ANDYCINE R1 User manual

R1
POCKET RGB LED VIDEO LIGHT
OPERATION MANUAL

Overview
Suitable for vlogging use, the on-camera Pocket LED RGB Video Light R1
from ANDYCINE features a built-in 1/4"-20 threaded mounting hole and a pocket-sized form, this
lightweight light fixture easily fits in the palm of your hand. Select from 360 hue control colors in
RGB mode, adjust the color temperature from 2500 to 7000K to match an ambient light source,
the fixture is dimmable from 100 to 10% brightness. It features a CRI rating of 97 and a TLCI
rating of 95, In addition to the HSI and CCT settings, the light has seven built-in FX settings, toggle
between any of the R1 ’ s seven built-in lighting effects presets to help you out in a pinch
The integrated battery will run the fixture for two hours at maximum brightness. The fixture
supports USB Type-C PD (Power Delivery) quick-charging protocol for rapid charging.
You'll find an OLED display on the rear of the light with one control wheel and one button on the
side. This aluminum fixture has a built-in on/off switch and includes a charging cable, a 1/4-20"
shoe mount and a soft carrying pouch.
Specifications
：
Light Fixture
Color Temperature
2500K-7000K
Color Accuracy Standard
CRI: 97 TLCI: 95
Dimming
Yes, 10%-100% , adjustable by 1% increments
llluminance
Distance
0.3m
0.5m
1m
Brightness
4000LUX
1500LUX
400LUX
Numbers of LEDs
120
Body Material
All aviation aluminum
Integrated Battery
Capacity (mAh)
3600mAh
Battery Chemistry
Lithium-Ion Polymer (LiPo)
Operating Voltage
3.7 VDC
Power
Max Power Consumption
10W
Power Input Connector
TYPE-C USB 5V 2A
Power Source
Integrated Battery
Battery working time
> 2h (maximum brightness)
Battery recharge time
3h (5V 2A)
Physical
Mount Type
1/4"-20 Female
Operating Temperature
32 to 113°F / 0 to 45°C
Dimensions
126*70*14.5mm
Weight
200g

Fixture
Operations：
1. Power switch: Turn on/off the light
2. Mode: Press the Mode button to change to CCT Mode, HSI mode and FX lightingt modes.
3. Multi-function wave whell: When in CCT mode, press the button to select CCT or BRI. Then
scroll the wave whell to adjust the parameters of the current mode.
When in HSI mode, press the button to select HUE or BRI. Then scroll the wave whell to
adjust the parameters of the current mode.

When in FX lightingt modes, scroll the wave whell to select the seven bulit-in lighting effects,
including lightning effect, TV, RGB circle, cop car etc.
4. LED screen: including battery icon,CCT, BRI, HUE, FX lighting effects.
5. USB Type-C charge port: USB 5V 2A
6. Over heat protection sensors are installed in the built-in battery and main PCB, if the
temperature of the light reaches the protection value, the light will shut off, and it can not be
used until it is cool.
What is including in the box?
R1 pockgt Light, USB charge cable, soft carrying pouch, shoe mount, operation manual.
Attention:
1. Please pull off the USB cable after charging
2. Please charge the light every 3 months
3. Please do not disassemble this light
4. Please lower the power if the ambient temperature is higher than 30 degree
Terms of warrranty
Warranty period is 12 months, which begins from the purchasing date.
Service Contact Information
Website: www.andycine.com
E-mail: [e-mail]
Facebook: @andycinegear
Instagram: @andycinegear
Youtube: @andycinegear
