III. Operating Instructions
1. Plug the power cord into a standard 110V/220V outlet and turn on the heat press by pressing the
power switch located on the side of machine.
Be sure that your heat press is positioned evenly on a steady and level surface. If using an extension
cord, be sure it is industrial grade.
2. Heat transfer parameters settings.
A. Press “OK” button to enter TEMPERATURE setting
When the TEMP indicator blinks, use Up/Down buttons “ ” “ ” to set the required temperature and
then press “OK” button again to complete the temperature setting.
B. Press “OK” button to enter PREHEAT TIME setting
When the TIME1 indicator blinks, use Up/Down buttons “ ” “ ” to set the required time for preheating
and then press “OK” button again to complete the setting.
C. Press “OK” button to enter TRANSFER TIME setting
When the TIME2 indicator blinks, use Up/Down buttons “ ” “ ” to set the required time for transferring
and then press “OK” button again to complete the setting. If you don’t need to preheat the transfer
material, TIME1 and TIME2 can be set in same values, and then the machine will be operating in
same transfer parameters in cycle.
D. Press OK button to enter into PRESSURE setting
The machine comes with segmented pressure mode, which can be adjusted according to different
thickness of transfer materials in bulk transfer.
Pressure value range: 0-10.
(Pressure will be higher if you increase the setting value)
The default setting value is 15, which suitable for transferring thin materials.
Pressure value 7 is suitable for transferring thick materials (When you set this value, there will
be more space between heating plate and silicon pad around 8-10mm)
E. After finishing above-mentioned settings, your machine is ready for pressing.
3. When the temperature reached to the set value, you can start the transfer printing by following below
A. Pull out the under plate, and place the transfer material flat onto the silicon pad.
B. Push the under plate back to its original position.
C. Press the start buttons with BOTH hands at the same time, heat platen press down automatically,
TIME1 indicator blinks and preheat timer starting to countdown.
E. When the timer counts to 3, the buzzer sounded; the heat platen opens automatically when the time
counts to end.
