.2 cm)
for gas stove tops and no higher than 30-inch (76.2 cm)
for electric cook tops.
• Itisimportanttoinstallthehoodatthepropermounting
height. Hoods mounted too low could result in heat
damageandfirehazard;whilehoodsmountedtoohigh
may be hard to reach and will lose its performance and
efficiency.
• Ifavailable,alsorefertostovetopmanufacturer’s
height clearance requirements and recommended
hood mounting height above range.
Installation
• This range hood is factory set for venting through the roof or wall.
• Ventworkcanterminateeitherthroughtherooforwall.Toventthroughawall,a90°elbowisneeded.
IMPORTANT:
• NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or
garages. All exhaust must be ducted to the outside.
• Use metal/aluminum duct work only.
• Fasten all connections with sheet metal screws and tape all joints with certied Silver Tape or Duct Tape.
• Use caulking to seal exterior wall or roof opening around the cap.
TOP VENTING ROOF EXHAUSTTOP VENTING WALL EXHAUST
Side wall
cap
Roof cap
Duct Run
Calculation
example:
One roof cap, two
90º elbows, and
one 45º elbow use.
0ft + 9ft + 9ft + 5ft
= 23ft used.
Deduct 23ft from
30ft, 7ft maximum
available for
straight duct run.

— 11 —
Installation
STEP 6
Preparations
NOTE: To avoid damage to your hood, prevent debris from entering the vent opening.
• Determine and mark the centre line on the ceiling or wall where the range hood will be installed.
• Make sure there is proper clearance within the ceiling or wall for exhaust vent.
• Duetotheweightandsizeofthisunit,pleasemakesurethatthesupportsystemorframeworkbeingusedisstableand
secure in the ceiling or wall.
• Put a thick, protective covering over counter top, cooktop or range to protect from damage or dirt.
• Removeanyhazardousobjectsaroundtheareawheninstalling.
CAUTION
If moving the cooking range is necessary to install the hood, turn OFF the power on an electric range at the main
electrical box. SHUT OFF THE GAS BEFORE MOVING A GAS RANGE.
Fig #1
STEP 7
Preparing the cabinet
• Measure and cut an opening at the bottom of the cabinet
to t the motor box of the range hood. (See Fig #1)
• Measure and cut a hole in the top of cabinet to t the duct
tube. (See Fig #1)
• Note that the hole in the top of the cabinet may not be
necessary depending on venting method chosen. (See
Page 10).
STEP 8
Attaching damper
• Fix the damper into the damper hole on top of the range hood motor box.
(See Fig #2).
Fig #2
Cut-out dimensions:
28 in.: 26.25 in. x 10.25 in.
(67 cm x 26 cm)
36 in.: 34.25 in. x 10.43 in.
(87 cm x 26.5 cm)

— 12 —
Installation
STEP 10
Venting
• Depending on the exterior venting chosen (See Page 10), either exit the ducting through the ceiling or wall.
• Alwaysuserigidtypemetal/aluminumducttube(followingthebuildingcodesinyourarea)tomaximizeairow.
• Makesurethatthebackdraftapscanopentoallowformaximumairow.Connecttheducttubetothevent/damper
and securely seal with duct tape so that it is air tight.
STEP 11
Connect to AC
• ConnectACplugintoagroundedACoutlethaving120V,60Hz.Placetheoutletatamaximumdistanceof33-1/2in.
(851 mm) from where the cord exits on the hood.
• SEE IMPORTANT INSTRUCTIONS ON NEXT PAGE. 3-Pronged Plug
Ground Plug
3-Prong Receptacle
STEP 9
Installing the hood
• Remove the lters, LED lights and the range hood cover. (See Fig #3)
• Align range hood to the opening in the bottom of the cabinet and screw in
with screws. (See Fig #4)
Fig #4Fig #3
SAFETY WARNING:
Risk of electrical shock. This range hood must be properly grounded. Make sure this is done by a
qualied electrician in accordance with all applicable national and local electrical codes. Before
connecting wires, switch power off at service panel and lock service panel to prevent power from
being switched on accidentally.

— 13 —
Fig #5
Installation
STEP 12
Install Filters
To install lters for the following four steps (See Fig #5):
• Angle the lter into slots at the back of the hood.
• Push the button on handle of the lter.
• Release the handle once the lter ts into a resting position.
• Repeat to install all lters.
IMPORTANT:
• Observeallgoverningcodesandordinances.
• It is the customer’s responsibility to contact a qualified electrical installer.
• Ifcodespermitandaseparategroundwireisused,itisrecommendedthataqualifiedelectriciandeterminethat
thegroundpathisadequate.A120-Volt,60Hz,AC-only,fusedelectricalsupplyisrequiredonaseparate15-amp
circuit, fused on both sides of the line.
• DONOTgroundtoagaspipe.
• Checkwithaqualifiedelectricianifyouarenotsurethattherangehoodisproperlygrounded.
• DONOThaveafuseintheneutralorgroundcircuit.
IMPORTANT: Save this Installation Guide for electrical inspector’s use.
GROUNDING INSTRUCTIONS:
• Thisappliancemustbegrounded.Intheeventofanelectricalshort-circuit,groundingreducestheriskofelectric
shock by providing an escape wire for the electric current.
• Thisapplianceisequippedwithacordhavingagroundingwirewithagroundingplug.Theplugmustbeplugged
into an outlet that is properly installed and grounded.
WARNING: Improper grounding can result in a risk of electric shock.
• Consultaqualifiedelectricianifthegroundinginstructionsarenotcompletelyunderstood,orifdoubtexistsasto
whether the appliance is properly grounded. DO NOT use an extension cord. If the power supply cord is too short,
have a qualified electrician install an outlet near the appliance.

— 14 —
Operation
Lamp Power
(On/off)
Increase
Auto Timer Decrease
NOTE: When the hood has been initially connected to the
Power or after a Power Failure, all indicators turn ON for 1
second then OFF, the hood is in Standby condition.
Once the hood is connected with electricity, if wires for the control
are not well connected or control board has poor connection or
malfunction,buzzerwillemitSix Beeps. You must then disconnect
the hood from the Power, x the problem and reconnect the hood.
Lamps
(with 3 luminance setting + auto mode)
uPress once: Lamps turn ON with High luminance.
Indicators for are ON.
v
Press second time:
Lamps turn ON with Low luminance.
Indicators for are ON.
w
Press third time:
Lamps turn ON with Night-Light luminance.
Indicators for are ON.
x
Press fourth time:
Lamps will turn OFF.
Indicator for is OFF.
Cycle is: “High luminance - Low luminance -
Night-Light luminance - lamps OFF - High luminance …”
Auto Night-Light
yPress once: You will hear a "Long audible beep",
Lamps now work in Auto Night-Light mode.
Indicators for are ON.
UPress second time: You will hear a "Short audible beep",
Auto Night Light mode is disabled.
Indicator for is OFF.
NOTE: When light sensor detects the room is dark, lamps
will turn on to Night-Light luminance. When light sensor
detects the room is less dark, Night-Light will turn OFF
automatically. And cycle repeats again and again.
Power
uPress once: Fan starts to work at 1st-speed.
Indicators for are ON.
v
Press second time:
Fan will turn OFF, hood is in Standby condition.
All indicators are OFF.
Fan
(with 3 speed setting)
uPress or once: Fan starts to work at 1st-speed (minimum speed).
Indicators for are ON.
v
Press second time:
Fan will work at 2nd-speed (medium speed).
Indicators for are ON.
w
Press third time:
Fan will work at 3rd-speed (maximum speed).
Indicators for are ON.
x
Press once:
Fan will work at 2nd-speed.
Indicators for are ON.
y
Press second time:
Fan will work at 1st-speed (minimum speed).
Indicators for are ON.
UPress third time:
Fan will turn OFF. Indicators are OFF.
Indicator is OFF (if lamps are OFF).
Timer
You can only activate the TIMER function when Fan is
working. TIMER will not function with only Lamps ON.
TIMER is xed for 3 minutes delay OFF.
u
Press once when Fan is working at any speed:

Fan will work continuously for 3 minutes, then Fan will
shut OFF automatically.
vPress again before the end of 3 minutes, and TIMER will be deactivated.
w
After activating the TIMER, if you change the FAN
speed, TIMER will be deactivated instantly.
AYD-056B
AYD-013B
AYD-055B
AYD-056B
AYD-013B
AYD-055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD-056B
AYD-013B
AYD-055B
AYD-056B
AYD-013B
AYD-055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD-056B
AYD-013B
AYD-055B
AYD-056B
AYD-013B
AYD-055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD-056B
AYD-013B
AYD-055B
AYD - 056B
AYD - 013B
AYD - 055B
AYD - 056B
AYD - 013B
AYD - 055B
IMPORTANT: When Lamps and/or Fan are working …
Pressing once will turn them OFF instantly!
AYD - 056B
AYD - 013B
AYD - 055B

— 15 —
Problem Possible Cause
If the range hood or LED light does
not operate after installation:
Check if the range hood has been plugged in, make sure that
all power has been turned back ON, fused not blown and all
electrical wiring are properly connected.
The range hood vibrates when the
blower is on:
The range hood might not have been secured properly on to the
ceiling or wall.
The blower or fan seems weak: Checkthattheductsizedusedisatleast6in.(15.3cm)or3
1/4 x 10 in. (8.3 x 25.4 cm) Range hood WILL NOT function
efcientlywithinsufcientductsize.Forexample:7in.(17.7cm)
duct over 6 in. (15.3 cm) hole and loosely secured.
Checkifductiscloggedorifdamperunit(half-circularange)is
not installed correctly or opening properly. A tight mesh on a side
wallcapunitmightalsocauserestrictiontotheairow.
The lights work but the fan is
not spinning at all, is stuck or is
rattling:
The fan might be jammed or scraping the bottom due to
shipping damage. Please contact us immediately.
Make sure the distance between the stove top and the bottom of
the hood is within 24 in. and 30 in. (61 and 76.2 cm) distance.
The hood is not venting out
properly:
Reduce the number of elbows and length of duct work. Check if
all joints are properly connected, sealed, and taped.
Troubleshooting

— 16 —
Maintenance
uMake sure the range hood is unplugged or turn OFF breaker.
vRemove lters. Reach into interior of range hood until touching both lateral clips located on the side
ofthepucklight.Gentlysqueezeandpushdown
until puck pops out from its location, pull out the
LED puck and unplug it.
CAUTION: PUCK MAY BE HOT, PLEASE TAKE
OUT THE PUCK WHEN THE PUCK IS
COMPLETELY COOL!
wReplace with a 10.2 Volt, 2.5 Watt max, LED lights. Plug in new puck and push back into light panel.
xTurn ON breaker and range hood to test for operation.
Replacing the Light Pucks
IMPORTANT:
ALWAYS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAIN PANEL BEFORE CARRYING OUT ANY OPERATION
ON THE APPLIANCE.
Fig #6 Fig #7
Cleaning Filters
IMPORTANT: Drain oil from spacers, lters, oil tunnels, oil containers before oil and residue overow!
• Remove all spacers, lters, grease tray, and oil containers and discard oil and residue.
• Wash with warm soapy water. NOTE: Stainless steel lters, spacers and oil tunnel are top rack dishwasher safe.
• Dry thoroughly before replacing and follow directions for installation in reverse.
• Filters should be cleaned after every 30 hours of use.
• Should lters wear out due to age and prolonged use, replace with a new lter.

— 17 —
Range Hood Assembly
Number Part
1 Power cord
2 Round duct or valve (Exhaust)
3 Housing assembly
4
Blower assembly (includes
motor)
5
6
7
8
9 Bracket of electronic box
10 Base of electronic box
11 PCB
12 Capacitor
13 Cover of electronic box
14 Bracket of switch
15 Switch board
16 Switch plastic box
17 Panel
18 LED puck lights
19 Aluminum lter (2 or 3 pieces)
20 Screw bag
u
v
w
x
y
U
V
W
X
at
ak
al
am
an
ao
ap
aq
ar
as
bt

— 18 —
Assembly
Circuit Diagram
Blower Assembly
Electrical Assembly
Number Part
1Junctionboxcover
2 Capacitor
3 Main PCB board
4Junctionboxbottom
u
v
w
x
AC 120V 60Hz
Main PCB
L
N
E
Capacitor
MAX 10.2V 250mA 2.5W
CN6
CN5
CN1
CN2
CN4
CH B
CN3
Motor
CN8
+
_
LED Pucks
___
Controls PCB
u
v
y
x
w
u
v
w
x
Number Part
1 Grid
2 Motor
3 Impeller
4 Blower
5 Wind drum inlet
Blower Assembly
Electrical Assembly
Number Part
1Junction box cover
2 Capacitor
3 Main PCB board
4Junction box bottom
u
v
w
x
Circuit Diagram
Assembly
AC 120V 60Hz
MainPCB
L
N
E
Capacitor
MAX10.2V250mA2.5W
Temperature / Humidity
Sensor
CN6
CN5
(Optional)
CN1
CN2
CN3
CN4
CH B CN8
Motor
+
_
LEDPucks
___
ControlsPCB
Number Part
1 Grid
2 Motor
3 Impeller
4 Blower
5 Wind drum inlet

— 19 —
Use and Care Information
Operations
• Read and understand all instructions and warnings in this manual before operating the appliance. Save these
instructions for future reference.
• Always leave safety grills and lters in place. Without these components, operating fans could catch on to hair, ngers
and loose clothing.
• NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into fans.
• NEVER leave cooking unattended. When frying, oil in the pan can easily overheat and catch re. The risk of self
combustion is higher when the oil has been used several times.
• NEVERcookon“open”amesundertherangehood.Checkdeep-fryersduringuse;superheatedoilmaybe
ammable.
Cleaning
• Thesaturationofgreasyresidueinthefanandltersmaycauseincreasedinammability.Keepunitcleanandfreeof
grease and residue build-up at all times to prevent possible res.
• Filters must be cleaned periodically and free from accumulation of cooking residue (see Cleaning Instructions below).
Old and worn lters must be replaced immediately.
• DO NOT operate fans when lters are removed. Never disassemble parts to clean without proper instructions.
Disassembly is recommended to be performed by qualied personnel only. Read and understand all instructions and
warnings in this manual before proceeding.
SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating!
For optimal operation, clean range hood and all bafe/spacer/lter/grease tray/oil container regularly. Regular care
will help preserve the appearance of the range hood.
Cleaning Exterior Surfaces
• Clean periodically with hot soapy water and clean cotton cloth. DO NOT use corrosive or abrasive detergent (e.g. Comet
Power Scrub®, EZ-Off® oven cleaner), or steel wool/scoring pads, which will scratch and damage the stainless steel
surface. For heavier soil use liquid degrease such as “Formula 409®” or “Fantastic®” brand cleaner.
• If hood looks splotchy (stainless steel hood), use a stainless steel cleaner to clean the surface of the hood. Avoid getting
cleaning solution onto or into the control panel. Follow directions of the stainless steel cleaner. CAUTION: DO NOT
leave on too long as this may cause damage to hood nish. Use soft towel to wipe off the cleaning solution, gently
rub off any stubborn spots. Use dry soft towel to dry the hood.
• After cleaning, you may use non-abrasive stainless steel polish such as 3M® or ZEP®, to polish and buff out the
stainless luster and grain. Always scrub lightly, with clean cotton cloth, and with the grain.
• DO NOT allow deposits to accumulate or remain on the hood.
• DO NOT use ordinary steel wool or steel brushes. Small bits of steel may adhere to the surface and cause rusting.
• DO NOT allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain in contact with stainless steel
for extended periods. Many of these compounds contain chemicals, which may be harmful.
• Rinse with water after exposure to these compounds and wipe dry with a clean cloth.

— 20 —
Please register your product warranty by visiting the Ancona Home website.
Canada & USA
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: www.anconahome.com
Ancona is in association with Mr Appliance for all after sales service calls.
Please contact their service provider or visit their website:
Phone: [phone]
Website: www.mrappliance.com
© 2019 Copyright of Ancona Home. All rights reserved. This material may not be reproduced, displayed, modied or distributed.
MAAN1316-01
