Andrea ARRAY2S User manual

C46-5429-100 Rev C
C46-5429-100 Rev C
Congratulations on your
purchase of the Andrea
ARRAY2S Mic with USB-SA
ARRAY2S MIC
with
USB-SA Adapter
TECHNICAL SERVICE
We hope that you enjoy your ARRAY2S/
USB-SA Adapter. If you have additional
questions, please visit our website at:
www.andreacommunications.com/support
or call Andrea Communication LLC’s
Technical Service team at
1-800-442-7787 (USA & Canada) for
assistance.
CONNECTING YOUR ARRAY2S
1. Plug pink 3.5mm plug into
microphone jack on your computer or
if using the USB-SA, plug into the
color coded pink jack.
CONNECTING YOUR ARRAY2S and
USB-SA
1. Plug pink 3.5mm plug into pink
microphone jack on the USB-SA, plug
into the color coded pink jack.
2. Plug USB connector into USB slot on
your computer.
The Andrea ARRAY2S Microphone is
a far-field, dual element microphone
with stereo output and offers the
highest quality and performance of a
low cost upgrade over a single element
microphone.
Features include:
• Small size for unobtrusive
mounting on a monitor or laptop.
• Stereo Recording
The Andrea USB-SA Digital Audio
Adapter is a high fidelity external
sound card device with stereo input
and output.
The ARRAY2S can record in stereo
when plugged into a computer with a
stereo microphone 3.5mm socket or
when connected to the computer with
the included USB-SA stereo adapter.
Package includes: One (1) ARRAY2S
Microphone, one (1) USB-SA Adapter
and one (1) ARRAY2S Mic/USB-SA
Publication.
TROUBLESHOOTING
Microphone does not record sound when
using a voice-recording application.
A. Check all connections.
B. Check input control for proper level
in software.
C. Check that microphone is not muted
in the PCs microphone audio panel.
WARRANTY INFORMATION
Please visit our website at:
www.andreacommunications/warranty
for all warranty information.
NOTES:

CONNECTING THE ARRAY2S MICROPHONE TO YOUR COMPUTERCONNECTING THE ARRAY2S MICROPHONE AND OPTIONAL SPEAKERS
TO YOUR COMPUTER USING THE USB-SA ADAPTER
Plug ARRAY2S
Microphone into the
Microphone (Pink) socket
on your computer
Plug USB-SA
Adapter into
USB Port
Plug Microphone
Array into USB-SA
Adapter
Plug Speakers
into USB-SA
Adapter
