Anderson ES 1300 User manual

Anderson Innovations
5506 Thompson Hill RD
Duluth, MN 55810
www.andinllc.com
User Manual
ES 1300 Ride On Floor Scraper
US Patent # 10273700, 10619365
EU Patent Granted
READ BEFORE USING EQUIPMENT

3
USER INSTRUCTIONS 2023-07
TABLE OF CONTENTS
1.1 Manual 4
1.2 Explanations of symbols and instructions 4
1.3 Intended use 5
1.4 Owner’s obligations 5
1.5 Operating personnel 6
1.6 Personal protective equipment 7
1.7 Signage 7
1.8 Safety installations 7
1.9 Occupational safety and special risks 8-11
2.1 Technical Description 12
2.2 Technical Specifications 12
2.3 Scope of delivery 12
2.4 13
Controls and equipment
3.1 Lifting With a Forklift 14
3.2 Using a Ramp 14
4.1 Blade Choice 15
4. 2 Blade Angle 16
4.3 Weights 16
4.4 Weights 17
5.1 Start-up / Shut-down 18
5.2 Safe Operation 18
5.3 Removal of floor coverings 19
6.1 Blade Sharpening 20
6.2 Regular maintenance 21
6.3 Hydraulic oil 22-24
1 Safety
2 Product Information
3 Transport
4 Setup
5 Operation
6 Maintenance
5.4 Battery System 20
7 Attachments
7.1 LNEX Battery Monitor / S.O.C. Manual 26-32
7.2 Lithium Battery Guide 33-38
7.3 Dakota Lithium Battery SDS 39-44
7.4 Hydraulic Oil SDS 45-60
7.5 Manufacturer Information 61

4USER INSTRUCTIONS 2023-07
1 SAFETY
1.1
anual
This manual guarantees the safe and efficient use of the ES 1300 "machine". This manual is
part of the machine, and must always be kept near the machine and be accessible for the
operating personnel at all times.
The operating personnel must carefully read and understand this manual before any work
begins. Prerequisite for safe working is compliance with all the safety and handling
instructions in this manual.
Furthermore, this machine is to be used in compliance with all local regulations and the general
safety requirements set forth by the Occupational Safety and Health Administration (OSHA).
Illustrations in this manual are for the purpose of explanation, and may differ from the actual
design of the machine.
When passing the machine on to third parties this manual must be included.
In the following cases the manufacturer does not accept any liability:
•Non-compliance with these instructions
•Improper use
•Operation by untrained personnel
•Unauthorized modifications
•Use of unauthorized replacement parts
Safety instructions in this manual are marked by symbols. Instructions are introduced by signal
words which express the scale of the hazard.
It is essential that these instructions are adhered to and the machine is operated with caution to
avoid accidents, injuries and material damage.
WARNING!
Indicates a potentially dangerous situation which if not avoided can lead to death or serious
injuries.
CAUTION!
Indicates a potentially dangerous situation which if not avoided can lead to minor or light
injuries.
PROHIBITION!
Indicates an immediate dangerous situation which if not avoided can lead to death or serious
injuries.
Safe Practices
Emphasizes tips and recommendations as well as information for efficient and failure-free
operation.
1.2
Explanations of
symbols and
instructions

5
USER INSTRUCTIONS 2023-07
1 SAFETY
The machine is used for the removal of all sorts of floor-coverings for example PVC,
linoleum, carpets, rubber floors as well as tiles, coatings, adhesives and wood flooring.
The machine is NOT to be used to pull things, or for non flooring related demolition
work.
Any utilization of the product beyond the intended use described above is considered
misuse.
WARNING! Danger due to misuse!
Misuse can lead to dangerous situations.
-Operation outside the specified limit values of the technical data.
- Bypassing or overriding of safety installations.
- Remodeling, refitting or changing the construction or individual parts with the
intention to alter the area of application or use of the machine.
- Use of the machine when not in perfect mechanical condition.
- Use of the machine in potentially explosive areas.
1.3
Intended use
Claims of any sort of damages following improper use:
The owner is a person who operates the machine for personal, commercial or economic use
or leaves it to a third party for use/application and during its use carries the legal
responsibility for the protection of the user, personnel or a third person. The machine is used
in the commercial sector. The owner of the machine is therefore obliged to comply with the
legal responsibilities for health and safety.
The local regulations of the place of use as well as accident prevention measures of the local
trade association must be adhered to.
It requires in particular that the owner:
-is informed about current health and safety regulations.
-determines during a risk assessment additional hazards which occur through specific
working conditions on the operating site of the machine.
-implements in a job control statement the necessary compliance requirements for the
operation of the machine on the operating site.
-regularly examines during the entire operating time that the operating instructions comply
with the current status of regulations.
-that the operating instructions-if necessary- are adjusted to new regulations, standards and
conditions of use.
-clearly regulates the responsibilities for the installation, operation, maintenance and
cleaning of the machine.
-ensures that all staff working near or with the machine have read and understood the
operating instructions. Furthermore the owner will train all personnel as needed to
adequately inform them about possible hazards.
Additionally the owner is responsible for:
-safe operating condition of the machine.
-the servicing of the machine in the recommended maintenance intervals.
-the regular inspection of all safety installations ensuring that they are complete and in
working order.
1.4
Owner’s
obligations

6USER INSTRUCTIONS 2023-07
1 SAFETY
QUALIFICATION
The different tasks described in this manual request various qualifications from the persons
dealing with the machine.
WARNING! Danger for persons with insufficient qualifications!
Insufficiently qualified persons cannot judge the risks when operating the machine and put
themselves and others at risk of serious injuries or death.
-All work must only be performed by qualified personnel.
-Insufficiently qualified persons must be kept away from the operating area.
In this manual the necessary qualifications for the persons and the different tasks are listed:
OPERATOR:
the operator has been instructed by the owner and been given the assigned tasks and has been
informed about the possible hazards in case of improper behavior. Tasks which go beyond
regular operation tasks can only be executed by the operator if listed in this manual and have
been explicitly authorized by the owner.
TRAINED PERSONS
have been instructed by the owner and been given the assigned tasks and have been informed
about the possible hazards in case of improper behavior.
QUALIFIED PERSONNEL
Qualified personnel is able to carry out assigned tasks and recognize and avoid independently
possible hazards given their specialist training, knowledge, and experience as well as their
knowledge of relevant norms and regulations.
MANUFACTURER
Certain work can only be carried out by trained personnel of the manufacturer. Other
personnel are not authorized to carry out this work. Please contact customer service for
required work.
UNAUTHORIZED PERSONS
WARNING! Danger for unauthorized persons in the operating area!
–Unauthorized persons have to be kept away from the operating area.
–If in doubt remove persons from the operating area.
–Interrupt the work as long as unauthorized persons are in the operating area.
INSTRUCTION
The owner of the machine must regularly instruct all personnel. For better
documentation an instruction protocol with the following minimum content
has to be kept:
-date, content of the instruction
-name of the instructor
-signatures of the instructed and instructor
1.5
Operating
personnel

7
USER INSTRUCTIONS 2023-07
1 SAFETY
When operating the machine personal protective equipment must be worn in order to
minimize health hazards.
The following protective clothing must be worn by anyone in the operating area.
Protective work clothing.
Wear appropriate work clothing! Work clothing should fit tightly and loose garments should
be avoided since they can get caught in the machine.
Protective gloves
Protective gloves to protect your hands when changing blades.
Ear protection + Protective goggles
Ear protection offers you protection from hearing damage through noise. Protective goggles
protect your eyes from flying debris.
Safety shoes
Safety shoes protect your feet from bruising and from sharp objects and from slipping on
slippery ground.
Respirator mask
Regular and prolonged exposure to dust can lead to chronic and debilitating lung disorders.
When working for a long time or on dusty ground a minimum of a NIOSH N95 dust mask
has to be worn to protect your respiratory tract from dust and from small particles.
WARNING! Danger with illegible signage!
With time labels and signage can become dirty or illegible so that hazards cannot be
recognized and necessary instructions adhered to. This causes an increased risk of injury.
-Keep all safety, warning and operating instructions always in legible condition.
-Damaged labels or signage must be replaced immediately.
The following symbols and signs can be found in the operating area.
They refer to the immediate area where they have been placed.
WARNIN S
sharp blade,
Sharp Object / Wear
Gloves
1.6
Personal
protective
equipment
1.7
Signage
WARNING! Danger through defective safety installations!
Defective or disabled safety installations can cause severe injuries and death.
-Before work can start all safety installations have to be inspected to see whether
they are functioning properly and have been correctly installed.
-Never disable safety methods or override them.
-Make sure that all safety methods are always accessible.
1.8
Safety
installations
Pinch Point Danger to hands Electrical Hazard

8USER INSTRUCTIONS 2023-07
1 SAFETY
The following paragraph explains residual risks which might be present even if the
machine is used correctly.
To reduce the risk for persons and material damages and to avoid dangerous situations
the listed safety information in this paragraph and in the remaining manual has to be
adhered to.
Improper use
WARNING! Danger through improper use!
Make sure:
–Only use machine when in good operating condition.
Broken parts must be repaired or replaced immediately.
–Modifications to the machine are not permitted and can impair safety.
–Before regular maintenance, cleaning and repairs, the power must be switched off and
secured against unintentional start-up.
–Never override, remove or switch off safety devices.
–All work on the machine and/or its electrical components must be carried out by trained
personnel.
–Repair or maintenance work must only be carried out when the machine is switched off.
The machine must also be secured against unintentional start-up.
Axis movements
WARNING! Danger of struck by injury!
Collision of persons with the machine or its tools can lead to severe injury.
Make sure:
–Unauthorized persons in the operating area are strictly prohibited!
–Safety installations and/or functions must not be switched off or overridden.
-Do not hold any body parts between moving components.
-Blades must only be changed when the machine is idle, secure, and
disconnected from power.
-Wear personal protective equipment in the operating area.
-Assistants must always maintain a safety distance of a minimum radius of 3
feet from the machine.
Removed materials
WARNING! Injuries through removed materials!
The removed floor-covering can fracture causing flying debris to be
thrown unexpectedly which can cause serious injury or damage to the
surrounding area.
Make sure:
-Wear face protection or fully closed and tight fitting goggles, protective clothing, protective
gloves and safety shoes.
-Seek medical attention immediately if particles have entered your eyes.
-Assistants must always keep a safety distance of a minimum radius
of 3 feet from the machine.
-Use protective coverings on delicate surfaces near the work area
1.9
Occupational safety
and special risks

9
USER INSTRUCTIONS 2023-07
1 SAFETY
Sharp edges and sharp corners
CAUTION! Danger of injury from sharp edges and sharp corners!
Sharp edges and sharp corners can scratch and cut into skin.
Make sure:
-Be careful when working near sharp edges and sharp corners.
-Wear protective gloves when in doubt.
Cutting tools (knives/blades)
CAUTION! Danger of injury through improper use of
tools! Scraping blades and associated tooling can cause severe
injuries if handled improperly. Always wear protective clothing.
Make sure blades are securely mounted when transporting, during
maintenance and when in use. When installing blades never push a
wrench toward the cutting edge.
-Use tools carefully and as intended.
-Consider the weight of tools in transport.
-Wear protective gloves and safety shoes.
Working environment
CAUTION! Avoid dangerous conditions!
Do not operate machine in rain, extreme humidity, wet areas or in explosive environments
(gaseous vapors, dust or flammable materials). Remove any material or debris which can
be ignited by sparks.
Keep your working area clean and well lit.
Untidy and dark working areas increase the danger and potential for accidents.
Keep spectators away from the working area.
Children and spectators must keep a safe distance from the working area to keep from
distracting the operator and not come in contact with the machine. The operator must
always be aware of who is nearby.
Protect other persons in the working area.
Provide safety screens and protective shields to protect others from the movement of the
machine and debris.
Always be aware of the position of your coworkers when the machine is in operation. Close
off working area from unnecessary foot traffic.
Personnel in proximity must never be in front or behind the running machine. Non-
compliance can lead to serious injuries or death.
Keep working area clean! Unsecured, scattered components and tools are a potential source
for accidents.
1.9
Occupational safety
and special risks

10 USER INSTRUCTIONS 2023-07
1 SAFETY
Start-up and operation
WARNING! Danger of injury through improper start-up and operation Improper start-
up and operation can lead to personal injury or material damage.
Make sure:
–Start-up and operation can only be executed by sufficiently trained personnel, authorized
and instructed by the owner of the machine.
–Before work commences all safety installations have to be inspected to check whether
they are functioning properly and have been correctly installed.
–Keep working area tidy and clean! Unsecured, scattered components
and tools are a potential source for accidents
WARNING! Non-stop work; Incorrect handle height, vibrations and machine
movements cause pain and fatigue
Make sure:
-Take regular breaks
Maintenance and troubleshooting
WARNING! Danger of injury through improper maintenance and troubleshooting!
Improper maintenance and troubleshooting can lead to severe personal injury and material
damage.
Make sure:
–Any maintenance work and troubleshooting must only be carried out by
sufficiently qualified and instructed personnel.
–Secure machine from unintentional start-up.
–Provide sufficient space before starting maintenance work.
–Keep working area clean and tidy! Unsecured, scattered components and tools are
a potential source for accidents.
When components need to be replaced:
-Contact manufacturer or authorized representative.
1.9
Occupational safety
and special risks

11
USER INSTRUCTIONS 2023-07
1 SAFETY
ELECTRICAL CONNECTIONS / Charging /ELECTRICAL COMPONENTS
WARNING! Risk of death due to electric current!
Only connect the machine / charger to a power source that matches the the rating plate.
Check before startup.
Only connect the machine to an approved power cable and outlet. Cables / extension
cords must be at least 12AWG, not exceed 25ft, and have molded plugs with ground lugs.
Using the machine with cables of insufficient gauge and / or excessive length may result
in poor performance, overload, tripped breakers and personal injury or property damage.
Have electrical equipment such as breakers, power cord, and extension cables checked by
an authorized electrician. If the circuit breaker trips or trips repeatedly, it is a sign of a
problem. Never use equipment on unprotected circuits.
Never work with a damaged cable or plug. Worn or damaged cables or plugs should be
replaced by an electrician or authorized service personnel.
Do not use damaged electrical cords. Do not pull on the cable to unplug from the wall.
Using the machine charger with a damaged cable can cause an electric shock.
Never remove or make unusable a ground lug from machine or cords. Using the machine
in a non-grounded circuit may result in electrocution. Consult an electrician if the
grounding wire is missing or if you believe that the circuit does not have adequate
grounding.
The machine may only be operated on circuits with current protective device (I.E. fuse or
circuit breaker).
When working on the machine always unplug the battery!
Maintenance, replacement or adjustment of components may result in personal injury to
the operator and / or bystanders if the machine is started accidentally.
Work on electrical components of the machine may only be carried out by a qualified
electrician.
Driving over or damaging the power cables with the machine may result in electric shock.
The machine is only suitable for operating in dry conditions. Do not expose the machine
to water including Rain, pressure washers, or hoses.
1.9
Occupational safety
and special risks

12 USER INSTRUCTIONS 2023-07
2 PRODUCT INFORMATION
2.1
Technical
Description
2.2 Technical
Specifications
SPECIAL FEATURES
The ES 1300 is a compact yet powerful ride-on floor scraper. It is
capable of removing difficult flooring such as ceramic, wood, tough
carpet and epoxy coating. The high performance lithium battery
provides up to 4000 cycles, and can be changed out when depleted
for a fully charged battery allowing for near continuous opperation.
The patented forward slope technology (F.S.T.) frame design gives
this compact machine the abaility to operate as effectively as larger
heavier equipment. A powerful motor combined with a highly
efficient hydraulic drive system produces excellent performance at a
low noise level.
2.3
Scope of
delivery
•Machine with 1 - 48V - 96AH Lithium Battery
•6" Blade Holder
•12" Blade Holder
•2" Carbide
•Safety Glasses and Cut resistant gloves
•Battery Charger
•Retaining Pins
•Safety Manual
•Blade and Slide Plate Adjustment Wrench
Technical Data
Power Supply: 48 VDC
Drive System: Hydraulic
Motor Size:
Speed:
5 HP
Up To 140 ft/min
1300 lbs, Removable Weight: 325.5 lbs
Total Weight:
Length: 52”
Width: 24”
Height: 38.5”
U.S. Patent # 10273700, 10619365
E.U. Patent Granted

13
USER INSTRUCTIONS 2023-07
2
2.4 Controls
and equipment
PRODUCT INFORMATION
Directional Control
Handles
ON/OFF Switch
E STOP
Battery state of
Charge Display
Slide Plate
Assembly
Side Weights x6 -
30.5lbs each
Bottom Weights x5
28.5 lbs each
Battery Hood
Blade Angle
Adjustment lever
Oil Level Sight
Gauge
Adjustable Foot
Pegs
Electrical panel

14USER INSTRUCTIONS 2023-07
3 TRANSPORT
32
Ramps USING RAMPS:
−Ramps can be dangerous to use
−Make sure ramp is rated to hold
machine and operator
−Ramp must be secured so it cannot slip
off on the high side
−Be sure ramp is free of debris and is not
slippery
−ALWAYS back up a ramp, keeping the
front of the machine "down hill"
−ALWAYS drive down a ramp keeping
the front of the machine "down hill"
Before using lift-gates, elevators or other powered lifting tools make sure the lift
equipment is in good operating condition, and is properly sized for use with this
machine. Refer to product specifications in this manual for weight and dimensions.
The machine can me moved without power by opening the hydraulic valves in the
intended direction of travel and then pushing the machine. DO NOT push the machine
by applying force to the control handles. Pushing or pulling the machine by the control
handles will cause damage to the handles and control linkages.
FORKLIFT:
Placing the machine on a skid/pallet is the safest way to transport with a forklift. If
using a forklift to move the machine without a skid / pallet, special attention must be
given to fork placement to keep the machine stable.
1. Set the forks to the inside width of the
tires
2. Pickup the machine from the back
getting as close as possible to the mast
of the lift truck
3. Ensure the forks are completely under
the weight tray and not catching on
the front caster
4. Slowly lift the machine and tip the
mast back
Extra care must be taken to ensure the safe use of a ramp. The ramp MUST be rated for the weight of the
machine and the operator. The operator is responsible for adhering to any safety regulations that apply
in their area of work.
OSHA regulation 29 CFR 1926.451(e)(5)(ii)
No ramp or walkway shall be inclined more than a slope of one (1) vertical to three (3) horizontal (20
degrees above the horizontal).
3.1
Lifting

15
USER INSTRUCTIONS 2023-07
Choice of blade
Using the correct blade size and style for various floor coverings and sub-
floors will provide the best performance of your machine.
The principles described are to help operators choose the best type of blade
for each job. There is not a "one size fits all" option with blade choice.
Blade size
For harder jobs it is better to use narrow blades,
for easy jobs you can select wider blades.
Narrow blades can increase production on tough jobs as the machine will
have less resistance and faster travel speed compared to using a wider
blade and will allow for longer run time and a cleaner subfloor. Start with a
narrow blade, switch to a wider blade if the material is coming up easily.
Blade bevel
Bevel up blade is
for hard
substrate like
concrete.
Self-scoring
blades When using self-scoring blades for soft floors, pre-scroring the flooring
material is unnecessary. Depending on the type of flooring to be removed and
the sharpness of the blade, it will be more difficult to control the machine.
Keep the blade and the side wings/edges sharp.
Insert / replace blade
Dull blades reduce the capacity and cutting performance of the
machine. Sharpen or replace the blades on a regular basis as
needed.
Remove the power plug
CAUTION ! Even "dull blades" can cut you. Wear protective
gloves
Use supplied extended wrench to keep hand safely away from
the edge of the blade. When installing or removing blade
NEVER use a short wrench that puts hand in-line with the
blade or push toward the cutting edge.
4 SETUP
4.1 Blade
Bevel down for
wood or soft sub-
floors.

16USER INSTRUCTIONS 2023-07
4 SETUP
4.2 The ES1300 has 2 blade adjustments. One for the height of the slide
plate assembly off of the floor, and a second for the angle of the
blade. In general, a low to medium angle will work best for
removing materials such as glued down carpet, VCT and ceramic
tile. A high angle is better suited for re-scraping adhesive and
removing thin coatings. The two large bolts on the back of the slide
plate assembly hold the slide plate at the desired height. Use the
36mm socket on the included wrench to loosen the bolts and then
raise or lower the slide plate as desired. Typically it is best to use a
high slide plate for a high blade angle and a low slide plate for a low
blade angle. The blade angle is adjusted with the control lever on the
low right hand side of the machine.
Low Blade Angle Medium Blade Angle High Blade Angle
When choosing a blade it is best to match the size of the blade to the holder. A large blade extending past the
sides of the holder will be unsupported, and less effective at cleaning the floor. A small blade in a large holder
can allow material to catch on the edges of the holder. For the best performance and efficiency match the size
of the blade with the holder
This blade is too
big for the holder
These blades are
matched to the size
of the holder

17
USER INSTRUCTIONS 2023-07
4 SETUP
4.3
Weights Use caution when handling weights. It is possible to
pinch or crush fingers as well as drop heavy parts onto your feet.
Wear gloves and safety shoes to help protect from injury.
Removing Weights
Depending on your application it may be necessary to remove weight from the
machine. Some common reasons to remove weight include: weight restriction for
elevator or lift gate, soft sub-floor that requires less pressure on the cutting edge,
restricted point load for elevated working surfaces. You will need a couple of tools
to remove the weights on the ES1300. Including a 36mm socket or wrench, 3/4"
socket or wrench and possibly a soft hammer or mallet.
Removing the side weights:
1. Use a 36mm wrench or socket to remove the
weight bolt. This bolt threads into a pin that holds
the weights in place. The weights will not slide off
the machine after the bolt is removed
2. Lift the weights off the pin and set them aside
3. Re-install the weight bolt so that it does not get
misplaced
Installing the side weights:
1. Remove the weight bolt if installed
2. Line up the corresponding mounting hole in
the weight and set onto the pin. The front of the
weights should line up as shown in the image.
3. Re-install the weight bolt
Removing the bottom weights:
1. Use a 17mm socket or wrench to remove both
bolts as shown from the bottom of the machine
2. Use a soft hammer or mallet if necessary to move
the top weight in the stack out of the machine.
3. Repeat for each additional weight.
4. Install the weight bolts when finished to keep
them from being misplaced
Installing the bottom weights:
1. Remove the weight bolt if necessary
2. Install the weight plates. WARNING fingers can be
pinched between the handle of the weight and the
machine or other installed weights
3. line up the weight stack so it is flush with tray on both
sides, use a soft hammer or mallet if necessary
4. Install the weight bolts
Weight Bolt
Bottom Weights
Weight Bolts x 2

18 USER INSTRUCTIONS 2023-07
5 OPERATION
5.1
Start-up and Shut Down
5.2
Safe operation
To start the machine follow this procedure:
1. Inspect the machine for any signs of
hydraulic leaks for other damage
2. Spread the handles apart and sit on
the seat with feet on the foot pegs
3. With the handles in the center/neutral
position twist the red cap on the
E-Stop to make sure it is in the "up"
position
4. Turn the key switch fully to start the
machine.
To shut down the machine follow this
procedure:
1. Allow the control handles to return
to the center / neutral position
2. Make sure the machine is on a flat,
level surface. Do not park the
machine on a ramp or inclined
surface.
3. Use the blade angle adjustment to
lower the blade so the cutting edge is
on the floor.
4. Turn the key switch to the off
position
5. Remain in the seat until the motor
has completely stopped
6. Step off of the machine
To move the machine use the control handles. Pushing
both handles forward will move the machine straight
forward. Pulling both handles backward moves the
machine straight back. Use the handles independently to
turn the machine. Use slow smooth movements with the
control handles for the best control. Operator must keep
good situational awareness avoiding people and job site
hazards.
Directional Control
Handles: Swing out
to provide easy
access to the seat.
E Stop
ON/OFF Key Switch

19
USER INSTRUCTIONS 2023-07
5 OPPERATION
VCT Tiles
Keep blades sharp! Keep your work area clean and clear of debris.
Always wear eye protection when working with the machine.
Never use a blade wider than the size of the tile being removed. If
material being removed will not come up clean or the machine jumps
out of the work continuously, reduce blade size to a smaller blade until
proper blade size is found or use a smaller portion of the blade.
Vinyl-, Rubber, PVC, Direct Glued Carpet
Before starting the machine, cut the flooring into strips approximately
the same width as the blade. Then use the machine to take up the strips.
Pre-scoreing carpet / sheet goods makes removed material easier to
handle and extends the runtime of the machine. For best results use a
stand-up scoring tool
If removing soft flooring with a strong bond, the self-scoring blade can
also be used. Cut ditches into the floor then demo perpendicular to the
ditch to make strips that are easy to handle. Keep debris cleaned off the
floor and out from under the machine. This will reduce the chance of
carpet scrap getting wrapped around the wheels and tangling with the
machine.
Ceramic and other types of floor tiles
Everyone in the area must be wearing safety glasses before removing
tile. Use a durable sheet material such as hard board to protect delicate
wall surfaces like glass or finished wood. Using a hammer and chisel or
electric demo hammer, remove a tile in a clear area of the work space to
open up the floor. Beginning at a doorway with an open edge is another
way to start removing tile, but can be more difficult to maneuver then
opening a space in the middle of the room. Use a small heavy blade or
preferably a carbide shank at a low angle to remove tile. Avoid
removing tile at a high angle as this is less efficient, and will shorten the
life of your tooling. Open a line of tile across the room and then work
perpendicular to that line in short passes along the line. Keep debris
cleaned out from under the machine. Use a stiff broom to push debris
out of the way. Debris is more easily pushed on the floor not yet
removed. It is best to stop and clean the floor regularly rather creating a
large volume of debris and working on top of the mess. Use a water
sprayer to mist debris before pushing to reduce dust. After removing
the tile use a water sprayer to mist any remaining thin-set or mortar
until it has the consistency of damp sand then re-scrape at a high angle
with a sharp carbide. DO NOT over-water the floor. Too much water
will create a slippery mess.
5.3
Removal of floor
coverings

20
USER INSTRUCTIONS 2023-07
5 OPERATION
5.4
Battery System
Summary:
The ES1300 uses a 48V Lithium Battery. For charging and battery
information refer to the attached manufacturers manual. The battery is
installed under the hood on the back of the machine. The blue plug on the
battery functions as an emergency disconnect and the charging point for
the battery. The machine is equipped with a state of charge display and a
low voltage interrupt "L.V.I."
Low Voltage Interrupt:
The L.V.I. will turn off the machine if the battery is in danger of
being over discharged. The machine will alert the operator with
an audible beep when the cut off voltage is near. Once the cut off voltage
is reached the machine will shut off. The operator can
override the L.V.I. by holding the key switch in the start position
to move the machine to a charging location or out of a
dangerous position such as a ramp or lift gate. The operator should NOT
use the L.V.I override to continue removing flooring.
State of Charge Display:
The S.O.C. display shows the percentage of charge in the battery as well as
voltage, amp draw, and an instantaneous run time estimate. The S.O.C.
MUST be reset to 100% when a fully charged battery is installed. To reset
the S.O.C. press and hold the up arrow on the SOC until the "%" shows
100. The display will immediately drop to 99% after reset.
If a battery is partially charged the battery percentage on the S.O.C. WILL
NOT BE CORRECT. The voltage will always be correct. Once the voltage
at idle is showing 44 VDC the battery is depleted and continued use will
activate the L.V.I.
The estimated runtime will fluctuate based on current amp draw of the
machine. While the machine is idling the runtime will show a high
number i.e. "4 Hours" under a heavy load the runtime will drop to low
number i.e. " 1 Hour" The median of the high and low runtime number
will be an approx runtime to expect. For additional information on the
S.O.C. display refer to the enclosed Linex Manual
How to Improve Runtime:
•Keep the blade sharp. A dull blade is harder to push than a sharp blade.
•Use a low blade angle and properly adjusted slide plate when removing
material. A high angle makes the machine work harder.
•Avoid turning the machine from a dead stop with the blade on the
floor. Lift the blade when moving from one work area to another
•Turn the machine off when waiting for helpers to clear debris.
•On difficult jobs; especially heavly glued carpet, use a smaller blade.
The machine will run longer and faster with a lower amp draw.
