AEG A18ERW38B User manual
A18ERW38B
Original instructions
2
Important!
It is essential that you read the instructions in this manual before
assembling, operating, and maintaining the product.
Subject to technical modifications.
3
p. 5
p. 6p. 6 p. 7
p. 4 p. 5
Belt clip screw
Belt clip
Battery port
Handle, insulated
gripping surface
Anvil
Battery pack
Lockout lever
Switch trigger
Direction of
rotation selector
Belt clip mount
screw hole
LED light
4
1
2
75-100 %
50-75 %
25-50 %
0-25 %
Remove the battery pack before starting any
work on the product.
5
1 2
6
LOCK UNLOCK
1
2
STOP
7
1
2
8
TECHNICAL DATA A18ERW38B
Type Cordless ratchet wrench
Battery voltage 18 V
No-load speed 0-250 min-1
Max torque* 74 Nm
Max manual breaking torque 156 Nm
Weight without battery pack 1.36 kg
Recommended ambient operating temperature -18...+50 ºC
Noise/Vibration Information
Measured values determined according to EN 62841
A-weighted sound pressure level (Uncertainty K=3 dB(A)) 81.0 dB (A)
A-weighted sound power level (Uncertainty K=3 dB(A)) 89.0 dB (A)
Wear ear protection!
Total vibration values (vector sum in the three axes) determined
according to EN 62841
Screw driving ah= 3.7 m/s2
Uncertainty K = 1.5 m/s2
WARNING!
The declared vibration total values and the declared noise emission values given in this instruction manual have been measured in
accordance with a standardised test given in EN 62841 and may be used to compare one tool with another. They may be used for a
preliminary assessment of exposure.
The declared vibration and noise emission values represent the main applications of the tool. However, if the tool is used for dierent
applications, used with dierent accessories, or poorly maintained, the vibration and noise emission may dier. These conditions may
signicantly increase the exposure levels over the total working period.
An estimation of the level of exposure to vibration and noise should take into account the times when the tool is turned o or when it is
running idle. These conditions may signicantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eects of vibration and noise, such as maintaining the tool and the
accessories, keeping the hands warm, and organising work patterns.
9
COMPATIBLE BATTERY PACKS (NOT INCLUDED)
L1820R
L1820S
A18FB2
L1825R
L1830R-X5
A18B4
L1840R
A18FB4
L1850R
A18FB5
L1860R
L1860R-X5
L1890R
Use AEG 18V battery and charger only
WARNING! Read all safety warnings, instructions,
illustrations and specications provided with this power tool.
Failure to follow all instructions listed below may result in electric
shock, re, and/or serious injury.
Save all warnings and instructions for future reference.
RATCHET WRENCH SAFETY WARNINGS
Safety instructions for all operations
Hold the power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory or
fasteners may contact hidden wiring. Fasteners contacting a
“live” wire may make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
Ambient temperature range for tool during operation is between
0°C and 40°C.
Ambient temperature range for tool storage is between 0°C and
40°C.
The recommended ambient temperature range for the charging
system during charging is between 10°C and 38°C.
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Use protective equipment. Always wear safety glasses when
working with the product. The use of protective clothing is
recommended, such as dust mask, protective gloves, sturdy non-
slip footwear, helmet and ear defenders.
The dust produced when using this product may be harmful to
health. Do not inhale the dust. Wear a suitable dust protection
mask.
Do not machine any materials that present a danger to health (e.g.
asbestos).
Do not direct the light beam at persons or animals and do not stare
into the light beam yourself (not even from a distance). Staring into
the light beam may result in serious injury or vision loss.
The product is not waterproof. Do not submerge in liquid. Failure to
heed this warning could result in serious personal injury.
Switch the product o immediately if the accessory stalls! Do
not switch the device on again while the accessory is stalled, as
doing so could trigger a sudden recoil with a high reactive force.
Determine why the accessory stalled and rectify this, paying heed
to the safety instructions.
The possible causes may be:
■it is tilted in the workpiece to be machined
■it has pierced through the material to be machined
■the power product is overloaded
Do not reach into the product while it is running. The accessory
may become hot during use.
WARNING! Danger of burns
■when changing products
■when setting the device down
Chips and splinters must not be removed while the product is
running.
When working in walls ceiling, or oor, take care to avoid electric
cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped
workpieces can cause severe injury and damage.
Remove the battery pack before starting any work on the product.
Remove battery pack before storing or transporting the product.
Do not dispose of used battery packs in the household refuse or
by burning them. AEG Distributors oer to retrieve old batteries to
protect our environment.
Do not store the battery pack together with metal objects (short
circuit risk).
Use only System AEG chargers for charging System AEG battery
packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store only in dry
rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme load
or extreme temperatures. In case of contact with battery acid wash
it o immediately with soap and water. In case of eye contact rinse
thoroughly for at least 10 minutes and immediately seek medical
attention.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING! To reduce the risk of re, personal injury, and
product damage due to a short circuit, never immerse your tool,
battery pack or charger in uid or allow a uid to ow inside them.
Corrosive or conductive uids, such as seawater, certain industrial
chemicals, and bleach or bleach containing products, etc., can
cause a short circuit.
Remove the battery pack before starting any work on the product.
Do not dispose of used battery packs in the household refuse or
by burning them. AEG Distributors oer to retrieve old batteries to
protect our environment.
Do not store the battery pack together with metal objects (short
circuit risk).
Use only System AEG chargers for charging System AEG battery
packs. Do not use battery packs from other systems.
Never break open battery packs and chargers and store only in dry
rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme load
or extreme temperatures. In case of contact with battery acid wash
it o immediately with soap and water. In case of eye contact rinse
thoroughly for at least 10 minutes and immediately seek medical
attention.
No metal parts must be allowed to enter the battery section of the
charger (short circuit risk).
ADDITIONAL SAFETY WARNING
Switch the device o immediately if the insertion tool stalls! Do not
switch the device on again while the insertion tool is stalled, as
doing so could trigger a sudden recoil with a high reactive force.
Determine why the insertion tool stalled and rectify this, paying
heed to the safety instructions.
The possible causes may be:
●It is tilted in the work piece to be machined
●It has pierced through the material to be machined
●The power tool is overloaded
RESIDUAL RISKS
Even when the product is used as prescribed, it is still impossible
to completely eliminate certain residual risk factors. The following
hazards may arise and the operator should pay special attention to
avoid the following:
■ Injury caused by vibration
●Hold the product by designated handles and restrict
working time and exposure.
■ Exposure to noise can cause hearing injury
●Wear ear protection and limit exposure.
■ Injury due to flying debris
●Wear eye protection, heavy long trousers, gloves and
substantial footwear at all times.
■Inhalation of toxic dusts
●Wear respiratory protection masks containing filters
appropriate to the materials being worked.
●Ensure adequate workplace ventilation.
●Do not eat, drink or smoke in the work area.
10
RISK REDUCTION
It has been reported that vibrations from handheld tools may
contribute to a condition called Raynaud’s Syndrome in certain
individuals. Symptoms may include tingling, numbness and
blanching of the ngers, usually apparent upon exposure to cold.
Hereditary factors, exposure to cold and dampness, diet, smoking,
and work practices are all thought to contribute to the development
of these symptoms. There are measures that can be taken by the
operator to possibly reduce the eects of vibration:
• Keep your body warm in cold weather. When operating the unit
wear gloves to keep the hands and wrists warm. It is reported
that cold weather is a major factor contributing to Raynaud’s
Syndrome.
• After each period of operation, exercise to increase blood
circulation.
• Take frequent work breaks. Limit the amount of exposure per
day.
If you experience any of the symptoms of this condition,
immediately discontinue use and see your doctor about these
symptoms.
SPECIFIED CONDITIONS OF USE
The cordless ratchet wrench is intended to be used only by adults
who have read and understood the instructions and warnings in
this manual, and can be considered responsible for their actions.
The product is intended for fastening and removing screws and
bolts using an impact socket.
Do not use the product for any other purpose not described above.
BATTERIES
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance
of the battery pack. Avoid extended exposure to heat or sunshine
(risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully
charged, after used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
• Store the battery pack where the temperature is below 27°C
and away from moisture.
• Store the battery packs in a 30% - 50% charged condition.
• Every six months of storage, charge the pack as normal.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods
Legislation requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
■The user can transport the batteries by road without further
requirements.
■Commercial transport of Lithium-Ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation
and transport are exclusively to be carried out by appropriately.
trained persons and the process has to be accompanied by
corresponding experts.
When transporting batteries:
■Ensure that battery contact terminals are protected and
insulated to prevent short circuit.
■Ensure that battery pack is secured against movement within
packaging.
■Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice.
BATTERY PACK PROTECTION
The battery pack has overload protection that protects it from being
overloaded and helps to ensure long life. Under extreme stress the
battery electronics switch o the product automatically. To restart,
switch the product o and then on again. If the product does not
start up again, the battery pack may have discharged completely.
In this case it must be recharged in the battery charger.
MAINTENANCE
The ventilation slots of the product must be kept clear at all times.
Use only AEG accessories and AEG spare parts. Should
components need to be replaced which have not been described,
please contact one of our AEG service agents (see our list of
guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please
state the Article No. as well as the product type printed on the label
and order the drawing at your local service agents or directly at:
Techtronic Industries Australia Pty Ltd
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 234 797
Australia
Techtronic Industries N.Z. Limited
PO Box 12-806
Penrose AUCKLAND 1642
Tel. no. 0800 234 797(0800 AEGPWR)
New Zealand
SYMBOLS
Safety alert
V
Volts
Direct current
min-1
Revolutions or reciprocations per minute
No-load speed
Regulatory Compliance Mark (RCM). Product meets
applicable regulatory requirements.
Remove the battery pack before starting any work
on the product.
Please read the instructions carefully before starting
the product.
Hot surface
11
Do not dispose of waste batteries, waste electrical
and electronic equipment as unsorted municipal
waste. Waste batteries and waste electrical and
electronic equipment must be collected separately.
Waste batteries, waste accumulators, and light
sources have to be removed from the equipment.
Check with your local authority or retailer for
recycling advice and collection point. According to
local regulations, retailers may have an obligation
to take back waste batteries and waste electrical
and electronic equipment free of charge. Your
contribution to the reuse and recycling of waste
batteries and waste electrical and electronic
equipment helps to reduce the demand of raw
materials. Waste batteries, in particular containing
lithium, and waste electrical and electronic
equipment contain valuable and recyclable
materials, which can adversely impact the
environment and the human health if not disposed
of in an environmentally compatible manner. Delete
personal data from waste equipment, if any.
Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley,
VIC, 3149, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
AEG is a registered trade mark used under
license from AB Electrolux (publ).
961001831-01A
This manual suits for next models
1
Table of contents
Other AEG Power Tools manuals
