Andersson AFR 3.1 User manual

User Manual
AFR 3.1 | AIR FRYER

Table of content / Innehållsförteckning / Innholdsfortegnelse
English
Safety instructions ..................................................................... 4-5
Overview ................................................................................... 6-7
Operation ................................................................................ 8-11
Maintenance............................................................................... 11
Cook guide............................................................................ 12-13
Trouble shooting.................................................................... 14-15
Specifications ............................................................................. 16
Other.......................................................................................... 17
Svenska
Säkerhetsinstruktioner ........................................................... 18-19
Översikt................................................................................. 20-21
Användning ........................................................................... 22-25
Underhåll.................................................................................... 25
Tillagningsguide..................................................................... 26-27
Felsökning............................................................................. 28-29
Specifikationer............................................................................ 30
Övrigt ......................................................................................... 31
Norsk
Sikkerhetsinstruksjoner.......................................................... 32-33
Oversikt................................................................................. 34-35
Bruk ...................................................................................... 36-39
Vedlikehold................................................................................. 39
Kokeveiledning ...................................................................... 40-41
Feilsøking .............................................................................. 42-43
Spesifikasjoner ........................................................................... 44
Annet ......................................................................................... 45

English
4
Electrical conducts:
´To reduce the risk of electric shock, do not
remove cover. No user serviceable parts inside.
Refer servicing to qualified service personnel.
´Before you connect the appliance, ensure the
voltage rating on the type plate corresponds to
your mains voltage (type plate is located on the
bottom side of the unit).
Technical conducts:
´Repairs to electrical appliances should only be
performed by qualified personnel. Improper
repairs may place the user and/or equipment at
serious risk.
´Do not operate this appliance with a damaged
plug or cord, after a malfunction or after being
dropped or damaged in any way.
´If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified people in order to avoid a
hazard.
´Do not push objects into any openings as
damage to the equipment and/or electric shock
may occur.
´If abnormal noise, smell, smoke or any other
failure is discovered during operation, turn off
the product and unplug the power plug. Then
contact the service center for repair.
´Do not remove the appliance from the mains
power supply by pulling the cord; pull the plug.
Operational conducts:
´This equipment is not intended for use by
people (including children) with reduced
physical, sensory or mental capabilities or lack
of experience or knowledge. They should be
given appropriate supervision and instructions
to use the equipment by a person responsible
for their safety.
´This product is not a toy. Never leave the
equipment within reach of children. Close
supervision is required when using this
equipment near children.
´This equipment is intended for household use
only and should not be used for industrial or
commercial purposes.
´Do not use this equipment for anything other
than its intended use.
´Do not immerse the product in water or any
other liquid.
Safety instructions

5
English
Safety instructions
´Always unplug the appliance after use and
before any cleaning or user maintenance.
Environmental conducts:
´Ensure the equipment is not too close to heat
emitting appliances or placed in direct sunlight.
´Do not use this appliance outdoors.
Other conducts:
´Warning: Keep the appliance away from
flammable materials.
´Caution: Hot surface! Do not touch the
hot section or heating components of the
appliance, as this could cause injury.
´Caution: Do not pour water on the heating
element.
´NEVER put anything on top of the appliance.
´NEVER cover the air vents on the top and back
of the cooking unit.
´NEVER use the door as a place to rest a hot
fry basket filled with food. The hot fry basket
could damage the door or cause the unit to tip.
Personal injury could result.
´ALWAYS use oven mitts when removing hot
crisper trays.

English
6
Overview
Main unit:
1. LED display
2. Door
3. Window
4. Air intake
5. Air outlet
Accessories:
6. Drip tray
7. Baking cage
8. Fry basket
9. Fry basket handle
10. Crisper trays
11. Rotisserie fetch tool
12. Rotisserie Shaft, Forks & Set Screws
1
5
2
3
64 7 8 9
10 11 12

7
English
Overview
Control panel:
1. Digital display
2. Temperature control
buttons
3. Internal light switch
4. Power button
5. Rotation button
6. Time control buttons
7. Fan icon
3
245 6
18
7
8. Preset menus buttons
Preset Button Temperature Time
French Fry 200 °C 15 mins.
Steaks/Chops 175 °C 25 mins.
Fish 165 °C 15 mins.
Shrimp 160 °C 12 mins.
Pizza 180 °C 15 mins.
Chicken 185 °C 40 mins.
Baking 160 °C 30 mins.
Rotisserie 190 °C 30 mins.
Dehydrator 30 °C 2 hours.
Keep warm 115 °C 12 mins.
Preheat 80 °C 5 mins.
Frozen food 200 °C 20 mins.

English
8
Operation
Before first use:
1. Ensure that the air fryer is switched off and unplugged from the
mains power supply. Wipe it with a soft, damp cloth and dry
thoroughly.
2. Clean the accessories in warm, soapy water, then rinse and dry
thoroughly.
Note: Do not immerse the air fryer in water or any other liquid.
Never use harsh or abrasive cleaning detergents or scourers to
clean it or its accessories, as this could cause damage.
3. Place the main unit on a stable, heat-resistant surface.
4. When using the air fryer for the first time, a slight smoke or
odour may be emitted. This is normal and will soon subside.
Ensure that there is sufficient ventilation around the air fryer
and connect the power cord into a wall outlet. Run the air fryer
without food for approximately 10 minutes before first use; this
will prevent the initial smoke or odour from affecting the taste of
the food.
Note: Always preheat the hot air fryer before starting to cook or
alternatively add approximately 3–5 minutes onto the cooking
time.
Get started:
1. Place the air fryer on a stable, level, horizontal, and heat-
resistant surface.
2. Place the drip tray in the bottom layer.
3. Select the cooking accessory for your recipe.
Baking cage Great for fries, roasted nuts, and other snacks.
Fry basket For dehydration and crispy snacks or reheat
items like pizza.
Crisper trays For roasts and whole chicken
4. Put the ingredients and the cooking accessory in place as
section “Using the Accessories” and close the door. Plug the
power cord into a 220-240V dedicated outlet.
5. Press the power button to turn on the air fryer.
6. Select a preset menu, the unit will automatically start the
cooking cycle a few seconds after a preset function is selected.
7. Or you can manually set by pressing the temperature and then
the time, press the power button to start cooking immediately

9
English
Operation
after the desired cooking time and temperature have been
selected manually.
Warning! DO NOT COVER the air intake while the unit is
operating.
8. The fan icon will blink in sequence while cooking is in
progress.
9. You may open the door to view the rotisserie at any time
during the process to check the progress. The timer will
automatically pause when the door is open and will only
continue to count down once the door is closed.
10. Once cooking is complete and the set time has elapsed, the
air fryer will switch off and beep 5 times. Use rotisserie fetch
tool or oven mitts to remove cooked or hot food.
Overheating Protection
´Should the inner temperature control system fail, the
overheating protection system will be activated and the Unit
will not function. Should this happen, unplug the power cord.
Allow time for the unit to cool completely before repair or
storing.
Automatic Shut-Off
´The appliance has a built-in shut-off device, that will
automatically shut down the unit when the timer reaches
zero. You can manually switch off the appliance by selecting
the Power Button. The fan will continue running for about 30
seconds. To cool down the unit.
Tips:
1. Foods that are smaller in size usually require a slightly shorter
cooking time than larger ones.
2. Large quantities of food only require a slightly longer cooking
time than smaller quantities.
3. Flipping or turning smaller sized foods halfway through the
cooking process ensures that all the pieces are evenly fried.
4. Misting a bit of vegetable oil on fresh potatoes is suggested
for a crispier result. When adding a little oil, do so just before
cooking.
5. Snacks normally cooked in an oven can also be cooked in the
air fryer.
6. Use pre-made dough to prepare filled snacks quickly and
easily. Pre-made dough also requires a shorter cooking time
than homemade dough.
7. Place a baking tin or oven dish in the air fryer when baking a
cake or quiche. A tin or dish is also suggested when cooking
fragile or filled foods.

English
10
Operation
Using the Accessories:
´Fry Basket
1. With the latch off the basket handle, compress the handle place
it between the slots on the fry basket, and release the handle.
2. Close the latch on the basket handle over the top of the handle,
pressing down on the latch to ensure that it is completely
secure.
3. The door cannot close with the basket handle still on the fry
basket. Remove handle before closing.
Note: The fry basket can be inserted into the Unit by hand, but
the Basket Handle should ALWAYS be used to remove the
Basket from the unit.
´Crisper Tray
1. Place crisper trays into air fryer by
sliding through the side grooves
and onto the back lip.
2. Place crisper trays closer to the top
heating element for faster cooking
and added crisp.
3. Always use oven mitts to remove
the crisper tray.
´Baking Cage
1. Open the door of the baking cage
and put the ingredients in it. Close
the door firmly.
2. Open the door of the air fryer.
3. Insert the left side of the baking
cage firstly into the rotisserie shaft
socket. Be sure the rotisserie shaft
is in place to engage rotation.
4. Place the right side of the baking cage onto the hanger.
5. After cooking, insert rotisserie fetch
tool beneath the rotisserie shaft.
Lift the right side of the rotisserie
fetch tool at a slight angle, then shift
to the right until the left side of the
shaft slides out of the rotisserie shaft
socket.
6. Carefully remove the baking cage or
from the air fryer.

11
English
´Rotisserie Shaft & Forks
1. Assemble the Rotisserie Shaft & Forks correctly.
Force shaft lengthwise through meat and center. Slide forks
onto shaft from either end into meat, then lock in place with set
screws. There are indentations on the shaft for the set screws.
You can adjust the screws closer to the middle if needed.
2. Open the door of the air fryer.
3. Insert the left side of the assembled rotisserie spit first into the
rotisserie shaft socket. Be sure the rotisserie shaft is in place to
engage rotation.
4. Place the right side of the baking cage onto the hanger.
5. After cooking, insert rotisserie fetch
tool beneath the rotisserie shaft.
Lift the right side of the rotisserie
fetch tool at a slight angle, then shift
to the right until the left side of the
shaft slides out of the rotisserie shaft
socket.
6. Carefully remove the rotisserie spit
from the air fryer.
Cleaning:
1. Clean the air fry after each use. The baking cage and other
accessories are made of durable stainless steel and are
dishwasher safe. Never use abrasive cleaning materials or
utensils on these surfaces. Caked-on food should be soaked for
easy removal in warm, soapy water.
2. Remove the power cord from the wall socket and be certain the
appliance is thoroughly cooled before cleaning.
3. Wipe the outside of the appliance with a warm, moist cloth and
mild detergent.
4. To clean glass, open the door of the unit.
5. Clean the inside of the appliance with hot water, a mild
detergent, and a nonabrasive sponge.
6. If necessary, remove unwanted food residue from the upper
screen with a cleaning brush.
Storage:
1. Unplug the appliance and let it cool thoroughly.
2. Make sure all components are clean and dry.
3. Place the appliance in the clean, dry place.
Operation Maintenance

English
12
Food Item Min-Max Time Temperature Comments
Thin Frozen Fries 1 1/4-3 cups 15-16 mins 200 ºC
Thick Frozen Fries 1 1/4-3 cups 15-20 mins 200 ºC
Homemade Fries 1 1/4-3 1/4 cups 10-16 mins 200 ºC Add 1/2 tbsp .oil
Homemade Potato Wedges 1 1/4-3 1/4 cups 18-22 mins 185 ºC Add 1/2 tbsp .oil
Homemade Potato Cubes 1 1/4-3 cups 12-18 mins 185 ºC Add 1/2 tbsp .oil
Hash Browns 1 cup 15-18 mins 185 ºC
Potato Gratin 2 cup 15-18 mins 200 ºC
Steak 1/4—1.1 lb 8-12 mins 185 ºC
Pork Chops 1/4—1.1 lb 10-14 mins 185 ºC
Hamburger 1/4—1.1 lb 7-14 mins 185 ºC
Sausage Roll 1/4—1.1 lb 13-15 mins 200 ºC
Chicken Drumsticks 1/4—1.1 lb 18-22 mins 185 ºC
Chicken Breast 1/4—1.1 lb 10-15 mins 185 ºC
Cooking guide

13
English
Cooking guide
Food Item Min-Max Time Temperature Comments
Spring Rolls 1/4-3/4 lb 15-20 mins 200 ºC
Frozen Chicken Nuggets 1/4—1.1 lb 10-15 mins 200 ºC
Frozen Fish Sticks 1/4—1.1 lb 6-10 mins 200 ºC
Mozzarella Sticks 1/4—1.1 lb 8-10 mins 185 ºC
Stuffed Vegetables 1/4—1.1 lb 10 mins 160 ºC
Cake 1 1/4 cups 20-25 mins 160 ºC
Quiche 1 1/2 cups 20-22 mins 185 ºC
Muffins 1 1/4 cups 15-18 mins 200 ºC
Sweet Snacks 1 1/2 cups 20 mins 160 ºC
Frozen Onion Rings 1 lb 15 mins 200 ºC

English
14
Trouble shooting
Problem Possible Cause Solution
The Air Fryer does not work 1. The appliance is not plugged in.
2. You have not turned the unit on by
setting the preparation time temperature.
1. Plug power cord into wall socket.
2. Set the temperature and time check that door
is closed.
Food not cooked
1. The baking cage is overloaded.
2. The temperature is set too low.
1. Use smaller batches for more even frying.
2. Raise temperature and continue cooking.
Food is not fried evenly 1. Some foods need to be turned during
the cooking process.
1. Turn the foods during the cooking process
White smoke coming from unit 1. Oil is being used.
2. Accessories have excess grease
residue from previous cooking.
1. Wipe down to remove excess oil.
2. Clean the baking cage after each use.
French fries are not fried evenly 1. Wrong type of potato being used.
2. Potatoes not blanched properly during
preparation
1. Use fresh potatoes
2. Use cut sticks and pat dry to remove excess
starch.
Fries are not crispy 1. Raw fries have too much water. 1. Dry potato sticks properly before misting oil.
Cut sticks smaller, add a bit more oil and blanch
cut potatoes.
E1 Broken circuit of the thermal sensor Call Customer Service
E2 Short circuit the thermal sensor Call customer service

15
English
Trouble shooting
Ask and answer:
´Can I prepare foods other than fried dishes with the air fryer?
Answer: You can prepare a variety of dishes, including steaks,
chops, burgers, and baked goods.
´Is the air fryer good for making or reheating soups and sauces?
Answer: Never cook or reheat liquids in the air fryer.
´What do I do if the air fryer shuts down while suggestions?
Answer: As a safety feature, the air fryer has an Auto Shut-Off
device that prevents damage from overheating.Unplug and
allow to cool down. Plug back in and restart with the power
button.
´Does the air fryer need time to heat up?
Answer: Preheating is needed when you are cooking from a
cold start, add 3 mins. to the cook time to compensate.
´Is it possible to shut off the air fryer at any time?
Answer: Press the power button once or open the door.
´Can I check the food during the cooking process?
Answer: You can remove the baking case at any time while
cooking is in progress. During this time, you can flip the
contents on the crisper trays if needed to ensure even cooking.
Time and temperature will resume where you left off.
´Is the air fryer dishwasher safe?
Answer: Only the accessories are dishwasher safe. The unit
itself containing the heating coil and electronics should never be
submersed in liquid of any kind or cleaned with anything more
than a hot, moist cloth or nonabrasive sponge with a small
amount of mild detergent.
´What happens if the air fryer still does not work after I have tried
all the troubleshooting suggestions?
Answer: Never attempt a home repair. Contact the
manufacturer and follow the procedures set forth by the
warranty. Failure to do so could render your warranty null and
void.

English
16
Specifications
Product name AFR 3.1
Power supply 220 - 240 V ~ 50/60 Hz
Effect 1800 W
Capacity 12 L
Cord length 1 m
Included in the
packaging
- Air fryer
- Drip tray
- Baking cage
- Fry basket
- Fry basket handle
- Crisper trays
- Rotisserie fetch tool
- Rotisserie Shaft, Forks & Set Screws
- User manual
Size 320 x 345 x 375 mm
Weight 7.7 kg

17
English
Copyright:
This manual is the copyright of CI no 556520-4137. No part
of this manual may be revised, copied or transmitted in any
way without written permission from CI no 556520-4137.
Recycling:
This product’s packaging materials are recyclable
and can be reused. This product and the accessories
packed together are the applicable product to the
WEEE directive except batteries. Please dispose of any
materials in accordance with your local recycling
regulations.
Batteries should never be thrown away or incinerated
but disposed of in accordance with your local regulations
concerning chemical wastes.
Law and Safety:
The CE mark indicates that this product has been
manufactured according to current regulations
for electromagnetic fields, which means that it is safe
to use if used according to safety instructions. The product
is manufactured according to current regulations within the
EU legislation, limiting the use of hazardous substances in
electrical and electronic equipment.
Statement:
This manual does not provide any warranty or related
declarations. All information in this manual including the
product specification, pictures and literatures is just for
reference, CI no 556520-4137 reserves the rights to
update contents of this manual without further notice.
Other

Svenska
18
Säkerhetsinstruktioner
Elektriska uppmaningar:
´För att förhindra risk för elchock, öppna aldrig
höljet. Det finns inga delar inuti som användaren
själv kan laga. Överlåt all service till kvalificerad
servicetekniker.
´Innan du kopplar in apparaten, kontrollera
att ditt vägguttags spänning motsvarar den
spänning som anges på produktens typskylt
(typskylten är placerad på undersidan av
enheten).
Tekniska uppmaningar:
´Reparation får endast utföras av behörig
tekniker. Felaktig reparation kan utsätta
användaren och/eller utrustningen för allvarlig
fara.
´Produkten får inte användas om den tappats
eller är skadad. Den får inte heller användas
om stickproppen eller nätsladden är skadade.
´Om strömkabeln eller kontakten skadats ska
den ersättas av tillverkaren, dess serviceagent
eller liknande kvalificerad servicepersonal för att
undvika fara för användaren.
´Tryck inte in några föremål i öppningar på
utrustningen, eftersom elektriska stötar kan
uppstå och skada användaren.
´Stäng av produkten och koppla ur
strömkontakten om ovanligt ljud, doft, rök eller
andra fel uppstår under användning. Kontakta
sedan kvalificerad servicepersonal.
´Koppla inte från enheten från vägguttaget
genom att dra i sladden, dra i kontakten.
Användningsuppmaningar:
´Denna utrustning får inte användas av personer
med nedsatt känsel, fysisk eller mental förmåga
eller har bristfällig erfarenhet eller kunskap. Den
får inte heller användas av barn. De ska ha
lämplig tillsyn och ges tillräckliga instruktioner
från en person som ansvarar för deras säkerhet,
för att få använda utrustningen.
´Apparaten får inte lämnas utan tillsyn när det
finns barn i närheten. Produkten är ingen
leksak! Noggrann tillsyn krävs när produkten
används i närheten av barn.
´Den här utrustningen är endast avsedd för
hushållsbruk, inte för kommersiell eller industriell
användning.
´Utrustningen får inte användas till annat än det
den är avsedd för.

19
Svenska
Säkerhetsinstruktioner
´Utrustningen får inte sänkas ned i vatten eller
annan vätska.
´Koppla alltid ur apparaten efter användning och
innan rengöring och underhåll.
Miljöuppmaningar:
´Utrustningen får inte placeras för nära värme-
avgivande apparater eller i direkt solljus.
´Använd inte utrustningen utomhus.
Övrig skötsel:
´Varning! Håll lättantändliga material på behörigt
avstånd från apparaten.
´Försiktighet! Varm yta! Vidrör inte apparatens
varma del eller värmekomponenter eftersom det
kan orsaka personskada.
´Försiktighet! Häll inte vatten på värmeelementet.
Dra alltid ut apparatens stickkontakt ur eluttaget
efter användning och före all rengöring eller
användarunderhåll.
´Lägg ALDRIG något ovanpå apparaten.
´Täck ALDRIG ventilationsöppningarna
på ovansidan och baksidan av
matlagningsaparaten.
´Använd ALDRIG luckan som plats för att sätta
en varm frityrkorg fylld med mat. Den heta
frityrkorgen kan skada luckan eller få enheten
att tippa. Personskador kan uppstå.
´Använd ALLTID grytvantar när du tar bort varma
pommes frites galler.

Svenska
20
Översikt
Huvudenhet:
1. LED-skärm
2. Dörr
3. Fönster
4. Luftintag
5. Luftutlopp
Tillbehör:
6. Droppbricka
7. Grillkorg
8. Frityrkorg
9. Frityrkorg handtag
10. Grillgaller
11. Rotisserie hämtningsverktyg
12. Rotisserie tång, gafflar och rillspettssatser
1
5
2
3
64 7 8 9
10 11 12
